UIDDG860AP2Touchstone DG860 Data Gateway

ARRIS

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 14, 2012
Application Purpose: Original Equipment
Date of Application: Aug 14, 2012
Equipment Note: Touchstone DG860 Data Gateway
Frequency Range: 2412.00000000 - 2462.00000000
Company: ARRIS
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Touchstone ® DG860P2 Data Gateway User’s Guide Get ready to experience the Internet’s express lane! Whether you’re checking out streaming media, downloading new software, or checking your email, the Touch- stone DG860P2 Data Gateway brings it all to you faster and more reliably with both wired and wireless connectivity. The Touchstone Data Gateway provides four Ethernet connections for use as the hub of your home/office Local Area Network (LAN). The Touchstone Data Gateway also provides 802.11b/g/n wireless connectivity for enhanced mobility and versa- tility. Installation is simple and your cable company will provide assistance to you for any special requirements. The links below provide more detailed instructions. Safety Requirements Getting Started Installing and Connecting Your Data Gateway Configuring Your Ethernet Connection Using the Data Gateway Troubleshooting Glossary Export Regulations This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Admin istration au- thorization. Any export or re-export by the purchaser, directly or indirectly, in contravention of U.S. Export Adminis tration Regulation is prohib- ited. Copyright © 2012 ARRIS. All rights reserved. The information in this document is subject to change without notice. The statements, configurations, technical data, and recom mendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Users must take full responsi- bility for their applications of any products specified in this document. The information in this docu ment is proprietary to ARRIS. ARRIS, Touchstone, and the ARRIS logo are trademarks or registered trademarks of ARRIS Group. All other trademarks and reg istered trade- marks are the property of their respective holders. Protected under one or more of the following U.S. patents: 7,031,435; 7,100,011. Other patents pending. ARSVD01480 Release 8 Draft 1.1 June 2012 Safety Requirements ARRIS Data Gateways comply with the applicable requirements for performance, construction, labeling, and information when used as outlined below: CAUTION Risk of shock Mains voltages inside this unit. No user serviceable parts inside. Refer service to qualified personnel only! • Do not use product near water (i.e. wet basement, bathtub, sink or near a swimming pool, etc.), to avoid risk of electrocu tion. • Do not use spray cleaners or aerosols on the gateway. • The product shall be cleaned using only a damp, lint-free, cloth. No sol- vents or cleaning agents shall be used. • Avoid using and/or connecting the equipment during an electri cal storm, to avoid risk of electrocution. • Do not locate the equipment within 6 feet (1.9 m) of a flame or ignition source (i.e. heat registers, space heaters, fireplaces, etc.). • Use only power supply and power cord included with the equip ment. • Equipment should be installed near the power outlet and should be easily accessible. • The shield of the coaxial cable must be connected to earth (grounded) at the entrance to the building in accordance with applicable national electrical in- stallation codes. In the U.S., this is required by NFPA 70 (National Electrical Code) Article 820. In the European Union and in certain other countries, CATV instal lation equipotential bonding requirements are specified in IEC 60728-11, Cable networks for television signals, sound signals and interac- tive services, Part 11: Safety. This equipment is in tended to be installed in accordance with the requirements of IEC 60728-11 for safe operation. Touchstone DG860P2 Data Gateway User’s Guide Safety Getting Started Installation Ethernet Configuration UsageTroubleshootingGlossary 3 If the equipment is to be installed in an area serviced by an IT power line network, as is found in many areas of Norway, spe cial attention should be given that the installation is in accor dance with IEC 60728-11, in particular Annex B and Figure B.4. • In areas of high surge events or poor grounding situations and areas prone to lightning strikes, additional surge protection may be required (i.e. PF11VNT3 from American Power Conver sion) on the AC, RF, and Ethernet lines. • When the Data Gateway is connected to a local computer through Ethernet cables, the computer must be proper ly grounded to the building/residence AC ground network. All plug-in cards within the computer must be properly installed and grounded to the computer frame per the manufacturer’s spec- ifications. • Ensure proper ventillation. Position the Data Gateway so that air flows freely around it and the ventillation holes on the unit are not blocked. • Do not mount the Data Gateway on surfaces that are sensitive to heat and/or which may be damaged by the heat generated by the modem, its power supply, or other accessories. Touchstone DG860P2 Data Gateway User’s Guide Safety Getting Started Installation Ethernet Configuration UsageTroubleshootingGlossary 4 FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in ac- cordance with the instructions, may cause harmful interference to radio communi- cations. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the fol- lowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit diffe…

Text truncated - open the document above for the full version.

Cover Letter(s)

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com May 23, 2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: UIDDG860AP2 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Edward R. Champion, Jr. Manager, Regulatory/Compliance ARRIS International, Inc. 3871 Lakefield Dr Suite 300 Suwanee, GA 30024

Cover Letter(s)

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com May 23, 2012 Federal Communications Commission Date: Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: ARRIS International, Inc. respectfully requests confidentiality of certain materials provided with the submission of the 860AP2 under FCC ID: UIDDG860AP2 in accordance with FCC Regulations 0.459. The confidentiality request applies to the (1) schematic diagrams, (2) detailed block diagrams, and (3) detailed operational descriptions contained in this filing and included in the following files. 12-0013 - System Block Diagram.pdf 12-0013 - Schematics.pdf 12-0013 - Theory of Operation.pdf The 860AP2 has been developed at considerable effort and expense by ARRIS International, Inc.. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Edward R. Champion, Jr. Title: Manager, Regulatory/Compliance Date: 05/23/2012

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 June 11, 2012 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: UIDDG860AP2 To Whom It May Concern: The following application is submitted on behalf of our client, Arris International, Inc., for evaluation of their model DG860P2 for certification under FCC Part 15.247. The DG860P2 is a Touchstone Data Gateway cable modem which includes 802.11b/g/n 2.4GHz MIMO 2x2 wireless networking. The DG860P2 was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDDG860AP2 IC: 6670A-DG860AP2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0013 Manufacturer: Arris International, Inc. Model: DG860P2 RF Exposure Model: DG860P2FCC ID: UIDDG860AP2IC: 6670A-DG860AP2 ACS Project: 12-0013Advanced Compliance SolutionsPage 2 General Information: Applicant:Arris International, Inc. Device Category:Mobile Environment:General Population/Uncontrolled Exposure Technical Information: Antenna Type: Embedded Antenna Antenna Gain: 4.6dBi Maximum Transmitter Conducted Power: 21.09 dBm, 128.53 mW Maximum System EIRP: 25.69dBm, 370.68 mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Calculator for Mobile Equipment Limits for General Population/Uncontrolled Exposure* 243721.091.00128.534.62.884 200.074 Power Density (mW/cm^2) Distance (cm) Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Installation Guidelines The installation manual should contain text similar to the following advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: RF Exposure In accordance with FCC requirements of human exposure to radio frequency fields, the radiating element shall be installed such that a minimum separation distance of 20 centimeters will be maintained. Conclusion This device complies with the MPE requirements by providing adequate separation between the device, any radiating structure and the general population.

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: UIDDG860AP2 IC: 6670A-DG860AP2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 12-0013.W06.1A Manufacturer: Arris International, Inc. Model: DG860P2 Test Begin Date: March 28, 2012 Test End Date: May 1, 2012 Report Issue Date: June 11, 2012 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 48 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 GENERAL ......................................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 4 2 TEST FACILITIES .............................................................................................................................. 5 2.1 LOCATION ....................................................................................................................................... 5 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 5 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 6 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 6 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 7 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 8 3 APPLICABLE STANDARD REFERENCES .................................................................................... 9 4 LIST OF TEST EQUIPMENT ............................................................................................................ 9 5 SUPPORT EQUIPMENT ...................................................................................................................10 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ..........................................................10 7 SUMMARY OF TESTS ......................................................................................................................11 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ........................................................................11 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.4 .......................11 7.2.1 Measurement Procedure ........................................................................................................11 7.2.2 Measurement Results .............................................................................................................11 7.3 6DB / 99% BANDWIDTH – FCC: SECTION 15.247(A)(2) IC: RSS-210 A8.2(A)...............................13 7.3.1 Measurement Procedure ........................................................................................................13 7.3.2 Measurement Results .............................................................................................................13 7.4 FUNDAMENTAL EMISSION OUTPUT POWER - FCC SECTION 15.247(B)(3) IC: RSS-210 A8.4(4) ...23 7.4.1 Measurement Procedure ........................................................................................................23 7.4.2 Measurement Results .............................................................................................................23 7.5 BAND-EDGE COMPLIANCE AND SPURIOUS EMISSIONS-FCC 15.247(D) IC:RSS-210 2.2, A8.5 ......30 7.5.1 Band-Edge Compliance .........................................................................................................30 7.5.1.1 Measurement Procedure ................................................................................................................... 30 7.5.1.2 Measurement Results ....................................................................................................................... 30 7.5.2 RF Conducted Spurious Emissions (Unwanted Emissions into Non-Restricted Frequency Bands) 33 7.5.2.1 Measurement Procedure ................................................................................................................... 33 7.5.2.2 Measurement Results ....................................................................................................................... 33 7.5.3 Radiated Spurious Emissions (Restricted Frequency Bands) ................................................38 7.5.3.1 Measurement Procedure ................................................................................................................... 38 7.5.3.2 Measurement Results ....................................................................................................................... 38 7.5.3.3 Sample Calculation: ......................................................................................................................... 40 7.6 MAXIMUM POWER SPECTRAL DENSITY LEVEL IN THE FUNDAMENTAL EMISSION - FCC SECTION 15.247(E…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Antonio A Figueiredo(Manager -Regulatory/Compliance)

[email protected]678-473-5067Fax: 678-473-8712

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	129.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the combined maximum conducted output power. This device is equipped with specific antennas operating in a 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz
