UIDSBR-AC1200PAC1200 Wi-Fi Router with RipCurrentTM Technology

SURFboard SBR-AC1200P Wi-Fi Router User Guide PN 365-095-28243 Release 33 ISSUE 1.3 December 2015 December 2015 SURFboard SBR-AC1200P Wi-Fi Router User Guide Release 33 ISSUE 1.3 ARRIS Copyrights and Trademarks ©ARRIS Enterprises, Inc. 2015 All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from ARRIS Enterprises, Inc. (“ARRIS”). ARRIS reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of ARRIS to provide notification of such revision or change. ARRIS and the ARRIS logo are all trademarks of ARRIS Enterprises, Inc. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and the names of their products. ARRIS disclaims proprietary interest in the marks and names of others. ARRIS provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. ARRIS may make improvements or changes in the product(s) described in this manual at any time. The capabilities, system requirements and/or compatibility with third-party products described herein are subject to change without notice. Patent Notice Protected under one or more of the following U.S. patents: http://www.arris.com/legal Other patents pending. Release 33 ISSUE 1.3 December 2015 SURFboard SBRAC1200P Wi-Fi Router User Guide Copyright ARRIS Enterprises, Inc. 2015. All Rights Reserved. 3 Table of Contents 1. Safety Requirements ............................................................................................... 6 Temperature Requirements .............................................................................................. 6 FCC Part 15 ........................................................................................................................ 6 RF Exposure ............................................................................................................... 7 Industry Canada Statement ............................................................................................... 7 2. Product Overview ................................................................................................. 10 Introduction ..................................................................................................................... 10 About The Wi-Fi Router ................................................................................................... 10 What is RipCurrent? ........................................................................................................ 11 What's in the Box? ........................................................................................................... 12 Items You Need ............................................................................................................... 12 System Requirements ...................................................................................................... 12 Recommended Hardware ....................................................................................... 12 Windows ................................................................................................................. 13 Mac OS .................................................................................................................... 13 Linux/Unix ............................................................................................................... 13 About this Manual ........................................................................................................... 13 Contact Information ........................................................................................................ 14 3. Installing the Wi-Fi Router ..................................................................................... 15 Front Panel ...................................................................................................................... 15 Rear Panel ........................................................................................................................ 15 Indicator Lights for the SBR-AC1200P ............................................................................. 16 Selecting an Installation Location .................................................................................... 17 Desktop Mounting Instructions .............................................................................. 17 Factors Affecting Wireless Range ........................................................................... 17 Ethernet, Wireless, or Gigabit Home Networking? ......................................................... 18 Connecting the Wi-Fi Router ........................................................................................... 19 Configuring the Wireless Connection .............................................................................. 19 4. Setting up an Internet Connection ......................................................................... 21 Configure Your IP Address ............................................................................................... 21 Verify & Renew Your IP Address ...................................................................................... 23 5. Setting Up a Wireless Network Connection ............................................................ 25 Launch the SBR-AC1200P Quick Start Wizard ................................................................. 25 Register Your SBR-AC1200P ............................................................................................. 28 Release 33 ISSUE 1.3 December 2015 SURFboard SBRAC1200P Wi-Fi Router User Guide Copyright ARRIS Enterprises, Inc. 2015. All Rights Reserved. …

Text truncated - open the document above for the full version.

ARRIS Group, Inc. 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Date: 2015/10/16 Federal Communications Commission 7435 Oakland Mills Rd, Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: UIDSBR-AC1200P To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model SBR-AC1200P to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Antonio Figueiredo Regulatory/Compliance ARRIS Group, Inc. Tel: 678-473-5067 E-mail: [email protected]

Date: October 16, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: UIDSBR-AC1200P To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after issue date. ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operational Description ☐ Bill of Materials ☐ Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Antonio Figueiredo Regulatory/Compliance ARRIS Group, Inc. Tel: 678-473-5067 E-mail: [email protected]

ARRIS Group, Inc. 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Date: October 16, 2015 Subject: Ad Hoc Mode Function Declaration To whom it may concern, We, ARRIS Group, Inc. declare that the device does not support any non-US channels and country code selection in all the operational mode(s) for the following product. FCC ID: UIDSBR-AC1200P IC: 6670A-SBRAC1200P Regards, Antonio Figueiredo Regulatory/Compliance ARRIS Group, Inc. Tel: 678-473-5067 E-mail: [email protected]

ARRIS Group, Inc. 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Date: October 16, 2015 Subject: FCC Application for FCC ID: UIDSBR-AC1200P To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures, which the report issued from International Certification Corp..(report number: FD592221) Antonio Figueiredo Regulatory/Compliance ARRIS Group, Inc. Tel: 678-473-5067 E-mail: [email protected]

Project No.: EP592203 Page No. : 1 of 15 Photographs of EUT Project No.: EP592203 Page No. : 2 of 15

2015.09.18 1 1 1 1 11 SBR-AC1200P Judy Du Fanking Fan Fanking Fan PLBL/Arris 932BF410GN Notes: 1.材質: 50#白色Mylar 2.背压花胶 3.尺寸/印刷:如圖示 4.公差:0.- 0.2mm 5.本料件使用之材料須符合RoHS Notes: 1.MATERIAL: #50 white Mylar 2.ADHESIVE:Embossed Adhesive 3.SIZE:as drawing 4.PRINTING COLOR:As note 5.TOLERANCES::0,- 0.2mm 6.The material must off accord RoHS 單位用量1 此处打4*3方孔, 10 3 3 以供打印机定位 此处轧齿刀线,方便撕开,label与label间距3mm 出纸方向,撕纸边 4 DIM LINE NO PRINT 18Sep15 R1 (The factory Print example) Scale/1:2 #50 white Mylar E214476 S/N:0123 4567 89AB CDE WAN MAC Address:0123456789AB WiFi Network Name (SSID):0123456789ABCD WiFi Passcode (Key):0123456789 AC1200 Wi-Fi Router with RipCurrent™ Technology Model: SBR-AC1200P P/N:SBR00ZP7BAC1200P Input:AC100~240V 50/60Hz 0.8A FCC ID:UIDSBR-AC1200P IC:6670A-SBRAC1200P www.arris.com/consumer Assembled in China 14*14MM 38*18MM E214476 AC1200 Wi-Fi Router with RipCurrent™ Technology Model: SBR-AC1200P P/N:SBR00ZP7BAC1200P Input:AC100~240V 50/60Hz 0.8A FCC ID:UIDSBR-AC1200P IC:6670A-SBRAC1200P www.arris.com/consumer Assembled in China E214476 AC1200 Wi-Fi Router with RipCurrent™ Technology Model: SBR-AC1200P P/N:SBR00ZP7BAC1200P Input:AC100~240V 50/60Hz 0.8A FCC ID:UIDSBR-AC1200PIC:6670A-SBRAC1200Pwww .arris.com/consumer Assembled in China Initial version

Report No.: FA592203 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : UIDSBR-AC1200P Equipment : AC1200 Wi-Fi Router with RipCurrent TM Technology Model No. : SBR-AC1200P Brand Name : ARRIS Applicant : ARRIS Group, Inc. Address : 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Standard : 47 CFR FCC Part 2.1091 Received Date : Sep. 22, 2015 Tested Date : Oct. 02 ~ Oct. 23, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FA592203 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 MPE EVALUATION RESULTS .............................................................................................................. 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA592203 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA592203 Rev. 01 Initial issue Nov. 20, 2015 Report No.: FA592203 Page : 4 of 6 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance Report No.: FA592203 Page : 5 of 6 Report Version: Rev. 01 1.3 MPE EVALUATION RESULTS MPE Evaluation of Single Transmission Non-beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412~2462 24.67 1.83 20 0.089 1 5180~5240 25.11 3.23 20 0.136 1 5745~5825 23.73 3.82 20 0.113 1 Beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 5180~5240 25.03 6.06 20 0.256 1 5745~5825 23.53 6.72 20 0.211 1 Note: 1. For 5150~5250 MHz band Directional gain = 10 * log((10 2.87/20 +10 3.23/20 ) 2 /2) = 6.06 dBi For 5745~5850 MHz band Directional gain = 10 * log((10 3.6/20 +10 3.82/20 ) 2 /2) = 6.72 dBi MPE Evaluation of Simultaneous Transmission 2.4 and 5GHz can transmit at the same time, MPE evaluation is as below formula PD1 / Limit1 + PD2 / Limit 2 + ..... < 1, PD = Power density Non-beamforming mode MPE Evaluation = Maximum MPE of 2.4GHz + Maximum MPE of 5 GHz = 0.089 / 1 + 0.136 / 1 = 0.225 < 1 Beamforming mode MPE Evaluation = Maximum MPE of 2.4GHz + Maximum MPE of 5 GHz = 0.089 / 1 + 0.256 / 1 = 0.345 < 1 Conclusion MPE evaluations of single and simultaneous transmission meet the requirement of standard. Report No.: FA592203 Page : 6 of 6 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp, it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan Hsiang. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR592203AN Page : 1 of 110 Report Version: Rev. 01 FCC Test Report FCC ID : UIDSBR-AC1200P Equipment : AC1200 Wi-Fi Router with RipCurrent TM Technology Model No. : SBR-AC1200P Brand Name : ARRIS Applicant : ARRIS Group, Inc. Address : 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Standard : 47 CFR FCC Part 15.407 Received Date : Sep. 22, 2015 Tested Date : Oct. 04 ~ Oct. 23, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR592203AN Page : 2 of 110 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Testing Applied Standards ................................................................................................................... 10 1.6 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION ..................................................................................................................... 11 2.1 Testing Condition ................................................................................................................................. 11 2.2 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TRANSMITTER TEST RESULTS ........................................................................................................ 14 3.1 Conducted Emissions ........................................................................................................................... 14 3.2 Emission Bandwidth ............................................................................................................................. 23 3.3 RF Output Power .................................................................................................................................. 28 3.4 Peak Power Spectral Density ............................................................................................................... 31 3.5 Transmitter Radiated and Band Edge Emissions ................................................................................ 37 3.6 Frequency Stability ............................................................................................................................. 108 4 TEST LABORATORY INFORMATION ............................................................................................. 110 Report No.: FR592203AN Page : 3 of 110 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR592203AN Rev. 01 Initial issue Nov. 20, 2015 Report No.: FR592203AN Page : 4 of 110 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 1.021MHz 42.39 (Margin -3.61dB) - AV Pass 15.407(b) 15.209 Radiated Emissions [dBuV/m at 3m]: 5150.00MHz 53.00 (Margin -1.00dB) - AV Pass 15.407(a) Emission Bandwidth Meet the requirement of limit Pass 15.407(e) 6dB bandwidth Meet the requirement of limit Pass 15.407(a) RF Output Power Max Power [dBm]: Non-beamforming mode 5150-5250MHz: 25.11 5725-5850MHz: 23.73 Beamforming mode 5150-5250MHz: 25.03 5725-5850MHz: 23.53 Pass 15.407(a) Peak Power Spectral Density Meet the requirement of limit Pass 15.407(g) Frequency Stability Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR592203AN Page : 5 of 110 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 5150-5250 a 5180-5240 36-48 [4] 2 6-54 Mbps 5150-5250 n (HT20) 5180-5240 36-48 [4] 2 MCS 0-15 5150-5250 n (HT40) 5190-5230 38-46 [2] 2 MCS 0-15 5150-5250 ac (VHT20) 5180-5240 36-48 [4] 2 MCS 0-9 5150-5250 ac (VHT40) 5190-5230 38-46 [2] 2 MCS 0-9 5150-5250 ac (VHT80) 5210 42 [1] 2 MCS 0-9 5725-5850 a 5745-5825 149-165 [5] 2 6-54 Mbps 5725-5850 n (HT20) 5745-5825 149-165 [5] 2 MCS 0-15 5725-5850 n (HT40) 5755-5795 151-159 [2] 2 MCS 0-15 5725-5850 ac (VHT20) 5745-5825 149-165 [5] 2 MCS 0-9 5725-5850 ac (VHT40) 5755-5795 151-159 [2] 2 MCS 0-9 5725-5850 ac (VHT80) 5775 155 [1] 2 MCS 0-9 Note 1: RF output power specifies that Maximum Conducted Output Power. Note 2: 802.11a/n/ac uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM, 256QAM modulation. Note 3: 802.11n/ac supports beamforming function. 1.1.2 Antenna Details Ant. No. Model Type Connector Operating Frequency (MHz) / Gain (dBi) 2400~2483.5 5150~5250 5725~5850 1 617210JN Dipole I-pex 1.83 -- -- 2 617210JM Dipole I-pex 2.02 -- -- 3 617210JP PIFA I-pex -- 2.87 3.60 4 617210K2 PIFA I-pex -- 3.23 3.82 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 100-240…

Text truncated - open the document above for the full version.

FCC EMI TEST REPORT Report No.: FV592221 SPORTON International Inc. TEL: 886-3-327-3456 FAX: 886-3-327-0973 FCC EMI TEST REPORT REPORT NO. : FV592221 MODEL NO. : SBR-AC1200P RECEIVED DATE : Sep. 24, 2015 FINAL TESTED DATE : Oct. 12, 2015 ISSUED DATE : Nov. 20, 2015 TEST STANDARD : 47 CFR 15.113 FCC 04-245 ICES-006 Filing Type : Verification APPLICANT : ARRIS Group, Inc. ADDRESS : 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States Manufacturer : Sercomm Corporation ADDRESS : 8F, No. 3-1, YuanQu St., (NanKang Software Park) Taipei, Taiwan 115 R.O.C. ISSUED BY : SPORTON International Inc. LAB ADDRESS : No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C.  The test result refers exclusively to the test presented test model / sample.  Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full.  This test report is only applicable to U.S.A. / Canada. FCC EMI TEST REPORT Report No.: FV592221 SPORTON International Inc. Page Number : i TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 Table of Contents VERIFICATION OF COMPLIANCE ......................................................................................................................1 1. Summary of Test Results ...............................................................................................................................2 2. General Description of Equipment under Test.............................................................................................3 3. Test Configuration of Equipment under Test ...............................................................................................4 4. General Information of Test..........................................................................................................................12 5. Test of Conducted Emission ........................................................................................................................13 6. Test of Radiated Emission............................................................................................................................18 7. List of Measuring Equipment Used .............................................................................................................39 8. Uncertainty of Test Site ................................................................................................................................40 Appendix A. TEST PHOTOS ................................................................................................................... A1 ~ A4 FCC EMI TEST REPORT Report No.: FV592221 SPORTON International Inc. Page Number : ii TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 History of This Test Report REPORT NO. VERSION ISSUED DATE Description FV592221 Rev. 01 Nov. 20, 2015 Initial issue of report FCC EMI TEST REPORT Report No.: FV592221 Page Number : 1 of 40 TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 Project No: CB10410160 VERIFICATION OF COMPLIANCE EQUIPMENT NAME : AC1200 Wi-Fi Router with RipCurrent™ Technology BRAND NAME : ARRIS MODEL NO. : SBR-AC1200P APPLICANT : ARRIS Group, Inc. ADDRESS : 3871 Lakefield Drive, Suite 300, Suwanee, Georgia 30024, United States FINAL TESTED DATE : Oct. 12, 2015 TEST STANDARD : 47 CFR 15.113 FCC 04-245 ICES-006 I HEREBY DECLARE THAT: The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4 – 2014 and CFR FCC Part15 Subpart B. The above equipment has been tested by SPORTON International Inc. LAB., and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMI characteristics under the conditions specified in this report. Ray Yeh / Vice Manager SPORTON INTERNATIONAL INC. FCC EMI TEST REPORT Report No.: FV592221 Page Number : 2 of 40 TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 1. Summary of Test Results After estimating all the combination of every test mode, the result shown as below is the worst case. The EUT has been tested according to the following specifications. Applicable Standard: CFR FCC Part15 Subpart B and ICES-006 FCC Test Standard IC Test Standard Test Type Result Remarks 15.107(c)(2) 5.2.2 AC Power Port Conducted emission test 0.535 MHz to 1.705 MHz PASS Meet minimum passing margin is -5.92dB at 1.6981MHz. 15.107(c)(3) 15.109(e) 15.113(e) 5.3 Radiated emission test 9 kHz to 1,000 MHzPASS Meet the requirements. FCC EMI TEST REPORT Report No.: FV592221 Page Number : 3 of 40 TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 2. General Description of Equipment under Test Product Detail Equipment Name AC1200 Wi-Fi Router with RipCurrent™ Technology Model No. SBR-AC1200P Brand Name ARRIS Power Supply Internal Power Supply 2.1. Feature of Equipment under Test 1. The EUT supports 2.4GHz / 5GHz wireless function. 2. Accessories: Description Power cable 1.5m, non-shielded, w/o core RJ-45 cable 1m, non-shielded, w/o core 3. For a more detailed features description, please refer to the manufacturer's specifications or the User's Manual. FCC EMI TEST REPORT Report No.: FV592221 Page Number : 4 of 40 TEL: 886-3-327-3456 Issued Date : Nov. 20, 2015 FAX: 886-3-327-0973 Version : Rev. 01 3. Test Configuration of Equipment under Test 3.1. Test Mode Investigation has been done on all the possible configurations for searching the worst cases. The following table is a list of the test modes shown in this test report. Conducted Emissions Test Mode Description 1 Normal Link Radiated Emissions Test Mode Description 1 Normal Link FCC EMI TEST REPORT Report No.: FV592221 Page Number : 5 of 40 TEL: 886-3-327-3456 Iss…

Text truncated - open the document above for the full version.

Report No.: FR592203 Page: : 1 of 4 Report Version: Rev. 01 Photographs of the Test Configuration Conducted Emission Test Report No.: FR592203 Page: : 2 of 4 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR592203 Page: : 3 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR592203 Page: : 4 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test
