UIDTG862Touchstone Wireless Telephony Gateway

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT Manual Touchstone ® TG862 Telephony Gateway User’s Guide Get ready to experience the Internet’s express lane! Whether you’re checking out streaming media, downloading new software, checking your email, or talking with friends on the phone, the Touchstone TG862 Telephony Gateway brings it all to you faster and more reliably. All while providing toll quality Voice over IP telephone ser - vice and both wired and wireless connectivity. It also provides a Lithi um-Ion bat- tery backup to provide continued telephone service during power outages. The Touchstone Telephony Gateway provides four Ethernet connections for use as the hub of your home/office Local Area Network (LAN). The Touchstone Telephony Gateway also provides 802.11b/g/n wireless connectivity for enhanced mobility and versatility. In addition, the Touchstone Telephony Gateway provides for up to two separate lines of telephone service. Installation is simple and your cable company will provide assistance to you for any special requirements. The links below provide more detailed instructions. Safety Requirements Getting Started Battery Installation and Removal Installing and Connecting Your Telephony Gateway Configuring Your Ethernet Connection Using the Telephony Gateway Troubleshooting Glossary Export Regulations This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Admin istration au- thorization. Any export or re-export by the purchaser, directly or indirectly, in contravention of U.S. Export Adminis tration Regulation is prohib- ited. Copyright © 2011 ARRIS. All rights reserved. The information in this document is subject to change without notice. The statements, configurations, technical data, and recom mendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Users must take full responsi- bility for their applications of any products specified in this document. The information in this docu ment is proprietary to ARRIS. ARRIS, Touchstone, and the ARRIS logo are trademarks or registered trademarks of ARRIS Group. All other trademarks and reg istered trade- marks are the property of their respective holders. Protected under one or more of the following U.S. patents: 7,031,435; 7,100,011. Other patents pending. ARSVD01367 Release 8 Standard 1.0 June 2011 Safety Requirements ARRIS Telephony Gateways comply with the applicable requirements for perform- ance, construction, labeling, and information when used as outlined below: CAUTION Risk of shock Mains voltages inside this unit. No user serviceable parts inside. Refer service to qualified personnel only! CAUTION Potential equipment damage Potential loss of service Connecting the Telephony Gateway to existing telephone wiring should only be performed by a professional installer. Physical connections to the previous telephone provider must be removed and the wiring must be checked; there must not be any voltages. Cancellation of telephone service is not adequate. Failure to do so may result in loss of service and/or permanent damage to the Telephony Gateway. CAUTION Risk of explosion Replacing the battery with an incorrect type, heating a battery above 75°C, or incinerating a battery, can cause product failure and a risk of fire or battery explosion. Do not dispose of in fire. Recycle or dispose of used batteries responsibly and in accordance with local ordinances. • The Telephony Gateway is designed to be connected directly to a telephone. • Connecting the Telephony Gateway to the home’s existing tele phone wiring should only be performed by a professional in staller. • Do not use product near water (i.e. wet basement, bathtub, sink or near a swimming pool, etc.), to avoid risk of electrocu tion. • Do not use the telephone to report a gas leak in the vicinity of the leak. Touchstone TG862 Telephony Gateway User’s Guide Safety Getting Started Battery Installation Installation Ethernet Configuration UsageTroubleshootingGlossary 3 • The product shall be cleaned using only a damp, lint-free, cloth. No sol- vents or cleaning agents shall be used. • Avoid using and/or connecting the equipment during an electri cal storm, to avoid risk of electrocution. • Do not locate the equipment within 6 feet (1.9 m) of a flame or ignition source (i.e. heat registers, space heaters, fireplaces, etc.). • Use only power supply and power cord included with the equip ment. • Equipment should be installed near the power outlet and should be easily accessible. • The shield of the coaxial cable must be connected to earth (grounded) at the entrance to the building in accordance with applicable national electrical in- stallation codes. In the U.S., this is required by NFPA 70 (National Electrical Code) Article 820. In the European Union and in certain other countries, CATV instal lation equipotential bonding requirements are specified in IEC 60728-11, Cable networks for television signals, sound signals and interac- tive services, Part 11: Safety. This equipment is in tended to be installed in accordance with the requirements of IEC 60728-11 for safe operation. If the equipment is to be installed in an area serviced by an IT power line network, as is found in many areas of Norway, spe cial attention should be given that the installation is in accor dance with IEC 60728-11, in particular Annex B and Figure B.4. • In areas of high surge events or poor grounding situations and areas prone to lightning strikes, additional surge protection may be required (i.e. PF11VNT3 from American Power Conver sion) on the AC, RF, Ethernet and Phone lines. • When the Telephony Gateway is connected to a local compu…

Text truncated - open the document above for the full version.

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com July 6, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: UIDTG862 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Edward R. Champion, Jr. Manager, Regulatory/Compliance ARRIS International, Inc. 3871 Lakefield Dr Suite 300 Suwanee, GA 30024

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com Federal Communications Commission Date: Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: ARRIS International, Inc. respectfully requests confidentiality of certain materials provided with the submission of the TG862 under FCC ID: UIDTG862 in accordance with FCC Regulations 0.459. The confidentiality request applies to the (1) schematic diagrams, (2) detailed block diagrams, and (3) detailed operational descriptions contained in this filing and included in the following files. 11-0038 - System Block Diagram.pdf 11-0038 - Schematics.pdf 11-0038 - Theory of Operation.pdf The TG862 has been developed at considerable effort and expense by ARRIS International, Inc.. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Edward R. Champion, Jr. Signature: ERROR: undefined OFFENDING COMMAND: ‘~ STACK:

5015 B. U. Bowman Dr. Buford, GA 30518 July 11, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: UIDTG862 To Whom It May Concern: The following application is submitted on behalf of our client, Arris International, Inc., for evaluation of models TG862G/CT and TG862G for certification under FCC Part 15.247. The TG862G/CT and TG862G are Touchstone Wireless Telephony Gateways which include 802.11b/g/n 2.4GHz MIMO 2x2 wireless networking. Models TG862G/CT and TG862G are identical in electrical construction and design and differ only in slight modifications to the enclosure for end user mounting. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT External Photos Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 2 Figure 1: TG862G – Top Figure 2: TG862G – Side – Battery Location Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 3 Figure 3: TG862G – Bottom Figure 4: TG862G – Back Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 4 Figure 5: TG862G/CT – Top Figure 6: TG862G/CT – Side Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 5 Figure 6: TG862G/CT – Top Figure 7: TG862G/CT with Battery Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 6 Figure 8: Battery Front Figure 9: Battery - Back Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 7 Figure 10: Close-up of Battery End

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT Label Information Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 2 Figure 1: Label Location – TG862G/CT Figure 2: Label Location – TG862G

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT Internal Photos Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 2 Figure 1: Internal Photo – Before Assembly Figure 2: Internal Photo – Assembled Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 3 Figure 3: Internal – PCB Removed Figure 4: PCB – Front Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 4 Figure 5: PCB – Side Figure 6: PCB – Close-up Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 5 Figure 7: PCB - Back Figure 8: PCB – Without Shields Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 6 Figure 9: PCB – Without Shields

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT RF Exposure Model: TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 2 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm2) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 ---------- ---------- F/300 6 1500-100,000 ---------- ---------- 5 6 B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm2) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 ---------- ---------- F/1500 30 1500-100,000 ---------- ---------- 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) = ____________________________________ Power Density: Pd (W/m 2 ) = E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Model: TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 3 1.3. Calculated Result and Limit – 802.11b/g Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11b/g: 25.12dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 2.98 1.986095 25.12 325.0873 0.1285 1.4. Calculated Result and Limit – 802.11n Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11n: 26.46dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 5.99 3.971915 26.46 442.5884 0.3499

SPORTON International Inc. Report Format Version: a FCC TEST REPORT Report No. : FR160127AC FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : Touchstone Wireless Telephony Gateway Model No. : TG862G , TG862G/CT Brand Name : Arris Filing Type : New Application Applicant : Arris International, Inc. 3871 Lakefield Drive, suite 300, Suwanee, GA30024. FCC ID : UIDTG862 Manufacturer : Arris International, Inc. 3871 Lakefield Drive, suite 300, Suwanee, GA30024. Received Date : May 27, 2011 Final Test Date : Jun. 17, 2011 Statement Test result included is only for the 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in complCaince with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan HsCaing, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jun. 16, 2011 FAX : 886-2-2696-2255 FCC ID : UIDTG862 FCC TEST REPORT Report No. : FR160127AC Table of Contents 1 SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2 GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details .........................................................................................................................................................................................3 2.2 Accessories ..............................................................................................................................................................................................3 2.3 Table for Filed Antenna ............................................................................................................................................................................3 2.4 Table for Carrier Frequencies ..................................................................................................................................................................3 2.5 Table for Test Modes ...............................................................................................................................................................................3 2.6 Table for Testing Locations ......................................................................................................................................................................4 2.7 Table for Supporting Units .......................................................................................................................................................................4 2.8 Table for Parameters of Test Software Setting ........................................................................................................................................4 2.9 EUT Operation during Test ......................................................................................................................................................................4 2.10 Test Configuration ....................................................................................................................................................................................5 3 TEST RESULT ......................................................................................................................................................... 6 3.1 AC Power Line Conducted Emissions Measurement ..............................................................................................................................6 3.2 Maximum Peak Output Power Measurement ........................................................................................................................................10 3.3 Power Spectral Density Measurement ...................................................................................................................................................12 3.4 6dB Spectrum Bandwidth Measurement ...............................................................................................................................................18 3.5 Radiated Emissions Measurement ........................................................................................................................................................24 3.6 Band Edge and Fundamental Emissions Measurement ........................................................................................................................42 3.7 Antenna Requirements ..........................................................................................................................................................................47 4 LIST OF MEASURING EQUIPMENTS .................................................................................................................. 48 5 TEST LOCATION ................................................................................................................................................... 50 6 TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 51 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE ................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT…

Text truncated - open the document above for the full version.

SPORTON International Inc. Report Format Version: b F FCC TEST REPORT Report No. : FR160127AI FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : Touchstone Wireless Telephony Gateway Model No. : TG862G , TG862G/CT Brand Name : Arris Filing Type : New Application Applicant : Arris International, Inc. 3871 Lakefield Drive, suite 300, Suwanee, GA30024. FCC ID : UIDTG862 Manufacturer : Arris International, Inc. 3871 Lakefield Drive, suite 300, Suwanee, GA30024. Received Date : May 27, 2011 Final Test Date : Jun. 17, 2011 Statement Test result included is only for the 802.11n (2400~2483.5MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jun. 16, 2011 FAX : 886-2-2696-2255 FCC ID : UIDTG862 F FCC TEST REPORT Report No. : FR160127AI Table of Contents 1 SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2 GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details .........................................................................................................................................................................................3 2.2 Accessories ..............................................................................................................................................................................................3 2.3 Table for Filed Antenna ............................................................................................................................................................................3 2.4 Table for Carrier Frequencies ..................................................................................................................................................................4 2.5 Table for Test Modes ...............................................................................................................................................................................4 2.6 Table for Testing Locations ......................................................................................................................................................................4 2.7 Table for Supporting Units .......................................................................................................................................................................5 2.8 Table for Parameters of Test Software Setting ........................................................................................................................................5 2.9 EUT Operation during Test ......................................................................................................................................................................5 2.10 Test Configuration ....................................................................................................................................................................................6 3 TEST RESULT ......................................................................................................................................................... 7 3.1 AC Power Line Conducted Emissions Measurement ..............................................................................................................................7 3.2 Maximum Peak Output Power Measurement ........................................................................................................................................11 3.3 Power Spectral Density Measurement ...................................................................................................................................................13 3.4 6dB Spectrum Bandwidth Measurement ...............................................................................................................................................23 3.5 Radiated Emissions Measurement ........................................................................................................................................................33 3.6 Band Edge and Fundamental Emissions Measurement ........................................................................................................................51 3.7 Antenna Requirements ..........................................................................................................................................................................58 4 LIST OF MEASURING EQUIPMENTS .................................................................................................................. 59 5 TEST LOCATION ................................................................................................................................................... 61 6 TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 62 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE ................................................................................. A1 ~ A4 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOG…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UIDTG862 IC: 6670A-TG862 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 11-0038 Manufacturer: ARRIS International, Inc. Model: TG862G, TG862G/CT Test Setup Photos Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 2 FRONT VIEW REAR VIEW Figure 1: Conducted Emissions – Front and Back Views Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 3 SIDE VIEW Figure 2: Conducted Emissions Side View Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 4 FRONT VIEW REAR VIEW Figure 3: Radiated Emissions 9kHz~30MHz – Front and Back Views Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 5 FRONT VIEW REAR VIEW Figure 4: Radiated Emissions 30 MHz~1GHz – Front and Back Views Model(s): TG862G, TG862G/CT FCC ID: UIDTG862 IC: 6670A-TG862 ACS Project: 11-0038 Advanced Compliance Solutions Page 6 FRONT VIEW REAR VIEW Figure 5: Radiated Emissions above 1GHz – Front and Back Views
