3871 Lakefield Drive • Suwanee, GA 30024 SDoC Attestation Letter Date: September 8, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: UIDW11 To Whom It May Concern: As the grantee of this project (FCC ID: UIDW11 / Brand Name: ARRIS / Model: W11), ARRIS hereby declares that the product meets the definition of a composite system, as defined in §2.947(f), and has been tested accordingly. The final product shall comply with FCC rules for composite devices using Certification and SDoC procedures. Sincerely, Applicant : ARRIS Address : 3871 Lakefield Drive, Suwanee, Georgia, 30024 USA Signature : Name and Title : Thomas Kelleher / Compliance Engineer E-Mail : [email protected] Telephone : +1-215-323-2257

Date: May 16, 2018 AUTHORIZATION LETTER To whom it may concern: I hereby authorize Thomas Kelleher, Compliance Engineer of ARRIS, to act on behalf of ARRIS in all matters relating to the FCC application for equipment authorization in connection with FCC grantee code UID, including signing of all documents relating to these matters. If you have any questions regarding this authorization, please don’t hesitate to contact me. Sincerely yours, --------------------------------------- Antonio Figueiredo ARRIS 3871 Lakefield Drive, Suwanee, GA 30024 Tel: (678) 473-5067 E-mail: [email protected]

3871 Lakefield Drive • Suwanee, GA 30024 Confidentiality Letter Date: September 8, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: UIDW11 To Whom It May Concern: Long Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: • Block Diagrams • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We understand that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Short Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request short- term confidential treatment of information accompanying this application as outlined below until 180 days after the Grant Date of Equipment Authorization to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Internal Photos • Test Setup Photos • User Manuals Sincerely, Applicant : ARRIS Address : 3871 Lakefield Drive, Suwanee, Georgia, 30024 USA Signature : Name and Title : Thomas Kelleher / Compliance Engineer E-Mail : [email protected] Telephone : +1-215-323-2257

3871 Lakefield Drive • Suwanee, GA 30024 Authorization Letter Date: September 8, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID: UIDW11 To Whom It May Concern: ARRIS hereby authorizes the following person to act as our agent regarding the application for equipment authorization, referenced by the FCC ID above. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] This authorization includes permission for the agent to complete FCC forms and sign the application on our behalf. We acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by FCC, still resides with ARRIS. We further certify that neither the applicant nor any party to this application, as defined in 47 CFR 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. Sincerely, Applicant : ARRIS Address : 3871 Lakefield Drive, Suwanee, Georgia, 30024 USA Signature : Name and Job : Thomas Kelleher / Compliance Engineer e-Mail : [email protected] Telephone : +1-215-323-2257

PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 1 of 3 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP Brand Name: ARRIS Model Name: W11 PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 2 of 3 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 3 of 3 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP

Label Location Label Here

PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 1 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP Brand Name: ARRIS Model Name: W11 PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 2 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 3 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 4 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 5 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 6 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 7 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 8 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 9 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 10 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 11 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 12 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 13 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 14 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 15 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 16 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 17 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 18 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 19 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 20 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 21 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 22 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP071418 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page Number : 23 of 44 TEL : 886-3-656-9065 Issued Date : Sep. 23, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT…

Text truncated - open the document above for the full version.

FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 2 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 Table of Contents History of this test report.................................................................................................................................3 Summary of Test Result...................................................................................................................................4 1 General Description .............................................................................................................................5 1.1 EUT General Information .......................................................................................................................5 1.2 Table for Radio function .........................................................................................................................5 1.3 Testing Location .....................................................................................................................................5 2 Maximum Permissible Exposure ........................................................................................................6 2.1 Limit of Maximum Permissible Exposure ...............................................................................................6 2.2 MPE Calculation Method........................................................................................................................6 2.3 Calculated Result and Limit....................................................................................................................7 Photographs of EUT v01 FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 3 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 History of this test report Report No. Version Description Issued Date FA071418 01 Initial issue of report Sep. 10, 2020 FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 4 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Reviewed by: Sam Chen Report Producer: Viola Huang FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 5 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 2.4GHz WLAN 2400-2483.5 2412-2462 802.11b: DSSS (DBPSK, DQPSK, CCK) 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) VHT: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) 5GHz WLAN 5150-5250 5725-5850 5180-5240 5745-5825 802.11a/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) 1.2 Table for Radio function Radio 2.4GHz 5GHz Band 1 5GHz Band 4 1 V V - 2 - - V 1.3 Testing Location Testing Location HWA YA ADD : No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. TEL : 886-3-327-3456 FAX : 886-3-327-0973 JHUBEI ADD : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. TEL : 886-3-656-9065 FAX : 886-3-656-9085 Test site Designation No. TW0006 with FCC. Test site registered number IC 4086D with Industry Canada. FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 6 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 2 Maximum Permissible Exposure 2.1 Limit of Maximum Permissible Exposure (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Method The MPE was calculated at 30 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   FCC RADIO EXPOSURE TEST REPORT Report No. : FA071418 TEL : 886-3-656-9065 Page Number : 7 of 7 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A1_1 Ver1.0 Report Version : 01 2.3 Calculated Result and Limit Exposure Environment: General Population / Uncontrolled Exposure Mode DG (dBi) Power (dBm) EIRP (dBm) Tolerance (dB) Tune-up EIRP (dBm) Tune-up EIRP (W) Distance (cm) S (mW/cm 2 ) S Limit (mW/cm 2 ) 2.4G;G1D 4.06 27.09 31.15 0.…

Text truncated - open the document above for the full version.

FCC RADIO TEST REPORT Report No. : FR071418AB TEL : 886-3-656-9065 Page Number : 2 of 28 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A12_1 Ver1.2 Report Version : 01 Table of Contents History of this test report.................................................................................................................................3 Summary of Test Result...................................................................................................................................4 1 General Description .............................................................................................................................5 1.1 Information..............................................................................................................................................5 1.2 Applicable Standards .............................................................................................................................9 1.3 Testing Location Information ..................................................................................................................9 1.4 Measurement Uncertainty ......................................................................................................................9 2 Test Configuration of EUT.................................................................................................................10 2.1 Test Channel Mode ..............................................................................................................................10 2.2 The Worst Case Measurement Configuration......................................................................................11 2.3 EUT Operation during Test ..................................................................................................................12 2.4 Accessories ..........................................................................................................................................12 2.5 Support Equipment...............................................................................................................................12 2.6 Test Setup Diagram .............................................................................................................................13 3 Transmitter Test Result .....................................................................................................................15 3.1 AC Power-line Conducted Emissions ..................................................................................................15 3.2 Emission Bandwidth .............................................................................................................................17 3.3 Maximum Conducted Output Power ....................................................................................................18 3.4 Peak Power Spectral Density...............................................................................................................20 3.5 Unwanted Emissions ............................................................................................................................23 4 Test Equipment and Calibration Data ..............................................................................................27 Appendix A. Test Results of AC Power-line Conducted Emissions Appendix B. Test Results of Emission Bandwidth Appendix C. Test Results of Maximum Conducted Output Power Appendix D. Test Results of Peak Power Spectral Density Appendix E. Test Results of Unwanted Emissions Appendix F. Test Photos Photographs of EUT v01 FCC RADIO TEST REPORT Report No. : FR071418AB TEL : 886-3-656-9065 Page Number : 3 of 28 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A12_1 Ver1.2 Report Version : 01 History of this test report Report No. Version Description Issued Date FR071418AB 01 Initial issue of report Sep. 10, 2020 FCC RADIO TEST REPORT Report No. : FR071418AB TEL : 886-3-656-9065 Page Number : 4 of 28 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A12_1 Ver1.2 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PASS - 3.1 15.207 AC Power-line Conducted Emissions PASS - 3.2 15.407(a) Emission Bandwidth PASS - 3.3 15.407(a) Maximum Conducted Output Power PASS - 3.4 15.407(a) Peak Power Spectral Density PASS - 3.5 15.407(b) Unwanted Emissions PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Reviewed by: Sam Chen Report Producer: Viola Huang FCC RADIO TEST REPORT Report No. : FR071418AB TEL : 886-3-656-9065 Page Number : 5 of 28 FAX : 886-3-656-9085 Issued Date : Sep. 10, 2020 Report Template No.: CB-A12_1 Ver1.2 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Frequency (MHz) Channel Number 5150-5250 5180-5240 36-48 [4] 5725-5850 a, n (HT20), ac (VHT20), ax (HEW20) 5745-5825 149-165 [5] 5150-5250 5190-5230 38-46 [2] 5725-5850 n (HT40), ac (VHT40), ax (HEW40) 5755-5795 151-159 [2] 5150-5250 5210 42 [1] 5725-5850 ac (VHT80), ax (HEW80) 5775 155 [1] For Radio 1 Band Mode BWch (MHz) Nant 5.15-5.25GHz 802.11a 20 2 5.15-5.25GHz 802.11n HT20 20 2 5.15-5.25GHz 802.11ac VHT20 20 2 5.15-5.25GHz 802.11ax HEW20 20 2 5.15-5.25GHz 802.11n HT40 40 2 5.15-5.25GHz 802.11ac VHT40 40 2 5.15-5.25GHz 802.11ax HEW40 40 2 5.15-5.25GHz 802.11ac VHT80 80 2 5.15-5.25GHz 802.11ax HEW80 80 2 For Radio 2 Band Mode BWch (MHz) Nant 5.725-5.85GHz 802.11a 20 4 5.725-5.85GHz 802.11n HT20 20 4 5.725-5…

Text truncated - open the document above for the full version.

Test Photos Appendix F SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page No. : 1 of 3 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 1 FRONT VIEW REAR VIEW Test Photos Appendix F SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page No. : 2 of 3 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 30MHz~1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW Test Photos Appendix F SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory Page No. : 3 of 3 Test Configuration: Above 1GHz FRONT VIEW REAR VIEW ─────THE END─────
