UL5-EW40USWireless Fan Controller

3916066 09.06 Installation & Operating Manual USA CAN EW 40 Wireless Fan Control EXHAUSTO Inc. 1200 Northmeadow Pkwy. Suite 180 Roswell, GA 30076 P: 770.587.3238 F: 770.587.4731 T: 800.255.2923 [email protected] us.exhausto.com Job Name: Installer: Installation Date: Product Information Mechanical Installation Electrical Installation Start Up and Configuration Maintenance and Troubleshooting ........................ Chapter 1 + 2 ......................... Chapter 3 ............................. Chapter 4 .................. Chapter 5 ...... Chapter 6 2 3916066 09.06 How to use this manual This installation manual does not contain any system design documentation. System design documentation is available from any authorized EXHAUSTO representative. Accessories, fans and variable frequency drives are not covered by this manual. Please refer to these component’s individual manuals. 1. Product Information 1.1 Function ...............................................................................................3 1.2 Shipping ...............................................................................................3 1.3 Warranty ...............................................................................................3 1.4 FCC Notifications and Requirements....................................................4 1.5 EW 40 Control Components and Locations..........................................5 2. Specifications 2.1 Dimensions & Capacities ......................................................................6 3. Mechanical Installation 3.1 Installing the Power Unit ......................................................................7 3.2 Installing the Control Unit .....................................................................7 3.3 Installing the Temperature Sensor ......................................................8 3.4 Installing the Proven Draft Switch (if applicable) .................................8 3.5 Installing the Repeater Unit (if applicable) ...........................................9 4. Electrical Installation 4.1 General ..............................................................................................10 4.2 Wiring of the EW 40 ...........................................................................11 5. Startup and Configuration 5.1 Control Unit Settings ..........................................................................12 5.2 Recommended Settings .....................................................................13 6. Maintenance and Troubleshooting ...........................................................................................................13 TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Caution: Indicates an imminent hazardous situation which, if not avoided, may result in personal injury or property damage. Symbol Legend: The following terms are used throughout this manual to bring attention to the presence of potential hazards or to important information concerning the product. Danger: Indicates an imminent hazardous situation which, if not avoided, will result in death, serious injury or substantial property damage. 1. Use this unit in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed on the front of the manual. 2. Before servicing or cleaning the unit, switch off at service panel and lock service panel to prevent power from being switched on accidentally. 3. Installation work and electrical wiring must be done by a qualified person(s) in accordance with applicable codes and standards. 4. Follow the appliance manufacturer’s guidelines and safety standards such as those published by the National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities. 5. This unit must be grounded. 3 3916066 09.06 1. Product Information 1.1 Function Use The EW 40 is a wireless control that can be used to operate and control an EXHAUSTO chimney fan or power venter. It is designed for use with fireplaces and stoves. The use is not restricted to any type of fuel. The unit allows the user to stop, start and control the speed of a chimney fan from a wireless Control Unit. It can be installed with or without a temperature sensor. For gas-fired appliances, a safety system in the form of a Proven Draft Switch (PDS) must be installed. ON/OFF Function. The user can switch the chimney fan on when necessary. Similarly, the user can switch it off when it is not needed. Increase/Decrease Speed. This function is used to regulate the speed of the chimney fan and thus the mechanical draft generated by it. When adding wood logs to a fire the control panel allows the user to regulate the fan speed and draft, which prevents smoke from entering the room and eases the combustion. When the temperature sensor is installed, the following additional functions are available: Start-up Function. Extra draft is needed when lighting a fire in a cold fireplace or stove. The Power Unit will make the chimney fan go into a “boost mode” (max. speed) for a set period (default is 7 minutes) when the ON/OFF switch is activated. After this period, the control automatically adjusts the speed to a lower level. When the temperature registered by the sensor exceeds the programmed start temperature, an asterisk (*) appears on the display indicating it is now possible to reduce the fan speed. Automatic Start. If the user forgets to switch on the chimney fan before lighting the fire, the fan will start automatically when the chimney warms up. The factory setting for this function is 25 degrees C. Refiring Function. The display on the Control Unit indicates when adding new fuel is required. The display will read “REFIRING” and a low audio signal (beep) will sound five times while the asterisk (*) flashes. When adding new fuel, press the ON/OFF switch before…
