UPEJVAS-QG01AVL(Automatic Vehicle Locator)

AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 1 AVL GPX-100 ƒ Installation ƒ Operation ƒ Specification AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 2 1. Installation................................................................................................................... 3 1.1. Software Installation and Configuration ............................................................. 3 1.1.1. System Requirement ....................................................................................... 3 1.1.2. Software Installation ....................................................................................... 3 1.1.3. Configuration .................................................................................................. 3 1.1.3.1. Setup general information (General Tab)............................................. 5 1.1.3.2. Setup phone call recipients (Call Tab) .................................................. 5 1.1.3.3. Setup Text Message recipients (Trace Tab) .......................................... 7 1.1.3.4. Setup input and output points (I/O Channel Tab).............................. 9 1.1.3.5. Setup Alarm/Event notifications (Events Tab) ..................................... 9 1.1.3.6. Setup remote controls (Keys Tab)......................................................... 10 1.1.3.7. Save and Download Configuration ........................................................... 11 1.2. Hardware installation ........................................................................................ 12 1.2.1. Power Source ................................................................................................ 12 1.2.2. GPS Antenna................................................................................................. 12 1.2.3. GSM Antenna ............................................................................................... 12 1.2.4. Input and Output ........................................................................................... 12 2. Operation...................................................................................................................13 2.1. Making a call..................................................................................................... 13 2.2. Receiving a call................................................................................................. 13 2.3. Sending current location ................................................................................... 13 2.4. Navigation......................................................................................................... 13 2.5. Arm/Disarm the device ..................................................................................... 14 3. Technical Reference.................................................................................................. 15 4. Legal Statement ........................................................................................................ 16 5. Appendix................................................................................................................... 17 5.1. Parts List ........................................................................................................... 17 AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 3 1. Installation 1.1. Software Installation and Configuration 1.1.1. System Requirement The minimum requirement to install the configuration application is 1. Operating System: Windows NT/2000/XP 2. Free Disk space: 5 Mbytes 3. One CD-ROM device 4. One DB-9 serial port connector 1.1.2. Software Installation To install the configuration application, 1. Insert the installation CD to the CD-ROM device; 2. The installation will guild you to finish the setup; and 3. A QUEST, , icon will be created on your platform desktop screen. 1.1.3. Configuration After the installation, you can click on the QUEST icon to configure your devices. To setup your device, 1. Connect DC adapter to your device as the power source. 2. Connect your device to PC with serial port cable; 3. Double click on QUEST icon, the Home tree will be shown as Figure 1 AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 4 Figure 1: Home Tree 4. Expend the Home tree, an AVLDevice tree will be shown as Figure 2. Figure 2: AVLDevice Tree 5. Expend the AVLDevice tree, there is a default device, MyDefaultDevice, has been created. (Figure 3) AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 5 Figure 3: Default Device 6. Double click on the ‘MyDefaultDevice’ device. You should be in the device configuration. (Figure 4) Figure4: Device Configuration 1.1.3.1. Setup general information (General Tab) From this interface, you can modify the device name, update device serial number (10 characters string from the back of the device), and device pin number. 1.1.3.2. Setup phone call recipients (Call Tab) AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 6 The device is able to store 4 pre-set phone numbers for speed dial phone call. From this interface (Figure 5), you can setup the phone numbers to be your phone call recipients. Figure 5: Call Recipient Setup The device panel has 6 keys (Figure 6). Figure 6: Device Panel ƒ To call 1 st recipient, press Call key and wait 3 second, the call will be made. ƒ To call 2 nd recipient, press F1/0 key, then press Call key and wait for 3 second, the call will be made. AVL GPX-100 User’s Manual 3G Quest Technologies, Inc. 7 ƒ To call 3 rd recipient, press F2/1 key, then press Call key and wait for 3 second, the call will be made. ƒ To call 4 th recipient, press F3/9 key, then press Call key and wait for 3 second, the call will be made. ƒ To make an emergency call 911, by pressing F3/9, F2/1, and F2/1, then waits for 3 second, the call will be made. Note that the time interval between 2 key presses should be less than 3 second; otherwise it would be treated as 2 separated operations instead of a single action. Before the ac…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17

FCC ID: UPEJVAS-QG01 Report No: SA950808H02 1 RF EXPOSURE REPORT REPORT NO.: SA950808H02 MODEL NO.: GPX-100 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: 3G Quest Technologies, Inc. ADDRESS: 171 School Street, Acton, MA 01720 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: UPEJVAS-QG01 Report No: SA950808H02 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: UPEJVAS-QG01 Report No: SA950808H02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of the product, under normal use condition, is at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: UPEJVAS-QG01 Report No: SA950808H02 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 0dBi or 1 (numeric) 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For GSM band: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 128 824.12 1901.078 0.378 1.0 190 836.58 1972.423 0.392 1.0 251 848.76 1823.896 0.363 1.0 For PCS band Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 512 1850.2 918.333 0.183 1.0 661 1880.0 959.401 0.191 1.0 810 1909.8 1025.652 0.204 1.0

Report no.: RF950808H02 1 Report Format Version 2.0.5 FCC TEST REPORT (PART 22) REPORT NO.: RF950808H02 MODEL NO.: GPX-100 RECEIVED: Sep. 21, 2006 TESTED: Nov. 01 ~ 08, 2006 ISSUED: Nov. 13, 2006 APPLICANT: 3G Quest Technologies, Inc. ADDRESS: 171 School Street, Acton, MA 01720, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 51 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report no.: RF950808H02 2 Report Format Version 2.0.5 TABLE OF CONTENTS 1 CERTIFICATION.........................................................................................................4 2 SUMMARY OF TEST RESULTS.................................................................................5 2.1 MEASUREMENT UNCERTAINTY.......................................................................6 3 GENERAL INFORMATION.........................................................................................7 3.1 GENERAL DESCRIPTION OF EUT.....................................................................7 3.2 DESCRIPTION OF TEST MODES.......................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST..................................................9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL......................10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.....................................12 3.4 DESCRIPTION OF SUPPORT UNITS...............................................................12 4 TEST TYPES AND RESULTS...................................................................................13 4.1 OUTPUT POWER MEASUREMENT.................................................................13 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT...............................................13 4.1.2 TEST INSTRUMENTS.......................................................................................14 4.1.3 TEST PROCEDURES........................................................................................15 4.1.4 TEST SETUP.....................................................................................................16 4.1.5 EUT OPERATING CONDITIONS.......................................................................17 4.1.6 TEST RESULTS.................................................................................................18 4.2 FREQUENCY STABILITY MEASUREMENT......................................................20 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT..................................20 4.2.2 TEST INSTRUMENTS.......................................................................................20 4.2.3 TEST PROCEDURE..........................................................................................21 4.2.4 TEST SETUP.....................................................................................................21 4.2.5 TEST RESULTS.................................................................................................22 4.3 OCCUPIED BANDWIDTH MEASUREMENT.....................................................24 4.3.1 LIMITS OF OCCUPIED BANDWIDTH MEASUREMENT...................................24 4.3.2 TEST INSTRUMENTS.......................................................................................24 4.3.3 TEST SETUP.....................................................................................................25 4.3.4 TEST PROCEDURES........................................................................................25 4.3.5 TEST RESULTS.................................................................................................26 4.4 BAND EDGE MEASUREMENT.........................................................................28 4.4.1 LIMITS OF BAND EDGE MEASUREMENT.......................................................28 4.4.2 TEST INSTRUMENTS.......................................................................................28 4.4.3 TEST SETUP.....................................................................................................28 4.4.4 TEST PROCEDURES........................................................................................29 4.4.5 EUT OPERATING CONDITION.........................................................................29 4.4.6 TEST RESULTS.................................................................................................30 4.5 CONDUCTED SPURIOUS EMISSIONS............................................................31 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT.............31 4.5.2 TEST INSTRUMENTS.......................................................................................31 4.5.3 TEST PROCEDURE..........................................................................................32 4.5.4 TEST SETUP.....................................................................................................32 4.5.5 EUT OPERATING CONDITIONS.......................................................................32 4.5.6 TEST RESULTS.................................................................................................33 Report no.: RF950808H02 3 Report Format Version 2.0.5 4.6 RADIATED EMISSION MEASUREMENT (BELOW 1GHz)................................39 4.6.1 LIMITS OF RADIATED EMISSION MEASUREMENT........................................39 4.6.2 TEST INSTRUMENTS.......................................................................................40 4.6.3 TEST PROCEDURES..............…
