OPERATIONAL DESCRIPTION 1. Features ¾Code Format : POCSAG ,1200BPS ¾Frequency : 457.5750MHz ¾LED : 1 EA (FULL COLOR LED) ¾LCD : 128 * 64 dots (B/W) ¾Alert : Vibrator & Buzzer & LED ¾Code process : Alpha 64 characters & Numeric message ¾Battery : 3.7V Re-chargeable ¾ID setting : 4 CAPCODE ¾Key : 1 key ( Alert stop ) ¾Out of range melody and display ¾Low battery melody and display 2. Circuit operational description - Receiver : super heterodyne receiver Carrier frequency (457.575MHz), passed thru antenna, amplifies at Q1, Q2. Q3 receives signals of Q4, Q1, Q2 and makes 1 st IF (21.4MHz) to send it to U1. U1 mixes 1 st IF with 2nd local oscillation frequency (20.945MHz) and makes 2nd IF (455KHz). The 455Khz is demodulated at Dis101(quadrature detect). U1 Sends FSK out to the Pin no 15 of CPU(U2).
