UPWWSD2006Wireless Automated liftslide module
Weiland Sliding Doors and Windows, Inc.
Click to zoom
Application Details
- Equipment Class
- DXT - Part 15 Low Power Transceiver, Rx Verified
- Date of Grant
- Nov 16, 2006
- Application Purpose
- Original Equipment
- Date of Application
- Nov 16, 2006
- Equipment Note
- Wireless Automated liftslide module
- Frequency Range
- 915.00000000 - 915.00000000
- Country
- United States
