UQBASR-03XDUHF RFID Reader Dongle

User Guide Preliminary, 2015-10-02 USER GUIDE Revision History Version Date Changes 00 2015-10-02 Preliminary USER GUIDE 1 OVERVIEW Appearance Accessories Rubber case Quick Manual Vehicle Mounts USER GUIDE 2 SPECIFICATIONS PHYSICAL Dimension(WxLxH) 117.3 x 65.8 x 17.1mm Weight 90g Indication Power on LED(Blue), Charging LED(Red), Tagging LED (Blinking Blue) Battery 700mAh Continuous Time 5 hours Standby Time 24 hous Charging Time 2 hous RFID PERFORMANCE RFID Reader Chip PHYCHIPS PR9200 Air Protocol EPCglobal Class 1 Gen 2 / ISO 18000-63 (formerly 18000-6C) Interface Apple Lightning Connector OS Apple iOS 7.0 Output Power 316mW(25dBm) for US, EU and Korea band 200mW(23dBm) for Japan band RFID Read Distance Up to 1.0m (depend on tags) Antenna Circularly Polarized Antenna RFID Function Read, Write, Lock, Kill USER ENVIRONMENT Operating Temp Discharge (-10 to 45°C), Charge (0 to 45°C) Storage Temp -20 to 60°C (1 month), -20 to 45°C (3 month), -20 to 20°C (1 year) Relative Humidity 5 to 95% humidity noncondensing REGULATORY RFID FCC Part 15 Subpart C 247, EN 302 208, KCC 2013-1, KCC 2012-102, ARIB STD T107 EMI/EMC EN 301 409-1, EN 301 409-3, EN61000-3-2, EN61000-3-3, KN 301 409-1/3, KN61000-4-2/3/4/5/6/11 Electrical Safety EN 60950-1 LIMITED WARRANTY The lithium-ion battery capacity is dropping linearly to 80% over 300 cycles. A charge cycle means using all of the battery’s capacity, but that doesn’t necessarily mean a full charge and discharge. The lithium-ion battery in RFID reader should not be replaced by the user. Contact where you buy it. USER GUIDE 2.1 Charging Vehicle mounts and RFID reader are shown below. To charge the device, mounting the device to the vehicle mounts. Note: When the user connects the device with iPhone during the charging, the device can charge itself and the device simultaneously. When charging is finished, LED shall be turned off. USER GUIDE 3 HOW TO USE DEVICE Install the vehicle mount to your vehicle as shown below. Connect iPhone to device as shown below. Note: This product is intended for use in vehicle mounting Please do not use this product for portable use USER GUIDE 4 HOW TO USE APPLICATION 4.1 How to install application in your iPhone Once iPhone is connected to lightning connector, there will be pop-up to choose whether to start App or not as picture above. If App is not installed, there will be a sign to download it from App-store. When you accept the alarm, the App will be launched. USER GUIDE 4.2 Launching the App If iPhone and dongle device is connected properly, ‘Unplugged’ will be changed to ‘Plugged’. And setting, read, clear, battery and stop button will be active. USER GUIDE 4.3 Main Display - Switch: Turn on or off the Reader - Read Button: Start to read “Tag EPC” - Clear Button: Remove Read Record - Stop Button: Stop Tag Reading - Display: Show Tag Read Record 4.4 Status Bar The number of tags displayed RFID READER Status - Unplugged: RFID READER is not inserted into headset jack. - Plugged: RFID READER is inserted into headset jack. - Connected: RFID READER is connected to app. Battery gauge USER GUIDE 4.5 Tag Read 1. Switch the button to "On" 2. Touch Read button to inventory tag continuously A. PC + EPC will appear. 3. Touch Stop button to finish inventory tag 4. Touch Clear button to clear the list of tags. USER GUIDE 5 CAUTION 5.1 Safety Information 1. Do not disassemble or repair arbitrarily but contact where you buy when RFID READER is in trouble. 2. Do not use chemical substance(alcohol, benzene, detergent etc) and water to clean RFID READER 3. Please avoid vibrations and shocks. Please place in a safe place when not in use. 4. Please avoid high/low temperature and high humidity. 5. Please turn RFID READER off in explosive area as there may be danger due to electric wave. 6. Please use medical device(pacemaker, hearing aid etc) which is blocked from RF energy. 7. Please stop using RFID READER and consult a medical expert in case of any allergic reactions and side effect. 5.2 Operation The device can be used over 20cm from the user. This product is intended for use in vehicle mounting Please do not use this product for portable use 1. The device will be automatically off from following situations. 2. When receives a phone call, the device automatically turn off the power. 3. Include a message, something pop-up by certain Apps. 4. When switching from Barcode App to other App or pressing Home button. 5. When pressing power button or the display automatically turns off to sleep mode or App display disappears or the display is covered by Pop-up, it will automatically off the App. 5.3 RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment must be installed and operated with minimum distance of 20cm between the radiator and your body. This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users.” 5.4 Compliance Information FCC Information Note: This equipment has been tested and found to comply with the limits for CLASS B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correcting the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. USER GUIDE 2. Increase the separation between the equipment and receiver. 3. …
