UZRDIYWR3Wireless Rearview System

Audio SignalInput Audio SignalAmplify Preemphasis FM Modulation (6.5MHz) Mixing Mixing Signal Amplify Filter bank 2.4GHz VCO Preemphasis Video SignalInput PLL CPU Channel Select Crystal Oscillator (8MHz)

ID label & location info. ID label location FCC ID: UZRDIYWR3

Operation Description (CCD) A picture is taken by a camera and is converted to an electrical analog signal by CCD. The analog signal is converted to 10-bit digital signal and is processed by DSP. DSP outputs an analog signal (vi deo signal) and is amplified to be standard video signal of 1Vp-p 75Ω. The signal is transmitted by antenna with 2.4GHz.

Operation Description (Transmitter) Transmit Frequency: 2468MHz, Modulation Type: FM Audio signal is input and amplified in the transmitter. The signal is further pre-emphasis and FM modulated with 6.5MHz and output to a mixer. Video signal is input and pre-emphasis to the mixer. The mixer mixes audio signal and video signal. CPU controls the frequency of crystal oscillator by channel select. PLL stabilizes the frequency. The mixed signal is amplified and filtered and finally transmitted by antenna at 2.4GHz.

D9 D5 BLK D3 Q2 2SC4177-T1 DN2 DS226 12 3 12 3 VX3 C2104 C9104 3.3V VX2 OBCP R71M C49 10uF/6V FV4 Q1 2SA1663Y C46 104 C15 475/25V C21102 R4 100K C19 1uF/25V 5V C4818p D9 C? 104 C11 475/25V 15V C4718p SCK CSN C24104 L422uH R? 100 R3100 3.3V D6 ISS355 12 U?IA171 1 2 34 5 6 PS VOUT SAGVIN GND VCC 3.3V ADCK SCK R1212K C13 100uF/6V X1 28.375MHZ D1 FCDS L310uH C2510n D2 C54 104 R2322K ADCLP C32 104 R64.7K C42104 C10 104 D4 ISS355 12 3.3V D6 D1 C27105 C4 10uF/20V D3 C3 104 C50104 L522uH FV3 C34104 C17 105 C7475/25 R?1k C18104 BLK OFDX R2470 C53104 VX2 C82200p C43104 C33104 R2122K C6104 FV3 3.3V C1 475/25V ZD18.2V 3.3V U6 7805 1 2 3 VOUT GND VIN FV1 VX3 VHX1 R25100K C45 104 C52104 3.3V D4 FS D4D8 C38104 D2 U1 LR38603 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 2122232425262728293031323334353637383940 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 6162636465666768697071727374757677787980 ACL CKI CKO VDD GND ADCK SCK SDATA AD19 AD18 AD17 AD16 AD15 AD14 VDD GND AD13 AD12 AD11 AD10 OBCP ADCLP BLKX EEPDA GND VDD EEPCK EEPFLEEPSL WB1WB2 MI R BLC GNDDA VDDDA VB IREF VREF GNDDA VIDEO EEMDS SHMD1 SHMD2 SHMD3 GND VDD DCK1 DCK2 EXCKI Y0 Y1 Y2 Y3 GND VDD Y4 Y5 Y6 Y7 HD VDV1XV2XV3XV4XVDDGNDVH1XVH3XOFDXVDDGNDFRFH1FH2VDDGNDRSFSFCDS R19 1M FCDS D8 VHX3 3.3V 15V VX4 D0 C22105 C14 475/25V U2IR3Y 48A1 1 2 3 4 5 6 7 8 9 10 11 12 131415161718192021222324 25 26 27 28 29 30 31 32 33 34 35 36 373839404142434445464748 NC AVDD4 NC VRN VRP AVDD2 AVDD2 AVSS2 AVSS2 VCON CCDIN REFIN CLPCAPADINOBCAPMONOUTNCA/SETAVDD1AVSS1NCADCKSHRSHD ADCLP BLK CCDCLP OBP SCK SDATA CSN STBYN AVSS3 AVDD3 RESTIN OUTCLK DO0DO1DO2DO3DO4 DVSS DVDD DO5DO6DO7DO8DO9 C44 104 ZD3 5.1V C51104 R2022K VX4 R51M C5 47uF/6V R2422K DN1 DS226 12 3 12 3 FV1 SDATA 3.3V C16105 3.3V U9 S-8520F33 1 2 34 5 1 2 34 5 D3 ISS355 12 VX1 3.3V C35104 R18100K R14.7K R15 22K U4 RJ2321AA 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 OD RS NC1 OS NC2 NC3 H2 H1NC4 OFD PW V1 V2 V3 V4 GND D1 RB411D(T146) 1 2 3 1 2 3 3.3V D7 <Doc > A/0 CAR-SH3 B 11 Tuesday , January 30, 2007 Tit leSize Document Number Rev Date: Sheet of FV4 L110uH D6D0 U5 AA87222 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 VSS OFDX V2X V1X VH1AX V3X VH3AX V4XV4 V3A VME V1A V2 VL POFD VH C23104 ADCK C40104 C26104 C12 100uF/6V 3.3V D5 FV2 ADCLP ZD25.1V R1622K U3 7W04 1234 5678 1A3Y2AGND 2Y 3A 1Y VCC C?104 C39104 15V R1722K FS VHX1 R11 4.7K 5V CN1 CN3P 123 123 3.3V VHX3 C31105 C36104 C41104 L2330uH R134.7K R14 22K VX1 SDATA FV2 CSN R2222K OFDX U7 78L15 1 2 3 VOUT GND VIN C20105 OBCP D7 U834C02 1234 5678 CE0CE1CE2GND SDA SCL MOD E VCC R26 4.7K C28 104 C37104

Y1 8MHZ C13105 C16 225 R9203 R8 203 C31 222 R1668 C5 104 R21 101 R13 75 R32104 ANT1 R26361 RCA1AV-inRCA2AL-in(6.5M) VCOVDD 1 VT 2 GND 3 CP 4 AVT2 5 ACP2 6 AOUT2 7 AVDD2 8 AOUT1 9 NC 10 AVT1 11 ACP1 12 AVDD1 13 VDD 14 SPI-SE 15 BCR 16 REG1D8 17 PD-REG1D8 18 XTAL1 19 XTAL2 20 VDD33 21 SP I CLK/CS0 22 SP I LE/CS1 23 SP I DATA/CS2 24 BX 25 SYNVSS 26 RFGND2 27 PAOUT2 28 PAOUT1 29 RFGND1 30 PA VDD 31 NC 32 U2 RTC6701 C39105 C2847 1 C25475 3.3V R30 103 R20 103 C21474 C2233 C2333 C24 104 R35 103 R34 103 R33 103 R36 103 3.3V L1 82 0 C11 01 R239 1 3.3V L3 2 2 NH C212 2 L2 392 C31 01 C14105 C35106 R27751 R171 53 C8 10 0 p C96105 C97105 C98105 R22 104 C2015 1 C19475 R19 103 R10 20 2 R5 10 0 R15122 C12105 R14 122 C18475 C101105 C7 1 01 VIDEO AL 3.3V 3.3V CH2CH1CH0 C29 823 R40 56 1 VT VT 3.3V R12 NP R18 NP R23 NP +5V C100 105 C4103 C102 105 C6 103 C103105 3.3V IN 1 GND 2 EN 3 BP 4 OUT 5 U1 RT9167A-33PB Q1 BFG540/X C111 21 R4123 L4 751 C9 22 1 R3 000 3.3V C101 01 L5 820 C15105 C17 1 01 R24NP TM103I-E .V1.0 1 1

Page 1of 23 FCC ID: UZRDIYWR3 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20070471 FCC CERTIFICATION On Behalf of Guangzhou Jincheng Electronic Technology Co., Ltd. Wireless Rearview System Model No.: DIY-w-r-3 FCC ID: UZRDIYWR3 Prepared for : Guangzhou Jincheng Electronic Technology Co., Ltd. Address : Building 4, No.3, South Road, Yongshan Village(Industrial Area), Shiji, Panyu, Guangzhou, Guangdong, China Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20070471 Date of Test : February 6, 2007 Date of Report : March 6, 2007 Page 2of 23 FCC ID: UZRDIYWR3 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20070471 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................4 1.3. Measurement Uncertainty.........................................................................................................................4 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 5 3. FUNDAMENTAL AND HARMONICS RADIATED EMISSION MEASURMENT ................ 6 3.1. Block Diagram of Test Setup....................................................................................................................6 3.2. The Emission Limit ..................................................................................................................................6 3.3. Configuration of EUT on Measurement ...................................................................................................7 3.4. Operating Condition of EUT ....................................................................................................................7 3.5. Test Procedure ..........................................................................................................................................7 3.6. The Field Strength of Radiation Emission Measurement Results ............................................................8 4. RADIATED EMISSION FOR FCC PART 15 SECTION 15.249(D)........................................... 9 4.1. Block Diagram of Test Setup....................................................................................................................9 4.2. The Emission Limit For Section 15.249(d) ..............................................................................................9 4.3. EUT Configuration on Measurement .....................................................................................................11 4.4. Operating Condition of EUT ..................................................................................................................11 4.5. Test Procedure ........................................................................................................................................11 4.6. The Emission Measurement Result ........................................................................................................12 5. BAND EDGES ................................................................................................................................. 13 5.1. The Requirement ....................................................................................................................................13 5.2. EUT Configuration on Measurement .....................................................................................................13 5.3. Operating Condition of EUT ..................................................................................................................13 5.4. Test Procedure ........................................................................................................................................13 5.5. The Measurement Result ........................................................................................................................14 6. ANTENNA REQUIREMENT........................................................................................................ 15 6.1. The Requirement ....................................................................................................................................15 6.2. Antenna Construction .............................................................................................................................15 APPENDIX I ( TEST CURVES) (7pages) Page 3of 23 FCC ID: UZRDIYWR3 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20070471 Test Report Certification Applicant : Guangzhou Jincheng Electronic Technology Co., Ltd. Manufacturer : Guangzhou Jincheng Electronic Technology Co., Ltd. EUT Description : Wireless Rearview System (A) MODEL NO.: DIY-w-r-3 (B) SERIAL NO.: N/A (C) POWER SUPPLY: DC 12V Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.249: 2006 & ANSI C63.4: 2003 The device described above is tested by ACCURATE TECHNOLOGY CO. LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section15.249 limits. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO. LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of ACCURATE TECH…
