V4P-KB882RFWireless 2.4G Keyboard

1 2 2 . . 4 4 G G H H z z C C o o r r d d l l e e s s s s K K e e y y b b o o a a r r d d KB-882RF keyboard User’s Manual 1. Preface The Keyboard utilizing 2.4GHz RF cordless technology, it is a slim design and Mouse combination. The keyboard built in hotkeys for Sleep and Multimedia functions, it has working range of 12 meters from the receiver. 2. Features 2.4GHz ISM band radio frequency 16 channels hopping channel from 2.402 ~ 2.480 GHz. 65536 ID number identify Operating distance up to 40 feet (12 meters) Advanced power saving management Error detection ability 4 Hotkeys for multimedia and Sleep Windows Me/2000/XP/Vista compatible FCC,CE, R&TTE, approvals 3. Power rating and temperature Keyboard Input power: 3V (2 PCs of 1.5V Battery) Operation Temperature: 0 ~ 70 °C 4. Establishing the communication link Connect the receiver to a USB port of the computer. LED light on the receiver will turn on automatically. Fig 1 Dongle ReceiverFig. 2 Keyboard backside 2 Press and release the Setup button on the receiver to turn off the LED light. (Fig. 1) Press the Connect button at the bottom of keyboard (Fig. 2). The LED light on receiver illuminates, indicating that the setup process has been completed. 5. Sleep Mode To save power consumption, this keyboard will enter into sleep mode automatically after two minutes left unused. LED li g ht of the M ouse will g o off and mouse cursor will have no movement temporarily. Sleep mode of Mouse does no t affect input function of other standard ke y s. Press an y key to wake up Mouse and to recover the Mouse function. 6. FCC Approved This de v i c e complie s with the part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation . 7. Caution To avoid the risk of batteries explosion, Please do not use alkaline batteries to charge them . Federal Communications Commission (FCC) S t atement 15.21 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

Shenzhen Fuyeda Industry Development Corp.,Ltd. No.1, Newmen Road, Tongsheng Village, Dalang Street, BaoAn, Shenzhen, China February 03, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID：V4P-KB882RF Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Name/Title: Geroge He / Managers Company Name: Shenzhen Fuyeda Industry Development Corp.,Ltd. Address: No.1, Newmen Road, Tongsheng Village, Dalang Street, BaoAn, Shenzhen, China TEL: +86-755-33669899 FAX: +86-755-33668968 Email: [email protected] Signature:

Shenzhen Fuyeda Industry Development Corp.,Ltd. No.1, Newmen Road, Tongsheng Village, Dalang Street, BaoAn, Shenzhen, China February 03, 2010 FCC ID：V4P-KB882RF Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China Name: Aven Zhou Job Title: Supervisor Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: NEWMEN/ KB-882RF FCC ID: V4P-KB882RF Product Name: Wireless 2.4G Keyboard Name/Title: Geroge He / Managers Company Name: Shenzhen Fuyeda Industry Development Corp.,Ltd. Address: No.1, Newmen Road, Tongsheng Village, Dalang Street, BaoAn, Shenzhen, China TEL: +86-755-33669899 FAX: +86-755-33668968 Email: [email protected] Signature:
