V4P-MS148OR-3Wireless Mouse

User manual Package contents Wireless Optical Mouse USB receiver 2 AAA alkaline batteries User manual Installing the battery (Diagram 1 ) Caution : Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. Compliance statement: 1: This device is verified to comply with Part 15 of the FCC Rules. Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Whenever new batteries are installed, make sure that they are fresh 1.5V AAA batteries. A)Remove the battery cover. B) Insert two AAA batteries into th e battery compartment, make sure to properly orient the positive (+) and negative (-) ends a s specified by the marks in the battery compartment. Replace the battery cover and make sure it is locked. C)Switch o n the mouse, the LED in bottom of mouse will blink. Installing the receiver (Diagram 2 ) The codes o f receiver and mouse were successfully connected in factory. User can directly use the complete set of products, no worry about the code connecting. A)Insert receiver into USB port of PC, the computer system will automatically detect it and prepare it for full operation. B)The mouse may use then. If the user wrongly operates, please redo the above operating procedures. "ON/OFF" switch (Diagram 1 ) Without using the mouse, user may turn off i t by "ON/OFF" switch for saving battery power. A)Using "DPI-adjusting key", th e resolution of mouse can be switched between 800DPI and 1600DPI in turn. That LED light in "DPI-adjusting key" blinks slowly indicates 800DPI and fast 1600DPI. B)Backward and Frontward keys for your easily navigating forward and backward on the Internet C) The 4-way scrolling wheel allows you to scroll up and down and side-to-side. It's simply a more efficient way to navigate documents, spreadsheets and Web pages. For example, if you're working with a super-wide worksheet, you can til t the wheel from side to side to scroll right and left, without clicking tiny scroll arrows. Low-voltage alarming function When batteries have been used for some time and discover the LED light in "DPI-adjusting key" blinks automatically, which reminds you that batteries' voltage is becoming low, suggested you replace the batteries with new ones. Note: If your operating system i s lower than Windows Vista, to activate the 4-way scrolling wheel, you may need to install driver. A CD driver i s included in this product. System requirements Windows ME, 2000, XP or Vista Specifications and functions 1. Super mini receiver can b e stored at bottom for easy carrying 2. 2.4GHz, freely operating within 1 0 meters 3. Wireless carrier frequency: 2403~2477MHz 4. 16 wireless working channels, automatic frequency jumping 5. Power ON/OFF function 6. Low-voltage alarming function 7. Resolution: 800DPI and 1600DPI adjustable 8. 2-way communication technology speeds up data transmission without delay 9. 4-way scrolling wheel for scrolling up and down and side-to-side efficiently ()Diagram 2()Diagram 1 ()Diagram 4 ()Diagram 3 Description of keys and DPI adjusting Frontward key Backward key 4-way scrolling wheel DPI-adjusting key Right key Left key ()Diagram 5 Mouse:MS-148OR Dongle:MX-205

Date: 24 March 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID: V4P-MS148OR-3 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Geroge He Manager Shenzhen Fuyeda Industry Development Corp.,Ltd. Tel:0755-33669899-2206 Fax:0755-33668968 Web site: www,newmen.com.cn E-mail: [email protected]

AGENCY AUTHORIZATION LETTER FCC ID: V4P-MS148OR-3 Date: 24 March 2011 To whom it may concern: We, the undersigned, hereby authorize NS Technology Co., Ltd. NS to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by NS within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Geroge He Manager Shenzhen Fuyeda Industry Development Corp.,Ltd. Tel:0755-33669899-2206 Fax:0755-33668968 Web site: www,newmen.com.cn E-mail: [email protected]

MS-148RL MS-148OR Mouse Made in China FCC ID: V4P-MS148OR-3 23mm 18mm Label location

Antenna Location
