V4P-NSPNM6103BKBluetooth Mouse

MOUSE FEATURESINSTALLING THE BATTERY AND CONNECTING THE MOUSE 1 Open the battery compartment and insert one AA battery (included). Make sure that you match the + and – symbols in the battery compartment. 2 Press the CONNECT button on the bottom of the mouse. The LED indicator blinks twice to indicate your mouse is in pairing mode. 3 Pair your mouse to your computer. PC: 1 Click the Bluetooth icon in your computer’s taskbar. 2 Click Add a Bluetooth device. Your computer searches for your mouse. 3 Double-click Bluetooth 3.0 Mouse. Mac: 1 Open System Preferences in the dock. 2 Click the Bluetooth icon. 3 Click + in the lower-left corner. Your computer searches for your mouse. 4 Double-click Bluetooth 3.0 Mouse. Note: If your computer has never connected to a Bluetooth device, click Set Up New Device to pair your mouse to your computer. When pairing is complete, the LED indicator lights for two seconds. TURNING YOUR MOUSE ON AND OFF 1 The first time you use your mouse, turn it on by moving the on/off switch on the bottom of the mouse to the on position. 2 If you don’t use your mouse for five minutes, it switches to standby mode to conserve the battery. To wake up your mouse, press any button or move it. Quick Setup Guide | NS-PNM6103-BK Bluetooth Mouse Before using your new product, please read these instructions to prevent any damage. PACKAGE CONTENTS • Bluetooth mouse • AA battery (1) • Quick Setup Guide SYSTEM REQUIREMENTS • Windows® 10, Windows®8.1, Windows®8, Windows®7, or Mac OS 10.x or higher • Built-in Bluetooth function or Bluetooth receiver FEATURES Final flat size: 314.33 x 148.08 mm Final fold size: 104.77 x 148.08 mm CONNECT button LED indicator FUNCTION LED indicator CONNECT button DESCRIPTION • Lights for three seconds when you turn on your mouse. • Blinks two times when your mouse is in pairing mode. • Lights for two seconds when pairing is complete. • Blinks every five seconds when the battery is low. • Lights for one minute when your mouse wakes up from standby mode. Press to put your mouse in pairing mode. On/off switch NS-PNM6103-BK_15-0609_QSG_V2_EN.ai 1 7/28/2015 12:09:50 PMNS-PNM6103-BK_15-0609_QSG_V2_EN.ai 1 7/28/2015 12:09:50 PM TROUBLESHOOTING My mouse is not working. • Move your mouse closer to your computer. • Make sure that your computer meets the system requirements. • Make sure that your mouse is paired by pressing the blue CONNECT button on the bottom of your mouse, then pair it with your computer. • Make sure that the Bluetooth function on your computer or your Bluetooth receiver is working. • Un-pair your mouse from your computer, then re-pair it. • If the LED indicator on your mouse is blinking every five seconds, replace the battery. LEGAL NOTICES FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. V2 ENGLISH 15-0609 Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RSS-Gen and RSS-210 statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RSS-102 statement This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies pour un environnement non contrôlé. ONE-YEAR LIMITED WARRANTY For complete warranty, visit www.insigniaproducts.com. CONTACT INSIGNIA 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC ©2015 Best Buy. All rights reserved. Made in China UN-PAIRING THE MOUSE FROM YOUR PC OR MAC PC: 1 Click the Bluetooth icon on your task bar. 2 Click Show Bluetooth Devices. 3 Right-click (Win 7) or click (Win 8) Bluetooth 3.0 Mouse. 4 Click Remove Device to un-pair the mouse. Mac: 1 Open System Preferences in the dock. 2 Click the Bluetooth icon . 3 Click the - in the left-lower corner. 4 When it asks Are you sure you want to remove this device?, click Remove to un-pair…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 17051456 001 Seite 54 von 57 Page 54 of 57 6. Safety Human Exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Pass Test standard : FCC KDB Publication 447498 D01 v05r02 The separation distance of the NS-PNM6103-BK should be 5mm.The measured maximum peak output power of the NS-PNM6103-BK is -3.82dBm (0.41mW, antenna gain:-1.53dBi), which is far below the SAR exclusion threshold level 10 mW (Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤50 mm), hence the EUT is excluded from SAR evaluation according to FCC KDB publication 447498 D01: Mobile and Portable RF Exposure. Guidance v05r02.

Produkte Products Prüfbericht - Nr.: Test Report No. 17051456 001 Seite 2 von 57 Page 2 of 57 TEST SUMMARY 5.1.1 ANTENNA REQUIREMENT RESULT: Passed 5.1.2 PEAK OUTPUT POWER RESULT: Passed 5.1.3 20DB BANDWIDTH RESULT: Passed 5.1.4 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100KHZ BANDWIDTH RESULT: Passed 5.1.5 SPURIOUS EMISSION RESULT: Passed 5.1.6 FREQUENCY SEPARATION RESULT: Passed 5.1.7 NUMBER OF HOPPING FREQUENCY RESULT: Passed 5.1.8 TIME OF OCCUPANCY RESULT: Passed 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Produkte Products Prüfbericht - Nr.: Test Report No. 17051456 001 Seite 3 von 57 Page 3 of 57 Contents 1. GENERAL REMARKS ........................................................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................................. 4 2. TEST SITES ........................................................................................................................................................ 4 2.1 TEST FACILITIES ................................................................................................................................................. 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS .................................................................................................. 5 2.3 TRACEABILITY .................................................................................................................................................... 5 2.4 CALIBRATION ..................................................................................................................................................... 5 2.5 MEASUREMENT UNCERTAINTY ............................................................................................................................. 6 2.6 LOCATION OF ORIGINAL DATA ............................................................................................................................. 6 2.7 STATUS OF FACILITY USED FOR TESTING .............................................................................................................. 6 3. GENERAL PRODUCT INFORMATION ....................................................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE .............................................................................................................. 7 3.2 RATINGS AND SYSTEM DETAILS ........................................................................................................................... 7 3.3 INDEPENDENT OPERATION MODES ....................................................................................................................... 7 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ........................................................................................... 8 3.5 SUBMITTED DOCUMENTS ..................................................................................................................................... 8 4. TEST SET-UP AND OPERATION MODES ................................................................................................................. 9 4.1 PRINCIPLE OF CONFIGURATION SELECTION ........................................................................................................... 9 4.2 TEST OPERATION AND TEST SOFTWARE ............................................................................................................... 9 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT .............................................................................................. 9 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE ............................................................................................ 9 4.5 TEST SETUP DIAGRAM ...................................................................................................................................... 10 5. TEST RESULTS ................................................................................................................................................. 12 5.1 TRANSMITTER REQUIREMENT & TEST SUITES ..................................................................................................... 12 5.1.1 Antenna Requirement ............................................................................................................................... 12 5.1.2 Peak Output Power ................................................................................................................................... 13 5.1.3 20dB Bandwidth ........................................................................................................................................ 14 5.1.4 Conducted spurious emissions measured in 100kHz Bandwidth .............................................................. 15 5.1.5 Spurious Emission .................................................................................................................................... 19 5.1.6 Frequency Separation ............................................................................................................................... 51 5.1.7 Number of hopping frequency ................................................................................................................... 52 5.1.8 Time of Occupancy ................................................................................................................................... 53 6. SAFETY HUMAN EXPOSURE ............................................................................................................................... 54 6.1 RADIO FREQUENCY EXPOSURE COMPLIANCE ...................................................................................................... 54 6.1.1 Electromagnetic Fields ...................................................................................…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 17051456 001 Seite 55 von 57 Page 55 of 57 7. Photographs of the Test Set-Up Photograph 1: Set-up for Spurious Emissions (9kHz-30MHz) Photograph 2: Set-up for Spurious Emissions (30MHz-1GHz) Produkte Products Prüfbericht - Nr.: Test Report No. 17051456 001 Seite 56 von 57 Page 56 of 57 Photograph 3: Set-up for Spurious Emissions (1GHz-18GHz) Photograph 4: Set-up for Spurious Emissions (18GHz-26GHz)
