Lane Electronic technology Co., Ltd No.11/B,Enping Foreign And Private Capital Industry Zone, GuangDong, China. Telephone: 86+750-7817728 Fax No.: +86-750-7815789 FCC ID: V63U-500 Operation Description The EUT is powered by 9V （1 x 6F22） battery and have one channel for each product, it cannot be tuned by the end user。 During manufacturing process, adjusting the peripheral circuit parameter of U3 1507 to get requested frequency. Wireless microphone circuit description of U-500。 AUDIO AMP CIRCUIT The audio signal is injected via the microphone sensor into the audio amp circuit composed of the amp Q5（N2）, pre-emphasize network (D1, C50, 51, 59 & L12). The level of the output signal is out put to modulation circuit. Integrator (R42-46 & C60-64) control the ocsilator. OSC & MODULATOR CIRCUIT The modulator circuit is a direct FM type built around the local oscillator controlled by Crystal Y1 XTAL1 (36 times to local oscillator), IC (U3 1507). The carrier frequency output from the PIN 8 of U3 and being sent to the RF amplifier which boosts the output to a nominal level (<1mW). RF PRE-AMPLIFIER & FINAL AMPLIFIER The 3-stage amplifier, using two transistors: pre-amp Q4 (N2) and RF final Q7(T33), culminating with a normal transmitter output of <1mW. The output filter (C37~40, L x 8, L7 suppress the output harmonics and matches the output to the integrate antenna. POWER STEADY CIRCUIT 2 transistors Q6, Q8 for voltage upper, U4 (7805) and U5(7803) provide voltage to modulation and RF amplifier respectively.

DESCRIPTIONSCommentQuantity RESISTOR100R2 100K1 10K11 10R3 12K1 15K1 1K5 22K5 2K21 3302 33K3 3K32 470K1 47K3 4K73 56K1 CERAMIC.CAPACITOR0.5P3 1011 1029 10320 1041 10P1 12P4 15P4 1P1 2012 2221 2231 22P3 24P1 27P1 30P2 3P1 47P6 6P3 8P1 ELECTRIC.CAPACITOR10U4 1U1 2U24 4U76 TANTALUM.CAPACITOR10U1 1U1 CHIP INDUCTOR15N3 22N1 6N81 FIXED INDUCTOR1UH2 RF TRANS(SPRING)1.5T22 2.5TK2 RF TRANS292 31(77)2 601 DIODE1N58191 BAV99(A7)1 KDV2511 LEDφ3 GRE1 φ3 RED1 TRANSISTORMMBR5179(7H) 3 2SC1623(L6)5 2SC3356(R24) 2 SWITCHSS22D03-G52 IC45581 571D1 78L051 VOLUMEB1031 B2021 CRYSTAL12M1 Components R34, R37 R16 R4, R7, R8, R9, R20, R24, R25, R30, R33, R35, R43 R38, R39, R41 R27 R12 R1, R5, R11, R13, R14 R2, R6, R15, R18, R22 R28 R3, R31 R29, R32, R36 R23, R26 R45 R17, R19, R40 R42, R44, R46 R21 C54, C62, C71 C72 C1, C7, C15, C27, C36, C53, C61, C83, C84 C8, C23, C26, C39, C40, C42, C47, C51, C55, C59, C63, C67, C68, C76, C77, C85, C87, C88, C89, C90 C35 C69 C56, C73, C80, C81 C49, C57, C60, C65 C46 C14, C70 C38 C18 C43, C75, C85 C52 C41 C3, C44 C78 C13, C45, C50, C58, C66, C74 C64, C79, C82 C48 C11, C12, C22, C24 C21 C2, C17, C20, C25 C4, C5, C6, C9, C16, C19 C86 C37 L16, L17, L18 L15 L14 L1, L2 L12, L13 L10, L11 L8, L9 L6, L7 L5 D2 D1 D4 LED1 LED2 Q5, Q6, Q7 Q1, Q2, Q3, Q4, Q10 Q8, Q9 SW1, SW2 U1 U2 U3 VR2 VR1 Y1

FCC ID: V63U-500 Report Number: HST201101-0127-FCC Page 1 of 22 Test Report Applicant: Lane Electronic Technology Co., Ltd. Address of Applicant: No. 11/B, Foreign and Private Capital Industry Zone, Enping, Guangdong, China. Equipment Under Test (EUT): EUT Name: UHF Wireless Microphone Model No.: U-500, U-1137, U-501, U-5537, U-502, U-5536, U-503, U-8610, U-505, U-8680, U-506, U-5638, U-507, U-610, U-508, U-620, U-509, U-630, U-510, U-640 Trade Mark: NA Serial No.: Not supplied by client Standards: FCC PART 74H:2010 Date of Receipt: Jan. 14, 2011 Date of Test: Jan. 14 to Jan. 20, 2011 Date of Issue: Jan 22, 2011 Test Result : PASS* z In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Henly Xie / Manager This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. The test report prepare by: Guangzhou Huesent Testing Service Co., Ltd. No.91, Dongguanzhuang Road, Tianhe District, Guangzhou, China. Tel: 86-20-28263298 Fax: 86-20-28263237 http://www.hst.org.cn E-mail: [email protected] REPORT No: HST201101-0127-FCC Page 2 of 22 Contents 1 TEST SUMMARY ...............................................................................................................3 2 GENERAL INFORMATION ................................................................................................4 2.1 Client Information.......................................................................................................4 2.2 General Description of E.U.T. ....................................................................................4 2.3 Details of E.U.T. .........................................................................................................4 2.4 Description of Support Units ......................................................................................4 2.5 Standards Applicable for Testing................................................................................4 2.6 Test Location..............................................................................................................5 2.7 Deviation from Standards ..........................................................................................5 2.8 Abnormalities from Standard Conditions....................................................................5 3 EQUIPMENTS USED DURING TEST ...............................................................................6 4 TEST RESULTS .................................................................................................................7 4.1 E.U.T. Operation Condition ........................................................................................7 4.2 Test Procedure & Measurement Data ........................................................................8 4.2.1 Carrier Radiated Power & Radiated Spurious Emissions .............................8 4.2.2 Occupied Bandwidth ................................................................................... 11 4.2.3 Frequency Stability .....................................................................................14 4.2.4 Modulation Characteristics..........................................................................16 4.2.5 EUT Constructional Details .........................................................................19 REPORT No: HST201101-0127-FCC Page 3 of 22 1 Test Summary Test Test Requirement Standard Paragraph Result Carrier Radiated Power FCC Part 2.1046 74.861 e) 1) 54–72, 76–88 & 174–216 MHz bands, 50 mW 470–608 and 614–806 MHz bands, 250 mW PASS Modulation Deviation FCC Part 2.1047 74.861 e) 3) Within 75kHz PASS Frequency Stability FCC Part 2.1055 74.861 e) 4) <0.005% 50 ppm PASS Operating Bandwidth FCC Part 2.1049 c) 74.861 e) 5) Within 200kHz PASS Unwanted Radiation FCC Part 2.1049 c) 74.861 e) 6) within the mask PASS Radiated Spurious Emission FCC Part 2.1053 74.861 d) 3) < 43+10lgP(W) dB PASS Remark: ♣The EUT has one channel, which is located in the range 614.0MHz to 698.0MHz . Only test result of three samples in 614.2 MHz, 656.3 MHz and 697.8 MHz were recorded in this report. REPORT No: HST201101-0127-FCC Page 4 of 22 2 General Information 2.1 Client Information Applicant: Lane Electronic Technology Co., Ltd. Address of Applicant: No. 11/B, Foreign and Private Capital Industry Zone, Enping, Guangdong, China. 2.2 General Description of E.U.T. EUT Name: UHF Wireless Microphone Item No.: U-500, U-1137, U-501, U-5537, U-502, U-5536, U-503, U-8610, U-505, U-8680, U-506, U-5638, U-507, U-610, U-508, U-620, U-509, U-630, U-510, U-640 Tested U-500 only, since the other models are electrical identical to U-500 except the model No. and the color of outlook. Serial No.: Not supplied by client 2.3 Details of E.U.T. Power Supply: 9Vdc, 1 x 6F22 Battery Main Function: Wireless microphone system with an associated receiver for transmitting voice. The final amplifier Collector Voltage and Collector Current are 0.3V & 3.5mA respectively. Necessary Bandwidth: 2M+2DK= 2 x 60kHz + 2 x 20kHz x 1.0 = 160 kHz 2.4 Description of Support Units Connect the EUT to mains power, and then test the EUT with signal generator. 2.5 Standard…
