VDPRLV410JN2122Radio Link V410

Radio Link V410 Operation Manual 0168 DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 2 of 18 I N D E X 1 VIEWING THE RADIO LINK V410............................................................................................................................... 3 2 ADDING OR CHANGING TERMINALS ...................................................................................................................... 6 3 PRINTING RADIO LINK V410 TEST REPORT ........................................................................................................ 15 4 GENERAL INFORMATION & DISCLAMERS.......................................................................................................... 17 5 CONTACT INFORMATION ......................................................................................................................................... 18 0168 DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 3 of 18 Radio Link V410 Testing or Updating: 1. Viewing the Radio Link V410. Open the Radio Link V410 testing program and click the ‘View’ button. The ‘View’ window will open so that you can able to see the status of the Radio Link V410 you are testing or updating. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 4 of 18 There are things that you have to observe in the view window that will show whether your Radio Link V410 is healthy or not. ∑ Communication Icon. This icon shows whether there is healthy communication between you Radio Link V410 and your computer. If there is a green icon with a tick mark , the communication is healthy. If the is a red icon with an X mark , the communication has failed. Check if the Radio Link V410 has power, and that the Radio Link V410 is connected to the computer. If there is power and the communication cable is in place, and the red icon is still there; close the ‘View’ window and open it again. ∑ The Clock. Check and see if the clock is counting. The program updates the clock on 5sec intervals. If the time of the clock is out, you can update it as following: Click the ‘Select Command’ button. Select and click ‘Synchronize Real Time Clock’ and the clock will be synchronize to your computer’ s time. ∑ Inputs. If you have a switch to test the inputs, you can toggle your input switches to see if they appear next to the input text, under the clock. ∑ Device Information. Device. Check your ‘Firmware’ version. Modem. Check that all the information is there from the Radio Link V410, especially the ‘Sim’ number. If the is some information missing, wait for it; as it my happen that you don’ t get all the modem information at the same time. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 5 of 18 Network. Check for the ‘Operator’ and ‘Signal Level’ information. If these are not available, please wait for them until received. The ‘Operator’ is your service provider MTN, VodaCom...etc. The ‘Signal Level’ shows the signal strength of the module. You can also see the signal strength on the signal-barometer, which is above the ‘Close’ button on the far right of the ‘View’ window. The smaller the number behind the minus(-), the stronger the signal. An acceptable signal strength is along the green part of the signal-barometer. If the signal is less than the green portion of the signal-barometer, check if the antenna is correctly connected. The signal strength may also depend on the geographical location of the Radio Link V410 in the unit. The ‘Base Station’ and the ‘Serving area’ are not critical to have. They are there for information purposes; to find out what is the closest network tower that the Radio Link V410 is using to send sms’ s. This information is dependant on your service provider to transmit. When you have checked all this information, you can close this window by clicking the ‘Close’ button on the bottom right-hand corner of the ‘View’ window. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 6 of 18 2. Adding or Changing Terminals. Terminals are the Radio Link V410s on the database. To view the Terminals, click the ‘Terminals’ button. The ‘Terminals’ window will open. This window contains the information of the Radio Link V410s that are already in the database. To see if you Radio Link V410 is in the database; just type the IMEI number which is on the modem and it will appear next to ‘Locate:’ above the ‘Close’ button as you type. The database will try to match it with the Radio Link V410s that are in the database. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 7 of 18 If the Radio Link V410 is not found in the database, you will have to insert is in the database. ∑ Inserting a New Radio Link V410 Click the ‘Insert’ button. A window will open. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 8 of 18 Click the ‘Read’ button to information from the Radio Link V410. A warning box appears. Click ‘Yes’ . A question box appears. Click ‘Yes’ . The information from the Radio Link V410 will be displayed. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 9 of 18 Click the ‘Load’ button. This loads the pre-set configuration values / information. A warning box appears. Click ‘Yes’ , and the defaults will be loaded. Click the ‘Write’ button. This allows you to send what you have on the screen to the Radio Link V410. A warning box appears. Click ‘Yes’ . A question box appears. Click ‘Yes’ . DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 10 of 18 An information box appears. Click ‘Ok’ . To save the information, click the ‘Save’ button next to the ‘Cancel’ button on the bottom right-hand corner of the window. After that ‘Save’ button is clicked, you will see the ‘Termina…

Text truncated - open the document above for the full version.

Radio Link V410 Operation Manual 0168 DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 2 of 18 I N D E X 1 VIEWING THE RADIO LINK V410............................................................................................................................... 3 2 ADDING OR CHANGING TERMINALS ...................................................................................................................... 6 3 PRINTING RADIO LINK V410 TEST REPORT ........................................................................................................ 15 4 GENERAL INFORMATION & DISCLAMERS.......................................................................................................... 17 5 CONTACT INFORMATION ......................................................................................................................................... 18 0168 DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 3 of 18 Radio Link V410 Testing or Updating: 1. Viewing the Radio Link V410. Open the Radio Link V410 testing program and click the ‘View’ button. The ‘View’ window will open so that you can able to see the status of the Radio Link V410 you are testing or updating. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 4 of 18 There are things that you have to observe in the view window that will show whether your Radio Link V410 is healthy or not. ∑ Communication Icon. This icon shows whether there is healthy communication between you Radio Link V410 and your computer. If there is a green icon with a tick mark , the communication is healthy. If the is a red icon with an X mark , the communication has failed. Check if the Radio Link V410 has power, and that the Radio Link V410 is connected to the computer. If there is power and the communication cable is in place, and the red icon is still there; close the ‘View’ window and open it again. ∑ The Clock. Check and see if the clock is counting. The program updates the clock on 5sec intervals. If the time of the clock is out, you can update it as following: Click the ‘Select Command’ button. Select and click ‘Synchronize Real Time Clock’ and the clock will be synchronize to your computer’ s time. ∑ Inputs. If you have a switch to test the inputs, you can toggle your input switches to see if they appear next to the input text, under the clock. ∑ Device Information. Device. Check your ‘Firmware’ version. Modem. Check that all the information is there from the Radio Link V410, especially the ‘Sim’ number. If the is some information missing, wait for it; as it my happen that you don’ t get all the modem information at the same time. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 5 of 18 Network. Check for the ‘Operator’ and ‘Signal Level’ information. If these are not available, please wait for them until received. The ‘Operator’ is your service provider MTN, VodaCom...etc. The ‘Signal Level’ shows the signal strength of the module. You can also see the signal strength on the signal-barometer, which is above the ‘Close’ button on the far right of the ‘View’ window. The smaller the number behind the minus(-), the stronger the signal. An acceptable signal strength is along the green part of the signal-barometer. If the signal is less than the green portion of the signal-barometer, check if the antenna is correctly connected. The signal strength may also depend on the geographical location of the Radio Link V410 in the unit. The ‘Base Station’ and the ‘Serving area’ are not critical to have. They are there for information purposes; to find out what is the closest network tower that the Radio Link V410 is using to send sms’ s. This information is dependant on your service provider to transmit. When you have checked all this information, you can close this window by clicking the ‘Close’ button on the bottom right-hand corner of the ‘View’ window. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 6 of 18 2. Adding or Changing Terminals. Terminals are the Radio Link V410s on the database. To view the Terminals, click the ‘Terminals’ button. The ‘Terminals’ window will open. This window contains the information of the Radio Link V410s that are already in the database. To see if you Radio Link V410 is in the database; just type the IMEI number which is on the modem and it will appear next to ‘Locate:’ above the ‘Close’ button as you type. The database will try to match it with the Radio Link V410s that are in the database. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 7 of 18 If the Radio Link V410 is not found in the database, you will have to insert is in the database. ∑ Inserting a New Radio Link V410 Click the ‘Insert’ button. A window will open. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 8 of 18 Click the ‘Read’ button to information from the Radio Link V410. A warning box appears. Click ‘Yes’ . A question box appears. Click ‘Yes’ . The information from the Radio Link V410 will be displayed. DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 9 of 18 Click the ‘Load’ button. This loads the pre-set configuration values / information. A warning box appears. Click ‘Yes’ , and the defaults will be loaded. Click the ‘Write’ button. This allows you to send what you have on the screen to the Radio Link V410. A warning box appears. Click ‘Yes’ . A question box appears. Click ‘Yes’ . DOC. NO. ISSUE TITLE YYYY /MM /DD CS0035 01 Operation Manual 2007/03/13 Radio Link V410 Page 10 of 18 An information box appears. Click ‘Ok’ . To save the information, click the ‘Save’ button next to the ‘Cancel’ button on the bottom right-hand corner of the window. After that ‘Save’ button is clicked, you will see the ‘Termina…

Text truncated - open the document above for the full version.

Declaration letter We, Umndeni Circon (Pty) Ltd. Main Reef Road, Boksburg North, 1459, South Africa Declares under our sole responsibility the our product: Type of equipment: GSM/GPRS fleet management system Brand name: Circon Model name: Radio Link V410 FCC ID: VDPRLV410JN2122 Integrates withouth any modification and following the manufacturer instructions the following product: Grantee name: Telit Communications S.p.A. Model: GE863-QUAD FCC ID: R17GE863L Signed on behalf of Umndeni Circon (Pty) Ltd. by: Name: Pieter Erasmus P.A. Date: August 8 th , 2007 Place: Boksburg North, South Africa Signature

attn: Reviewing Engineer MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR D301 (FCC ID: VDPRLV410JN2122) To Whom It May Concern: Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, Umndeni Circon (Pty) Ltd. requests confidentiality for the following products: FCC ID Model VDPRLV410JN2122 RADIO LINK V410 For the product stated above, we request that the following information be held confidential: 1) Circuit diagrams 2) Block Diagrams 3) Bill of materials 4) Operational Description 5) Power tune-up procedure No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Umndeni Circon (Pty) Ltd. trade secrets and proprietary information that could be of benefit to our competitors. This material is not customarily available to the general public and we request that it be withheld from public inspection. Please contact me if there is any information you may need. Sincerely, P.A. Name/Title: Mr. Pieter Erasmus / Circon Systems’ Manager Company name: Umndeni Circon (Pty) Ltd. Telephone: +2711 8980240 E-mail Address: [email protected]

Attn: Reviewing Engineer MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: 15.19 Statement (FCC ID: VDPRLV410JN2122) TO WHOM IT MAY CONCERN The statement: "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation” Is not placed in the label of the equipment due to the following reasons: - Type label is too small (No room for this writing). - Required text is already included in the user guide This statement is placed in a prominent location in the instruction manual. Please contact me if there is any information you may need. If you have any questions, please feel free to contact me at the address shown below. Sincerely, P.A. Name/Title: Mr. Pieter Erasmus / Circon Systems’ Manager Company name: Umndeni Circon (Pty) Ltd. Telephone: +2711 8980240 E-mail Address: [email protected]

Declaration letter We, Umndeni Circon (Pty) Ltd. Main Reef Road, Boksburg North, 1459, South Africa Declares under our sole responsibility the our product: Type of equipment: GSM/GPRS fleet management system Brand name: Circon Model name: Radio Link V410 FCC ID: VDPRLV410JN2122 Integrates withouth any modification and following the manufacturer instructions the following product: Grantee name: Telit Communications S.p.A. Model: GE863-QUAD FCC ID: R17GE863L Signed on behalf of Umndeni Circon (Pty) Ltd. by: Name: Pieter Erasmus P.A. Date: August 8 th , 2007 Place: Boksburg North, South Africa Signature

attn: Reviewing Engineer MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR D301 (FCC ID: VDPRLV410JN2122) To Whom It May Concern: Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, Umndeni Circon (Pty) Ltd. requests confidentiality for the following products: FCC ID Model VDPRLV410JN2122 RADIO LINK V410 For the product stated above, we request that the following information be held confidential: 1) Circuit diagrams 2) Block Diagrams 3) Bill of materials 4) Operational Description 5) Power tune-up procedure No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Umndeni Circon (Pty) Ltd. trade secrets and proprietary information that could be of benefit to our competitors. This material is not customarily available to the general public and we request that it be withheld from public inspection. Please contact me if there is any information you may need. Sincerely, P.A. Name/Title: Mr. Pieter Erasmus / Circon Systems’ Manager Company name: Umndeni Circon (Pty) Ltd. Telephone: +2711 8980240 E-mail Address: [email protected]

Radio Link V410 6-30 V , 300-60 mA 0168 FCC ID: VDPRLV410JN2122 Made in R.S.A. by Umndeni Circon IMEI : 358485000376054

Radio Link V410 6-30 V , 300-60 mA 0168 FCC ID: VDPRLV410JN2122 Made in R.S.A. by Umndeni Circon IMEI : 358485000376054

914 West Patapsco Avenue Baltimore, MD 21230 United States of America Attention: Reviewing Engineer RE: RF exposure information for the equipment Radio Link V410 (FCC ID: VDPRLV410JN2122) RF exposure information The device Radio Link V410 (FCC ID: VDPRLV410JN2122) is designed as module to be installed in a car. This device is to be used only for fixed and mobile applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter. The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: The equipment GE863-QUAD transmits in the following frequency ranges so that the applicable limits are: Frequency range Limit 1850.2 - 1909.8 MHz 1 mW/cm 2 824.2 - 848.8 MHz 0.54 mW/cm 2 The equipment is a GPRS Class 10, so that the maximum duty cicle is 2/8 = 1/4 Under conditions stated above MPE limits can be guaranteed as the calculation below shows: 850 MHz frequency band Maximum output power: 0.554 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.554 W x 1/4 = 0.1385 W = 138.5 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 138.5 mW / 4·pi·(20 cm) 2 = 0.0276 mW/cm 2 < 0.54 mW/cm 2 (limit) MET Labs 1900 MHz frequency band Maximum output power: 0.033 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.033 W x 1/4 = 0.00825 W = 8.25 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 8.25 mW / 4·pi·(20 cm) 2 = 0.00164 mW/cm 2 < 1 mW/cm 2 (limit) These predictions demonstrate that: The power density levels at a distance of 20 cm are below the maximum levels allowed by the FCC rules. Conclusion: The equipment Radio Link V410 complies with the MPE limits if used with the provided antenna and this antenna is installed to provide a separation distance of at least 20 cm from all the persons. Warning: To ensure the compliance with the MPE limits the antenna gain has been limited and a warning statement has been included in page 17. Signed on behalf of Umndeni Circon (Pty) Ltd. by P.A. Pieter Erasmus Circon Systems' Manager Umndeni Circon (Pty) Ltd. 136 Main Reef Road, Boksburg North, 1459, South Africa Phone: +27 11 898 0240 E-mail: [email protected] Date: 2007-08-09

914 West Patapsco Avenue Baltimore, MD 21230 United States of America Attention: Reviewing Engineer RE: RF exposure information for the equipment Radio Link V410 (FCC ID: VDPRLV410JN2122) RF exposure information The device Radio Link V410 (FCC ID: VDPRLV410JN2122) is designed as module to be installed in a car. This device is to be used only for fixed and mobile applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter. The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: The equipment GE863-QUAD transmits in the following frequency ranges so that the applicable limits are: Frequency range Limit 1850.2 - 1909.8 MHz 1 mW/cm 2 824.2 - 848.8 MHz 0.54 mW/cm 2 The equipment is a GPRS Class 10, so that the maximum duty cicle is 2/8 = 1/4 Under conditions stated above MPE limits can be guaranteed as the calculation below shows: 850 MHz frequency band Maximum output power: 0.554 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.554 W x 1/4 = 0.1385 W = 138.5 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 138.5 mW / 4·pi·(20 cm) 2 = 0.0276 mW/cm 2 < 0.54 mW/cm 2 (limit) MET Labs 1900 MHz frequency band Maximum output power: 0.033 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.033 W x 1/4 = 0.00825 W = 8.25 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 8.25 mW / 4·pi·(20 cm) 2 = 0.00164 mW/cm 2 < 1 mW/cm 2 (limit) These predictions demonstrate that: The power density levels at a distance of 20 cm are below the maximum levels allowed by the FCC rules. Conclusion: The equipment Radio Link V410 complies with the MPE limits if used with the provided antenna and this antenna is installed to provide a separation distance of at least 20 cm from all the persons. Warning: To ensure the compliance with the MPE limits the antenna gain has been limited and a warning statement has been included in page 17. Signed on behalf of Umndeni Circon (Pty) Ltd. by P.A. Pieter Erasmus Circon Systems' Manager Umndeni Circon (Pty) Ltd. 136 Main Reef Road, Boksburg North, 1459, South Africa Phone: +27 11 898 0240 E-mail: [email protected] Date: 2007-08-09

914 West Patapsco Avenue Baltimore, MD 21230 United States of America Attention: Reviewing Engineer RE: RF exposure information for the equipment Radio Link V410 (FCC ID: VDPRLV410JN2122) RF exposure information The device Radio Link V410 (FCC ID: VDPRLV410JN2122) is designed as module to be installed in a car. This device is to be used only for fixed and mobile applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter. The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: The equipment GE863-QUAD transmits in the following frequency ranges so that the applicable limits are: Frequency range Limit 1850.2 - 1909.8 MHz 1 mW/cm 2 824.2 - 848.8 MHz 0.54 mW/cm 2 The equipment is a GPRS Class 10, so that the maximum duty cicle is 2/8 = 1/4 Under conditions stated above MPE limits can be guaranteed as the calculation below shows: 850 MHz frequency band Maximum output power: 0.554 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.554 W x 1/4 = 0.1385 W = 138.5 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 138.5 mW / 4·pi·(20 cm) 2 = 0.0276 mW/cm 2 < 0.54 mW/cm 2 (limit) MET Labs 1900 MHz frequency band Maximum output power: 0.033 W Duty cicle: 1/4 Equivalent output power = Maximum output power x Duty cicle = 0.033 W x 1/4 = 0.00825 W = 8.25 mW Using the equation: S = P·G/4·pi·R 2 Where, S = power density in mW/cm 2 P = power input to the antenna in mW G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna in cm (20 cm Prediction distance) S = 8.25 mW / 4·pi·(20 cm) 2 = 0.00164 mW/cm 2 < 1 mW/cm 2 (limit) These predictions demonstrate that: The power density levels at a distance of 20 cm are below the maximum levels allowed by the FCC rules. Conclusion: The equipment Radio Link V410 complies with the MPE limits if used with the provided antenna and this antenna is installed to provide a separation distance of at least 20 cm from all the persons. Warning: To ensure the compliance with the MPE limits the antenna gain has been limited and a warning statement has been included in page 17. Signed on behalf of Umndeni Circon (Pty) Ltd. by P.A. Pieter Erasmus Circon Systems' Manager Umndeni Circon (Pty) Ltd. 136 Main Reef Road, Boksburg North, 1459, South Africa Phone: +27 11 898 0240 E-mail: [email protected] Date: 2007-08-09

Report No.: 26213RET Date: 2007-09-14 Page: 2 of 7 FDT08_04 INDEX 1. COMPETENCE AND GUARANTEES..........................................................................................3 2. GENERAL CONDITIONS..............................................................................................................3 3. CHARACTERISTICS OF THE TEST............................................................................................3 3.1 TEST REQUESTED.................................................................................................................3 3.2 REQUIREMENTS AND METHOD........................................................................................3 4. IDENTIFICATION DATA SUPPLIED BY THE APPLICANT.....................................................4 4.1 APPLICANT.............................................................................................................................4 4.2 REPRESENTATIVE................................................................................................................4 4.3 TEST SAMPLES SUPPLIER...................................................................................................5 4.4 IDENTIFICATION OF ITEM/ITEMS TESTED.....................................................................5 5. USAGE OF SAMPLES, PERIOD OF TESTING AND ENVIRONMENTAL CONDITIONS.....5 5.1 USAGE OF SAMPLES............................................................................................................5 5.2 PERIOD OF TESTING............................................................................................................5 5.3 ENVIROMENTAL CONDITIONS..........................................................................................6 6. TEST RESULTS..............................................................................................................................7 7. REMARKS AND COMMENTS......................................................................................................7 8. SUMMARY......................................................................................................................................7 ANNEXES ANNEX A. TEST RESULTS FOR FCC PART 22 ANNEX B. TEST RESULTS FOR FCC PART 24 ANNEX C. PHOTOGRAPHS Report No.: 26213RET Date: 2007-09-14 Page: 3 of 7 FDT08_04 1. COMPETENCE AND GUARANTEES Centro de Tecnología de las Comunicaciones (AT4 WIRELESS), S.A. is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjunction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 905266. In order to assure the traceability to other national and international laboratories, AT4 WIRELESS has a calibration and maintenance programme for its measuring equipment. AT4 WIRELESS guarantees the reliability of the data presented in this report, which is the result of measurements and tests performed to the item under test on the date and under the conditions stated on the report and is based on the knowledge and technical facilities available at AT4 WIRELESS at the time of execution of the test. AT4 WIRELESS is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the item under test and the results of the test. 2. GENERAL CONDITIONS 1. This report only refers to the item that has undergone the test. 2. This report does not constitute or imply by its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without written approval of AT4 WIRELESS. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of AT4 WIRELESS and the Accreditation Bodies. 3. CHARACTERISTICS OF THE TEST 3.1 TEST REQUESTED 1. Measurements for PCS 850 and PCS 1900 devices according to FCC parts 22 and 24: -Radiated RF output power. -Radi…

Text truncated - open the document above for the full version.
