VL4-MAX-2X36WFLUORESCENT ELECTRONIC BALLAST

东莞市隆迪电子科技有限公司 Dongguan Hopestar Electronic Co., Ltd. Electronic ballast instruction manual Warning To avoid the risk of electric shock,do not disassemble or refit this ballast. Please consult a qualified electrician for installation and wiring. Do not install on the tinder surface. Do not expose to rain or water logging. Please use the designated type lamps,otherwise the product will be damaged completely. Make sure the power is off before installing or maintenance this ballast. Installation Shut off the power supply. Prepare the necessary tool and material(such as:wire cutters,screwdriver, insulating tape) According to the product’s power and type lampes to prepare lamps. According to the product’s dimension and mounting loles to detemine the correct installation place. According to the wiring instruction of product label turn on power. Check and make sure the wiring is correct before turn on power. Operation＆maintenance Power on and off control by the wall switch, turn power on to let ballast operate. In order to prolong lamp’s life ,not to turn power on and off again and angain in a short time. The lamp is wearing parts, it needs periodic replacement, make sure the power is off before replacing The lamp. The product has protection function for lamp abnormity(end of life, diop out or break). Replace it when the lamp becomes flicker or darkening. This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference, and(2) this device must accept any interfere received, including interference that may cause undesired operation. FCC NOTE The manufacture is not responsible for any radio or TV interference caused by unauthorized Modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45—30 MHz.

东莞市隆迪电子科技有限公司 Dongguan Hopestar Electronic Co., Ltd. Electronic Ballast Block Diagram 120VAC Input AC/DC transfer Circuit Transfer circuit 40kHz Booster circuit To La mp Protection circuit for lamp abnormity

EUT-Front View for LEB-204~213 EUT-Back View for LEB-204~213 EUT-Front View for LEB-214~218 EUT-Back View for LEB-214~218 EUT-Front View for LEB-219~236 EUT-Back View for LEB-219~236

FCC ID Label Sample for Model LEB-204~213, LEB-214~218, LEB-219~236 FCC ID: VL4-MAX-2X36W

FCC ID Label This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed Label Location on EUT EUT Top View/ proposed FCC Mark Location FCC ID: VL4-MAX-2X36W This device complies with Part 18 of the FCC Rules.

PCB-Front View for LEB-204~213 PCB-Back View for LEB-204~213 PCB-Front View for LEB-214~218 PCB-Back View for LEB-214~218 PCB-Front View for LEB-219~236 PCB-Back View for LEB-219~236

东莞市隆迪电子科技有限公司 Dongguan Hopestar Electronic Co., Ltd. Electronic ballast operating principle This series of electronic ballast has three models LEB-204~213,LEB-214~218, LEB-219~236, Power 2*13W, 2*18W, 2*36W. The circuit of the unit comprises AC/DC transfer circuit, transfer circuit, booster circuit and Protection circuit for lamp abnormity. AC/DC transfer circuit: It comprises D1-D4 and CD1 CD2, the C1-C3, CY1, CY2, L1, L2 remove high frequency noise and interferences which were from network supply and this ballst. In the AC/DC transfer circuit a 120VAC input is rectified by the diode D1 D2 C14 C15 to a DC voltage. Transfer circuit: It comprises T1 T2 L5 L6 C6 C7 and Tr,it converts the DC voltage into a high frequency AC voltage. Booster circuit: It comprises L3 L4 and C11 C12 , it boosts the high frequency AC voltage high enough to start the lamp, it stabilities the lamp current when the lamp is operating. Protection circuit for lamp abnormity: It comprises D11 D12 D9 SCR DB3-1 CD3 and T3, it supplies signal for transfer cricuit stop working when the lamp become abnormity (end of life, dropout or break).

东莞市隆迪电子科技有限公司 Dongguan Hopestar Electronic Co., Ltd. Circuit diagram R2 C2 C3 C8 C9 D1 D8 D2 D4 D3 D7 D10 D5 CD 1 Tr-n3 Tr-n1 Tr-n2 T1 T2 DB3 D6 L4 SCR DB3-1 CD3 T3 D11 R6 R3 R8 R1 1 R6 L N Input 120Vac FS C1 2 L2 CD2 C4 C5 C6 C7 R1 R5 L5 L6 D9 L1 C1 CY2 CY1 R4 C1 1 L3 D12 R7 R9 C1 0 Model: LEB-204~213 LEB-214~218 LEB-219~236

FCC TEST REPORT Page 1 of 25 FCC ID : VL4-MAX-2X36W Applicant : DONGGUAN HOPESTAR ELECTRONIC CO., LTD. SANJIANG INDUSTRIAL PARK HENGLI TOWN DONGGUAN GUANGDONG 523000 CHINA Equipment Under Test (EUT) : Product description : FLUORESCENT ELECTRONIC BALLAST Model No. : LEB-204~213, LEB-214~218, LEB-219~236 Standards : FCC Part 18 Date of Test : Sep.3, 2007 Test Engineer : Tiger Su Reviewed By : PERPARED BY: Waltek Services (Shenzhen) Co., Ltd. 8C,West Tower, Aidi Building, No.5003 Binhe Rd, Futian District, Shenzhen518045, Guangdong, China. Tel: 86-755-83551033 Fax: 86-755-83552400 DONGGUAN HOPESTAR ELECTRONIC CO., LTD. FCC ID: VL4-MAX-2X36W Page 2 of 25 2 Contents Page 1 COVER PAGE..........................................................................................................................................................1 2 CONTENTS ..............................................................................................................................................................2 3 TEST SUMMARY....................................................................................................................................................3 4 GENERAL INFORMATION..................................................................................................................................4 4.1 CLIENT INFORMATION............................................................................................................................................4 4.2 GENERAL DESCRIPTION OF E.U.T...........................................................................................................................4 4.3 DETAILS OF E.U.T. .................................................................................................................................................4 4.4 DESCRIPTION OF SUPPORT UNITS...........................................................................................................................4 4.5 STANDARDS APPLICABLE FOR TESTING..................................................................................................................4 4.6 TEST METHODOLOGY.............................................................................................................................................4 4.7 TEST FACILITY........................................................................................................................................................5 4.8 TEST LOCATION......................................................................................................................................................5 5 EQUIPMENT USED DURING TEST ...................................................................................................................6 6 CONDUCTED EMISSION TEST ..........................................................................................................................7 6.1 TEST EQUIPMENT....................................................................................................................................................7 6.2 TEST PROCEDURE...................................................................................................................................................7 6.3 CONDUCTED TEST SETUP.......................................................................................................................................8 6.4 EUT OPERATING CONDITION.................................................................................................................................8 6.5 CONDUCTED EMISSION LIMITS...............................................................................................................................9 6.6 SPECTRUM ANALYZER............................................................................................................................................9 6.7 FREQUENCY RANGE OF MEASUREMENTS.............................................................................................................10 6.8 CONDUCTED EMISSION TEST RESULT...................................................................................................................10 6.8.1 Measurement Data .....................................................................................................................................10 7 PHOTOGRAPHS OF TESTING..........................................................................................................................17 7.1 CONDUCTED EMISSION TEST VIEW FOR LEB-213 ................................................................................................17 7.2 CONDUCTED EMISSION TEST VIEW FOR LEB-218 ................................................................................................17 7.3 CONDUCTED EMISSION TEST VIEW FOR LEB-228 ................................................................................................18 8 PHOTOGRAPHS-CONSTRUCTIONAL DETAILS .........................................................................................19 8.1 EUT-FRONT VIEW FOR LEB-213 .........................................................................................................................19 8.2 EUT-BACK VIEW FOR LEB-213...........................................................................................................................19 8.3 EUT-FRONT VIEW FOR LEB-218 .........................................................................................................................20 8.4 EUT-BACK VIEW FOR LEB-218...........................................................................................................................20 8.5 EUT-FRONT VIEW FOR LEB-228 .........................................................................................................................21 8.6 EUT-BACK VIEW FOR LEB-228...........................................................................................................................2…

Text truncated - open the document above for the full version.

Conducted Emission Test View for LEB-204~213 Conducted Emission Test View for LEB-214~218 Conducted Emission Test View for LEB-219~236
