VLE15035-PPLToy Helicopter
Asian Express Holdings Limited
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Jul 05, 2012
- Application Purpose
- Original Equipment
- Date of Application
- Jul 05, 2012
- Equipment Note
- Toy Helicopter
- Frequency Range
- 2402.00000000 - 2480.00000000
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
USER MANUAL THIS PACKAGE CONTAINS: Colors and styles may slightly vary. WARNING: ATOM I TM is an indoor Bluetooth ® controlled helicopter. Your ATOM I TM helicopter is not suited to handle wind or other outdoor environmental conditions. Attempting to fly this helicopter outdoors may lead to severe damage. Made in China Conforms to safety requirements of ASTM, CPSIA and FCC. BATTERY WARNINGS RECHARGEABLE BATTERY: This helicopter uses an internal Li-Poly rechargeable battery and is not replaceable. If battery no longer stays charged, dispose of it properly according to local disposal requirements. CARE AND MAINTENANCE • Always remove the batteries from the wireless infrared remote control when it is not being used for an extended period of time. • To clean, gently wipe the remote control and helicopter with a clean damp cloth. • Keep the toy away from direct heat or sunlight. • Do not submerge the toy into water. This can damage the unit beyond repair. • Parental guidance recommended when installing or replacing the batteries. FCC Part 15 B Notice CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CHOKING HAZARD - Small parts. Not suitable for children under 3 years. Spare Parts USB Charging Cable PROPEL RC™ and ATOM I™ are trademarks of Rooftop Brands. ©2012 Rooftop Brands™ All rights reserved Tel: + (1) 949-566-9573 • www.rooftopbrands.com 3-CHANNEL HELICOPTER WITH GYRO STABILIZATION Helicopter Instruction Manual 13 1 TABLE OF CONTENTS Features.......................................................................................... 1 COMPATIBLE Bluetooth® DEVICES................................................................. 1 Charging The Helicopter........................................................................... 2 Propel Atom I App Installation................................................................... 2 Pairing Bluetooth® Devices....................................................................... 2 Helicopter Diagram ............................................................................... 3 Preparing For Flight .............................................................................. 3 Getting Started................................................................................... 3 Manual Control Diagram .......................................................................... 4 Motion Control Diagram .......................................................................... 4 Using Manual Controls............................................................................ 5 Using Motion Controls............................................................................. 6 Understanding Helicopter Trim Adjustments...................................................... 7 Agility Options.....................................................................................7 Flying Tips..........................................................................................8 Troubleshooting.................................................................................8 Helicopter Warning And Safety Precautions........................................................9 Part Replacement Instructions.................................................................. 10 Contents.........................................................................................10 Atom I Propeller System..........................................................................10 Replacing Connecting Rod ....................................................................... 10 Replacing The Upper Propeller Blade .............................................................11 Replacing The Bottom Propeller Blade............................................................11 Battery Warnings.............................................................................. 13 Care and Maintenance...........................................................................13 FCC Information................................................................................. 13 FEATURES • Bluetooth® controlled helicopter works with iPhone® and Android TM operating systems • Free app download from Apple® and Android TM app stores • Uses both manual and gesture control • Built-in gyroscopic chip for extreme stability and control • Rechargeable Li-poly battery included • 7-way control: fly up, down, left, right, forward, backwards and hover • Multicolored blinking LEDs can be turned on/off remotely CHARGING THE HELICOPTER 1. Make sure the helicopter power sw…
Text truncated - open the document above for the full version.
Cover Letter(s)
Date: 06.14.2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: VLE15035-PPL Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name： Company name: Asian Express Holdings Limited Tel.：0755-85235694-609 Fax：0755-85235743
Cover Letter(s)
AGENCY AUTHORIZATION LETTER FCC ID: VLE15035-PPL Date: 06.14.2012 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Shenzhen Co. Ltd Dongguan Branch., to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BVDG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name： Company name: Asian Express Holdings Limited Tel.：0755-85235694-609 Fax：0755-85235743
External Photos
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 2 Report Version 1 Reference No.: 120528N017 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 2 Report Version 1 Reference No.: 120528N017
Internal Photos
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 2 Report Version 1 Reference No.: 120528N017 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 2 Report Version 1 Reference No.: 120528N017 ANT
Test Report
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 on 27 Report Version 1 Test Report No.:FC120528N017 TEST REPORT Applicant: Asian Express Holdings Ltd. Address: 4F,-4,No.669 Jingping Rd., Zhonghe City, Taipei Country 235,Tainwan R.O.C. Manufacturer or Supplier Asian Express Holdings Ltd. Address 4F,-4,No.669 Jingping Rd., Zhonghe City, Taipei Country 235,Tainwan R.O.C. Product: Atoml Brand Name: N/A Model: 15035-PPL-B-ASM Additional Model & Model Difference N/A Date of tests: May 29 ~ June 14, 2012 the tests have been carried out according to the requirements of the following standards: FCC Part 15, Subpart C (Section 15.249) CONCLUSION: The submitted sample was found to COMPLY with the test requirement Prepared by Glyn He Project Engineer / EMC Department Approved by Sam Tung Manager / EMC Department Date: June 14, 2012 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 on 27 Report Version 1 Test Report No.:FC120528N017 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 3 1 SUMMARY OF TEST RESULTS.................................................................................................... 4 2 MEASUREMENT UNCERTAINTY................................................................................................. 4 3 GENERAL INFORMATION ............................................................................................................5 3.1 GENERAL DESCRIPTION OF EUT ........................................................................................... 5 3.2 DESCRIPTION OF TEST MODES ............................................................................................. 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................ 7 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................... 7 4. TEST TYPES AND RESULTS........................................................................................................ 8 4.1 RADIATED EMISSION MEASUREMENT .................................................................................. 8 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................................... 8 4.2.2 TEST INSTRUMENTS....................................................................................................... 9 4.2.3 TEST PROCEDURES ..................................................................................................... 10 4.2.4 DEVIATION FROM TEST STANDARD ........................................................................... 10 4.2.5 TEST SETUP....................................................................................................................11 4.2.6 EUT OPERATING CONDITIONS .....................................................................................11 4.2.7 TEST RESULTS .............................................................................................................. 12 4.2 20dB BANDWIDTH MEASUREMENT...................................................................................... 17 4.3.1 LIMITS OF 20dB BANDWIDTH MEASUREMENT.......................................................... 17 4.3.2 TEST INSTRUMENTS..................................................................................................... 17 4.3.3 TEST PROCEDURE........................................................................................................ 18 4.3.4 DEVIATION FROM TEST STANDARD ........................................................................... 18 4.3.5 TEST SETUP................................................................................................................... 19 4.3.6 EUT OPERATING CONDITIONS .................................................................................... 19 4.3.7 TEST RESULTS .............................................................................................................. 20 5 PHOTOGRAPHS OF THE TEST CONFIGURATION .................................................................. 26 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB .................................................................................................................................. …
Text truncated - open the document above for the full version.
Test Setup Photos
1 Set-up for radiated emission test <Frequency Range 30MHz~1GHz> <Frequency Range above1GHz>
Contact Information
Applicant
Nancy Chen(QA Manager)
Test Firm
Bureau Veritas Shenzhen Co., Ltd. Dongguan BranchAlec Hu
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |
