VLE2930-TController of Atom 1 Micro Drone

Propel Atom-1.0 Mini Drone Trim size 4.5 x 6.875 in. Spread size 9 x 6.875 in. AB C1C2D Arrow Mark Front Rotor Blades (Light Gray) Rear Rotar Blades (Black) Charging Socket Charging Socket On/Off Switch Atom 1.0™ QUADCOPTER DIAGRAM Atom 1.0™ REMOTE DIAGRAM Landing Gear Forward TrimBackward Trim Throttle ControlDirection Control Power Indicator Light Power On/Off SwitchLeft TrimRight Trim RECOGNIZING THE FRONT & BACK OF THE Atom 1.0™ Even though the Atom 1.0™ has four rotors there is still a front or "forward" facing direction and "back" or backwards facing direction. The forward Front and forward facing direction of the Atom 1.0™ is the side with two gray propellers (see diagram E ). The rear and back of the Quadrocopter is the side with two black propellers (see diagram E). NOTE: The front of the Quadrocopter displays RED LED lights and the back of the Quadrocopter displays BLUE LED lights. E F G H I J K L FRONT REAR M Q N O P FRONT REAR Diagram S Switch On Push Down Made in China Conforms to safety requirements of ASTM, CPSIA and FCC. ©2015 Rooftop Brands™ All rights reserved Tel: + (1) 949-566-9573 • www.propelrc.com FCC Part 15 B Notice CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CHOKING HAZARD - Small parts. Not suitable for children under 3 years. WARNING! 12 34 56 78 910 WARNING: Never leave product charging unattended for extended periods of time. Always disconnect HD Sonic Drone from charger immediately after the HD Sonic Drone is fully charged. Please refer to enclosed safety instructions. INSTRUCTION BOOKLET Colors and styles may slightly vary. PACKAGE CONTAINS: 2.4G Wireless ControllerInstruction ManualSpare PartsUSB charging cordHD Sonic Drone Atom 1.0™ DRONE 2.4GHz Quadrocopter TABLE OF CONTENTS Product Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Remote Control Battery Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Charging Your Atom 1.0™ Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Atom 1.0™ Quadcopter Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Remote Control Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Flight Preperation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Synching Your Atom 1.0™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Flying Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Recognizing The Front & Back Of The Atom 1.0™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 4 Channel Flight Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Understanding Trim Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Level Surface Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Low Battery Warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Switching The Flight Lever To The Left Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Switching To High Speed Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Performing A 360º Stunt Roll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Casting Off From Your Palm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Replacing The Propeller Blades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Battery Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Care and Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

External Photo

30 mm 2.4 mm

Internal Photo

TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 32 Mr. WONG Lap-pong, Andrew Manager Electrical Division FCC ID: VLE2930-T IC: 10819B-2930T Application No. : LT015146(6) Applicant : Asian Express Holdings Limited 4F,-4, No.669 Jingping Rd., Zhonghe City, TaiPei county 235 Taiwan R.O.C, Taiwan Client : Asian Express Holdings Limited Rm804 Sino Centre,582-592 Nathan Road, Mongkok, Kowloon, Hong Kong. Sample Description : One(1) item of submitted sample stated to be Sample Description Model No. ATOM 1 Micro Done PL-1390 / PL-1391 / PL-1392 / PL-1393 / PL-1394 / PL-1395 / PL-1396 / PL-1397 / PL-1398 / PL-1399 / AT-2930 / AT-2931 / AT-2932 / AT-2934 / AT-2935 / AT-2936 Sample registration No. : RT018334-002, RT023431-001 Radio Frequency : 2405MHz – 2475 MHz Transceiver Radio Frequency : 2 x 1.5V AAA size batteries No. of submitted sample : Six (6) set(s) Date Received : 15 Apr 2015, 14 May 2015 Test Period : 04 Apr 2015 to 29 May 2015. Test Requested : FCC Part 15 Certificate, Industry Canada Interference Causing Equipment Standard RSS-210 Test Method : 47 CFR Part 15 (10-1-12 Edition), ANSI C63.4 – 2009 Industry Canada RSS-Gen Issue 3 Test Engineer : Mr. LEUNG Shu-kan, Ken Test Result : See attached sheet(s) from page 2 to 32. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B and C and Industry Canada RSS-210 Issue 8. TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Page 2 of 32 FCC ID: VLE2930-T IC: 10819B-2930T Remark : All sixteen models are the same in circuitry and components; and therefore model PL-1390 was chosen to be the representative of the test sample. The difference between the tested model and the declared model(s) is/are the Model no. and Color TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Page 3 of 32 FCC ID: VLE2930-T IC: 10819B-2930T Table of Contents 1 General Information ................................................................................................................................... 4 1.1 General Description ............................................................................................................................ 4 1.2 Location of the test site ....................................................................................................................... 5 1.3 List of measuring equipment............................................................................................................... 6 1.4 Measurement Uncertainty ................................................................................................................... 7 2 Description of the radiated emission test ................................................................................................... 8 2.1 Test Procedure .................................................................................................................................... 8 2.2 Test Result .......................................................................................................................................... 9 2.3 Radiated Emission Measurement Data ............................................................................................. 10 3 Description of the Line-conducted Test ................................................................................................... 13 3.1 Test Procedure .................................................................................................................................. 13 3.2 Test Result ........................................................................................................................................ 13 3.3 Graph and Table of Conducted Emission Measurement Data .......................................................... 13 4 Photograph ............................................................................................................................................... 14 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................. 14 4.2 Photographs of the External and Internal Configurations of the EUT .............................................. 14 5 Supplementary document ......................................................................................................................... 15 5.1 Bandwidth ......................................................................................................................................... 15 6 Appendices ............................................................................................................................................... 16 TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Page 4 of 32 FCC ID: VLE2930-T IC: 10819B-2930T 1 General Information 1.1 General Description The equipment under test (EUT) is a controller for Atom 1 Micro Drone. The EUT is power by 2 x 1.5V AAA size batteries. It operates at 2405MHz – 2475MHz. There are buttons and two joysticks. When the buttons are pressed or joysticks are moved, there are radio signals transmitting to receiver. The brief circuit description is listed as follows: - U1 (RF) and its associated circuit act as 2.4GHz RF module - U1 (main) and its associated circuit act as MCU - X3 and its associated circuit act as oscillator - K1, K2, K3, K4, K5, K6, VR1, VR2, VR3, VR4 and its associated circuit act as copter control - U2, U3 and its associated circuit act as power regulator TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Page 5 of 32 FCC ID: VLE2930-T IC: 10819B-2930T 1.2 Location of the test site FCC Registered Test Site Number: 552221 Industry Canada Registered Test Site Number: 4093A Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at: Ground Floor, Yan Hing Centre…

Text truncated - open the document above for the full version.

TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 27 of 32 FCC ID: VLE2930-T IC: 10819B-2930T A5. Band Edge Lower edge (Peak measurement) Lower edge (Average measurement) TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 28 of 32 FCC ID: VLE2930-T IC: 10819B-2930T A5. Band Edge Higher edge (Peak measurement) Higher edge (Average measurement)

TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 29 of 32 FCC ID: VLE2930-T IC: 10819B-2930T A6. 20dB Bandwidth Plot Bandwidth 1 (2405MHz) Bandwidth 2 (2445MHz) TEST REPORT Report No. : AT0031840(5) Date : 29 May 2015 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 30 of 32 FCC ID: VLE2930-T IC: 10819B-2930T A6. 20dB Bandwidth Plot Bandwidth 3 (2475MHz)

Test Setup Photo Front view (30MHz – 1GHz) Rear view (30MHz – 1GHz) Front view (9kHz – 30MHz) Rear view (9kHz – 30MHz) Front view (1GHz – 25GHz) Rear view (1GHz – 25GHz)
