External Photo

Transmitter： Remark: We will print the FCC ID on the transmitter by Pad Printing.

Internal Photo

TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 25 Mr. WONG Lap-pong, Andrew Manager Electrical Division FCC ID: VLEPL1350 Application No. : LS032328(7) Applicant : Asian Express Holdings Limited 4F,-4, No.669 Jingping Rd., Zhonghe City, TaiPei county 235 Taiwan R.O.C, Taiwan Client : Asian Express Holdings Limited Rm804 Sino Centre,582-592 Nathan Road, Mongkok, Kowloon, Hong Kong. Sample Description : One(1) item of submitted sample stated to be Sample Description Model No. Proton Z PL-1350 / PL-1351 / PL-1352 / PL-1353 / PL-1354 / PL-1355 / PL-1356 / PL-1357 / PL-1358 / PL-1359 / HS-1938 Sample registration No. : RS036638-001 Radio Frequency : 2410MHz – 2470 MHz Transmitter Rating : 2 x 1.5V AAA size batteries No. of submitted sample : Two (2) piece (s) Date Received : 26 Aug 2014 Test Period : 01 Sep 2014 to 10 Sep 2014. Test Requested : FCC Part 15 Certificate Test Method : 47 CFR Part 15 (10-1-12 Edition), ANSI C63.4 – 2009 Test Engineer : Mr. LEUNG Shu-kan, Ken Test Result : See attached sheet(s) from page 2 to 25. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. Remark : All eleven models are the same in circuitry and components; and therefore model PL-1350 was chosen to be the representative of the test sample. The difference between the tested model and the declared model(s) is/are the Model no. TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Page 2 of 25 FCC ID: VLEPL1350 Table of Contents 1 General Information ................................................................................................................................... 3 1.1 General Description ............................................................................................................................ 3 1.2 Location of the test site ....................................................................................................................... 4 1.3 List of measuring equipment............................................................................................................... 5 1.4 Measurement Uncertainty ................................................................................................................... 6 2 Description of the radiated emission test ................................................................................................... 7 2.1 Test Procedure .................................................................................................................................... 7 2.2 Test Result .......................................................................................................................................... 8 2.3 Radiated Emission Measurement Data ............................................................................................... 9 3 Description of the Line-conducted Test ................................................................................................... 12 3.1 Test Procedure .................................................................................................................................. 12 3.2 Test Result ........................................................................................................................................ 12 3.3 Graph and Table of Conducted Emission Measurement Data .......................................................... 12 4 Photograph ...............................................................................................................................................13 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................. 13 4.2 Photographs of the External and Internal Configurations of the EUT.............................................. 13 5 Supplementary document......................................................................................................................... 14 5.1 Bandwidth ......................................................................................................................................... 14 5.2 Duty cycle ......................................................................................................................................... 14 5.3 Transmission time ............................................................................................................................. 14 5.4 Power Spectral Density..................................................................................................................... 14 5.5 Average on time ................................................................................................................................ 14 6 Appendices...............................................................................................................................................15 TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Page 3 of 25 FCC ID: VLEPL1350 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for Proton Z. The EUT is power by 2 x 1.5V AAA size batteries. It operates at 2410MHz – 2470 MHz. There are six buttons and two joysticks. When the buttons are pressed or joysticks are moved, there are radio signals transmitting to receiver. The brief circuit description is listed as follows: - U3 and its associated circuit act as MCU - U1 and its associated circuit act as RF module - Y1 and its associated circuit act as oscillator - VR1, VR2, K1, K2, K3, K4 and its associated circuit act as copter control TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Page 4 of 25 FCC ID: VLEPL1350 1.2 Location of the test site FCC Registered Test Site Number: 552221 Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and locat…

Text truncated - open the document above for the full version.

TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 22 of 25 FCC ID: VLEPL1350 A5. Band Edge Lower edge (Peak measurement) Lower edge (Average measurement) TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 23 of 25 FCC ID: VLEPL1350 A5. Band Edge Higher edge (Peak measurement) Higher edge (Average measurement)

TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 24 of 25 FCC ID: VLEPL1350 A6. 20dB Bandwidth Plot Bandwidth 1 (2410MHz) Bandwidth 2 (2450MHz) TEST REPORT Report No. : AS0054227(9) Date : 10 Sep 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 25 of 25 FCC ID: VLEPL1350 A6. 20dB Bandwidth Plot Bandwidth 3 (2470MHz) ***** End of Report *****
