Huawei Technologies Co., Ltd. Address:Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP:518129 Page :1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject:Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISM318to be kept confidential: 1. Schematic diagram & PCB layout. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 123.00 mW |
Huawei M318 CDMA Handset SECRET Page1,Total 7 External Photo of HUAWEI M318 Huawei M318 CDMA Handset SECRET Page2,Total 7 Huawei M318 CDMA Handset SECRET Page3,Total 7 Huawei M318 CDMA Handset SECRET Page4,Total 7 Huawei M318 CDMA Handset SECRET Page5,Total 7 Huawei M318 CDMA Handset SECRET Page6,Total 7 Huawei M318 CDMA Handset SECRET Page7,Total 7
Huawei M318 CDMA Handset SECRET Page1, Total 1 Label _M318 Label Location_M318
Huawei M318 CDMA Handset SECRET Page1,Total 5 Internal Photo of HUAWEI M318 Huawei M318 CDMA Handset SECRET Page2,Total 5 Huawei M318 CDMA Handset SECRET Page3,Total 5 Huawei M318 CDMA Handset SECRET Page4,Total 5 Huawei M318 CDMA Handset SECRET Page5,Total 5
No. 2007EEE01578 Page 31 of 105 Fig. 8 Z-Scan at power reference point (CDMA 835MHz CH777) No. 2007EEE01578 Page 32 of 105 CDMA 835 MHz Left Tilt Middle Electronics: DAE3 Sn536 Medium: 835 Head Medium parameters used (interpolated): f = 836.52 MHz; σ = 0.928 mho/m; ε r = 40.1; ρ = 1000 kg/m 3 Ambient Temperature:24.5 o C Liqiud Temperature: 24.0 o C Communication System: CDMA 800 Frequency: 836.52 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Middle/Area Scan (51x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.077 mW/g Tilt Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.53 V/m; Power Drift = -0.085 dB Peak SAR (extrapolated) = 0.086 W/kg SAR(1 g) = 0.067 mW/g; SAR(10 g) = 0.049 mW/g Maximum value of SAR (measured) = 0.070 mW/g 0 dB = 0.070mW/g Fig. 9 Left Hand Tilt 15°CDMA 835MHz CH384 No. 2007EEE01578 Page 33 of 105 Fig. 10 Z-Scan at power reference point (CDMA 835MHz CH384) No. 2007EEE01578 Page 34 of 105 CDMA 835 MHz Left Tilt Low Electronics: DAE3 Sn536 Medium: 835 Head Medium parameters used (interpolated): f = 824.7 MHz; σ = 0.925 mho/m; ε r = 40.2; ρ = 1000 kg/m 3 Ambient Temperature:24.5 o C Liqiud Temperature: 24.0 o C Communication System: CDMA 800 Frequency: 824.7 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Low/Area Scan (51x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.092 mW/g Tilt Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.96 V/m; Power Drift = -0.188 dB Peak SAR (extrapolated) = 0.102 W/kg SAR(1 g) = 0.082 mW/g; SAR(10 g) = 0.059 mW/g Maximum value of SAR (measured) = 0.090 mW/g 0 dB = 0.090mW/g Fig. 11 Left Hand Tilt 15°CDMA 835MHz CH1013 No. 2007EEE01578 Page 35 of 105 Fig. 12 Z-Scan at power reference point (CDMA 835MHz CH1013) No. 2007EEE01578 Page 36 of 105 CDMA 835 MHz Right Cheek High Electronics: DAE3 Sn536 Medium: 835 Head Me...
No. 2007EEE01578 Page 56 of 105 CDMA 1900 MHz Left Cheek Middle Electronics: DAE3 Sn536 Medium: Head 1900 MHz Medium parameters used: f = 1880 MHz; σ = 1.35 mho/m; ε r = 39.7; ρ = 1000 kg/m 3 Ambient Temperature:24.5 o C Liqiud Temperature: 24.0 o C Communication System: CDMA 1900 Frequency: 1880 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(5.4, 5.4, 5.4) Cheek Middle/Area Scan (51x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.403 mW/g Cheek Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.60 V/m; Power Drift = -0.118 dB Peak SAR (extrapolated) = 0.744 W/kg SAR(1 g) = 0.339 mW/g; SAR(10 g) = 0.173 mW/g Maximum value of SAR (measured) = 0.392 mW/g 0 dB = 0.392mW/g Fig. 33 Left Hand Touch Cheek CDMA 1900MHz CH600 No. 2007EEE01578 Page 57 of 105 Fig. 34 Z-Scan at power reference point (CDMA 1900MHz, CH600) No. 2007EEE01578 Page 58 of 105 CDMA 1900 MHz Left Cheek Low Electronics: DAE3 Sn536 Medium: Head 1900 MHz Medium parameters used (interpolated): f = 1851.25 MHz; σ = 1.33 mho/m; ε r = 39.8; ρ = 1000 kg/m 3 Ambient Temperature:24.5 o C Liqiud Temperature: 24.0 o C Communication System: CDMA 1900 Frequency: 1851.25 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(5.4, 5.4, 5.4) Cheek Low/Area Scan (51x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.764 mW/g Cheek Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.40 V/m; Power Drift = -0.113 dB Peak SAR (extrapolated) = 0.999 W/kg SAR(1 g) = 0.641 mW/g; SAR(10 g) = 0.327 mW/g Maximum value of SAR (measured) = 0.731 mW/g 0 dB = 0.731mW/g Fig. 35 Left Hand Touch Cheek CDMA 1900MHz CH25 No. 2007EEE01578 Page 59 of 105 Fig. 36 Z-Scan at power reference point (CDMA 1900MHz, CH25) No. 2007EEE01578 Page 60 of 105 CDMA 1900 MHz Left Tilt High Electronics: DAE3 Sn536 Medium: Head 1900 MHz Medium parameters used (interpolated): f = 1908.75 MHz; σ = 1.37 mho/m; ε r = 39....
No. 2007EEE01578 Page 86 of 105 ANNEX E PROBE CALIBRATION CERTIFICATE No. 2007EEE01578 Page 87 of 105 No. 2007EEE01578 Page 88 of 105 No. 2007EEE01578 Page 89 of 105 No. 2007EEE01578 Page 90 of 105 No. 2007EEE01578 Page 91 of 105 No. 2007EEE01578 Page 92 of 105 No. 2007EEE01578 Page 93 of 105 No. 2007EEE01578 Page 94 of 105 No. 2007EEE01578 Page 95 of 105 ANNEX F DIPOLE CALIBRATION CERTIFICATE No. 2007EEE01578 Page 96 of 105 No. 2007EEE01578 Page 97 of 105 No. 2007EEE01578 Page 98 of 105 No. 2007EEE01578 Page 99 of 105 No. 2007EEE01578 Page 100 of 105 No. 2007EEE01578 Page 101 of 105 No. 2007EEE01578 Page 102 of 105 No. 2007EEE01578 Page 103 of 105 No. 2007EEE01578 Page 104 of 105 No. 2007EEE01578 Page 105 of 105
FCC TEST REPORT OF Huawei CDMA Mobile Station M/N: M318 Jun. 04, 2007 Reliability Laboratory of Huawei Technologies Co., Ltd. All Right Reserved Report No: SYBH(R)60052007 FCC ID: QISM318 Report No: SYBH (R) 60052007 Confidential Information of Huawei. No Distribution without Permission Page2, Total39 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Committee for Laboratories (CNAL), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is C1758, R1672, and T153. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. Any copy of the test report is invalid if not re-marked with the "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Report No: SYBH (R) 60052007 Confidential Information of Huawei. No Distribution without Permission Page3, Total39 REPORT ON FCC Test of Huawei CDMA Mobile Station M/N: M318 Report No: ...
