VMNBC002

Chong Ngai Electronics Co., Ltd

BT Handsfree Kit

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Sep 28, 2007
Application Purpose: Original Equipment
Date of Application: Sep 27, 2007
Equipment Note: BT Handsfree Kit
Frequency Range: 2402.00000000 - 2480.00000000
Company: Chong Ngai Electronics Co., Ltd
Country: Hong Kong

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Test Report

Test Setup Photos
