+ Store Owner’s Manual Store Owner’s Manual 2 INSTRUCTION TO THE USER This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non- approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment Store Owner’s Manual 3 DECLARATION OF CONFORMITY TRADE NAME: POPickup MODEL NUMBER: 31A000026 COMPLIANCE TEST REPORT NUMBER: B80311A1 COMPLIANCE TEST REPORT DATE: March 12, 2008 RESPONSIBLE PARTY (IN USA): PerSage, Inc. ADDRESS : 18627 Brookhurst St #185 Fountain Valley, CA 92708 TELEPHONE: 714-593-1529 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the unit does cause harmful interference to radio or television reception, please refer to your user’s manual for instructions on correcting the problem. I, the undersigned, hereby declare that the equipment specified above conforms to the above requirements. Place: Orange County, CA Signature: Date: March 19, 2008 Full Name: James M. Carrigan Position: President Store Owner’s Manual 4 Table of Contents INSTRUCTION TO THE USER 2 INTRODUCTION 5 HARDWARE 6 Gateway 6 Sensor 7 GETTING STARTED 8 Select POPickup Service Host Computer 8 POPickup Store Registration Information 8 STORE OWNER PORTAL 10 Install POPickup Agent 11 Install Gateway Driver 17 Register Gateway 19 Select Alert Message Configuration 22 SETUP POPICKUP ENABLED MAILBOXES 24 Associate Sensor with Mailbox 24 Record Mailbox Details 27 Register Sensor to POPickup application 27 Register Customer and Assign Mailbox 30 Assign Mailbox 31 Set Up Customer Account 32 STORE SETTINGS 36 Profile and Contacts 36 Edit Store Profile 37 Change Password 39 Alert Message Configuration 39 Store Owner’s Manual 5 Introduction Welcome to POPickup Notification Service by PerSage, Inc. As a store owner there are a few things to set up before you can begin offering the POPickup Notification Service to your mailbox customers. Store Owner’s Manual 6 Hardware POPickup notification service requires two key hardware devices described in this section. These work together with your store’s host computer. Gateway Gateway The Gateway relays signals from the mailbox sensors to the PerSage Web Servers via your store’s internet connection. The PerSage Web Servers then send a notification to your customers of their mail item. The Gateway is connected to your store’s computer via a USB cable. Your Gateway unit looks similar to the one pictured here. NOTE: Your internet connection must be up and running for the POPickup Notification Service to work. Store Owner’s Manual 7 Sensor Senso r The sensor unit is placed inside your customer’s mailbox when they elect to have POPickup notification service. The sensor ‘talks’ to the POPickup gateway and is the start of the notification cycle. When one of the three buttons is pressed by the mail sorter, the customer receives the message you have designated for that alert button. Your sensor looks like one this. Store Owner’s Manual 8 Getting Started This section covers the preparation steps required to get your store up and running with POPickup Service. You will need to: Select POPickup Host Computer Have Store Registration Information (from email) You will then be ready to login to the Store Owner Portal from the PerSage.com website and begin installation and registration. Select POPickup Service Host Computer Select POPickup Servi ceHost Computer The following requirements should be considered when selecting which computer will host your POPickup Service. All specifications listed below must be satisfied. Must be located within 100 feet of all the mailboxes Must have Windows XP Operating System Í Vista OS to be supported in the future Must have dedicated USB connection for Gateway Í NOTE: USB hub has been reported to work but a dedicated USB connection is recommended. Must maintain full operating status during business operations Í NOTE: The USB port must remain active during business hours, regardless of the power save feature in use. Can be shut down outside business hours P P O O P P i i c c k k u u p p S S t t o o r r e e R R e e g g i i s s t t r r a a t t i i o o n n I I n n f f o o r r m m a a t t i i o o n n When you signed up for the service a store account was created for…

Text truncated - open the document above for the full version.

+ Store Owner’s Manual Store Owner’s Manual 2 INSTRUCTION TO THE USER This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non- approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment Store Owner’s Manual 3 DECLARATION OF CONFORMITY TRADE NAME: POPickup MODEL NUMBER: 31A000026 COMPLIANCE TEST REPORT NUMBER: B80311A1 COMPLIANCE TEST REPORT DATE: March 12, 2008 RESPONSIBLE PARTY (IN USA): PerSage, Inc. ADDRESS : 18627 Brookhurst St #185 Fountain Valley, CA 92708 TELEPHONE: 714-593-1529 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the unit does cause harmful interference to radio or television reception, please refer to your user’s manual for instructions on correcting the problem. I, the undersigned, hereby declare that the equipment specified above conforms to the above requirements. Place: Orange County, CA Signature: Date: March 19, 2008 Full Name: James M. Carrigan Position: President Store Owner’s Manual 4 Table of Contents INSTRUCTION TO THE USER 2 INTRODUCTION 5 HARDWARE 6 Gateway 6 Sensor 7 GETTING STARTED 8 Select POPickup Service Host Computer 8 POPickup Store Registration Information 8 STORE OWNER PORTAL 10 Install POPickup Agent 11 Install Gateway Driver 17 Register Gateway 19 Select Alert Message Configuration 22 SETUP POPICKUP ENABLED MAILBOXES 24 Associate Sensor with Mailbox 24 Record Mailbox Details 27 Register Sensor to POPickup application 27 Register Customer and Assign Mailbox 30 Assign Mailbox 31 Set Up Customer Account 32 STORE SETTINGS 36 Profile and Contacts 36 Edit Store Profile 37 Change Password 39 Alert Message Configuration 39 Store Owner’s Manual 5 Introduction Welcome to POPickup Notification Service by PerSage, Inc. As a store owner there are a few things to set up before you can begin offering the POPickup Notification Service to your mailbox customers. Store Owner’s Manual 6 Hardware POPickup notification service requires two key hardware devices described in this section. These work together with your store’s host computer. Gateway Gateway The Gateway relays signals from the mailbox sensors to the PerSage Web Servers via your store’s internet connection. The PerSage Web Servers then send a notification to your customers of their mail item. The Gateway is connected to your store’s computer via a USB cable. Your Gateway unit looks similar to the one pictured here. NOTE: Your internet connection must be up and running for the POPickup Notification Service to work. Store Owner’s Manual 7 Sensor Senso r The sensor unit is placed inside your customer’s mailbox when they elect to have POPickup notification service. The sensor ‘talks’ to the POPickup gateway and is the start of the notification cycle. When one of the three buttons is pressed by the mail sorter, the customer receives the message you have designated for that alert button. Your sensor looks like one this. Store Owner’s Manual 8 Getting Started This section covers the preparation steps required to get your store up and running with POPickup Service. You will need to: Select POPickup Host Computer Have Store Registration Information (from email) You will then be ready to login to the Store Owner Portal from the PerSage.com website and begin installation and registration. Select POPickup Service Host Computer Select POPickup Servi ceHost Computer The following requirements should be considered when selecting which computer will host your POPickup Service. All specifications listed below must be satisfied. Must be located within 100 feet of all the mailboxes Must have Windows XP Operating System Í Vista OS to be supported in the future Must have dedicated USB connection for Gateway Í NOTE: USB hub has been reported to work but a dedicated USB connection is recommended. Must maintain full operating status during business operations Í NOTE: The USB port must remain active during business hours, regardless of the power save feature in use. Can be shut down outside business hours P P O O P P i i c c k k u u p p S S t t o o r r e e R R e e g g i i s s t t r r a a t t i i o o n n I I n n f f o o r r m m a a t t i i o o n n When you signed up for the service a store account was created for…

Text truncated - open the document above for the full version.

PerSage, Inc. Tel: 714.593.1529 18627 Brookhurst Street FAX: 714.459.7309 Suite 185 [email protected] Fountain Valley, CA 92708-6748 www.persage.com March 6, 2008 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compa ti ble Electronics, as an Agent for PerSage, Inc, 18627 Brookhurst St #185, Fountain Valley, CA 92708, for a period of one year, to sign appli cati ons before the certification body on our behalf, to make representati ons to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following PerSage products: POPickup Gateway POPickup Sensor under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither PerSage nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, PerSage will notify the Federal Communications Commission if, at any time, the situation changes causing PerSage to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714-593-1529. Sincerely, James M. Carrigan President/CEO

DECLARATION OF CONFORMITY TRADE NAME: POPickup MODEL NUMBER: 31A000026 COMPLIANCE TEST REPORT NUMBER: B80311A1 COMPLIANCE TEST REPORT DATE: March 12, 2008 RESPONSIBLE PARTY (IN USA): PerSage, Inc. ADDRESS : 18627 Brookhurst St #185 Fountain Valley, CA 92708 TELEPHONE: 714-593-1529 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the unit does cause harmful interference to radio or television reception, please refer to your user’s manual for instructions on correcting the problem. I, the undersigned, hereby declare that the equipment specified above conforms to the above requirements. Place: Orange County, CA Signature: Date: March 19, 2008 Full Name: James M. Carrigan Position: President

PerSage, Inc. Tel: 714.593.1529 18627 Brookhurst Street FAX: 714.459.7309 Suite 185 [email protected] Fountain Valley, CA 92708-6748 www.persage.com March 6, 2008 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, PerSage, Inc. would like to declare that the application being submitted for the devices with FCC IDs as follows: VOL31A000025 Sensor VOL31A000026 Gateway These items have not been submitted to another TCB for certification. If you have any questions, please do not hesitate to contact us at 714-593-1529 Sincerely, James M. Carrigan President/CEO

PerSage, Inc. Tel: 714.593.1529 18627 Brookhurst Street FAX: 714.459.7309 Suite 185 [email protected] Fountain Valley, CA 92708-6748 www.persage.com March 6, 2008 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, PerSage, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at 714-593-1529 Sincerely, James M. Carrigan President/CEO

Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Wednesday, March 19, 2008 9:09 AM To: '[email protected]' Cc: '[email protected]' Subject: FCC ID: VOL31A000026 3/19/2008 Mr. Fujimoto: In order for processing of this certification application (FCC ID: VOL31A000026) to continue, the following issue(s) will have to be addressed: 1) Please indicate the type of modulation employed by the device. 2) Please provide band-edge data showing compliance with 15.209 of the rules. 3) Since this device is also a personal computer peripheral, subject to either Declaration of Conformity or Certification; please provide either; the FCC ID of the related application, or a copy of the manufacturer’s Declaration of Conformity. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is VOL31A000026. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB

Correspondence by Project Project Number: Correspondence Number Memo VOL31A000026 1. See the Revised Expository Statement 2. See the Revised Test Report 3. See the Revised Owners Manual and separate exhibit fort the DoC 4. The Block Diagram has also been revised 1413904352

Gateway FCC ID: VOL31A000026 Gateway This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation .

Report Number: B80311A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report POPickup P/N: 31A000026 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for POPickup Part Number: 31A000026 Prepared for PERSAGE, INC. 18627 BROOKHURST STREET, SUITE 185 FOUNTAIN VALLEY, CALIFORNIA 92708 Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MARCH 12, 2008 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 20 17 59 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B80311A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report POPickup P/N: 31A000026 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.1.3 Radiated Emissions (Spurious and Harmonics) Test (Continued) 15 8. CONCLUSIONS 16 Report Number: B80311A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report POPickup P/N: 31A000026 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Conducted and Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of The 3 Meter Radiated Site Report Number: B80311A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report POPickup P/N: 31A000026 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: POPickup P/N: 31A000026 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: PerSage, Inc. 18627 Brookhurst Street, Suite 185 Fountain Valley, California 92708 Test Dates: March 7, 10 and 11, 2008 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207. 2 Radiated RF Emissions, 10 kHz – 9050.01 MHz (Transmitter Portion) Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209, and 15.249. 3 Radiated RF Emissions, 10 kHz – 9050.01 MHz (Digital and Receiver Portions) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B. Report Number: B80311A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report POPickup P/N: 31A000026 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the POPickup, P/N: 31A000026. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are …
