Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Oct 01, 2007
- Application Purpose
- Original Equipment
- Date of Application
- Sep 30, 2007
- Equipment Note
- Bluetooth Earphone
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- SCOTOR(Hong Kong)Limited
- Country
- China
Documents & Files
Select a file to view
Users Manual
Block Diagram
Cover Letter(s)
External Photos
ID Label/Location Info
Internal Photos
Operational Description
Schematics
Test Report
Test Setup Photos
Document Text Content (5 documents)
Cover Letter(s)
Alereon, Inc. AL4512-EVB S/N: W500 FCC ID: U9YAL4512
External Photos
Alereon AL4512 Label Placement Bottom view of PCBA showing label placement
Operational Description
Alereon Confidential Page 1 5/1/2007 Theory of operation; Alereon AL4512 USB 4-Port Hub. The Alereon AL4504 incorporates the functionality of a UWB radio device and a 4-Port USB Hub. This device is intended to provide a short-range wireless USB connection to computers for up to four peripheral units equipped with a USB 2.0 interface. The AL4512 is powered by a +5 Volt power unit which operates from the commercial A.C. power mains. The AL4512 operates in the frequency band defined in the FCC Rules and Regulations for UWB devices. Specifically, it operates between the frequencies of 3.168 and 4.752 GHz per the industry-defined WiMedia 1.1 specification. The AL4512 is comprised of three integrated circuit devices and supporting circuitry for filtering, interface and power conditioning. The AL4512 employs an antenna external to the device which attaches to the device by a Reverse-Polarity SMA connector complying with the requirements of 47 CFR 15.212(a)(iv). The schematic diagram shows a connector, Murata type MM8430, in the RF path on the printed wiring board. This is a production test connector, it is not accessible from outside of the unit housing. Following the antenna is a bandpass filter with a passband from 3.1 GHz to 4.752 GHz which provides suppression of unwanted transmitter emissions and receiver interference rejection in the 2.4 GHz and 5.1 GHz bands. The AL4100 RF Transceiver generates the system reference frequency from a 33 MHz crystal resonator. The 33 MHz reference frequency is multiplied to 4.224 GHz internally within the AL4100 by a PLL multiplier. From this frequency the three band frequencies, 3.432 GHz, 3.960 GHz and 4,488 GHz for both transmit and receive modes are derived internally within the AL4100 by direct synthesis. In addition to the band frequencies, a 1056 MHz clock for ADCs and DACs within the AL4200 Baseband Processor is generated. The interface between the AL4100 RF Transceiver and the AL4200 Baseband Processor consists of the analog R...
Operational Description
All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK R&D Corporation. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government. Compliance Report of Alereon AL4512 Module Customer: Alereon, Inc. Date: May 14, 2007 TDK Report: TTS-TR-T112-004 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Report A. Medina P. Carson This document contains confidential information and cannot be disclosed outside of Alereon or any affiliated company in whole or in part without the express written permission of TDK R&D Corporation. TTS-TR-T112-004 page 2 of 51 1. Executive Summary An EMC evaluation to determine compliance of the Alereon AL4512 UWB Module with requirements of FCC 47 CFR Part 15, Subpart F Section 15.519 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that are currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the Modular Wireless USB Hub. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.519(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.519(b) Yes Radiated Emissions 15.519(c), 15.209 Yes Radiated Emissions in GPS Bands 15.519(d) Yes Peak Emissions within a 50 MH...
Contact Information
Applicant
JianWen Chen(President)
Test Firm
Bay Area Compliance Laboratory Corp. (Shenzhen)John Chan
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.64 mW |
