FCC ID: 2BGR7-WF117 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation WiFi mode Mode Output power to antenna (dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 19.98 19(±1) 20 100 0.0199 1.0 PASS Remark: antenna gain=0dBi
FCC ID: G9H2-7950A ETC Report No.: 07-06-MAS-119-02 Sheet 1 of 42 Sheets Electronics Testing Center, Taiwan No.8, Lane 29, Wenming RD., LeShan Tsuen, GuiShan Shiang, Taoyuan County 33383, Taiwan, R.O.C. Rev. No 1.0 CONFORMANCE TEST REPORT FOR FCC Part 15, subpart D (15.323c) Report No.: 07-06-MAS-119-02 Client: Thomson Inc. Product: DECT 6.0 Cordless Phone w/ITAD Speakerphone (FP) Model: 27950XXX-A FCC ID: G9H2-7950A Manufacturer/supplier: Telefield Ltd. Date test item received: 2007/06/11 Date test campaign completed: 2007/07/27 Date of issue: 2007/07/27 The test result only corresponds to the tested sample. It is not permitted to copy this report, in part or in full, without the permission of the test laboratory. Total number of pages of this test report: 42 pages Test Engineer Checked By Approved By James Cheng Joe Hsieh Winpo Tsai FCC ID: G9H2-7950A ETC Report No.: 07-06-MAS-119-02 Sheet 2 of 42 Sheets Electronics Testing Center, Taiwan No.8, Lane 29, Wenming RD., LeShan Tsuen, GuiShan Shiang, Taoyuan County 33383, Taiwan, R.O.C. Rev. No 1.0 Table of Contents Page 1 GENARAL INFORMATION...............................................................................................................3 1.1 Testing Laboratory...........................................................................................................................3 1.2 Client Information.............................................................................................................................3 1.3 Manufacturer....................................................................................................................................3 2 TEST INFORMATION........................................................................................................................4 2.1 Description of Tested Device(s)....................................................................................................4 2.2 Test Environment.........................................
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.03 mW |
2007-06-21 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _ Ixia______________ hereby authorize Bay Area Compliance Laboratory Corp to act as a laboratory for testing and test report generation for the following project: Model: IxWLAN SED-MR+, FCC ID: RCXGC617644; A test and measurement device that emulates up to 128 wireless stations in an IEEE 802.11 wireless LAN environment. This is a client device (programmed at the point of manufacture) without autonomous transmitting capability. We affirm that between BACL and Ixia, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. We also hereby authorize Lisa Tang (Sales Representative of Bay Area Compliance Laboratory Corp.) to act as Agent on our behalf in all matters relating to product certification submittal to Bay Area Compliance Corp., as a Certification Body for the purpose of performing product certification services for the above listed project(s). Sincerely, Al Cummins Sr. Compliance Engineer 26601 Agoura Rd Calabasas, CA 91302
IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 46 of 62 FCC Part 15.247 Test Report EXHIBIT A - FCC ID LABEL INFORMATION FCC § 2.925 Identification of equipment (a) Each equipment covered in an application for equipment authorization shall bear a nameplate or label listing the following: (1) FCC Identifier consisting of the two elements in the exact order specified in §2.926. The FCC Identifier shall be preceded by the term FCC ID in capital letters on a single line, and shall be of a type size large enough to be legible without the aid of magnification. Example: FCC ID XXX123. XXX—Grantee Code 123—Equipment Product Code FCC ID Label Requirements as per FCC § 15.19 (a) In addition to the requirements in part 2 of this chapter, a device subject to certification, or verification shall be labeled as follows: (3) All other devices shall bear the following statement in a conspicuous location on the device: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (5) When the device is so small or for such use that it is not practicable to place the statement specified under paragraph (a) of this section on it, the information required by this paragraph shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. However, the FCC identifier or the unique identifier, as appropriate, must be displayed on the device. Proposed FCC ID Label IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 47 of 62 FCC Part 15.247 Test Report Proposed Label Location on EUT As per FCC §15.17 (b)(4), the label shall not be a stick-on, paper label. The label on these products shall be permanently affixed to the product and shall be readily visible ...
IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 11 of 62 FCC Part 15.247 Test Report § 15.247 (i) and § 2.1091 - RF EXPOSURE According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density MPE Prediction Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 802.11b mode: Maximum peak output power at antenna input terminal: 22.724 (dBm ) Maximum peak output power at antenna input terminal: 187.24 (mW) Prediction distance: 20 (cm) Predication frequency: 2437(MHz) Antenna Gain (typical): 4.0 (dBi) antenna gain: 2.51 (numeric) Power density at predication frequency at 20 cm: 0.094 (mW/cm 2 ) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm 2 ) IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 12 of 62 FCC Part 15.247 Test Report 802.11g mode: Maximum peak output power at antenna input terminal: 22.912 (dBm ) Maximum peak output power at antenna input terminal: 195.52 (mW) Prediction distance: 20 (cm) Predication frequency: 2462(MHz) Antenna Gain (typical): 4.0 (dBi) antenna gain: 2.51 (numeric) Power density at predi...
IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 48 of 62 FCC Part 15.247 Test Report EXHIBIT B - TEST SETUP PHOTOGRAPHS Conducted Emissions –Front View Conducted Emissions – Rear View IXIA FCC ID: RCXGC617644 Report No.: R0706045-247 Page 49 of 62 FCC Part 15.247 Test Report Radiated Emissions - Front View Radiated Emissions - Rear View
