VRKDOCKING0203

Hakuto Taiwan Ltd.

Bluetooth Module

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 07, 2007
Application Purpose: Original Equipment
Date of Application: Nov 07, 2007
Equipment Note: Bluetooth Module
Frequency Range: 2402.00000000 - 2480.00000000
Company: Hakuto Taiwan Ltd.
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Attestation Statements

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Operational Description

RF Exposure Info

Test Report

Test Setup Photos

Document Text Content (11 documents)

Attestation Statements

INEW Digital Company Supply Bureau 3 rd floor KT&G #203-1 Pyongchon-dong, Daedeog-gu, Daejeon, Korea TEL. 82-42-933-7328 FAX. 82-42-934-4829 Date: JUNE 8, 2007 Compliance Certification Services Certification Division 47173 Benicia Street, Fremont CA 94538, USA To whom it may concern: We, INEW Digital Company, the undersigned, hereby authorize SGS Testing Korea Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Testing Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). In authorizing SGS Testing Korea Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that INEW Digital Company Supply Bureau 3 rd floor KT&G #203-1 Pyongchon-dong, Daedeog-gu, Daejeon, Korea TEL. 82-42-933-7328 FAX. 82-42-934-4829 contains any reference thereto and return any certificat...

Cover Letter(s)

Compliance Certification Services July 18, 2007 Certification Division 47173 Benicia Street, Fremont, CA 94538, USA Re: Model name : CDM-650PRO INEW Digital Company Supply Bureau 3th floor KT&G #203-1, Pyong chon-dong, Daedeog-gu, Daejeon, Korea Subject : Authorization to use technical material and test report for C-motech’s CDU-650 Model (FCC ID : TARCDU-650). To Whom It May Concern: This letter grants authorization for representatives of INEW Digital Company to use all existing compliance technical material and test reports of CDU-650 model from C-motech Co., Ltd. for the above referenced model. We understand and agree that INEW Digital Company will submit applicable C-motech Co., Ltd. ’s test reports to regulators for the purpose of gaining new regulatory approvals. Sincerely, Mr. Byung-Young Choi Senior Research Engineer C-motech Co., Ltd. 5F., Etronix BLD., 17-10 Yoido-dong Youngdungpo-gu, Seoul, Korea (150-874) Email: [email protected] URL: http://www.cmotech.com TEL:82-2-785-5540 FAX:82-2-785-2369

Contact Information

Applicant

Steven Chen

[email protected]886-2-87728910Fax: 886-2-87728918

Technical Contact

QuieTek CorporationVincent Lin

[email protected]886-2-8601-3788

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	390.00 µW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Limited Modular approval. For RF shielding this device is dependent on a suitable host. Power output listed is conducted. The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with specific operating instructions for satisfying RF exposure compliance.

Cover Letter(s)

INEW Digital Company Supply Bureau 3 rd floor KT&G #203-1 Pyongchon-dong, Daedeog-gu, Daejeon, Korea TEL. 82-42-933-7328 FAX. 82-42-934-4829 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentleman: This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. We, INEW Digital Company would like the following documents regarding this submission for FCC ID: UFSINK650D to be kept confidential. 1. Schematics 2. Parts List 3. Block diagram 4. Theory of operation The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Ha-Young Lee Chief INEW Digital Company Friday, 18 August 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: C-motech Co., Ltd. FCC ID: TARCDU-650 FCC Part 22 and FCC Part 24 Certification Request for Confidentiality Dear Sir’s/Madam’s: In accordance with 0.457 and 0.459 of CFR 47, C-motech Co., Ltd. hereby requests confidentiality treatment of information accompanying this application as outlined below: - CDU-650 block diagram, parts list, and schematics - CDU-650 Theory of operation - CDU-650 antenna specifications These documents contain detailed system and equipment description and related information about the product in which C-motech Co., Ltd. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, C-motech Co., Ltd. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Mr. Byung-Young Choi Senior Research Engineer C-motech Co., Ltd. 5F., Etronix BLD., 17-10 Yoido-dong Youngdungpo-gu, Seoul,...

Cover Letter(s)

Mike Kuo From: Kwon, James (Gunpo) [[email protected]] Sent: Wednesday, October 18, 2006 5:37 AM To: Mike Kuo Cc: Ham, Denny (Gunpo); Jeong, Feel (Gunpo); [email protected]; [email protected]; Ryu, Erwin (Gunpo) Subject: RE: C-motech Co., Ltd., FCC ID: TARCDU-650, Assessment NO.: AN06T6194, Notice#1 10/18/2006 Hi Mike, Regarding your findings, pls find our reply embedded at below . There are 2 items to be revised on 731 form, pls change at your side : 1) emission designator : 1M28F9W ---> 1M43F9W 2) Transmit Power to be revised : CDMA : ERP 21.90 dBm (0.155 W) US PCS :EIRP 21.84 dBm (0.153 W) James/SGS -----Original Message----- From: Mike Kuo Sent: Sunday, October 08, 2006 5:10 PM To: Mike Kuo Subject: C-motech Co., Ltd., FCC ID: TARCDU-650, Assessment NO.: AN06T6194, Notice#1 Administrative Review portion: Question #1:Please update theory of operation to provide the following radio capabilities : -> Updated and uploaded it. A. What is MS protocol revision number that this device is supporting -> IS-2000 & IS-856 (1xRTT & EVDO Revision 0) B.What is revision number of 1xEVDO that this device is capable of -> 1xEVDO Revision 0 (No 1xEVDO RevisionA) C.This radio is design per which version of 3GPP standard. -> IS98E & IS-856-2 D. Please list the Radio configuration ( RC ) and Service option ( SO ) that this device is capable of -> See below table (As you know, similar to Question11.A ) Radio Configurations Radio Programming C.S0002-A Standard Test Mode in Radio Configuration can be changed at any time, but is not applicable till next connection if having connected. Config Mnemonic Forward Traffic Channel Radio Configuration Reverse Traffic Channel Radio Configuration TIA/EIA-98-E (Fwd1, Rvs1) F1R1 RC1 RC1 1 (Fwd2, Rvs2) F2R2 RC2 RC2 2 (Fwd3, Rvs3) F3R3 RC3 RC3 3 (Fwd4, Rvs3) F4R3 RC4 RC3 4 (Fwd5, Rvs4) F5R4 RC5 RC4 5 The traffic channel may consist of one or more code channels such as fundamental channel, supplemental channel. Service Options Service Option Setup ...

External Photos

FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 30 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Appendix D. Photos of the EUT Top View of Product Bottom View of Product FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 31 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Front View of Product Rear View of Product FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 32 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Right View of Product Left View of Product

Internal Photos

FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 33 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Inside View of Product Top View of Main Board FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 34 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Top View of Main Board (Removed shield cap) Bottom View of Main Board FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 35 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Bottom View of Main Board (Removed shield cap) Top View of Modem FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 36 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Bottom View of Modem Top Main-Board of Modem FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 37 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Bottom Main-Board of Modem

Operational Description

FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 1 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com TEST REPORT OF FCC Part 22H, Part 24E and Part 15 FCC ID : UFSINK650D Equipment Under Test : Wireless Router Model Name : CDM-650PRO Serial No. : N/A Applicant : INEW DIGITAL COMPANY Manufacturer : INEW DIGITAL COMPANY Date of Test(s) : 2007-05-10 ~ 2007-06-04 Date of Issue : 2007-07-06 In the configuration tested, the EUT complied with the standards specified above. Te s t e d B y : Date: 2007-07-06 Feel Jeong Approved By: Date: 2007-07-06 Denny Ham FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 2 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com INDEX TABLE OF CONTENTS Page 1. General Information ------------------------------------------------------------------------- 3 2. AC Power Line Conducted Emissions ---------------------------------------------------- 7 3. RF Radiated Output Power ----------------------------------------------------------------- 15 4. Spurious Radiated Emissions --------------------------------------------------------------- 18 5. Field Strength of Radiated Emissions ---------------------------------------------------- 22 6. RF Exposure Evaluation ----------------------------------------------------------------- 25 Appendix A. Photos of AC Power Line Conducted Emissions Test Appendix B. Photos of Field Strength Radiated Emission Test Appendix C. Photo of RF Rated output power & Spurious Emissions Test Appendix D. Photos of the EUT FCC ID : UFSINK650D Report File No. : STROR...

RF Exposure Info

FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 27 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Appendix A. Photos of AC Power Line Conducted Emissions Test Front View of Conducted Emission Rear View of Conducted Emission FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 28 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Appendix B. Photos of Field Strength Radiated Emission Test FCC ID : UFSINK650D Report File No. : STROR-07-038 Page : 29 of 37 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com Appendix C. Photo of RF Rated output power & Spurious Emission Test

Test Report

FAE Manual Page 1 of 62 Connect your network on wireless Internet easily CDM-650PRO FAE manual Wireless CDMA Docking Station INEW Digital Company Technical Support: [email protected] TEL: 82-42-933-7328 FAX: 82-42-934-4829 www.inewdc.com Regulatory Information & Safety notices 1. Regulatory Notices This device is compliant with Parts 15, 22 and 24 of the FCC Rules. Operation of this device is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesirable operations. FCC RF EXPOSURE COMPLIANCE In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. This device should not be operated in conjunction with another transmitter in order to comply with the FCC's RF Exposure requirements. During operation, a 20 cm separation distance should be maintained between the antenna, whether extended or retracted, and the user’s/bystander’s body (excluding hands, wrists, feet, and ankles) to ensure FCC RF exposure compliance. CAUTION Unauthorized modification or change not expressly approved by INEW Digital Company could void compliance with regulatory rules and thereby your authority to use this equipment. Regulatory Information & Safety notices WARNING (EMI) This equipment has been tested and found to comply with the limits pursuant to Part 15, 22 ...
