VSBBH0103212

BONPHI TECHNOLOGY LIMITED

Bluetooth Speakerphone

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 12, 2007
Application Purpose: Original Equipment
Date of Application: Nov 12, 2007
Equipment Note: Bluetooth Speakerphone
Frequency Range: 2402.00000000 - 2480.00000000
Company: BONPHI TECHNOLOGY LIMITED
Country: China

Documents & Files

Select a file to view

Users Manual

Attestation Statements

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Parts List/Tune Up Info

Test Report

Test Setup Photos

Document Text Content (4 documents)

Internal Photos

ACX Advanced Ceramic X AT3216 Series Multilayer Chip Antenna Features Monolithic SMD with small, low-profile and light-weight type. Wide bandwidth Applications Bluetooth/Wireless LAN/Home RF ISM band 2.4GHz applications Specifications Part Number Frequency Range (MHz) Peak Gain （XZ-V） Average Gain （XZ-V） VSWR Impedance AT3216 -B2R7HAA_ 2400 ~ 2500 0.5 dBi typ. -0.5 dBi typ.2 max. 50 Ω Q’ty/Reel (pcs) : 3,000pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 3W max. Part Number AT 3216 - B 2R7 HAA i ghfe dc c Type AT : Antenna d Dimensions ( L × W ) 3.2× 1.6 mm e Material Code B f Frequency Range 2R7=2700MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Unit : mm a W T L Mark L W T a Dimensions 3.2±0.2 1.6±0.2 1.3+ 0.1/-0.2 0.5±0.3 (a) Without Matching Circuits (b) With Matching Circuits 1.2pF 3.3nH 2.6 4.2 1.6 1.9 2.7nH 0.4 * *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) Test Board Ground 13.5mm 6.5mm 39.5mm 4mm No Ground Matching Circuit 50Ω Feed Line 19mm Antenna 6.5mm Return Loss (a) Without Matching Circuits (b) With Matching Circuits ACX Advanced Ceramic X Radiation Patterns .... XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal Z 270 o 0 o X Y XY-cut scanning direction Y 270 o 0 o X Z XZ-cut scanning direction Z X 0 o 270 Y YZ-cut scanning direction 180 180 180 o XY-V/XY-H 90 o 90 o 90 o Advanced Ceramic X Corp. 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan TEL:886-3-5987008 FAX:886-3-5987001 E-mail: [email protected] http://www.acxc.com.tw

Test Report

IN ACCORDANCE WITH THE REQUIREMENTS OF FCC OET BULLETIN 65 SUPPLEMENT C FOR HANDHELD SCANNER MODEL: FALCON 4410 & 4420 FCC ID: U4SRSB REPORT NUMBER: 07U11195-1, REVISION B ISSUE DATE: AUGUST 14, 2007 Prepared for DATALOGIC MOBILE, INC. 1505 WESTEC DRIVE EUGENE, OREGON, 97402 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET, FREMONT, CA 94538 USA REPORT NO: 07U11195-1B DATE: August 14, 2007 FCC ID: U4SRSB COMPLIANCE CERTIFICATION SERVICES Page: 2 of 33 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issued date Revisions Revised By -- August 6, 2007 Initial issue Sunny Shih B August 14, 2007 Modified WLAN module description T. Hong REPORT NO: 07U11195-1B DATE: August 14, 2007 FCC ID: U4SRSB COMPLIANCE CERTIFICATION SERVICES Page: 3 of 33 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: August 1 and 2, 2007 APPLICANT: ADDRESS: Datalogic Mobile, Inc. 1505 Westec Drive, Eugene, Oregon, 97402 USA FCC ID: MODEL: U4SRSB Falcon 4410 & 4420 Note: Falcon 4410 does not include a handle while Falcon 4420 does. DEVICE CATEGORY: EXPOSURE CATEGORY: Portable Device General Population/Uncontrolled Exposure Handheld Scanner is tested for SAR which includes WLAN module Summit Data Communications FCC ID: TWG-SDCCF10G and Bluetooth Module FCC ID: QOQWT12. Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11g Frequency Hopping Spread Spectrum (FHSS) for Bluetooth module Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] Collocation SAR Values [1g_mW/g] FCC 15.247 2412 - 2462 0.079 0.055 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Std. C95....

Contact Information

Applicant

NEAL XIE(SALES MANAGER)

[email protected]86-755-29633980Fax: 86-75527333560

Test Firm

Electronics Testing Center, TaiwanWill Yauo

[email protected]886-3-3280026Fax: 886-3-3280034

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	401.00 µW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.

Test Setup Photos

Date/Time: 8/1/2007 5:02:11 PM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2;Serial: D2450V2 - SN:706 Communication System: CW - 2450 MHz;Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 2.02 mho/m; ε r = 54.6; ρ = 1000 kg/m 3 Phantom section: Flat Section Room AmbientTemperature: 23.0deg. C; Liquid Temperature: 22.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and witha peak SAR value greater than 0.0012W/kg - Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 4/24/2007 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 11/16/2006 - Phantom: Flat Phantom ELI4.0; Type: QDOVA001BA; Serial: SN:1003 - Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 d=10mm, Pin=250mW/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 15.4 mW/g d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 87.9 V/m; Power Drift = -0.161 dB Peak SAR (extrapolated) = 27.3 W/kg SAR(1 g) = 13.7 mW/g; SAR(10 g) = 6.42 mW/g Maximum value of SAR (measured) = 15.3 mW/g 0 dB = 15.3mW/g Date/Time: 8/1/2007 5:12:56 PM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:706 Communication System: CW - 2450 MHz; Frequency: 2450 MHz;Duty Cycle: 1:1 d=10mm, Pin=250mW/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 16.5 mW/g Date/Time: 8/2/2007 8:23:40 AM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2;Serial: D2450V2 - SN:706 Communication System: CW - 2450 MHz;Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.96 mho/m; ε r = 52; ρ = 1000 kg/m 3 Phantom s...
