APPLICANT: ACTIVE WAVE INC. FCC ID: VJRTAG-141-145 EXTERNAL PHOTOS: EXERNAL – TOP VIEW – JUMBO TAG EXERNAL – BOTTOM VIEW – JUMBO TAG EXTERNAL TOP VIEW – CREDIT CARD TAG (FIXED BATTERY) EXTERNAL – BOTTOM VIEW – CREDIT CARD TAG (FIXED BATTERY)
APPLICANT: ACTIVE WAVE INC. FCC ID: VJRTAG-141-145 LABEL LOCATION LABEL LOCATION – JUMBO TAG LABEL LOCATION - CREDIT CARD TAG
CREDIT CARD TAG AND JUMBO TAG FCC ID: VJRTAG-141-145 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
APPLICANT: ACTIVE WAVE INC. FCC ID: VJRTAG-141-145 INTERNAL PHOTOS: COMPONENT VIEW - JUMBO TAG COMPONENT VIEW – CREDIT CARD TAG (HAS FIXED BATTERY) SOLDER VIEW – JUMBO TAG SOLDER VIEW – CREDIT CARD TAG (WITH FIXED BATTERY)
ACTIVE WAVE INC. FCC ID: VJRTAG-141-145 OCCUPIED BANDWIDTH PLOT CALCULATION OF DUTY CYCLE The period of the pulse train is determined by observing it on an oscilloscope or a spectrum analyzer with zero (0) frequency span. A plot is then made of the pulse train with a sweep time of 100 milliseconds. This sweep determines the duration of the pulse train. This sweep allows the determination of the number of and type of pulses, i.e. long & short. Plots are then made showing the duration of each type of pulse and its duration. From the 100 ms plot, the number of a given type of pulse is then multiplied by the duration of that type pulse. This allows the calculation of the amount of time the DUT is on within 100 ms. If the pulse train is longer than 100 ms then this number is multiplied by 100 to determine the percentage “ON TIME”. If the pulse train is less than 100 ms the total on time is divided by the length of the pulse train and then multiplied by 100 to determine the percentage “ON TIME”. The average field strength is determined by multiplying the peak field strength by the percent “ON TIME” in dB’s. Duration of all long pulse = Duration of all short pulses = Total on time = 26.6 ms The period = 100 ms dB = 20*log(ON TIME)/PERIOD dB = 20*log(26.6/100) dB = 11.5 dB In this case the whole pulse train is considered on time and the period is taken as 100ms. The manufacturer considers this worst case.
EMI Research and Development Laboratory Department of Electrical Engineering Florida Atlantic University 3998 FAU Blvd., Suite 310 Boca Raton, Flroida 33431 (561) 338-1650 FCC PART 15.249 TEST REPORT Applicant ACTIVE WAVE, INC. Address 902 CLINT MOORE ROAD SUITE 118 BOCA RATON, FL 33487 FCC ID VJRTAG-141-145 Product Description CREDIT CARD TAG AND JUMBO TAG READER Date Sample Received JULY 18, 2005 Date Tested AUGUST 24, 2005 Tested By RAYMOND AINA Approved By VICHATE UNGVICHIAN Test Results PASS FAIL FAU EM I R&D LAB EMI Research and Development Laboratory Department of Electrical Engineering Florida Atlantic University 3998 FAU Blvd, Suite 310 Boca Raton, Florida 33431 (561) 338-1650 Technical Report No. 05-041-9 "EMI Evaluation of the Active Wave Credit Card Tag to FCC Part 15 Unintentional Radiators, Class A, Radiated Emission Requirements and Intentional Radiators, Section 15.249 Performed: 18 July – August 24, 2005 Customer: Active Wave, Inc. Attn: Arnold Banks 902 Clint Moore Road, Suite 118 Boca Raton, FL 33487 Company Official responsible for product(s) tested: _______________________________ Arnold Banks, Engineer 561-999-9423 Test Performed and Reported By: _______________________________ Raymond Aina, BSEE, BSME FAU EMI R&D Laboratory Approved by: ________________________________ Vichate Ungvichian, Ph.D., P.E. Director, FAU EMI R&D Laboratory 2129.01 Technical Report 05-041-9 Technical Report 05-041-9 2 1. INTRODUCTION The Active Wave Credit Card Tag is a transceiver, which is capable to transmit at 916.5 MHz and receive at 433.92 MHz via an internal antenna. The unit was powered by a 3-volt Lithium Battery (Model 2032). Evaluation results reported herein apply only to the specific items of equipment, configurations (including software and unit operation), and procedures supplied to the Florida Atlantic University EMI Research Lab by Active Wave, Inc. under the test conditions listed herein. 2. OBJECTIVE This evaluation was performed to verify the confo...
4.2.2 RADIATED EMISSIONS The Active Wave Credit Card Tag was set up on a wooden turntable 80 centimeters above the ground plane of the FAU 3-m Semi-anechoic chamber, which is an FCC listed and A2LA registered site. The unit was programmed to operate in a receiving mode for Section 15.109 (b). For an intentional radiator, Section 15.245 (b), the unit was programmed to transmit at 916.5 MHz. Photographs 1 and 2 show the set up used during the radiated emissions testing. PHOTOGRAPHS 1 & 2: RADIATED EMISSION TEST SETUP Technical Report 05-041-9 5
ActiveWave Inc. Active RFID Reader Service Manual 1 Service Manual for Active RFID Credit card & Jumbo Tag Version: 2.00 ActiveWave, Inc. 902 Clint Moore Road Suite 118 Boca Raton, FL 33487 Tel: 561.999.9423 Fax: 561.999.9428 www.activewaveinc.com ActiveWave Inc. Active RFID Reader Service Manual 2 Table of Contents 1 Introduction...................................................................................................................... 4 2 Product Overview ............................................................................................................ 4 2.1 CardTag.....................................................................................................................5 2.2 CompactTag .............................................................................................................. 6 2.3 MiniTag.....................................................................................................................7 2.4 WristbandTag............................................................................................................ 8 2.5 JumboTag.................................................................................................................. 9 3 Part Numbers .................................................................................................................10 4 Troubleshooting Guide .................................................................................................. 12 5 Dismantling the Tag....................................................................................................... 13 6 Re-assembly Instructions ............................................................................................... 13 7 Preparing for First Time Use ......................................................................................... 13 8 Testing............................................................................................................................ 16 9...
Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong Phone: 852-27908778 Fax: 852-23436151 E-mail: [email protected] AGENCY AUTHORIZATION LETTER FCC ID: MVAHP4390-001R Date: Sep 14, 2007 To whom it may concern: We, the undersigned, hereby authorize SHENZHEN HUATONGWEI INTERNATIONAL INSPECTION CO., LTD of China to act on our behalf, as our agent in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification, Any act carried out by SHENZHEN HUATONGWEI INTERNATIONAL INSPECTION CO., LTD within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely,
UNI-ART PRECISE PRODUCTS LTD Address: 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Uni-Art Precise Products Ltd. would like the following documents regarding this submission for FCC ID: MV AHP4390-001R to be kept confidential. 1. Document. CONF APPENDIX 1 Block Diagram.PDF/CONF APPENDIX 2 Schematic.PDF/CONF APPENDIX 3 Theory of Operation .PDF 2. Repeat above format for each item requested. CONF APPENDIX 1 Block Diagram .PDF/CONF APPENDIX 2 Schematic.PDF/CONF APPENDIX 3 Theory of Operation .PDF The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public.
No. 5-22, Ruei-Shu Valley,Ruei-Ping Tsuen, Lin-Kou · Taipei · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 700.00 µW |
