VU3-COMMPASS457JTECH PAGER

1 Pager and Charger Guide Part Number 321032B4 Premises Pager System ® CommPass ® Pagers GuestPass ™ Pagers MediPass ™ Pagers ShopperPass ™ Pagers 3 4 3 4 3 4 7 3 4 1 8 2 Introduction: Congratulations on your purchase of the JTECH Paging System. Please take a few minutes to review this manual prior to installing and operating your system. Please inspect the System upon receipt. If the contents appear to be damaged, notify the shipper immediately to file a claim and notify JTECH Customer Care. If any component is missing, please contact JTECH Customer Care. If you have any questions or need assistance, please call JTECH Customer Care at 800-321-6221 or 561-997-0772, option 6. CommPass Pager System Components: Pager Certifications: FCC statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment. RSS-Gen: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. AC Power Cord Jumpers Pager Certifications Components Introduction CommPass Pager with Standard Insert 3 2.4 A or 7.3A (Optional) Power Adapter Charger with Key Attached Mounting 3 Pager Dimensions/Weight: LxWxH 5.4x 2.3x 0.9” (137x58x23mm) Weight 3.5oz (99gm) Charger Dimensions/Weight: LxWxH 7.3x 6.9x 13.1” (184x176x333mm) Weight (Empty) 6.6lbs (3.0Kg) Weight (With 20 Pagers) 11.0lbs (5.0Kg) Multiple Chargers: A single Charger can hold up to 20 Pagers. Combine two or three Chargers using the optional Jumpers and 7.3A Power Adapter. Mounting Chargers: Chargers can be wall or counter top mounted using the supplied Mounting Plate. Wood screws are include for table or shelf mounting. If mounted to a shelf or table, the four rubber feet on the bottom of the Charger must be removed. Wall anchor hardware is user supplied. 3 W L H Mounting Chargers Multiple Chargers Pager and Charger Dimensions/Weight W H L 4 Connecting Power: 1. Insert the Power Adapter plug into the jack at the bottom of the Charger. 2. Connect the Power Adapter to the Power Cord. 3. Plug the Power Cord into a 120VAC outlet. 4. The green LED on the Charger will light (ON). 5. Once the Charger is ON, the Pagers can be inserted. Power Adapter Plug Charger Jack 120VAC Outlet Charging Rack Adapter Power Cord Connecting Power to the Charger 5 Charging and Storing Pagers Charging Pagers Charging Pagers: Pagers are turned OFF for shipment from JTECH. When first received, Pagers are to be charged for a minimum of 3 hours prior to use. This first charge will also turn ON the Pagers. To charge: 1. Insert Pagers into the empty Charger locations. 2. Once in the powered (ON) Charger, each Pager’s LED will light: 3. The LED color indicates charging condition. Flashing yellow light = Battery charge very low. Charge needed. Do not use the Pager. Solid yellow light = Charge Needed. Solid green light = OK to use. The charging system is two stage, with a fast initial charge and then a final maintenance charge. Pagers in use and returned to the Charger within 24 hours will fully charge within three hours. If not returned within 24 hours, charging time of up to eight hours may be required to fully charge batteries. Charging and Storing Pagers: To maintain maximum battery capacity, store Pagers in the powered (ON) Charger. If Pagers are left uncharged for more than 4 days, it is recommended to disconnect the batteries until their next use. See “Replacing the Battery” on page 10 for instructions. If left uncharged for extended periods of time, Pager batteries can damage beyond repair and will need to be replaced. When charged and stored properly, a battery life of 18-24 months can be expected before replacement is suggested. 1 0 9 8 7 6 5 4 3 2 1 2 0 1 9 1 8 1 1 6 1 5 1 4 1 3 1 2 1 1 1 9 8 7 6 5 4 3 2 1 2 1 1 1 1 1 1 1 1 1 6 Paging Using a Desktop Transmitter: 1. Remove the Pager you wish to page from the Charger. 2. The Pager will flash and vibrate to confirm it is ready for use. 3. The Pager LED in the front of the Pager will continue to flash every 3-4 seconds to confirm the Pager is ON and ready to accept a page. 4. Enter the number of the Pager you wish to page on the Transmitter or Remote Keypad. 5. Press # to send the page. Press the # or SEND button if using an IntelFlex Desktop Transmitter. 6. The XMIT light on the Transmitter will turn ON, confirming the page is being sent. If using a Remote Keypad, the Keypad XMIT light does not ON. 7. The Pager will vibrate, flash tone or speak as required. 8. See “Enter Pager #” Menu Functions in your Transmitter manual for more information. Paging Using a Desktop Transmitter 3 3 3 3 3 7 1 6 1 5 6 5 1 4 3 3 3 7 7 1 6 1 5 6 5 1 4 5 Paging Using a 8205 or 8214 SmartAlert with RS232 and Telephone Transmitter Paging using the Telephone: 1. Remove the Pager you wish to page from the Charger. 2. The Pager will flash and vibrate to confirm it is ready for use. 3. The Pager charge LED will continue to flash, confirming it is ready to receive a page. 4. Pick up the telephone and listen for the dial tone. 5. Dial the tel…

Text truncated - open the document above for the full version.

Page 1 of 2 Type Designation: Report Number: Fig. 1: External view Fig. 2: External view Page 2 of 2 Type Designation: Report Number: Fig. 3: External view

289-53161XN BOTTOM LABEL 粘贴位置 舊FCC LABEL 粘贴位置 舊FCC LABEL 粘贴位置 舊FCC LABEL 粘贴位置

Page 1 of 2 Type Designation: Report Number: Fig. 1: Internal view Fig. 2: Internal view Page 2 of 2 Type Designation: Report Number: Fig. 3: Internal view

Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 2 von 19 Page 2 of 19 TEST SUMMARY 5.1.1 CONDUCTED EMISSION RESULT: Passed 5.2.1 RADIATED EMISSION RESULT: Passed Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 3 von 19 Page 3 of 19 Contents 1. GENERAL REMARKS......................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS.......................................................................................... 4 2. TEST SITES...................................................................................................................... 4 2.1 TEST FACILITIES............................................................................................................... 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS............................................................... 5 2.3 TRACEABILITY.................................................................................................................. 5 2.4 CALIBRATION................................................................................................................... 5 2.5 MEASUREMENT UNCERTAINTY.......................................................................................... 6 2.6 LOCATION OF ORIGINAL DATA.......................................................................................... 6 2.7 STATUS OF FACILITY USED FOR TESTING........................................................................... 6 3. GENERAL PRODUCT INFORMATION.................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE........................................................................... 7 3.2 RATINGS AND SYSTEM DETAILS........................................................................................ 7 3.3 INDEPENDENT OPERATION MODES.................................................................................... 8 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS....................................................... 8 3.5 SUBMITTED DOCUMENTS.................................................................................................. 8 4. TEST SET-UP AND OPERATION MODES.............................................................................. 9 4.1 PRINCIPLE OF CONFIGURATION SELECTION....................................................................... 9 4.2 TEST OPERATION AND TEST SOFTWARE............................................................................ 9 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT.......................................................... 9 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE......................................................... 9 4.5 TEST SETUP DIAGRAM.................................................................................................... 10 5. TEST RESULTS E M I S S I O N .................................................................................... 12 5.1 EMISSION IN THE FREQUENCY RANGE UP TO 30 MHZ....................................................... 12 5.1.1 Conducted Emission ..................................................................................................................12 5.2 EMISSION IN THE FREQUENCY RANGE ABOVE 30 MHZ...................................................... 13 5.2.1 Radiated Emission .....................................................................................................................13 6. PHOTOGRAPHS OF THE TEST SET-UP.............................................................................. 14 7. LIST OF TABLES............................................................................................................. 19 8. LIST OF PHOTOGRAPHS.................................................................................................. 19 Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 4 von 19 Page 4 of 19 1. General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix 1: Test Result 2. Test Sites 2.1 Test Facilities FCC Registration No.: 752051 Test site Industry Canada No.: 5077A The tests at the test site have been conducted under the supervision of a TÜV engineer. Shenzhen Accurate Technology Co., Ltd. F1, Bldg. A, Changyuan New Meterial Port, Keyuan Rd., Science & Industry Park Nanshan District, Shenzhen 518057, P.R. China Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 5 von 19 Page 5 of 19 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment Manufacturer Type S/N Calibrated until Conducted Emission Test Receiver Rohde & Schwarz ESCS30 100307 2013-01-07 Artificial Mains Network Schwarzbeck NLSK8126 8126431 2013-01-07 Radiated Emission Spectrum Analyzer Agilent E7405A MY45115511 2013-01-07 Test Receiver Rohde & Schwarz ESCS30 100307 2013-01-07 Bilog Antenna Schwarzbeck VULB9163 9163-323 2013-01-07 Loop Antenna Schwarzbeck FMZB1516 1516131 2013-01-07 Horn Antenna Schwarzbeck BBHA9120D 9120D-655 2013-01-07 50 Coaxial Switch Anritsu Corp MP59B 6200506474 2013-01-07 Pre-Amplifier Rohde & Schwarz CBLU11835 40-01 3791 2013-01-07 2.3 Traceability All measurement equipment calibrations are traceable to NIST or where calibration is performed outside the United States, to equivalent nationally recognized standards organizations. 2.4 Calibration Equipment requiring calibration is calibrated periodically by the manufacturer or according to manufacturer’s specifications. Additionally all equipment is verified for proper performance on a regular basics using in house standards or comparisons. Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 6 von 19 Page 6 of 19 2.5 Measurement Uncertainty The estimated combined standard uncertainty for radiated emissions and conducted emis…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 12 von 15 Page 12 of 15 6. Photographs of the Test Set-Up Photograph 1: Set-up for Conducted Emission, model 450163 Photograph 2: Set-up for Radiated Emission, below 1GHz, model 450163 Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 13 von 15 Page 13 of 15 Photograph 3: Set-up for Radiated Emission, above 1GHz, model 450163 Photograph 4: Set-up for Conducted Emission, model 450180 Produkte Products Prüfbericht - Nr.: Test Report No. 17027314 001 Seite 14 von 15 Page 14 of 15 Photograph 5: Set-up for Radiated Emission, below 1GHz, model 450180 Photograph 6: Set-up for Radiated Emission, above 1GHz, model 450180
