VV6WM62GSM/GPRS/EDGE/WCDMA/HSDPA Data Modem

HSDPA MODEM USER Manual 2 Index Introduction .....................................................................................3 Main interface introduction ..............................................................5 Entrance to main interface ..............................................................8 Connect to the Internet....................................................................9 SMS Service .................................................................................13 Contacts ........................................................................................16 Settings .........................................................................................19 FAQ ...............................................................................................25 FCC Part 15 statement .................................................................29 3 Introduction This PC Suite is designed to enable users to access the Internet via the GPRS / EDGE / UMTS / HSDPA networks. With this application, users can access the following functions: y Wireless Internet connection y An SMS service y A contact manager y Settings 1. Internet connection This application will ensure easy connection to the Internet. Users will be able to enjoy a high-speed data service by clicking on the button in the main window or by clicking directly on the device. Users can also access the connection status in the tray bar, including connection time and volume of data transferred. 2. SMS service With this PC Suite, users can use the following functions: 4 y New SMS y Edit SMS y Group SMS y Reply y Forward y Save number y Export to PC y Delete 3. Contacts It contains 2 memories: PC and (U)SIM card. It supports the following functions: y New y Edit y Send SMS y Export vCard file y Export text file y Copy to PC and (U)SIM card y Delete y Search 5 4. Settings This contains the following settings: y Network mode y Network band y Network selection y Request PIN y Modify PIN y Connection profile settings y Diagnostics y SMS settings y System settings y Help y About Main interface introduction 1. Function icon /: Connect / disconnect to Internet : Access the SMS service window 6 : Access the contact management window : Set parameters of the PC suite 2. Status bar information Current network operator name will be displayed on the status bar. y If no device is found, ”No device” is displayed y If no SIM card is found, “No (U)SIM card” is displayed y If the SIM card is invalid, “Invalid (U)SIM card” is displayed y During Initialization, ”Initializing” is displayed y If searching for the network, “Searching” is displayed y If no network is found,” No service” is displayed 3. Signal status bar : Indicates the signal strength of the current network Network type: is displayed when GSM/GPRS is connected is displayed when UMTS is connected Support data service: is displayed if HSDPA is available is displayed if EDGE is available 7 Nothing is displayed if GPRS support is available : Indicates that there is an unread SMS in main interface : Indicates that the (U)SIM card memory is full 4. Tray Icon If you click on , the main window is closed and the tray icon will appear in the tray bar. The main window can be reopened by double clicking on the tray icon. 5. System tray menu y Open: Opens the main window y Connect/Disconnect: Connects/disconnects to the Internet y Statistics: Displays connection status information y Contacts: Opens contact management window y SMS: Opens SMS service window y About: Application version y Exit: Exits the application 8 Entrance to main interface y The application runs automatically and the main window will pop up when a device is connected. Users can also access and run the application from the <Start> menu. y If the PIN code is enabled, please enter the correct PIN code in the entry field, and click on <OK>. Users may try only 3 times to enter the correct PIN code; after three incorrect attempts, the (U)SIM card will be blocked. y A PUK dialog box will then be displayed asking the user to enter the right PUK code. Click on <OK>, and a default PIN code will be retrieved. If the user fails to input the correct PUK code after 10 attempts, he should contact the operator. y If the PIN code is correct, the application will be launched and all functions can be used. 9 Figure1: Main window Connect to the Internet 1. Connecting with the default log-on profile If you want to connect to the Internet without setting any user-defined or predefined profiles, press . The default connection profile will be used in accordance with your (U)SIM card. Connecting 10 y Click on from the main window; y Wait several seconds until the connection is established; y Once you are connected, will change into and the connection information window will appear in the tray bar. Disconnecting Click on from the main window to disconnect from the Internet. 2. Connecting with a user-defined log-on profile Click on and select the <Connection settings> menu to open the profile setting window. Adding a new connection profile Click on <Add> to open a new connection profile window: 1. If <New profile> is selected y Click on <Next>, and the edit settings window will pop up; y Enter any profile such as APN; y Click on <Finish> to add it to the available profile list. 2. If <Choose from predefined list> is selected y Click on <Next>, and a predefined list will pop up as shown below; y Select one item in the predefined profile list; 11 y Click on <Finish> to add it to the available profile list. Note：Users may obtain APN information from their operator. Setting a default connection profile 1. Select one item from the list of available connection profile(s); 2. Click on <Set default> to set it as the default profile; 3. Click on to start the connection using the specified profile. 3. Connection status information A connection status window will be displayed in the tray bar as soon as you are connected. Figure 1: Statisti…

Text truncated - open the document above for the full version.

Chris Harvey From: wubinyu [[email protected]] Sent: Thursday, December 27, 2007 12:28 AM To: [email protected] Cc: 'Lucy Tsai'; 'Yang Lixia' Subject: RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Attachments: 14.Change and Modification.rar 12/28/2007 Dear Chris, Many thanks for your comments; please see our answer and attached documents. Looking forward to hearing from you soon. Thanks and Best regards, Beverley Wu -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: 2007Äê12ÔÂ21ÈÕ 1:56 To: [email protected] Cc: [email protected] Subject: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Dear Beverly (Bin Yu) Wu, You are listed as the Contact for the above referenced TCB application. The following item(s) need(s) to be resolved before the review can be continued: 1. In order for someone other than the applicant to submit an application for the applicant, they must be authorized by the applicant in writing. Please provide the Agent Authorization letter from Longcheer to you at ritt 7 Layers China. <Longcheer> please refer to <1_power of attorney>. 2. The TCB Application form and test report document the FCC ID: VV6WM62 where the FCC Label shows FCC ID: VV6-WM62 (contains a '-'). Please determine the correct FCC ID for this device and submit revised exhibit(s) as needed. <Longcheer> please refer to <2_Phone label and location>. 3. The Users Manual has the following statement which is not in accordance with FCC Requirements: For body worn operation, this Data Card has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 20 cms from the body (length of the data cable in accessory). Use of other accessories may not ensure compliance with FCC RF exposure guidelines This statement is misleading because this device should not be Body-worn. Please remove this statement and replace it with a notice to the User to maintain at least 20cm to this device and its antenna. <Longcheer>please refer to <3_revised user manual>. 4. The Internal Photos show both sides of the PC Board with all components, but there are no photographs of the inside of the enclosure, the RF Shields (shown in the RF test report), the Internal Antenna and the general construction of the inside of this device. Please update the Internal Photographs to include these items. <Longcheer> please refer to <4_revised internal photos> 5. This device, while being a transmitter, is also classified by the FCC as a Computer Peripheral (USB connection to Computer). FCC 15.101 requires that Computer Peripherals be approved by either FCC Declaration of Conformity (DoC) or Certification. There is no FCC Logo on this label (which would be required for DoC approval) and there is no associated Certification application submitted for the Computer Peripheral portion of this device. Please indicate whether this device is DoC or Certification approved for the Computer Peripheral portion and provide the updated exhibits accordingly. If this is DoC approved, please provide the name and location of the laboratory used for this DoC Approval. 6. The RF Test Report submitted documents that this was tested according to FCC Part 22 (Oct. 2002 edition) and Part 24 (Oct 1997 edition). The FCC requires that the testing on Licensed Service devices be performed in accordance with the Measurement Procedures of EIA/TIA-603B or C (especially the substitution method). Please review all the documents above, determine if the testing was performed in accordance with EIA/TIA-603 and if the device complies with the current FCC Rules and update the exhibits accordingly. 7. The FCC has released measurement guidelines for 3G devices in their 3G SAR guidance document (can be found online at http://gullfoss2.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?id=26930&sw itch=P). Please review this document in detail and include all required specific references to indicate that this device was tested correctly (include specific references to the setup, power control, 8. The Antenna Details exhibit lists the gain for the 850MHz and 1900MHz bands (but does not contain any measurement plots or data) which is different than the gain details used in the MPE calculation exhibit. Also, the MPE calculation seems to list different RF output power and antenna gain for different modulations in the same band. Please explain and correct this discrepancy. 12/28/2007 <Longcheer> please refer to the revised <8_ Antenna details> 9. The test photos show the computer connected to this device for testing, but the computer is not listed in the test report. Please update the test report accordingly. 10. Please provide the Spectrum Analyzer plots for the measurements performed in this test report and the screen-shots (showing settings) CMU 200 settings for each tested mode. 11. This device is described as having GSM/GPRS(Class12)/EDGE/WCDMA/UMTS/HDSPA/FDD(II and V), yet data has been supplied only for GPRS and WCDMA modes without any explanation. Please justify the modes selected or provide additional data as needed. 12. The FCC application form indicates that the China Telecommunication Technology Lab is accredited to ISO Guide 17025 by DaTech, where the test report indicates the accreditation is by CNAL. Please clarify and provide the Accreditation Certificate and scope. <CTTL> please refer to < 9_DATech certificate and scope_ CTTL> 13. The FCC requires listing each band and modulation by the center frequency of the lowest and highest channel, RF Power, Frequency Tolerance, Emission Designator (for each unique bandwidth and modulation). Please provide a table showing this information for each band and modulation and I can update the TCB application form for you. <Longcheer> The items indicated above must be submitted before processing can continue on th…

Text truncated - open the document above for the full version.

Chris Harvey From: yanglixia [[email protected]] Sent: Thursday, January 03, 2008 8:29 AM To: 'Chris Harvey' Cc: 'Lucy Tsai'; [email protected]; 'wubinyu' Subject: RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Attachments: wm62.rar 1/3/2008 Dear Chris: I am Yang lixia from ritt7layers. Beverley is on holiday, so I contact with you. For the WM62 FCC comments of 5, 6, 7, 9, 10&11, the test lab performs the test according to your comments. Please refer to the test report in the attachment. Because the lab¡ ̄s director is on business, so the report is no signature, But we hope you can review the report and feedback the comments if there have to us ASAP. The certificate deadline customer required is on Jan.8, 2008; if we can get your comments earlier we can have the time to revise it. Please treat this project as a special one. We will submit the report with signature ASAP. Best Regards Yang Lixia ritt7layers From: wubinyu [mailto:[email protected]] Sent: 2007Äê12ÔÂ29ÈÕ 9:38 AM To: 'Chris Harvey' Cc: 'Lucy Tsai'; 'Yang Lixia'; [email protected] Subject: RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Hi Chris, Thank you for your reply. To answer questions 5,6,7,9,10&11, the test lab need perform some testing. Test report will ready to submit around 3 rd January. If there are some more comment concern about questions 1,2,3,4,8,12 and 13, please let me know. Thanks a lot. Happy New Year! Beverley Wu From: Chris Harvey [mailto:[email protected]] Sent: 2007Äê12ÔÂ28ÈÕ 21:58 To: 'wubinyu' Cc: 'Lucy Tsai'; 'Yang Lixia'; [email protected] Subject: RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Thank you for your response; however, you have not responded to questions # 5, 6, 7, 9, 10 & 11. Please respond completely to all questions so this application review can be continued. Best regards, Chris Harvey From: wubinyu [mailto:[email protected]] Sent: Thursday, December 27, 2007 12:28 AM To: [email protected] Cc: 'Lucy Tsai'; 'Yang Lixia' Subject: RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Dear Chris, Many thanks for your comments; please see our answer and attached documents. Looking forward to hearing from you soon. Thanks and Best regards, Beverley Wu -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: 2007Äê12ÔÂ21ÈÕ 1:56 To: [email protected] Cc: [email protected] Subject: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#2 Dear Beverly (Bin Yu) Wu, 1/3/2008 You are listed as the Contact for the above referenced TCB application. The following item(s) need(s) to be resolved before the review can be continued: 1. In order for someone other than the applicant to submit an application for the applicant, they must be authorized by the applicant in writing. Please provide the Agent Authorization letter from Longcheer to you at ritt 7 Layers China. <Longcheer> please refer to <1_power of attorney>. 2. The TCB Application form and test report document the FCC ID: VV6WM62 where the FCC Label shows FCC ID: VV6-WM62 (contains a '-'). Please determine the correct FCC ID for this device and submit revised exhibit(s) as needed. <Longcheer> please refer to <2_Phone label and location>. 3. The Users Manual has the following statement which is not in accordance with FCC Requirements: For body worn operation, this Data Card has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 20 cms from the body (length of the data cable in accessory). Use of other accessories may not ensure compliance with FCC RF exposure guidelines This statement is misleading because this device should not be Body-worn. Please remove this statement and replace it with a notice to the User to maintain at least 20cm to this device and its antenna. <Longcheer>please refer to <3_revised user manual>. 4. The Internal Photos show both sides of the PC Board with all components, but there are no photographs of the inside of the enclosure, the RF Shields (shown in the RF test report), the Internal Antenna and the general construction of the inside of this device. Please update the Internal Photographs to include these items. <Longcheer> please refer to <4_revised internal photos> 5. This device, while being a transmitter, is also classified by the FCC as a Computer Peripheral (USB connection to Computer). FCC 15.101 requires that Computer Peripherals be approved by either FCC Declaration of Conformity (DoC) or Certification. There is no FCC Logo on this label (which would be required for DoC approval) and there is no associated Certification application submitted for the Computer Peripheral portion of this device. Please indicate whether this device is DoC or Certification approved for the Computer Peripheral portion and provide the updated exhibits accordingly. If this is DoC approved, please provide the name and location of the laboratory used for this DoC Approval. 6. The RF Test Report submitted documents that this was tested according to FCC Part 22 (Oct. 2002 edition) and Part 24 (Oct 1997 edition). The FCC requires that the testing on Licensed Service devices be performed in accordance with the Measurement Procedures of EIA/TIA-603B or C (especially the substitution method). Please review all the documents 1/3/2008 above, determine if the testing was performed in accordance with EIA/TIA-603 and if the device complies with the current FCC Rules and update the exhibits accordingly. 7. The FCC has released measurement guidelines for 3G devices in their 3G SAR guidance document (can be found online at http://gullfoss2.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?id=26930&sw itch=P). Please review this docume…

Text truncated - open the document above for the full version.

Chris Harvey From: wubinyu [[email protected]] Sent: Friday, January 04, 2008 9:20 AM To: [email protected] Cc: [email protected]; [email protected]; 'Lucy Tsai'; 'liuwei' Subject: WM62 update 2-1 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Attachments: WM62 update2 20080104.zip 1/4/2008 Dear Chris, Thanks for your comments. Please see attached test report after modification. As the files are too big, I send by to mails, this is 2-1. It is a very urgent case, could you please review the test report, if there is any question, please let us know ASAP. Thanks in advance for your support. Have a good weekend. Best regards, Beverley -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: 2008 Äê1ÔÂ4ÈÕ 6:17 To: [email protected] Cc: [email protected]; [email protected]; [email protected] Subject: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Dear Beverly (Bin Yu) Wu (copy Yang Lixia) I have received your response to my second notice and still find significant errors in the application. I have not completed this review and have found the following items that need to be addressed: 1. EDGE emission designator should be G7W (not GXW) <CTTL> Please ref Test report < I07GE6474-FCC-EMC1> and < Attachment to I07GE6474-FCC-PART15> 2. FCC PC Peripheral Test Report listed 15.209 and without AC line conducted test data. The test setup is not complied with ANSI C63.4 Annex E to have at least two different I/O port connected during the tests. Also, a Certification application (as a composite device) must be submitted since this device was tested in a laboratory that does not qualify for DoC testing. DoC route is not an option for CCTL. They need to retest 15.109/15.107 with proper test setup. <CTTL> Please ref test report < I07GE6474-FCC-PART15> 3. Part 22/24 test report did not specify test procedure used. I think you using EU procedure for ERP/EIRP tests which is not acceptable to FCC. <CTTL> We add the information in the test report < I07GE6474-FCC-EMC1>, test performed was based on TIA/EIA-603-B. 4. In regards to 3G policy, you were provided a guideline to do the base line investigation on the output power. This data must be provided in order to comply with the FCC 3G policies. If you can not provide CMU 200 screen shots, you can provide a detailed text description on the CMU 200 setting. <CTTL> Please ref <Worse Case Evaluation per FCC 3G SAR Evaluation Criteria _WM62>, the CMU 200 and Agilent 8960 screen shots are in < Attachment to I07GE6474-FCC-EMC1> The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] 1/4/2008

Chris Harvey From: Mike Kuo [[email protected]] Sent: Tuesday, January 08, 2008 9:43 PM To: Chris Harvey Subject: RE: mail 2-2 RE: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Importance: High 1/8/2008 Hi Chris: Can you work on the grant condition first? Three people from 7 layer called me. They have to have grant issued today. I informed them they have to confirm the file before we can issue the grant. They said will provide confirmation within 1 hour. At the meantime, please work on the grant condition. Once you received thei r confirmation, please send me evaluation report and I will get back to you right away. I will do the file upload with your TC confirmation number. Best Regards Mike Kuo Compliance Certification Services 47173 Benicia Street Fremont, CA 94538 Direct: (510) 771-1105 Fax: (510) 661-0888 Main: (510) 771-1000 e-mail:[email protected] Web Site:www.ccsemc.com From: Chris Harvey [mailto:[email protected]] Sent: Tuesday, January 08, 2008 2:32 PM To: 'wubinyu' Cc: Mike Kuo Subject: RE: mail 2-2 RE: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Beverly, I reviewed this along with Mike Kuo and have the following additional request regarding the test simulator screen shots: 1. Please see the attached revised file and confirm that this is correct. If you can confirm that you used the same setting, please send a revised file to me, then we can use the revised file without needing any more screen shots. The screen shots that you provided did not provide the information that we are looking for. Please contact me if you have any further questions. Best regards, Chris Harvey From: wubinyu [mailto:[email protected]] Sent: Tuesday, January 08, 2008 11:37 AM To: 'Chris Harvey' Subject: RE: mail 2-2 RE: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Thank you Chris! From: Chris Harvey [mailto:[email protected]] Sent: 2008Äê1ÔÂ9ÈÕ 0:25 To: 'wubinyu'; [email protected] Cc: [email protected]; [email protected]; 'Lucy Tsai'; 'liuwei' Subject: RE: mail 2-2 RE: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Beverly, I have received both e-mails with attachments and will start reviewing shortly. Best regards, Chris Harvey From: wubinyu [mailto:[email protected]] Sent: Tuesday, January 08, 2008 11:11 AM To: 'Chris Harvey'; [email protected] Cc: [email protected]; [email protected]; 'Lucy Tsai'; 'liuwei' Subject: mail 2-2 RE: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 This is mail 2-2. Thanks. Beverley From: wubinyu [mailto:[email protected]] Sent: 2008Äê1ÔÂ9ÈÕ 0:06 To: 'liuwei'; 'Chris Harvey'; '[email protected]' Cc: '[email protected]'; '[email protected]'; 'Lucy Tsai' 1/8/2008 Subject: mail 2-1 RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Dear Chris, Please see our respond below. Update file: Folder <20080108_1> 01_Authorization Letter for FCC application(new Jan72008)_FCC Confidentiality Request Send by mail 2-1 Folder<20080108_2> Attachment to I07GE6474-FCC-EMC I07GE6474-FCC-PART15B2 Send by mail 2-1 Folder<20080108_3> I07GE6474-FCC-EMC2 Send by mail 2-2 Could you please check the screen shot first, please send us a feedback. We are waiting in the office. If it still not clear, we will send again. Many thanks. Best regards, Beverley From: Chris Harvey [mailto:[email protected]] Sent: Tuesday, January 08, 2008 12:31 AM To: 'liuwei'; [email protected] Cc: [email protected]; [email protected]; 'Lucy Tsai'; 'wubinyu' Subject: RE: WM62 update 2-2 RE: Longcheer Technology (Shanghai) Co., Ltd., FCC ID: VV6WM62, Assessment NO.: AN07T7436, Notice#3 Here are the current comments on the application. There are still significant issues with this application and it is difficult to tell if the correct testing was performed. You completed the following table, but there are several errors: <Longcheer> Frequency Range Operating Mode Rated RF Power output in watts Frequency tolerance %, Hz ppm Emission designator (see FCC 47 CFR 2.201 and 1/8/2008 You were requested to list the frequency from the center of the lowest channel to the center frequency of the highest channel, but listed something different and the correct Emission Designators. The test report indicates that the Emission Designator of EDGE modulation is 400KG7W. As an example, the report has data for GPRS mode of 824.2 ̈C 848.8 MHz, 29.25 dBm ERP (equals 0.841 Watts ERP) and emission designator 248KGXW. Please complete the table for each modulation, center frequency of low and high channel of operation, measured ERP/EIRP power, and Emission Designator using the measured 99% BW and correct Modulation code. The test report has data for The test report shows test data for channel 128 operating at 823.927856 MHz (page 34 o f 73), which is outside of the allowed FCC band for Pt. 22H. <CTTL>please ref. update test report < Attachment to I07GE6474-FCC-EMC2> The band edge data does not have data for band edge of GPRS channel 128. The information is not consistent in the report, but Channel 128 appears to have a center frequency of 824.2 MHz. The EDGE modulated signal is approximately 400 kHz wide, which would have emissions of significant strength on the band edge of 824.0MHz. The data on pages 15 and 16 of 73 has ¡® band edge¡ ̄ radiated data, with the EUT operating in the center frequency of the band, but also indicates levels that exceed the -13dBm limit stated on page 13. Band edge data should be provided fo r each modulation at the lowest and highest channel of operation in each band, and should i…

Text truncated - open the document above for the full version.

External photos for WM62 Picture 1：The front view of the Sample Picture 2: The back view of the Sample Picture 3: The top view of the sample Picture 4: The bottom of the sample Picture 5: The left view of the sample Picture 6: The right view of the sample.

Internal Photos for WM62 Picture 1: The top view of the sample Picture 2: The back view of the sample Picture 3: the top view of the sample with the RF shield-1 Picture 4: the back view of the sample with the RF shield-2 Picture 5: the antenna of the sample Picture 6: the inside of the enclosure-1 Picture 7: the inside of the enclosure-2

Antenna Details for WM62 Main Antenna: Type: monopole Antenna Gain GSM 850: 1.40dBi GSM 900: 0.68dBi GSM 1800: 3.37dBi GSM 1900: 2.99dBi WCDMA 850: 1.40dBi WCDMA 1900: 3.40dBi WCDMA 2100: 3.26dBi The location of the antennas inside mobile phone is shown below:

MPE calculation for WM62 S = (0.0795 * 10 ^ ((P + G) / 10)) / (d^2) d = MPE distance in cm P = Power in dBm G = Antenna Gain in dBi S = Power Density Limit in mW/cm^2 BANDGAIN(dBi)POWER(dBm)D(cm)S GSM8501.432.5200.48 GSM9000.6832.5200.413 DCS18003.3729.5200.385 PCS19002.9929.5200.353 UMTS21003.2622.8200.08 UMTS19003.422.8200.083 UMTS8501.423200.055

FCC Parts 2, 22, 24 Equipment: WM62 REPORT NO.: I07GE6474-FCC-EMC2 Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 2 of 74 China Telecommunication Technology Labs. ® FCC ID: VV6WM62 Report Date: 2008-1-8 Test Firm Name: China Telecommunication Technology Labs Registration Number: 840587 Statement The measurements shown in this report were made in accordance with the procedures described on test pages. All reported tests were carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Parts 2, 22, and 24. The sample tested was found to comply with the requirements defined in the applied rules. FCC Parts 2, 22, 24 Equipment: WM62 REPORT NO.: I07GE6474-FCC-EMC2 Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 3 of 74 China Telecommunication Technology Labs. ® CONTENTS 1 GENERAL INFORMATION ................................................................. 4 1.1 NOTES......................................................................................... 4 1.2 TESTERS....................................................................................... 5 1.3 TESTING LABORATORY INFORMATION...................................................... 7 1.4 DETAILS OF APPLICANT OR MANUFACTURER............................................... 8 2 TEST ITEM ....................................................................................... 9 2.1 GENERAL INFORMATION...........................…

Text truncated - open the document above for the full version.
