Leyant Industry Co. Ltd No. 20, Lane 929, San Feng Rd., FengYuan City, Taichung Hsien420, Taiwan 12/05/2007 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize ETS Product Service Co., Ltd. to act on our behalf in all matters relating to applications for equipment authorization REMOTE CONTROL, (Model No.:AK8200AS, FCC ID: VVP-AK8200AS) including the signing of all documents relating to these matters. Any and all acts carried out by ETS Product Service Co., Ltd. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Name: Mr. KO-KUO HUA Title: QC Manager Company: Leyant Industry Co. Ltd

Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 13 of 22 External Photos Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 14 of 22 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 15 of 22

Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 16 of 22 Internal Photos Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 17 of 22 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 18 of 22 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 19 of 22 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 20 of 22 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Appendix page 21 of 22

of Applicant: Leyant Industry Co. Ltd Address: No. 20, Lane 929, San Feng Rd., FengYuan City, Taichung Hsien 420, Taiwan Tested and Prepared By Taiwan ETS Product Service Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1 A2LA Accredited No.: 1983.02 PTCRB Accredited Type Certification Test House Report No.: W6M20711-8720-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for REMOTE CONTROL Model No.: AK8200AS FCC ID: VVP-AK8200AS Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 1 of 19 TABLE OF CONTENTS 1 GENERAL INFORMATION 2 1.1 NOTES 2 1.2 TESTING LABORATORY 3 1.2.1 LOCATION 3 1.2.2 DETAILS OF ACCREDITATION STATUS 3 1.3 DETAILS OF APPROVAL HOLDER 3 1.4 APPLICATION DETAILS 4 1.5 TEST ITEM 4 1.6 TEST STANDARDS 5 2 TECHNICAL TEST 5 2.1 SUMMARY OF TEST RESULTS 5 2.2 TEST ENVIRONMENT 5 2.3 TEST MODE 5 2.4 TEST EQUIPMENT UTILIZED 6 2.5 GENERAL TEST PROCEDURE 8 3 T EST RESULTS (ENCLOSURE) 9 3.1 TRANSMISSION REQUIREMENTS 10 3.1.1 Limit of Transmission Time 10 3.1.2 Active Time 10 3.2 OUTPUT POWER (FIELD STRENGTH) 11 3.3 OUT OF BAND RADIATED EMISSIONS 12 3.4 TRANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS 13 3.5 SPURIOUS EMISSION RADIATED, TRANSMITTER 14 3.6 CHANNEL BANDWIDTH 16 3.7 ANTENNA REQUIREMENT 17 3.8 DUTY CYCLE 18 3.9 CONDUCTED MEASUREMENT AT (AC) POWER LINE 19 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 2 of 19 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Taiwan ETS Product Service Co., Ltd. Tester: Jan 08, 2008 Jay Chaing Date ETS-Lab. Name Signature Technical responsibility for area of testing: Jan 08, 2008 Steven Chuang Date ETS Name Signature Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 3 of 19 1.2 Testing laboratory 1.2.1 Location OATS No.5-1, Shuang Sing Village, LiShuei Rd., Wanli Township, Taipei County 207, Taiwan (R.O.C.) Company Taiwan ETS Product Service Co., Ltd. 6F, NO. 58, LANE 188, RUEY-KUANG RD. NEIHU, TAIPEI 114, TAIWAN R.O.C. Tel : 886-2-66068877 Fax : 886-2-66068879 1.2.2 Details of accreditation status Accredited testing laboratory A2LA accredited number: 1983.02 FCC filed test laboratory Reg. No. 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1 PTCRB Accredited Type Certification Test House Town: ./. Country: ./. Telephone: ./. Fax: ./. 1.3 Details of approval holder Name: Leyant Industry Co. Ltd Street: No. 20, Lane 929, San Feng Rd., FengYuan City, Town: Taichung Hsien, 420 Country: Taiwan Telephone: (04)25235678 Fax: (04)25260658 Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 4 of 19 1.4 Application details Date of receipt of test item: Nov 30, 2007 Date of test: from Nov 30, 2007 to Jan 07, 2007 1.5 Test item Description of test item: REMOTE CONTROL Type identification: AK8200AS Multi-listing Model No.: ZRA-E30, ZRM-E30, ZRO-E30, ZNA-M90, ZNA-E42, AK8300-AS, ZML-M90S, ZML-90G, ZMI-M90S, ZMI-M90G Brand name: Pacific Multi-listing model number: without Transmitting frequency: 315 MHz Operation mode: simplex Voltage supply: Battery ( 3A*1 ) (If the device is using battery, please check if the device is tested under fresh battery condition.) Highest clock frequency: 315 MHz Antenna type: Copper wire antenna Photos: see Appendix Manufacturer (if applicable) Name: ./. Street: ./. Town: ./. Country: ./. Additional information: ./. Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 5 of 19 1.6 Test standards Technical standard : FCC RULES PART 15 SUBPART B / SUBPART C § 15.231 (a) (2007-09) 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 3 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature: 23 o C Relative humidity content: 20 ... 75 % Air pressure: 86 ... 103 kPa Details of power supply: Battery ( 3A*1 ) 2.3 Test Mode This EUT is the portable device. So the EUT was tested on three different axes. Please see assessment test results as section 3 of this test report. Registration number: W6M20711-8720-C-1 FCC ID: VVP-AK8200AS Taiwan ETS Product Service Co., Ltd. Page 6 of 19 2.4 Test equipment utilized No. Test equipment Type Serial No. Manufacturer Cal. Date Next Cal. Date ETSTW-CE 001 EMI TEST RECEIVER ESHS10 842121/013 R&S 2007/10/15 2008/10/14 ETSTW-CE 002 PREREULATOR MODE DC POWER SUPPLY None None Function Test ETSTW-CE 003 AC POWER SOURCE APS-9102 D161137 GW Function Test ETSTW-CE 004 ZWEILEITER-V- NETZNACHBILDUNG TWO- LINE V-NETWORK ESH3-Z5 840731/011 R&S 2007/10/15 2008/10/14 ETSTW-CE 005 Line-Impedance Stabilisation Network NNBM 8126D 137 Schwarzbeck 2007…
