VVXLM505BLUETOOTH HCI USB MODULE

LM505-M Page 1 of 3 +44(0)207 428 2647 | www.lm-technologies.com | [email protected] Product: LM505 Module Part No: 505-0513 Datasheet Rev 1.0/25-07-12 1 Features • Easily integrated in Embedded Devices • Compatible with Bluetooth v2.1+EDR specification. Backward compatible with Bluetooth 2.0 + EDR devices • Support Maximum Asynchronous Data Rate 3 Mbps • Provide data access via USB 2.0 interface • Low power consumption LM505 USB Module 2 Description LM505 EDR Bluetooth HCI ROM Module is an ideal solution for providing Bluetooth connectivity to embedded devices running an OS with Bluetooth Stack like Embedded Linux with BlueZ support. This is a very small form factor and high performance module which allows you to connect to upto 7 Bluetooth devices simultaneously. The module integrates high performance Bluetooth Radio, Baseband, Link Manager, Host Controller Interface and can be used with embedded Bluetooth Stacks which offers a huge range of Bluetooth profiles for variety of connectivity applications. Due to its small size, high performance, low power consumption and high sensitivity this adapter is ideally suited for Bluetooth connectivity applications where the adapter can fit discreetly into portable devices that have USB interface. Bluetooth HCI ROM USB Module with Broadcom Chip BT v2.1 USB Module • Very small Size (19.7 mm x 10 mm) • Supported on Embedded Linux BlueZ Stack • Stereo Audio supported. VoIP calls over Bluetooth also supported • Interoperable with PDAs, Phones • Class 2 device with 10 m range LM505-M Page 2 of 3 +44(0)207 428 2647 | www.lm-technologies.com | [email protected] 3 Packaging Options 4 General Specification Product: LM505 Module Part No: 505-0513 Datasheet Rev 1.0/25-07-12 1x Bluetooth USB Module Tape and Reel or Tray Part No 505-0513 SpecificationDescription Product NameLM505 Bluetooth HCI USB Module ChipsetBroadcom BCM2046 Bluetooth StandardBluetooth v2.1 + EDR Frequency Band2.4 - 2.4835 GHz ISM Band Modulation MethodGFSK for 1 Mbps, π/4-DQPSK for 2 Mbps, 8-DPSK for 3 Mbps Spread SpectrumFHSS (Frequency Hopping Spread Spectrum) Transfer Rate (Max)3 Mbps enhanced data rate RF Output PowerClass 2 Working Distance10 m - 25 m in open space Rx Sensitivity -80 dBm at 0.1 % BER Input Voltage DC 5V (via USB interface) I/O InterfaceUSB 2.0 LED indicatorPower/Active OS SupportEmbedded Linux or WinCE with Bluetooth Stack support Size19.7 (L) x 10(W) Software/DriversLinux BlueZ, Windows CE, Windows Mobile Bluetooth Driver Bluetooth ProfilesGAP,SPP,HSP, HFP, DUN, FTP, FAX, PAN, LAN, HID, SYNC, HCRP, A2DP, AVRCP, BIP, GOEP, SDAP, OPP 5 FCC Warning Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. Note 1: This module certified that complies with RF exposure requirment under portable or mobile or fixed condition, this module is to be installed only in portable or mobile or fixed applications. A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 centimeter separation requirement. A fixed device is defined as a device is physically secured at one location and is not able to be easily moved to another location. Note 2: Any modifications made to the module will void the Grant of Certification, this module is limited to OEM installation only and must not be sold to end-users, end-user has no manual instructions to remove or install the device, only software or operating procedure shall be placed in the end-user operating manual of final products. Note 3: The device must not transmit simultaneously with any other antenna or transmitter. Note 4: To ensure compliance with all non-transmitter functions the host manufacturer is responsible for ensuring compliance with the modu…

Text truncated - open the document above for the full version.

LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2

LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I FCC PART 15.247 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: VVXLM505 Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS Solder Board-Component View 1 Solder Board-Component View 2

LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I PAGE 1 OF 40 FCC PART 15.247 FCC Part 15C Measurement and Test Report For LM Technologies Ltd. Unit19, Spectrum House, 32-34, Gordon House Road, London, NW5 1LP, United Kingdom FCC ID: VVXLM505 FCC Rules: FCC Part 15.247 Product Description: Bluetooth HCI USB Module Tested Model: LM505-0513 Report No.: STR12078307I Tested Date: 2012-07-31 to 2012-08-06 Issued Date: 2012-08-13 Tested By: Susan Su / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: SEM.Test Compliance Service Co., Ltd 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by SEM.Test Compliance Service Co., Ltd LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I PAGE 2 OF 40 FCC PART 15.247 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)...............................................................................4 1.2 TEST STANDARDS...................................................................................................................................................5 1.3 TEST METHODOLOGY.............................................................................................................................................5 1.4 TEST FACILITY.......................................................................................................................................................5 1.5 EUT SETUP AND TEST MODE.................................................................................................................................6 2. SUMMARY OF TEST RESULTS ...........................................................................................................................7 3. ANTENNA REQUIREMENT ..................................................................................................................................8 3.1 STANDARD APPLICABLE.........................................................................................................................................8 3.2 EVALUATION INFORMATION..................................................................................................................................8 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .....................................................................................9 4.1 STANDARD APPLICABLE.........................................................................................................................................9 4.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE......................................................................................9 4.3 FREQUENCY HOPPING SYSTEM.............................................................................................................................10 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION ...................................................11 5.1 STANDARD APPLICABLE.......................................................................................................................................11 5.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................11 5.3 TEST PROCEDURE.................................................................................................................................................11 5.4 ENVIRONMENTAL CONDITIONS............................................................................................................................11 5.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................12 6. DWELL TIME OF HOPPING CHANNEL ..........................................................................................................14 6.1 STANDARD APPLICABLE.......................................................................................................................................14 6.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................14 6.3 TEST PROCEDURE.................................................................................................................................................14 6.4 ENVIRONMENTAL CONDITIONS............................................................................................................................14 6.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................15 7. 20DB BANDWIDTH ...............................................................................................................................................17 7.1 STANDARD APPLICABLE.......................................................................................................................................17 7.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................17 7.3 TEST PROCEDURE.................................................................................................................................................17 7.4 ENVIRONMENTAL CONDITIONS............................................................................................................................17 7.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................17…

Text truncated - open the document above for the full version.

LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I FCC PART 15.247 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) LM Technologies Ltd. Model: LM505-0513 REPORT NO.: STR12078307I FCC PART 15.247 Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (Above 1GHz)
