VYV-TGW202-6TGW202-6

Iton Technology Corp.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 26, 2023
Application Purpose: Original Equipment
Date of Application: Jun 28, 2023
Equipment Note: TGW202-6
Frequency Range: 2412.00000000 - 2462.00000000
Company: Iton Technology Corp.
Country: China

Documents & Files

Select a file to view

Internal Photos

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

10.1 List of applicable FCC rules FCC Part 15 Subpart C 15.247 & 15.207 & 15.209 10.2 Specific operational use conditions Operation Mode: BT BLE Support Rate:1Mbps/ 2Mbps Operation Frequency:2402~2480MHz Number of Channel :40 Channels Modulation Type:GFSK Operation Mode:802.11b/802.11g/802.11n(HT20) Operation Frequency:2412~2462MHz Number of Channel :11 Channel for 20MHz bandwidth (2412~2462MHz) Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Antenna Type:Monopole antenna Antenna Gain(Peak):2 dBi The module is typically use in industrial, household and general office / ITE and audio & video, EV charging system end-products. The product must not be co-located or operating in conjunction with any other antenna or transmitters. 10.3 Limited module procedures The module compliance with FCC requirements based on Limit module procedure as no shielding cover included. Any installation or operation that does not follow this manual will require further evaluation. Host Installation instructions：Plug the signal port of the module into the corresponding port on the main board of the host. See the figure below, marked in the red box The module is installed inside the host Note: See Appendix 1 at the end for detailed instructions on how to install. 10.4 Trace antenna designs The module itself does not come with an antenna, and the rod antenna provided by the laboratory is used for testing.any changes or modifications by the OEM integrator will require additional testing and evaluation. 10.5 RF exposure considerations The module has been evaluated and shown compliant with the FCC RF Exposure limits under Mobile exposure conditions. OEM integrator shall equipped the antenna to compliance with antenna requirement part 15.203 &15.204 and must not be co-located or operating in conjunction with any other antenna or transmitters,otherwise, a Class II Permissive Change (C2PC) must be filed with the FCC and/or a new FCC authorization must be applied. 10.6 Antennas Antenna Specification are as follows: Antenna Type:Monopole antenna Antenna Gain(Peak):2 dBi End product must include the antenna This device is intended only for host manufacturers under the following conditions: The transmitter module may not be co-located with any other transmitter or antenna; The module shall be only used with the External antenna(s) that has been originally tested and certified with this module. The antenna must be either permanently attached or employ a ‘unique’antenna coupler. As long as the conditions above are met, further transmitter test will not be required. However, the host manufacturer is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheralrequirements, etc.). 10.7Labelandcomplianceinformation Thefinalendproductmustbelabelledinavisibleareawiththefollowing: “ContainsFCCID:VYV-TGW202-6” Ifthesizeoftheendproductissmallerthan8x10cm,thenadditionalFCCpart15.19statementis requiredtobeavailableintheusers'manual:ThisdevicecomplieswithPart15oftheFCCRules. Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseharmful interference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Auser'smanualforthefinishedproductshouldincludeoneofthefollowingstatements:ForaClass Adigitaldeviceorperipheral,theinstructionsfurnishedtheusershallincludethefollowingorsimilar statement,placedinaprominentlocationinthetextofthemanual: ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice, pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferencewhentheequipmentisoperatedinacommercialenvironment.This equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedin accordancewiththeinstructionmanual,maycauseharmfulinterferencetoradiocommunications. Operationofthisequipmentinaresidentialareaislikelytocauseharmfulinterferenceinwhichcase theuserwillberequiredtocorrecttheinterferenceathisownexpense. ForaClassBdigitaldeviceorperipheral,theinstructionsfurnishedtheusershallincludethe followingorsimilarstatement,placedinaprominentlocationinthetextofthemanual: ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB digitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,uses andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe instructions,maycauseharmfulinterferencetoradiocommunications. However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis equipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedetermined byturningtheequipmentoffandon,theuserisencouragedtotryto correcttheinterferencebyoneormoreofthefollowingmeasures: ---Reorientorrelocatethereceivingantenna. ---Increasetheseparationbetweentheequipmentandreceiver. ---Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. ---Consultthedealeroranexperiencedradio/TVtechnicianforhelp. TheUser'sManualforThefinishedproductshouldincludethefollowingstatements: AnychangesormodificationstothisequipmentnotexpresslyapprovedbytheOEM/Integratormay causeharmfulinterferenceandvoidtheuser'sauthoritytooperatethisequipment. RFExposure ThisdevicehasbeenevaluatedandshowncompliantwiththeFCCRFExposurelimitsunderMoblie fixedexposureconditions. 10.8Informationontestmodesandadditionaltestingrequirements DatatransfermoduledemoboardcancontroltheEUTworkinRFtestmodeatspecifiedconditions. Thisradiomodulemustnotbeinstalledtoco-locateandoperatingsimultaneouslywithotherradiosin thehostsystemexceptinaccordancewithFCCmulti-transmitterproductprocedures.Additional testingandequipmentauthorizationmayberequiredoperatesimultaneouslywithotherradio. …

Text truncated - open the document above for the full version.

Users Manual

TGW202-6 V1.0-July.2021 www.sziton.com TGW202-6 Wi-Fi802.11b/g/n+BluetoothLE5.0Module DISCLAIMERANDCOPYRIGHTNOTICE Informationinthisdocument,includingURLreferences,issubjecttochangewithoutnotice. Thisdocumentisprovided“Asif”withnowhatsoever,includinganywarrantyofmerchantability,noninfringement,fitnessforany purpose,oranywarrantyotherwisearisingoutofanyproposal,specificationorsamples. Allliability,includingliabilityforinfringementofanyproprietaryrights,relatingtouseofinformationinthisdocumentisdisclaimed.No licensesexpressorimplied,byestoppelorotherwise,toanyintellectualpropertyrightsaregrantedherein. TheBluetoothlogoandsymbolbelongtotheBluetoothSIGInc. TheWi-FiAllianceMemberLogoisatrademarkoftheWi-FiAlliance. Alltradenames,trademarksandregisteredtrademarksmentionedinthisdocumentarepropertyoftheirrespectiveowners,andare herebyacknowledged. CopyrightbyITONTechnologyCorp.Allrightsreserved. TGW202-6 V1.0-July.2021 www.sziton.com Tableofcontents 1.ProductFeaturesandSpecifications..........................................................................................3 2.Modulepindefinition................................................................................................................4 3.ElectricalCharacteristicsSpecifications....................................................................................5 3.2BLERFSpecifications............................................................................................................5 3.3Recommendedworkingenvironment......................................................................................6 3.4Moduleelectricalparameters...................................................................................................6 4.Refertoapplication.....................................................................................................................6 5.ModuleMechanicalDimensions................................................................................................7 5.1ModuleMechanicalDimensions（tolerance±0.15mm）.....................................................7 5.2ReferenceLayoutpackagesize （ tolerance ± 0.15m ） ...........................................................7 6.LayoutPrecautions.....................................................................................................................8 7.Packaginginformation...............................................................................................................8 8.Wavesolderingreferencecurve................................................................................................8 9.Historymodificationrecord........................................................................................................9 10.IntegrationinstructionsforhostproductmanufacturersaccordingtoKDB996369D03OEM Manualv01..............................................................................................................................9 10.2Specificoperationaluseconditions..................................................................................9 10.3Limitedmoduleprocedures...................................................................................................9 10.4Traceantennadesigns..........................................................................................................10 10.5RFexposureconsiderations............................................................................................10 10.6Antennas............................................................................................................................10 10.7Labelandcomplianceinformation..................................................................................11 10.8Informationontestmodesandadditionaltestingrequirements.................................11 10.9Additionaltesting,Part15SubpartBdisclaimer..........................................................12 GeneralStatements..................................................................................................................12 ITONTechnologyCorp.Page2of8 TGW202-6 V1.0-July.2021 www.sziton.com 1.ProductFeaturesandSpecifications 1.1Describe TheTGW202-6moduleisdesignedbasedonanewgenerationofintelligentandhighlyintegratedWi-Fiand BluetoothLEcombinationchipTG7100C.Thewirelesssubsystemincludes2.4Gradio,Wi-Fi802.11b/g/nand LEbaseband/MACdesign.Themicrocontrollersubsystemcontainsalow-power32-bitRISCCPU,cacheand memory.Thepowermanagementunitprovidesflexiblesettingstoimplementlow-powermodesandsupportsa varietyofsecurityfeatures.TGW202-6moduleDIPpinweldingmethodisdesigned,whichisespecially convenientforsmall-sizedlampsandlanterns.Themoduleleadsouttheantennapad,whichisconvenientfor structuraldesign;itsupportsI2CcontrolorsupportsuptothreePWMoutputsatthesametime,whichcan realizesimpleandfastaccesstotheTmallGenieecosystem. 1.2ProductFeatures  802.11b/g/n，Wi-Fi+BluetoothLE5.0Combo，supportSTA，SoftAP和Sniffer Supportstheuseofopensourceself-controllableRISC-VCPU,adjustablefrom1to160MHz,276KB SRAM Ultra-lowpowerconsumption:sleeppowerconsumptionisonly0.5uA,networkstandbypower consumptionisonly40uA(DTIM10 Ultra-fastconnection:coldstartfastconnectionisonly70ms  Ultra-longdistance:transmitpowerupto21dBm,sensitivity-90dBm,penetratingonemorewall  Highsecurity:supportsecureboot,securedebugging,AES128/192/256encryptionengine,WPA3,MD5, SHA-1/224/256,PKA (RSA/ECC)encryptionengine supportWi-Fi和BluetoothLE 1.3Moduleblockdiagram Figure1TGW202-6moduleblockdiagram ITONTechnologyCorp.Page3of8 TGW202-6 V1.0-July.2021 www.sziton.com 1.4Applicationscenarios SmartLighting 2.Modulepindefinition pin1pin2pin3pin4pin5pin6 Figure2Modulepins Modulepindefinition pin Numbering Modulepinnameillustrate 1ANT1Externalantenna 2PWM2GPIO22 3PWM0GPIO20 4VDD33PowerSupply 5PWM1GPIO21 6GNDGround Note:Thismodulecanbeconfiguredwithupto3independentPWMchannels. ITONTechnologyCorp.Page4of8 TGW202-6 V1.0-July.2021 www.sziton.com 3.ElectricalCharacteristicsSpecifications 3.1WiFiRFSpecifications Pro…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Attestation Statements

ItonTechnologyCorp. 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ItonTechnologyCorp. Address:7FloorEast,BuildingC,ShenzhenInternationalInnovationCenter,No.1006ShennanRd. FutianDist,Shenzhen,China ProductName:TGW202-6 FCCID:VYV-TGW202-6 Model(s):TGW202-6 2.911(d)(5)(i)EquipmentType We,[ItonTechnologyCorp.]certifythattheequipmentforwhichauthorizationissoughtthrough certificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:ZhanchiZhaDate:2023-02-08 TitleandCompanyname:ProductManager/ItonTechnologyCorp. NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

ItonTechnologyCorp. 2.911(d)(5)(ii)ApplicantAttestationv1.2 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname: ItonTechnologyCorp. Address:7FloorEast,BuildingC,ShenzhenInternationalInnovationCenter,No.1006ShennanRd. FutianDist,Shenzhen,China ProductName:TGW202-6 FCCID:VYV-TGW202-6 Model(s):TGW202-6 2.911(d)(5)(ii)Applicantfiling We,[ItonTechnologyCorp.]certifythat,asofthedateofthefilingoftheapplication,theapplicantis identified/isnotidentified NOTE1 onthe“CoveredList” NOTE2 ,establishedpursuantto §1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:ZhanchiZhaDate:2023-02-08 TitleandCompanyname:ProductManager/ItonTechn ologyCorp. NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com ItonTechnologyCorp. 2.911(d)(5)(ii)ApplicantAttestationv1.2 munications-supply-chain-through-the

Attestation Statements

-lton Technology Corp. - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 3/29/23 U.S. A�nation rnA ' n,(L)(P)l l6 · ;: - 1u;,bfJv - sn [1;,,pomrs寸 [lton Technology Corp.] acknowledges thei「 consent for the following contact located in the United States to act as their agent for service of process for the equipment for which autho「ization is sought ( FCC ID: [VYV- TGW206-6] ) N ame and company of U.S. agent: Stone Trading Limited Ph ysical U.S. address of agent: 6547 N Academy Blvd #2266,Colorado Springs,CO 80918,United States FRN o f U.S. agent: 0033401936 Email address of U.S. agent: [email protected] Telephone No of U.S. agent: +12 134573118 Stone Trading Limited acknowledges their obligation to accept service of process on behalf of [lton Technology Corp.]. [lton Technology Corp.] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements li sted unde「§ 2.911 ( d ) ( ? ) . Sincerely, 严b 名三｀， Signatu [N ame ] [Title ] [ C omp Sign勹 [Name of U.S. agent] Dongmei Fang [T itle of U.S. agent ] Manager [Com p any of U.S. agent] Stone Trading Limited The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 DOI. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC

Cover Letter(s)

ItonTechnologyCorp. AgentAuthorizationLetter (2023-02-08) RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,authorizeMicomLabsInc.,575BoulderCourt,Pleasanton,California94566, USAtoactonourbehalfinallmattersrelatingtoapplicationforequipment authorization,includingthesigningofalldocumentsrelatingtothesematters. Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, ZhanchiZha/ProductManager CompanyName:ItonTechnologyCorp. Address:7FloorEast,BuildingC,ShenzhenInternationalInnovationCenter, No.1006ShennanRd.FutianDist,Shenzhen,China

Cover Letter(s)

ItonTechnologyCorp. FCCModularApprovalRequestRev3.0 FederalCommunicationsCommission EquipmentAuthorizationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023-04-18 Subject;ModularTransmitterApplication Companyname: FCCID:VYV-TGW202-6 DearSir/Madam, ThisletterincludestheFCCapplicationrequirementsforModularTransmitterApprovalRequest for;- FCCKDB996369D01‘ModuleCertificationGuidev02;and FCCKDB996369D03OEMManualv01 Inaccordancewith47CFR15.212ModularTransmittersandKDB996369D01‘ModuleEquip AuthGuidev02’.FCCIDVYV-TGW202-6hasbeenexaminedagainstthefollowing requirements. Requirementper15.212andKDB996369D01ExplanationfromGrantee (donotwriteyes/no,butexplainwhyproduct complies/howitisachieved) Theradioelementsmusthavetheradiofrequencycircuitry shielded.Physicalcomponentsandtuningcapacitor(s)maybe locatedexternaltotheshield,butmustbeonthemodule assembly. HasnotRFshielding. Themodulemusthavebufferedmodulation/datainputstoensure thatthedevicewillcomplywithPart15requirementswithanytype ofinputsignal. Themodularhavebufferedmodulation/data inputs. Themodulemustcontainpowersupplyregulationonthemodule. Themodulartransmitterhaveitsownpower supplyregulation.(DC3.3V) Themodulemustcontainapermanentlyattachedantenna,or containauniqueantennaconnector,andbemarketedand operatedonlywithspecificantenna(s),per§§15.203,15.204(b), 15.204(c),15.212(a),2.929(b). Themodelnumberofthereplaceable antennaisspecifiedinthemanual. Themodulemustdemonstratecomplianceinastand-alone configuration. Themodulewastestedinastand-alone configuration,pleaserefertotheSetupPhoto forthedetail ThemodulemustbelabeledwithitspermanentlyaffixedFCCID label,oruseanelectronicdisplay(seeKDBPublication784748). Pleaserefertolabelsampleexhibit-host labelingisdescribedinintegrationmanual Themodulemustcomplywithallspecificrulesapplicabletothe transmitter,includingalltheconditionsprovidedintheintegration instructionsbythegrantee. TherequiredFCCrulehasbeenfulfilledand alltheinstructionsforthemaintaining compliancehavebeenclearlystatedinthe UserManual. ThemodulemustcomplywithRFexposurerequirements TheMPEevaluationwith20cmdistance restrictionissubmittedforthecomplianceof RFExposurerequirement. ItonTechnologyCorp. FCCModularApprovalRequestRev3.0 IntegrationInstructionsforhostproductmanufacturers ThefollowingitemsaresubmittedinsupportofapplicationforModularTransmitterFCCIDas notedaboveasrequiredbytheFCCKDB996369D03OEMManualv01. Theseitemsareprovidedasintegrationinstructionsforhostproductmanufacturers(e.g.,OEM instructionmanual)tousewhenintegratingamoduleinahostproduct. AnyrequirementsthatarenotapplicabletotheModuleareasindicatedbelow. SummaryofrequirementsandChecklist.RefertotheKDBfordescriptionofthecompleterequirements; KDB RefSect RequirementsofKDB996369D03UserManualPageNumber reference 2.2ListofapplicableFCCrules Page11~12 2.3Summarizethespecificoperationaluseconditions Page11~12 2.4Limitedmoduleprocedures Page11~12 2.5Traceantennadesigns Page11~12 2.6RFexposureconsiderations Page11~12 2.7Antennas Page11~12 2.8Labelandcomplianceinformation Page11~12 2.9Informationontestmodesandadditionaltesting requirements Page11~12 2.10Additionaltesting,Part15SubpartBdisclaimer Page11~12 Name:ZhanchiZhaDate:2023-04-18 Title:ProductManager Signatureofapplicant

Cover Letter(s)

ItonTechnologyCorp. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023-02-08 Subject;RequestforConfidentiality FCCID:VYV-TGW202-6 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram OperationalDescription SWSECURITYDESCRIPTION PartsList Tuneup Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:ZhanchiZha Title:ProductManager

External Photos

Code:AB-RF-05-b ExternalPhotograph Code:AB-RF-05-b Code:AB-RF-05-b

ID Label/Location Info

LabelLocationOnEUT Label ProductName:TGW202-6 ModelNo.:TGW202-6 FCCID:VYV-TGW202-6

RF Exposure Info

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:VYV-TGW202-6 EUTSpecification EUT TGW202-6 Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.24GHz WLAN:5.745GHz~5.825GHz Others:Bluetooth:2402-2480MHz DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Antennagain(Max) BLE:2dBi WiFi2.4G:2dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MaxMeasurementResult Operating Mode Measured Power Tuneup tolerance Max.Tune upPower Antenna Gain Power densityat 20cm Power densityLimits (mW/cm2) (dBm)(dBm)(dBm)(dBi)(mW/cm2) BLE1.911.91±12.9120.00061 2.4GWIFI16.4416.44±117.4420.01751 Result:NoStandaloneSARtestisrequired.

Test Report

PCTEL Antenna Products Group, Inc. 471 Brighton Drive, Bloomingdale, IL 60108 / Tel: +1-630-372-6800 / Fax: +1-630-372-8077 / www.pctel.com 00753-2035-003x Test Report This document contains the measured data for the 00753-2035-003x antennas. The measurements were taken in PCTEL’s high quality near field antenna range test facility (NFR) and verified using the tapered far field antenna range. The data in this report comes from the NFR and is saved for future inquiry. The antenna was mounted to the sensor housing for all the measurements in order to improve the usefulness of the data. The first p…

Text truncated - open the document above for the full version.

Contact Information

Applicant

zhanchi Zha(Product Manager)

[email protected]15768474829Fax: 0755-82079390

Technical Contact

Iton Technology Corp.

[email protected]

China

Test Firm

Shenzhen Anbotek Compliance Laboratory LimitedJeff Zhu

[email protected]13798230942

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	44.10 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Limited Modular Approval. Output power listed is conducted power. This device contains 20 and 40 MHz signal bandwidth. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
