emporia Life 2 My Mobile – My Safety emporia Life - User Guide DEAR MOBILE PHONE USERS! D Congratulations on having purchased your emporia Life mobile phone! This booklet will provide you with the most essential information needed for quick familiarisation with your new mobile phone. You can use the following pages of this user guide to decide on just how much time you want to invest in getting to know the most important functions of your mobile phone. D We hope you will enjoy using your emporia Life EMPORIA Telecom ITEMS INCLUDED: Mobile PhoneMobile Phone Charger Rechargeable Battery Instruction Manual emporia Life 3 emporia Life 4 1 START 1.1 FAMILIARISING YOURSELF WITH THE KEYS D Loudspeaker D Display (= Screen) D Arrow keys For scrolling through the phone book and menu D Answer/OK key q Answering calls q Select options shown above this key on the screen D End call/Clear/Back key q End the call q Select options shown above this key on the screen (mostly “return” or “delete”) D Alert lights q ...green: blinks during incoming calls q ...red: blinks when the battery needs to be recharged q ...orange: blinks during charging and remains on when the battery is full D Microphone D Socket for battery charger D Lanyard For carrying the mobile phone around the neck D Emergency Button D Volume Control q Change volume during a call q The phone is ringing: press to turn off the ring tone (the ring tone will automatically be on for the next call again) D Battery Compartment High-performance Li-ion battery or non-rechargeable battery cells (3 x AAA) – only USA-version Battery Status Call forward active Alarm on Roaming (if you are abroad, this symbol replaces signal strength – and lets you know that making calls is now more expensive) only USA-version Top 10: the most important numbers at the beginning of the phone book, independent of alphabetical order (store: phone book menu, Top10, see chapter 4.2.4) Ring tone off Clock (if on, see also Section 4.4.6, page 31) Signal strength emporia Life 5 -Key: q Press and hold: most recent 10 numbers dialled q Press twice: + (for international dialling codes, e.g. +44 for the UK) q Text messages: special characters -Key: Press and hold to call your voice- mail service -Key: Shift between capital and lower-case letters and numbers when writing text messages Flashlight Press and hold: flashlight is on On/Off Button Press and hold for 3 seconds Alarm Clock Button Activate/deactivate the alarm clock Key lock Prevents accidental pressing of keys (press for 3 seconds to activate/ deactivate the key lock) PUSH TO OPEN THE SLIDER emporia Life 6 Contents 1 Start 1.1 Familiarising yourself with the keys . . . . . . . . . . . . . . . . . . . . . . . . . 03 1.2 Technical data and DOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09 1.3 Inserting the SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.4 Inserting the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.5 Inserting standard batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.6 Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.7 Turning the phone on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 1.8 Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 2 Getting to know your mobile phone in 10 minutes 2.1 Don’t worry if you get lost in the menu!. . . . . . . . . . . . . . . . . . . . . 13 2.2 Accepting an incoming call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.3 Dialling with the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.4 Last number redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 2.5 Calling a contact from the phone book . . . . . . . . . . . . . . . . . . . . 14 2.6 Phone book remote service via SMS . . . . . . . . . . . . . . . . . . . . . . . 14 3 Getting to know your mobile phone in 20 minutes 3.1 Small menu – slider closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1.1 Dialled numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1.2 Missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1.3 Received calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1.4 Received text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 3.1.5 Battery and signal strength indication . . . . . . . . . . . . . . . . . . . . . . . 16 emporia Life 7 3.2 Alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 3.2.1 Setting the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 3.2.2 Alarm and snooze function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.2.3 Editing the alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.2.4 Deactivating the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.2.5 Setting the alarm melody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.3 Manual key lock and auto-key lock . . . . . . . . . . . . . . . . . . . . . . . 18 3.3.1 Manual key lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 3.3.2 Automatic key lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 3.4 My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 3.4.1 Activating My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 3.4.2 Entering My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 3.4.3 Selecting your favourite menu items for “My …

Text truncated - open the document above for the full version.

emporia Life 20 4.1 SMS/TEXT MESSAGES An SMS (Short Message Service) is a written short message, which can be sent to all mobile phone users and some landline phones that support this function. Costs are only incurred when sending an SMS. ■ 4.1.1 Service centre number A central network operator number via which the short message service is handled. This number is usually already stored on your SIM card by the operator and does not have to be entered or changed. ■ 4.1.2 Writing an SMS D Open the mobile phone and select SMS Messages with . D Select Write New SMS with . D Use the keypad to write your SMS. To delete individual characters, press . This deletes the entered character to the left of the vertical line | . To delete all entered text, hold down for three seconds. D To move around the text, use . Your position in the text is then wherever the | symbol is located. All characters and functions, which can be selected are listed in the following table. Every key stands for several characters or functions depending on how often the respective key is pressed when in the “ABC mode” (see the explanations after the table). D . , ! ? ‚ „ @ : 1 D a b c 2 ä à D d e f 3 è D g h i 4 D j k l 5 D m n o 6 ö D p q r s 7 ß D t u v 8 ü D w x y z 9 D space; 0 D . , ? ! ‚ „ : ; ( ) @ - + $ € £ ¥ # % * & ~ = ¤ D You are able to change between lower and upper case letters, as well as selecting numbers only (“Abc” “ABC” “abc” “123”) 4 GETTING TO KNOW YOUR MOBILE PHONE IN 30 MINUTES emporia Life 21 Examples for function keys: D press 1x = j D press 1x = Space D press 2x = k D press 2x = 0 D press 3x = l D press 4x = 5 D To insert blank spaces (the space between characters), press once. D Insert punctuation marks (. , ! ?) by pressing repeatedly. D Special characters: enter the selection menu for special characters by pressing . By repeatedly pressing or , you can move from left to right. Using 2 , you can move up in the table, with 4 to the left, with 6 to the right, and with 8 down. If you have reached the desired character, press to i nsert the character into your text. D With you can switch between four options: ABC: upper case Abc: mixed case (lower case letters with capital letters at the beginning of a sentence) abc: lower case letters 123: numbers only The selected mode is shown on the display next to the ¢ symbol. D While entering text you can also insert numbers by following these steps: press for Next, scroll to Insert numbers with and confirm with . You can enter a number by using the keypad or Search for a number from the Phonebook or from the list of Unsaved numbers. D Contacts from the phone book (name and telephone number) can be inserted into the SMS text as follows: press for Next, go to Insert name with and confirm with . Select names in the phone book using the keypad or and insert them into the SMS with . D In the upper right hand corner of the display, you can see how many characters you have left to enter in the SMS. Example. 1/135 shows that you are in the first text message and you have 135 characters remaining in this SMS. If you enter more than 160 characters, the text is sent in two messages. As soon as you roll over into a second message, the display will read 2/.... You can send a maximum of 480 characters at once (this will automatically be divided in up to three messages). jkl emporia Life 22 ■ 4.1.3 Sending an SMS D To send the completed text, press . D Select Send with . D There are three ways to choose or enter the recipient of your message: D The number is already in your phone book: Select “Phone book” by pressing twice. Go to the name with or enter the first letter of the name with the keypad. When the desired contact is highlighted with a black background, confirm it with . To then send the message press . D The telephone number has recently been used but is not stored as a contact in your phone book: Select Search with , go to Unsaved numbers with and confirm with . With the list of telephone numbers now displayed (dialled, received and missed calls), select the desired number with and confirm with . D You can also enter a telephone number manually using the keypad. Then send the SMS with . ■ 4.1.4 Receiving an SMS D A short alert tone and vibration informs you that you have received an SMS. The screen will display New SMS. D To read the SMS, select . To read longer texts, scroll down using . ■ 4.1.5 Answering a received SMS D After reading the SMS press several times until reaching the following points: Delete SMS, Call number, Read next SMS, Reply, Forward, Save to PhoneBook D Then select and confirm Reply with . Now you have the choice between 4 options: D Empty Screen (enter your own text using the keypad) D Original Text (this will copy the text of the received SMS into your answer) D Templates D Prewritten short answers (for example, Yes, No, Everything OK) Scroll to one of the options using and select with . D Send the message pressing twice. emporia Life 23 ■ 4.1.6 Deleting SMS Since you cannot receive further text messages when the SMS memory is full, you need to delete messages to create memory space from time to time. D Open the phone and select SMS Messages with . D Go to Delete SMS with and select using . You can delete all saved mes- sages by selecting All SMS. You can also delete specific folders, for example, all received messages. To do this, go to Received SMS with and select with . You are then asked Delete all received SMS?, confirm this with . D You can delete specific messages from within the SMS itself by scrolling down to the bottom and selecting Delete Message. To confirm press twice. ■ 4.1.7 Creating and inserting templates Templates are prewritten messages, such as Call me, Coming later or I love you. A selection of templates is already stored on your phone, and you can also create your own. They are useful for saving time when sending short messages. All templates can be changed before you send them (see be- low). Creating new templates: D Sl…
