W6U700P800PMultiple-Enclosure Booster System

Confidential & Proprietary 1/117 SC‐DAS SC‐DAS Installation and Operation Manual Document Reference: Version: V5.0 Document Status: Release 5 Issue Date: Feb. 13, 2013 Author: Kyung Eun Han Department: R&D Division Team 3 Authorizing Manager: Young shin Yeo Confidential & Proprietary 2/117 SC‐DAS REVISION HISTORY Version Issue Date No. of Pages Initials Details of Revision Changes V 1.0 April. 11, 2011 Original V 2.0 Dec. 08,2011 Add Sprint band V 3.0 Jan. 06,2012 Add Sprint band V 4.0 Jan. 07,2013 Add VzW (MRU MIMO) band V 5.0 Feb. 13,2013 Add PS (MRU) band Technical Support SOLiD serial numbers must be available to authorize technical support and/or to establish a return authorization for defective units. The serial numbers are located on the back of the unit, as well as on the box in which they were delivered. Additional support information may be obtained by accessing the SOLiD, Inc. website at www.solid.co.kr or send email at [email protected] This manual is produced by Global Business Division Business Team 1. Printed in Korea. Confidential & Proprietary 3/117 SC‐DAS Contents Section1 Safety & Certification Notice ....................................................................... 12 Section2 System Overview ....................................................................................... 15 2.1 General overview ............................................................................................ 16 2.2 System overview ............................................................................................. 18 Section3 System Specifications ................................................................................ 21 3.1 System specifications ...................................................................................... 22 3.1.1 Physical Specifications .............................................................................. 22 3.1.2 Optical wavelength and Laser power......................................................... 23 3.1.3 Environmental specifications .................................................................... 23 3.1.4 Available Frequency Bands ........................................................................ 23 3.1.5 Band Specifications ................................................................................... 24 Section4 System Configuration and Functions ........................................................... 25 4.1 BIU (BTS Interface Unit) .................................................................................. 26 4.1.1 BIU Specifications .................................................................................................... 26 4.1.2 BIU block diagram ................................................................................................... 27 4.1.3 BIU assemblies ........................................................................................................ 27 4.1.4 Sub Assembly Description ........................................................................................ 28 4.1.5 BIU front/rear panel overview .................................................................................. 32 4.2 ODU (Optic distribution Unit) .......................................................................... 35 4.2.1 ODU specifications ................................................................................................... 35 4.2.2 ODU block diagram ................................................................................................. 36 4.2.3 ODU assemblies ....................................................................................................... 36 4.2.4 Sub Assembly description ......................................................................... 37 4.2.5 ODU front/rear panel overview ................................................................................ 38 4.2.6 ODU Interface with BIU ............................................................................................ 40 4.3 OEU (Optic Expansion Unit) ............................................................................. 42 4.3.1 Specifications of OEU ............................................................................................... 42 Confidential & Proprietary 4/117 SC‐DAS 4.3.2 OEU block diagram ................................................................................... 43 4.3.3 OEU assemblies ....................................................................................................... 43 4.3.4 Sub Assembly description ........................................................................................ 44 4.3.5 OEU front/rear panel overview .................................................................. 47 4.4 ROU (Remote Optic Unit) ................................................................................ 48 4.4.1 ROU specifications .................................................................................... 49 4.4.2 ROU block diagram ................................................................................... 50 4.4.2.1 Combination of MRU 1900PCS+850C/ARU 700LTE+AWS‐1 ........................... 50 4.4.2.2 Combination of MRU 1900PCS/ARU 900I+800I ........................................... 50 4.4.2.3 Combination of MRU 700LTE+AWS‐1 .......................................................... 51 4.4.2.4 Combination of MRU 700PS+800PS ........................................................... 51 4.4.2.5 Combination of MRU 1900PCS+850C/ARU 700LTE+AWS‐1 ........................... 52 4.4.2.6 Combination of MRU 1900PCS/ARU 900I+800I ........................................... 53 4.4.2.7 Combination of MRU 700LTE+AWS‐1 .......................................................... 54 4.4.3 Sub Assembly description ......................................................................... 56 4.4.4 Bottom of ROU ..................................................................................…

Text truncated - open the document above for the full version.

          !"  # $%&$ ' ()*&%+% ,()*&%+% -----------------------------------------------------------------------------------       ./01+ * 2.!/  3%1+* ./01+ * . '!  !  4!  42. 5   5! . 5 ! 6 ./01+ * 2.789 '!  !  4!  4   .  5! 8:/26 ./01+ * .789 '!  !  4!  42. 5     .  5!  .  5 ! 8:/26

Page 1 of 1 FCC ID: W6U700P800P IC ID: CT Project:P13a0005 From: Shawn McMillen Date: 5/8/14 1. The RF exposure information/safe operating distances need to be in the user’s manual. --Sent request to Solid. DW 2. Per section 90.543 for equipment designed to operate in 769-775MHz adjacent channel power needs to be measured. CT – I talked to John Erhard and he mentioned per the latest draft KDB and recent FCC discussions, that ACP does not need to be performed. Response by: Mike Graffeo Submitted by: Date: 5/12/14

Page 1 of 1 FCC ID: W6U700P800P IC ID: CT Project:P13a0005 From: Shawn McMillen Date:05/14/2014 The label need to be in accordance with the latest FCC booster requirements. See KDB 935210. DW-Customer provided updated label. CT - Response by: Submitted by: Date: 6/2/14

          !"  # $%&$ ' ()*&%+% ,()*&%+% ----------------------------------------------------------------------------------- (

SOLiD, Inc. 10,9th Floor, SOLiD Space 220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 463-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 ________________________________________________________________________________ label Location ID Label WARNING Label SOLiD, Inc. 10,9th Floor, SOLiD Space 220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 463-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 ________________________________________________________________________________ Booster Warning Label Aartwork SOLiD, Inc. 10,9th Floor, SOLiD Space 220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 463-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 ________________________________________________________________________________ FCC ID Label Aartwork 1. SC-MRU700PS800PS-AC 2. SC-MRU700PS800PS-AC(N) 3. SC-MRU700PS800PS-DC 4. SC-MRU700PS800PS-DC(N)

          !"  # $%&$ ' ()*&%+% ,()*&%+% (

p13a0005_FCC_Part 1.1310_Rev 1.0 Page 1 of 4 Test Report Prepared for: Solid Technologies Model: EXPRESS Public Safety Description: Booster System SC-MRU700PS800PS – 700/800 MHz Amplifier To FCC Part 1.1310 Date of Issue: April 30, 2014 On the behalf of the applicant: Solid Technologies 4332 E Siesta Lane Phoenix, AZ 85050 Attention of: Gregory Glenn Ph: (408) 649-4803 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p13a0005 Mike Graffeo Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p13a0005_FCC_Part 1.1310_Rev 1.0 Page 2 of 4 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 April 30, 2014 Mike Graffeo Original Document p13a0005_FCC_Part 1.1310_Rev 1.0 Page 3 of 4 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p13a0005_FCC_Part 1.1310_Rev 1.0 Page 4 of 4 Description: Worse case composite 1Watt: if all both amplifiers are simultaneously transmitting within the single enclosure (1000mW). Minimum Safe Distance is based off the highest antenna gain of 14.45 and the strictest limit of 2.555mW/cm^2 Minimum Safe Distance Calculations Formula = R=((PG)/(4*PI*S)) 0.5 =((1000*14.45)/(4*PI*2.555))^0.5 Minimum Safe Distance (R) = 21.22 cm END OF TEST REPORT

p13a0005_FCC_Part 90_Rev 4.0 Page 1 of 26 Test Report Prepared for: Solid Technologies Model: EXPRESS Public Safety Description: Class B Part 90 Booster System SC-MRU700PS800PS – 700/800 MHz Amplifier FCC ID: W6U700P800P To FCC Part 90 Date of Issue: July 28, 2014 On the behalf of the applicant: Solid Technologies 4332 E Siesta Lane Phoenix, AZ 85050 Attention of: Gregory Glenn (408) 649-4803 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p13a0005 Mike Graffeo Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p13a0005_FCC_Part 90_Rev 4.0 Page 2 of 26 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 April 29, 2014 Mike Graffeo Original Document 2.0 May 7, 2014 Mike Graffeo Updated Emission Designators 3.0 July 8, 2014 John Erhard Add additional part 90 rule section information to test summary table 4.0 July 28, 2014 Mike Graffeo Added noise figure tests to show compliance with 90.219(e)(2) p13a0005_FCC_Part 90_Rev 4.0 Page 3 of 26 Table of Contents Description Page Standard Test Conditions and Engineering Practices 6 Test Result Summary 7 Out of Band Rejection 8 Carrier Output Power (Conducted) 10 Conducted Spurious Emissions 11 Emission Masks (Occupied Bandwidth) 15 Intermodulation 20 Noise Figure Test 22 Radiated Spurious Emissions 24 Test Equipment Utilized 26 p13a0005_FCC_Part 90_Rev 4.0 Page 4 of 26 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p13a0005_FCC_Part 90_Rev 4.0 Page 5 of 26 The Applicant has been cautioned as to the following: 15.21: Information to the User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a): Special Accessories Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p13a0005_FCC_Part 90_Rev 4.0 Page 6 of 26 Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations Part 90.219, KDB 935210 D02, and FCC Part 2 where appropriate. Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing. In accordance with ANSI/TIA 603C, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Environmental Conditions Temp (ºC) Humidity (%) Pressure (mbar) 21.6 - 29.0 40.2 - 57.9 964.7 - 969.4 Measurement results, unless otherwise noted, are worst-case measurements. EUT Description Model: EXPRESS Public Safety Description: Multiple-Enclosure Booster System Firmware: N/A Test Software: DAS Management Ver12 Accessories: None Cables: Customer Supplied Modifications: None Additional Information: The EUT is an industrial booster that amplifies the signal of cellular phone signals and data communication devices. The following frequency bands and emission types are utilized Frequency Band (MHz) Downlink 758 to 775 851 to 869 Emission Designator F3E F3D F1E F3E F3D F1E EUT Operation during Tests The EUT was in a normal operating condition. Accessories: None Cables: None Modifications: None p13a0005_FCC_Part 90_Rev 4.0 Page 7 of 26 Test Result Summary Specification Test Name Pass, Fail, N/A Comments KDB 935210-D03 Out of Band Rejection Pass 2.1046 Output Power (Conducted) Pass 90.210 2.1049 Occupied Bandwidth (Emission Masks) Pass 90.219(e)(2) Noise Figure Pass 2.1051 Spurious Emissions (Transmitter Conducted) Pass KDB 935210-D03 Intermodulation Pass 90.21…

Text truncated - open the document above for the full version.

Test Setup Photos FCC ID: W6U700P800P RF Conducted RF Radiated
