W6UER781719DAS System

Confidential & Proprietary 1/19 Alliance_eROU User Manual Document Reference: Version: V1.3 Document Status: Release 4 Issue Date: Mar 10, 2022 Author: Hyo-Seok Oh Department: R&D Division Team 2 Authorizing Manager: hyun-suk Chae Confidential & Proprietary 2/19 REVISION HISTORY Version Issue Date No. of Pages Initials Details of Revision Changes V 1.0 March 09, 2020 Original V 1.1 Jun 23,2020 eROUa_682335 Add V 1.2 Jan 25,2022 eROUa_682335_R Add V 1.3 Mar 10, 2022 eROU_781717 Add Technical Support SOLiD serial numbers must be available to authorize technical support and/or to establish a return authorization for defective units. The serial numbers are located on the back of the unit, as well as on the box in which they were delivered. Additional support information may be obtained by accessing the SOLiD Tehcnology, Inc. website at www.solid.co.kr or send email at [email protected] This manual is produced by Global Business Division Business Team Printed in Korea. Confidential & Proprietary 3/19 Contents Section1 Safety & Certification Notice .................................................................................. 4 Section2 System configuration and Functions ...................................................................... 8 2.1 eROU(edge Remote Optic Unit) .......................................................................... 8 2.1.1 Specifications of eROU ................................................................................ 9 2.1.2 Port on eROU ........................................................................................... 11 2.1.2.1 Functions ................................................................................................. 11 2.2 AC/DC Adaptor information ............................................................................. 12 Section3 System Installation ............................................................................................... 13 3.1 eROU Installation ............................................................................................ 13 3.1.1 eROU Enclosure installation ....................................................................... 13 3.1.2 eROU(External Antenna) Mount Installation................................................. 15 3.1.3 Installation Cable Gland ............................................................................. 17 3.1.4 Power cabling ........................................................................................... 18 3.1.8 Ground cabling ......................................................................................... 18 Confidential & Proprietary 4/19 Section1 Safety & Certification Notice Confidential & Proprietary 5/19 “Only qualified personnel should handle the DAS equipment. Any person involved in installation or service of the DAS should understand and follow these safety guidelines.” - Obey all general and regional installation and safety regulations relating to work on high voltage installations, as well as regulations covering correct use of tools and personal protective equipment. - The power supply unit in repeaters contains dangerous voltage level, which can cause electric shock. Switch the mains off prior to any work in such a repeater. Any local regulations are to be followed when servicing repeaters. - eROU equipment is exclusive to the indoor. - Use this unit only for the purpose specified by the manufacturer. Do not carry out any modifications or fit any spare parts which are not sold or recommended by the manufacturer. This could cause fires, electric shock or other injuries. - Any DAS system or Fiber BDA will generate radio (RF) signals and continuously emit RF energy. Avoid prolonged exposure to the antennas. SOLiD recommends maintaining a 50 cm minimum clearance from the antenna while the system is operating. - Do not operate this unit on or close to flammable materials, as the unit may reach high temperatures due to power dissipation. - Do not use any solvents, chemicals, or cleaning solutions containing alcohol, ammonia, or abrasives on the DAS equipment. Alcohol may be used to clean fiber optic cabling ends and connectors. - To prevent electrical shock, switch the main power supply off prior to working with the DAS System or Fiber BDA. Never install or use electrical equipment in a wet location or during a lightning storm. - Do not look into the ends of any optical fiber or directly into the optical transceiver of any digital unit. Use an optical spectrum analyzer to verify active fibers. Place a protective cap over any radiating transceiver or optical fiber connector to avoid the potential of radiation exposure. - Allow sufficient fiber length to permit routing without severe bends. - For pluggable equipment, make sure to install the socket outlet near the equipment so that it is easily accessible. - A readily accessible disconnect device shall be incorporated external to the equipment. - This power of this system shall be supplied through wiring installed in a normal building. If powered directly from the mains distribution system, it shall be used additional protection, such as Confidential & Proprietary 6/19 overvoltage protection device - Only 50 ohm rated antennas, cables and passive equipment shall be used with this remote. Any equipment attached to this device not meeting this standard may cause degradation and unwanted signals in the bi-directional system. All components connected to this device must operate in the frequency range of this device. - Only 50 ohm rated antennas, cables and passive components operating from 150 - 3 GHz shall be used with this device. - The head end unit must always be connected to the Base Station using a direct cabled connection. This system has not been approved for use with a wireless connection via server antenna to the base station. - Access can only be gained by SERVICE PERSONS or by USERS who have been instructed about the reasons for the restrictions applied to t…

Text truncated - open the document above for the full version.

SOLiD, Inc. 10,9th Floor, SOLiD Space 220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 463-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 ____________________________________________________________________________ Date: March 31, 2022 Fed eral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Subject: Letter for Warning Label Message FCC ID:W6UER781719 To Whom It May Concern: Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device per KDB 935210 D02 Signal Boosters Certification v04r02 in Section IV clause (d) . Best Regards Company Name : SOLiD, Inc. Company Address : 10,9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Contact Person Name/Title (in print) : Yong chul Kim / Team Manager E-mail : [email protected]

Date : Nov. 9, 2017 Rev : 2.3 FCC Agent Authorization Letter HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC Date : Nov. 9, 2017 Rev : 2.3 REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC SOLiD, Inc. DATE : March 15, 2022 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : FCC Agent Authorization Letter for FCC ID : W6UER781719 We, the undersigned, her eby authorize HCT CO., LTD. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO., LTD. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: Company Name : SOLiD, Inc. Company Address : 10,9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Contact Person Name/Title (in print) : Yong chul Kim / Team Manager E-mail : [email protected] HACS-F004 FCC Agent Authorization Letter Rev : 2.3

Date : Nov. 09, 2017 Rev : 3.0 FCC Confidentiality Request Letter H ACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC Date : Nov. 09, 2017 Rev : 3.0 REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 3.0 Updated LTC and STC Confidentiality table 11/09/2017 QM H ACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC SOLiD, Inc. DATE : March 15, 2022 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT : Request for Confidentiality for FCC ID : W6UER781719 We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Operational Description 3 Parts List 4 Schematics 5 Tune-up Procedure SHORT-TERM CONFIDENTIAL (180 DAYS) 6 External Photos 7 Internal Photos 8 Test-Setup Photos 9 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: Company Name : SOLiD, Inc. Company Address : 10,9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Contact Person Name/Title (in print) : Yong chul Kim / Team Manager E-mail : [email protected] HACS-F003 FCC Confidentiality Request Letter Rev : 3.0

SOLiD, Inc. DATE: March 15, 2022 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Product Equality Declaration •FCC ID: W6UER781719 •model name: eROU_781719L1_X, eROU_781719L2_X, eROU_781719L1_N, eROU_781719L2_N There are some models under this FCC ID: W6UER781719 and we evaluated all models as described in the test report. Please refer to the operational description for the detailed information. If you have questions or need further information, please contact the undersigned. Sincerely, Company Name : SOLiD, Inc. Company Address : 10,9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Contact Person Name/Title (in print) : Yong chul Kim / Team Manager E-mail : [email protected]

FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 17 EXTERNAL PHOTOGRAPHS FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 17 ■ EXTERNAL PHOTO(Internal Left) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 17 ■ EXTERNAL PHOTO(Internal Right) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 17 ■ EXTERNAL PHOTO(Internal Rear) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 17 ■ EXTERNAL PHOTO(Internal Front) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 17 ■ EXTERNAL PHOTO(Internal Bottom) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 17 ■ EXTERNAL PHOTO(Internal Top) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 17 ■ EXTERNAL PHOTO(External Bottom) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 17 ■ EXTERNAL PHOTO(External Top) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 17 ■ EXTERNAL PHOTO(External Top-1) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 17 ■ EXTERNAL PHOTO(External Top-2) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １２ of 17 ■ EXTERNAL PHOTO(External Top-3) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １３ of 17 ■ EXTERNAL PHOTO(External Top-4) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １４ of 17 ■ EXTERNAL PHOTO(External Side-1) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １５ of 17 ■ EXTERNAL PHOTO(External Side-2) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １６ of 17 ■ EXTERNAL PHOTO(External Side-3) FCC ID: W6UER781719 HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １７ of 17 ■ EXTERNAL PHOTO(External Side-4)

FCC ID location Alliance eROU_781719L1 Label (Internal) MODEL : AGCS_DC RATING : 39-57V , 0.82-0.58A TM SOLiDGENESIS Made in Korea eROU_781719L1_N SOLiDAlliance FCC ID : W6UER781719 MODEL : AGCS_DC TM SOLiDGENESIS Made in Vietnam eROU_781719L1_N SOLiDAlliance FCC ID : W6UER781719 RATING : 39-57V , 0.82-0.58A Alliance eROU_781719L1 Label (External) MODEL : AGCS_DC RATING : 39-57V , 0.82-0.58A TM SOLiDGENESIS Made in Korea eROU_781719L1_X SOLiDAlliance MODEL : AGCS_DC TM SOLiDGENESIS Made in Vietnam eROU_781719L1_X SOLiDAlliance RATING : 39-57V , 0.82-0.58A FCC ID : W6UER781719FCC ID : W6UER781719 Alliance eROU_781719L2 Label (Internal) MODEL : AGCS_DC RATING : 39-57V , 0.82-0.58A TM SOLiDGENESIS Made in Korea eROU_781719L2_N SOLiDAlliance MODEL : AGCS_DC TM SOLiDGENESIS Made in Vietnam eROU_781719L2_N SOLiDAlliance RATING : 39-57V , 0.82-0.58A FCC ID : W6UER781719FCC ID : W6UER781719 Alliance eROU_781719L2 Label (External) MODEL : AGCS_DC RATING : 39-57V , 0.82-0.58A TM SOLiDGENESIS Made in Korea eROU_781719L2_X SOLiDAlliance MODEL : AGCS_DC TM SOLiDGENESIS Made in Vietnam eROU_781719L2_X SOLiDAlliance RATING : 39-57V , 0.82-0.58A FCC ID : W6UER781719FCC ID : W6UER781719

FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 6 INTERNAL PHOTOGRAPHS FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 6 [TOP] FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 6 [Bottom] FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 6 [External Antenna Port] FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 6 [Internal Ant] FCC ID: W6UER781719 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 6 [Internal Cover]

TEST REPORT FCC MPE Test for eROU_781719L1_X Certification APPLICANT SOLiD, Inc. REPORT NO. HCT-RF-2203-FC008-R1 DATE OF ISSUE April 8, 2022 Tested by Kyung Soo Kang Technical Manager Jong Seok Lee F-TP22-03(Rev.04) HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 Fax. +82 31 645 6401 1 / 25 The report shall not be reproduced except in full(only partly) without approval of the laboratory. F-TP22-03 (Rev. 04) Page 2 of 25 HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 Fax. +82 31 645 6401 TEST REPORT FCC MPE Test for eROU_781719L1_X REPORT NO. HCT-RF-2203-FC008-R1 DATE OF ISSUE April 08, 2022 Additional Model eROU_781719L1_N, eROU_781719L2_X, eROU_781719L2_N ApplicantSOLiD, Inc. 10, 9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400, South Korea Eut Type Model Name ALLIANCE eROU eROU_781719L1_X FCC ID W6UER781719 The result shown in this test report refer only to the sample(s) tested unless otherwise stated. This test results were applied only to the test methods required by the standard. Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 3 of 25 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 March 03, 2022 Initial Release 1 April 08, 2022 Revised the result. The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance. If this report is required to confirmation of authenticity, please contact to www.hct.co.kr Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 4 of 25 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34 1.34 - 30 30 - 300 300 - 1500 1500 - 100.000 614 824/f 27.5   1.63 2.19/f 0.073   *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 5 of 25 3. Result [Internal Antenna] - Lower 700 MHz - LTE 5 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 728.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.4853 mW/cm 2 - Lower 700 MHz - LTE 10 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 728.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.4853 mW/cm 2 Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 6 of 25 - Upper 700 MHz - LTE 5 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 746.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.4973 mW/cm 2 - Upper 700 MHz - LTE 10 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 746.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.4973 mW/cm 2 Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 7 of 25 - FirstNet - LTE 5 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 758.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5053 mW/cm 2 - FirstNet - LTE 10 MHz (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 758.00 MHz Antenna Gain(typical) 3.27 dBi Antenna Gain(numeric) 2.12 - Power density at prediction frequency( S) 0.0138 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5053 mW/cm 2 Report No. HCT-RF-2203-FC008-R1 F-TP22-03 (Rev. 04) Page 8 of 25 - ESMR - CDMA (Downlink) Max Peak output Power at antenna input terminal 20.00 dBm Max Peak output Power at antenna input terminal 100.00 mW Prediction distance 35.00 cm Prediction frequency 862.00 MHz Antenna Gain(typical) 3.67 dBi Antenna Gain(numeric) 2.33 - Power density at prediction frequency( S) 0.0151 mW/cm 2 MPE limit for uncont…
