Confidential & Proprietary 1/32 Alliance-TR_N2ROU_CALA for Mexico(Remote Unit) User Manual SOLiD, Inc. 10,9th Floor, SOLiD Space220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 393-400 Tel: +82-31-627-6290 Fax: +82-31-627-6209 Confidential & Proprietary 2/32 REVISION HISTORY Version Issue Date Section Description V 1.0 April 27, 2020 All Original Preface Technicians using these manuals should have completed the SOLiD Certification Program. SOLiD also recommends technicians be familiar with the concepts of fiber optic cabling, networking and wireless communication technologies, and SNMP. We further recommend training programs offered through CIBET (Certified In Building Engineering Technologist) and BICSI (Building Industry Consulting Service International). Copyright This manual is written and produced by SOLiD and printed in the USA. All rights are reserved ©2015 SOLiD. Confidential and proprietary. Information contained in this document is company private to SOLiD and should not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of SOLiD. Technical Support SOLiD serial numbers must be available to authorize technical support and/or to establish a return authorization for defective units. The serial numbers are located on the back of the unit, as well as on the box in which they were delivered. Additional support information may be obtained by accessing the SOLiD Tehcnology, Inc. website at www.solid.co.kr Confidential & Proprietary 3/32 Contents Section1 1.1 Safety & Certification Notice ............................................................................... 4 Section2 2.1 Overview ........................................................................................................... 7 2.2 N2ROU .............................................................................................................. 8 Section3 3.1 Functional Description ....................................................................................... 9 3.2 N2ROU Component .......................................................................................... 11 3.3 Dimension ....................................................................................................... 13 Section4 4.1 Installation ...................................................................................................... 14 4.2 Required Materials ........................................................................................... 14 4.3 Install N2ROU .................................................................................................. 17 4.3.1 Install N2ROU .................................................................................................. 17 4.3.2 N2ROU Power Cabling ...................................................................................... 21 4.3.3 N2ROU Ground Cabling .................................................................................... 22 4.3.4 Optical Cabling ................................................................................................. 24 4.3.5 Mounting N2RDU (Optional Modules) ............................................................... 25 4.3.6 MIMO Antenna Connection (Optional) .............................................................. 28 Section5 5.1 Specifications................................................................................................... 29 5.2 RF Performance ............................................................................................... 30 5.3 Certification ..................................................................................................... 30 Confidential & Proprietary 4/32 Section1 1.1 Safety & Certification Notice “Only qualified personnel should handle the DAS equipment. Any person involved in installation or service of the DAS should understand and follow these safety guidelines.” - Obey all general and regional safety regulations relating to work on high voltage installations, as well as regulations covering correct use of tools and personal protective equipment. - The power supply unit in repeaters contains dangerous voltage level, which can cause electric shock. Switch the mains off prior to any work in such a repeater. Any local regulations are to be followed when servicing repeaters. - To prevent electrical shock, switch the main power supply off prior to working with the DAS System or Fiber BDA. Never install or use electrical equipment in a wet location or during a lightning storm. - When working with units outdoors, make sure to securely fasten the door or cover in an open position to prevent the door from slamming shut in windy conditions. - Use this unit only for the purpose specified by the manufacturer. Do not modify or fit any spare parts that are not sold or recommended by the manufacturer. This could cause fires, electric shock or other injuries. - Any DAS system or Fiber BDA will generate radio (RF) signals and continuously emit RF energy. Avoid prolonged exposure to the antennas. SOLiD recommends maintaining a 310cm minimum clearance from the antenna while the system is operating. - Do not operate this unit on or close to flammable materials, as the unit may reach high temperatures due to power dissipation. - Do not use any solvents, chemicals, or cleaning solutions containing alcohol, ammonia, or abrasives on the DAS equipment. Alcohol may be used to clean fiber optic cabling ends and connectors. - Do not look into the ends of any optical fiber or directly into the optical transceiver of any digital unit. Use an optical spectrum analyzer to verify active fibers. Place a protective cap over any radiating transceiver or optical fiber connector to avoid the potential of radiation exposure. - Allow sufficient fiber length to permit routing without severe bends. Confidential & Proprietary 5/32 - For pluggable equipment, make sure to install the socket outlet near the equipmen…
Text truncated - open the document above for the full version.
SOLiD, Inc. 10,9th Floor, SOLiD Space 220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 463-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 ____________________________________________________________________________ Date: Jun 10, 2020 Federal Communications Com mission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Subject: Letter for Warning Label Message FCC ID: W6ULL2600FM To Whom It May Concern: Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device per KDB 935210 D02 Signal Boosters Certification v04r02 in Section IV clause. Best Regards Contact Name : Yong chul Kim E-mail : [email protected]
Date : Nov. 9, 2017 Rev : 2.3 FCC Agent Authorization Letter HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC Date : Nov. 9, 2017 Rev : 2.3 REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC SOLiD, Inc. DATE : Jun 10, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: S ubject : FCC Agent Authorization Letter for FCC ID : W6ULL2600FM We, the un dersigned, hereby authorize HCT CO., LTD. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO., LTD. on our behalf shall have the same effect as acts of our own. We, the un dersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: Company Name : SOLiD, Inc. Company Address : 10,9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Contact Person Name/Title (in print) : Yong chul Kim / Manager E-mail : [email protected] HACS-F004 FCC Agent Authorization Letter Rev : 2.3
FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 1 of 7 EXTERNAL PHOTOGRAPHS FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 2 of 7 ■ EXTERNAL PHOTO(LEFT) FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 3 of 7 ■ EXTERNAL PHOTO(RIGHT) FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 4 of 7 ■ EXTERNAL PHOTO(REAR) FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 5 of 7 ■ EXTERNAL PHOTO(FRONT) FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 6 of 7 ■ EXTERNAL PHOTO(BOTTOM) FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 7 of 7 ■ EXTERNAL PHOTO(TOP)
Trigonometry SYM. REV. DESCRIPTION DRAWN APPROVED DATE Q'TY/SETMATERIALFINISH ERP Code : TITLE APPROVALS DRAWN CHECKED APPROVED SIZE TOLERANCE ANGULAR UNLESS OTHERWISE SPECIFIED : DECIMAL DIMENSION ARE IN MM 1 A WEIGHT SCALE DATE Korea RF ~ 150 150~300 300~1000 ±0.1 ±0.2 ±0.3 DIVISION TOLERANCE GENERAL TAP DP ±0.1 ±0.1 DIVISION TOLERANCE DIMENSIONAL ALLOWANCE (mm) Model : STRAIGHTNESS & FLATNESS (mm) White Chromate (Cr3+) Electrolysis Nickel Anode MA.KIM JY.MAENG 1SET 2019-10-28 - THOR N2RDU Assy AL6061 AL5052 외형도 KIS2635-70LS-RNG ALM ON RX OUT RX IN I/O TX OUT TX IN (BYPASS)(BYPASS) MUX_TXMUX_RX TX(IF) VGS2 VGS1 TX(RF) RX TR_N2RDU_L2600F_M ALLIANCE-TR 290 5 140 140 1305 140 25 13158415 11,84 74 6- ∅ 4.5 Hole Thru WARNING. This is NOT a CONSUMER device. It is designed for installation by FCCLICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or expressconsent of an FCC Licensee to operate this device. You MUST register Part 90 Class B signal boosters (as defined in 47 CFR 90.219) online at forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. Part 90 and Part 20 Signal Boosterswww.fcc.gov/signal-boosters/registration. Unauthorized use may result in significant THIS IS A 90.219. CLASS B DEVICE
FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 1 of 4 INTERNAL PHOTOGRAPHS FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 2 of 4 [RDU PCB TOP] FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 3 of 4 [RDU PCB Bottom] FCC ID: W6ULL2600FM / IC: 9354A-LL2600FM HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page 4 of 4 [RDU]
TEST REPORT FCC MPE Test for TR_N2RDU_L2600F_M APPLICANT SOLiD, Inc. REPORT NO. HCT-RF-2005-FC028-R3 DATE OF ISSUE 1 July 2020 Tested by Kyung Soo Kang Technical Manager Jong Seok Lee HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 F-TP22-03 (Rev. 03) Page 2 of 6 HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 Fax. +82 31 645 6401 TEST REPORT FCC MPE Test for TR_N2RDU_L2600F_M REPORT NO. HCT-RF-2005-FC028-R3 DATE OF ISSUE July 01, 2020 Additional Model - ApplicantSOLiD, Inc. 10, 9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400, South Korea Eut Type Model Name DAS TR_N2RDU_L2600F_M FCC ID W6ULL2600FM The result shown in this test report refer only to the sample(s) tested unless otherwise stated. This test results were applied only to the test methods required by the standard. Report No. HCT-RF-2005-FC028-R3 F-TP22-03 (Rev. 03) Page 3 of 6 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 June 04, 2020 Initial Release 1 June 16, 2020 - Revised Eut Type from ˎAlliance TR N2ROU CALAˏ to ˎDASˏ - Revised the data table. - Added MIMO data(optional) and the simultaneous band emission conditions. 2 June 29, 2020 - Revised model name and ID. 3 July 01, 2020 - Revised model name. The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance. * The report shall not be reproduced except in full(only partly) without approval of the laboratory. Report No. HCT-RF-2005-FC028-R3 F-TP22-03 (Rev. 03) Page 4 of 6 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1.34 - 30 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 30 - 300 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 300 - 1500 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1500 - 100.000 ̆ ̆ ̆ ̆ ̆ ̆ 614 824/f 27.5 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1.63 2.19/f 0.073 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No. HCT-RF-2005-FC028-R3 F-TP22-03 (Rev. 03) Page 5 of 6 - BRS/EBS B Path ˊ LTE 10 MHz (Downlink) Max Peak output Power at antenna input terminal 34.00 dBm Max Peak output Power at antenna input terminal 2511.89 mW Prediction distance 320.00 cm Prediction frequency 2636.10 MHz Antenna Gain(typical) 17.00 dBi Antenna Gain(numeric) 50.12 - Power density at prediction frequency( S) 0.0978 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.0000 mW/cm 2 [Optional: Ant 1 + Ant 2 (MIMO)] - BRS/EBS (Downlink) Max Peak output Power at antenna input terminal 37.00 dBm Max Peak output Power at antenna input terminal 5011.87 mW Prediction distance 320.00 cm Prediction frequency 2636.10 MHz Antenna Gain(typical) 17.00 dBi Antenna Gain(numeric) 50.12 - Power density at prediction frequency( S) 0.1952 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.0000 mW/cm 2 Report No. HCT-RF-2005-FC028-R3 F-TP22-03 (Rev. 03) Page 6 of 6 Simultaneous band emission conditions TR_N2RDU_1900P_M & TR_N2RDU_L2600F_M Band MPE Ratio (Power density / Limit) Sum of MPE Ratio PCS 0.0978 0.1957 ͕ 1 BRS/EBS 0.0978 TR_N2RDU_AWS13_M & TR_N2RDU_L2600F_M Band MPE Ratio (Power density / Limit) Sum of MPE Ratio AWS 0.0978 0.1957 ͕ 1 BRS/EBS 0.0978 *Note 1. The result of each band was applied to the worst value. 2. MPE ratios are calculated as [(Power density1 / MPE Limit) + [(Power density2 / MPE Limit) + ̆] ͕ 1
TEST REPORT FCC Test for TR_N2RDU_L2600F_M APPLICANT SOLiD, Inc. REPORT NO. HCT-RF-2005-FC027-R4 DATE OF ISSUE 1 July 2020 Tested by Kyung Soo Kang Technical Manager Jong Seok Lee HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 F-TP22-03 (Rev. 03) Page 2 of 49 HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 Fax. +82 31 645 6401 TEST REPORT FCC Test for TR_N2RDU_L2600F_M REPORT NO. HCT-RF-2005-FC027-R4 DATE OF ISSUE July 01, 2020 Additional Model - ApplicantSOLiD, Inc. 10, 9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400, South Korea Eut Type Model Name DAS TR_N2RDU_L2600F_M FCC ID W6ULL2600FM Output Power33 dBm Date of TestMay 15, 2020 ~ May 28, 2020 FCC Rule PartsCFR 47 Part 2, Part 27 The result shown in this test report refer only to the sample(s) tested unless otherwise stated. This test results were applied only to the test methods required by the standard. Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 3 of 49 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of IssueDescription 0 June 04, 2020Initial Release 1 June 16, 2020 - Revised Eut Type from ˎAlliance TR N2ROU CALAˏ to ˎDASˏ - Added Watt unit to output power table in Section 5.4 - Added MIMO sum data(optional) in Section 5.4.. - Revised RSE test result table in Section 5.6 2 June 19, 2020 - Revised the Radiated test diagram in Section 3.5. 3 June 29, 2020 - Revised the Radiated test diagram in Section 3.5. - Revised model name and ID. 4 July 01, 2020 - Revised model name and ID. The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance. * The report shall not be reproduced except in full(only partly) without approval of the laboratory. Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 4 of 49 CONTENTS 1. GENERAL INFORMATION 5 1.1. APPLICANT INFORMATION 5 1.2. PRODUCT INFORMATION 5 1.3. TEST INFORMATION 5 2. FACILITIES AND ACCREDITATIONS 6 2.1. FACILITIES 6 2.2. EQUIPMENT 6 3. TEST SPECIFICATIONS 7 3.1. STANDARDS 7 3.2. ADDITIONAL DESCRIPTIONS ABOUT TEST 8 3.3. MEASUREMENTUNCERTAINTY 10 3.4. STANDARDS ENVIRONMENTAL TEST CONDITIONS 10 3.5. TEST DIAGRAMS 11 4. TEST EQUIPMENTS 12 5. TEST RESULT 13 5.1. AGC THRESHOLD 13 5.2. OUT-OF-BAND REJECTION 15 5.3. INPUT-VERSUS-OUTPUT SIGNAL COMPARISON 17 5.4. INPUT/OUTPUT POWER AND AMPLIFIER/BOOSTER GAIN 22 5.5. OUT-OF-BAND/OUT-OF-BLOCK EMISSIONS AND SPURIOUS EMISSIONS 26 5.6. RADIATED SPURIOUS EMISSIONS 46 6. Annex A_EUT AND TEST SETUP PHOTO 49 Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 5 of 49 1. GENERAL INFORMATION 1.1. APPLICANT INFORMATION Company Name SOLiD, Inc. Company Address 10, 9th Floor, SOLiD Space, Pangyoyeok-ro 220, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400, South Korea 1.2. PRODUCT INFORMATION EUT Type DAS EUT Serial Number S0001 Power Supply 100-240VAC, 50/60Hz Frequency Range Band Name Uplink (MHz) Downlink (MHz) BRS/EBS 2 620 ~ 2 690 Tx Output Power 33 dBm Antenna Peak Gain 17 dBi 1.3. TEST INFORMATION FCC Rule Parts CFR 47 Part 2, Part 27 Measurement Standards KDB 935210 D05 v01r04, ANSI C63.26-2015 Test Location HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 6 of 49 2. FACILITIES AND ACCREDITATIONS 2.1. FACILITIES The SAC(Semi-Anechoic Chamber) and conducted measurement facility used to collect the radiated data are located at the 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 (Version: 2014) and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated April 02, 2018 (Registration Number: KR0032). 2.2. EQUIPMENT Radiated emissions are measured with one or more of the following types of linearly polarized antennas: tuned dipole, bi-conical, log periodic, bi-log, and/or ridged waveguide, horn. Spectrum analyzers with pre-selectors and quasi-peak detectors are used to perform radiated measurements. Calibrated wideband preamplifiers, coaxial cables, and coaxial attenuators are also used for making measurements. All receiving equipment conforms to CISPR Publication 16-1, ˑRadio Interference Measuring Apparatus and Measurement Methods.˒ Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 7 of 49 3. TEST SPECIFICATIONS 3.1. STANDARDS The following tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 2 and Part 27. Description Reference Results AGC threshold KDB 935210 D05 v01r04 3.2 Compliant Out-of-band rejection KDB 935210 D05 v01r04 3.3 Compliant Input-versus-output signal comparison §2.1049 Compliant Input/output power and amplifier/booster gain§2.1046, §27.50(h) Compliant Out-of-band/out-of-block emissions and spurious emissions §2.1051, §27.53(m) Compliant Spurious emissions radiated §2.1053 Compliant Report No. HCT-RF-2005-FC027-R4 F-TP22-03 (Rev. 03) Page 8 of 49 3.2. ADDITIONAL DESCRIPTIONS ABOUT TEST Except for the following cases, EUT was tested under normal operating conditions. : Out-of-band rejection test requires maximum gain condition without AGC. This EUT is supported power supply both of AC and DC. Test results are only attached worst cases. The test was generally based on the method of KDB 935210 …
