W9Z-INTEGRA5G8Point-To-Point Digital Transmission System

SAF Tehnika AS

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Oct 01, 2023
Application Purpose: Original Equipment
Date of Application: Sep 25, 2023
Equipment Note: Point-To-Point Digital Transmission System
Frequency Range: 5727.50000000 - 5847.50000000
Company: SAF Tehnika AS
Country: Latvia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INTEGRA/-S/-G/-GS User Manual WEB GUI SAF Tehnika JSC 95 Press button. Modify mode (buttons appear at the bottom of the page) 1) Statistics for – time during which statistics have been gathered; 2) Ingress Pkts. – Packets that ingress on the port; 3) Ingress Bytes – Bytes that ingress on the port; 4) Egress Pkts. – Packets that egress on the port; 5) Egress Bytes – Bytes that egress on the port; 6) Total Multicast Pkts. – The total number of good packets received that were directed to a multicast address. Note that this number does not include packets directed to the broadcast address; 7) Total Broadcast Pkts. – The total number of good packets received that were directed to the broadcast address. Note that this does not include multicast packets; 8) Total Pkts. 64 Octets – The total number of packets (including bad packets) that were 64 octets in length (excluding framing bits but including FCS octets); 9) Total Pkts. 65 to 127 Octets –The total number of packets (including bad packets) that were between 65 and 127 octets in length inclusive (excluding framing bits but including FCS octets); 10) Total Pkts. 128 to 255 Octets – The total number of packets (including bad packets) that were between 128 and 255 octets in length inclusive (excluding framing bits but including FCS octets); 11) Total Pkts. 256 to 511 Octets – The total number of packets (including bad packets) that were between 256 and 511 octets in length inclusive (excluding framing bits but including FCS octets); 12) Total Pkts. 512 to 1023 Octets – The total number of packets (including bad packets) that were between 512 and 1023 octets in length inclusive (excluding framing bits but including FCS octets); 13) Total Pkts. 1024 to 1518 Octets –The total number of packets (including bad packets) that were between 1024 and 1518 octets in length inclusive (excluding framing bits but including FCS octets); 14) Total Oversize Pkts. – The total number of packets that were longer than 1522 octets (excluding framing bits but including FCS octets) and were otherwise well formed; 15) Rx Oversize Pkts. – The total number of packets received that were longer than 1522 octets (excluding framing bits but including FCS octets) and were otherwise well formed; 16) Tx Oversize Pkts. – The total number of packets transmitted that were longer than 1522 octets (excluding framing bits but including FCS octets) and were otherwise well formed; 17) Total Octets – The total number of octets of data (including those in bad packets) received on the network (excluding framing bits but including FCS octets); 18) Total Pkts. – The total number of packets (including bad packets, broadcast packets, and multicast packets) received and transmitted; 19) Tx No Errors – The number of frames that have been transmitted by this port from its segment excluding fragmented and FCS error frames; 20) Rx No Errors – The number of frames that have been received by this port from its segment excluding fragmented and FCS error frames; INTEGRA/-S/-G/-GS User Manual WEB GUI SAF Tehnika JSC 96 21) Total Pkts. 1519 to 1522 Octets – The total number of packets (including bad packets) that were between 1519 and 1522 octets in length inclusive (excluding framing bits but including FCS octets); 22) In. Octets – The total number of octets received on the interface, including framing characters; 23) Out. Octets – The total number of octets transmitted out of the interface, including framing characters; 24) Dot1 Port In Frames – The number of frames that have been received by this port from its segment. Note that a frame received on the interface corresponding to this port is only counted by this object if and only if it is for a protocol being processed by the local bridging function, including bridge management frames; 25) Dot1 Port Out Frames – The number of frames that have been transmitted by this port to its segment. Note that a frame transmitted on the interface corresponding to this port is only counted by this object if and only if it is for a protocol being processed by the local bridging function, including bridge management frames.; 26) Received Pkts. 64 Octets – The total number of packets (including bad packets) received that were 64 octets in length (excluding framing bits but including FCS octets); 27) Transmitted Pkts. 64 Octets – The total number of packets (including bad packets) transmitted that were 64 octets in length (excluding framing bits but including FCS octets); 28) Received Pkts. 65 to 127 Octets – The total number of packets (including bad packets) received that were between 65 and 127 octets in length inclusive (excluding framing bits but including FCS octets); 29) Transmitted Pkts. 65 to 127 Octets – The total number of packets (including bad packets) transmitted that were between 65 and 127 octets in length inclusive (excluding framing bits but including FCS octets); 30) Received Pkts. 128 to 255 Octets – The total number of packets (including bad packets) received that were between 128 and 255 octets in length inclusive (excluding framing bits but including FCS octets); 31) Transmitted Pkts. 128 to 255 Octets – The total number of packets (including bad packets) transmitted that were between 128 and 255 octets in length inclusive (excluding framing bits but including FCS octets); 32) Received Pkts. 256 to 511 Octets – The total number of packets (including bad packets) received that were between 256 and 511 octets in length inclusive (excluding framing bits but including FCS octets); 33) Transmitted Pkts. 256 to 511 Octets – The total number of packets (including bad packets) transmitted that were between 256 and 511 octets in length inclusive (excluding framing bits but including FCS octets); 34) Received Pkts. 512 to 1023 Octets – The total number of packets (including bad packets) received that were between 512 and 1023 octets in length inclusive (excluding framing bits but including FCS octets); 35) Transmitted Pkts. 512 to 1023 Octets – The tota…

Text truncated - open the document above for the full version.

Users Manual

SAF Tehnika JSC 1 User manual Integra Integra-S Integra-G Integra-GS VER 2.37 FW 3.2 0 .19 INTEGRA/-S/-G/-GS User Manual OVERVIEW SAF Tehnika JSC 2 Proprietary notice The information presented in this guide is the property of SAF Tehnika, JSC. No part of this document may be reproduced or transmitted without proper permission from SAF Tehnika, JSC. The specifications or information contained in this document are subject to change without notice due to continuing introduction of design improvements. If there is any conflict between this document and compliance statements, the latter will supersede this document. SAF Tehnika, JSC has no liability for typing errors in this document or damages of any kind that result from the use of this document. To get up to date information about accessories and their availability, please contact a sales representative. FODU does not contain serviceable parts. Warranty will not be applicable in the event FODU has been hermetically unsealed. SAF Tehnika, JSC is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. The operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: − Reorient or relocate the receiving antenna. − Increase the separation between the equipment and the receiver. − Connect the equipment to an outlet on a circuit different from the one connected to the receiver. − Consult the dealer or an experienced radio/TV technician for help. This device complies with Industry Canada license-exempt RSS standard(s). The operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Copyright Notice Copyright © 2023 SAF Tehnika, JSC. All rights reserved. INTEGRA/-S/-G/-GS User Manual OVERVIEW SAF Tehnika JSC 3 Contents Chapter 1: OVERVIEW 6 Labeling ............................................................................................................... 6 Microwave Radiation .......................................................................................... 7 Integra-G 24 GHz FCC & IC IDs .......................................................................... 8 Chapter 2: INSTALLATION 9 Package contents ............................................................................................... 9 Integra/Integra-G FODU: assembling mounting bracket and installing with an antenna on a pole .......................................................................................... 9 Disassembled mounting bracket and tools required for assembly ............ 9 Changing the polarization of Integra/Integra-G FODU and antenna ....... 10 Assembly procedure ............................................................................... 12 Antenna alignment .................................................................................. 14 Integra-S/Integra-GS 15-42GHz* FODU: attaching to the antenna ............... 16 Integra-S/Integra-GS 6-13GHz* FODU: attaching to the antenna ................. 18 Integra-S/Integra-GS 6-13GHz* 2+0 & OMT interconnection ........................ 21 Connecting FO interface using fiber conduit kit ............................................. 23 Integra-GS 6-13GHz* remote mount kit assembly ......................................... 24 Integra-GS 15-42GHz* remote mount kit assembly ....................................... 25 Initial setup in the indoor environment ........................................................... 26 Chapter 3: WEB GUI 27 Initial configuration ........................................................................................... 27 Powering Integra/Integra-S/Integra-G/Integra-GS FODU and connecting to PC ....................................................................................................... 27 PoE injector (P/N I0ATPI22) ................................................................... 27 Universal programmable PoE injector (P/N I0ATPI24/I0ATPI44) ........... 28 System requirements .............................................................................. 29 Ethernet management connection configuration ..................................... 30 Accessing Web GUI ................................................................................ 30 Main page ............................................................................................... 32 Modifying basic system parameters ..........................…

Text truncated - open the document above for the full version.

Attestation Statements

SAF Tehnika AS VAT No.: LV40003474109 24a, Ganibu dambis Phone: +371 67046840 Riga, LV-1005, Latvia Fax: +371 67046840 www.saftehnika.com E-mail: [email protected] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 19, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: W9Z-INTEGRA5G8 SAF Tehnika AS, FRN: 0018662312 (“the applicant”) certifies that, as of the date of the filing of the application, SAF North America LLC is our designated U.S. agent for service of process for the above referenced FCC ID. SAF Tehnika AS accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. SAF North America LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: SAF North America LLC Address: 3250 Quentin Street, Unit 128, Aurora CO 80011 FRN: 0025802372 Contact Person: Peteris D’Carlo Tel.: (303) 501-9425 Email: [email protected] Sincerely, SAF Tehnika AS SAF North America LLC Aivis Danovskis Peteris D’Carlo (U.S. Agent signature) DocuSign Envelope ID: B751AA05-942D-44B3-9F58-38F0F88ACFF5

Attestation Statements

Cover Letter(s)

SAF Tehnika AS VAT No.: LV40003474109 24a, Ganibu dambis Phone: +371 67046840 Riga, LV-1005, Latvia Fax: +371 67046840 www.saftehnika.com E-mail: [email protected] Date: September 19, 2023 Innovation, Science and Economic Development Canada 3701 Carling Ave., Bldg. 94 Ottawa, ON, K2H 8S2 Applicant: Company Name: SAF Tehnika AS Company Address: 24a, Ganibu dambis Riga, Latvia, LV-1005 Equipment: Integra-5G8 IC: 8855A-INTEGRA5G8 Family Approval Cover Letter To whom it may concern SAF Tehnika AS does hereby state the equipment D06GSR18L, D06GSR18H are electrically identical, are produced using the same Printed Circuit Boards, Transmit and Receive modules and Diplexer, as well as they use the same firmware. D06GSR18L, D06GSR18H are in fact the Low and High Side Radios of Integra-5G8 product, and the only difference between them are different transmit (Tx) and receive (Rx) ranges, which are set during the manufacturing process and cannot be modified by user. Sincerely Aivis Danovskis Product Manager

Cover Letter(s)

File: INTEGRA5G8 Submittal letter Page 1 of 1 September 13, 2023 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: SAF Tehnika AS 24a, Ganibu dambis, Riga Latvia LV-1005 FCC ID: W9Z-INTEGRA5G8 FCC Rules: 15E U-NII-3 Point to Point 5 GHz transceiver Gentlemen The form 731 and application have been electronically submitted and any attachments will be uploaded to your site to be used in obtaining grant of certification. Permanent SAF Tehnika AS requests that the material in the Schematics, Block Diagram, Operational Descriptions, and Internal Photograph be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. Schematics Conf Schem D0M6LTXG01_R04_CDM.pdf Schematics Conf Schem D0MMDS02_R06_ADG_00.pdf Schematics Conf Schem D0MMDS02_R06_CDM_00.pdf Schematics Conf Schem D0M6LTXG01_R04_ADG.pdf Schematics Conf Schem D0M6LRXG01_R00_ADG_01.pdf Schematics Conf Schem D0M6LRXG01_R00_CDM_01.pdf Block Diagram Conf_Block_Diagram_Integra-5G8.pdf Operational Description Conf_IntPho_Integra-5G8.pdf Internal Photograph Conf_IntPho_Integra-5G8.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Cover Letter(s)

File: INTEGRA5G8 Conf Request Letter Page 1 of 2 September 13, 2023 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: SAF Tehnika AS 24a, Ganibu dambis, Riga Latvia LV-1005 FCC ID: W9Z-INTEGRA5G8 FCC Rules: 15E U-NII-3 Point to Point 5 GHz transceiver Dear Sirs: SAF Tehnika AS requests that the material in the Schematics, Block Diagram, Operational Description, and Internal Photographs be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, SAF Tehnika AS submits the following: Long Term Confidential Files Include Schematics Conf Schem D0M6LTXG01_R04_CDM.pdf Schematics Conf Schem D0MMDS02_R06_ADG_00.pdf Schematics Conf Schem D0MMDS02_R06_CDM_00.pdf Schematics Conf Schem D0M6LTXG01_R04_ADG.pdf Schematics Conf Schem D0M6LRXG01_R00_ADG_01.pdf Schematics Conf Schem D0M6LRXG01_R00_CDM_01.pdf Block Diagram Conf_Block_Diagram_Integra-5G8.pdf Operational Description Conf_IntPho_Integra-5G8.pdf Internal Photograph Conf_IntPho_Integra-5G8.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Schematics, Block Diagram, Operational Description, and Internal Photographs which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID: W9Z-INTEGRA5G8 ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 File: INTEGRA5G8 Conf Request Letter Page 2 of 2 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail detailed confidential information which is not publicly available. As such, this material is treated as highly confidential business information. 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of SAF Tehnika AS engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to SAF Tehnika AS. Internal photos should be held confidential for a permanent amount of time. The device is sealed, and disassembly would destroy the product. The device will not be accessible by general public and is only serviceable by SAF Tehnika AS or authorized representatives directly. Releasing internal photos will reveal company secrets and take away any competitive advantage in the market. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by SAF Tehnika AS and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Cover Letter(s)

September 12, 2023 SAF Tehnika AS 24a, Ganibu dambis, Riga Latvia LV-1005 RE: Confidentiality Request FCC ID: W9Z-INTEGRA5G8 To Whom It May Concern: This letter serves as an official request for confidentiality status under sections 0.457 and 0.459 of CFR 47. We have requested that the following listed items, which are required to be submitted with this application, be permanently w ithheld from public review. Schematics Block Diagram Operational Description Internal Photographs The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. Disclosure would, in effect, give away the fruits of the labors of SAF Tehnika AS engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to SAF Tehnika AS. The information which confidentiality is being requested is not available or accessible to the public and available only to those held under a Non-Disclosure Agreement. Internal photos should be held confidential for a permanent amount of time. The device is sealed, and disassembly would destroy the product. The device will not be accessible by general public and is only serviceable by SAF Tehnika AS or authorized representatives directly. Releasing internal photos or User Manual will reveal company secrets and take away any competitive advantage in the market. Please contact me if there is any information you may need. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053

External Photos

Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 1 of 8 External photographs of equipment under test (Low side, D06GSR18L) Label Placement Label Placement Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 2 of 8 Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 3 of 8 Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 4 of 8 High Side, D06GSR18H Label Placement Label Placement Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 5 of 8 Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 6 of 8 Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 7 of 8 Rogers Labs, Inc. SAF Tehnika AS S/N’s: 508120100587 / 501810100588 4405 W. 259th Terr PMN: Integra-5G8 FCC ID: W9Z-INTEGRA5G8 Louisburg, KS 66053 Test: 230711 IC: 8855A-INTEGRA5G8 Phone/Fax: (913) 837-3214 Test to: 47CFR, 15.407, RSS-247 Date: September 20, 2023 Revision 1 File: INTEGRA5G8 ExtPho1 Page 8 of 8

ID Label/Location Info

Rogers Labs, Inc. 4405 West 259th Terrace Louisburg, KS 66053 Phone/Fax: (913) 837-3214 Revision 1 SAF Tehnika AS Model: Integra-5G8 Test: 230709 Test to: 47CFR, Part 15E, §15.407 and Canada RSS-247 Issue 2 File: LabelSmpl_Integra-5G8.pdf Date: July 4, 2023 FCC: W9Z-INTEGRA5G8 IC: 8855A-INTEGRA5G8 Page 1 of 3 Label samples of the equipment under tests Radio model number: SAF Integra-5G8. Date taken: 2023-07-04. Pic. 1, 2. Label placement Label is always placed: • Between the rips in the middle of the heatsink on the front side of the product, assuming the front side is where the antenna flange is located. • On the left upper corner of the back side of the product, if wire handle is located on the top but connectors - on the bottom. Rogers Labs, Inc. 4405 West 259th Terrace Louisburg, KS 66053 Phone/Fax: (913) 837-3214 Revision 1 SAF Tehnika AS Model: Integra-5G8 Test: 230709 Test to: 47CFR, Part 15E, §15.407 and Canada RSS-247 Issue 2 File: LabelSmpl_Integra-5G8.pdf Date: July 4, 2023 FCC: W9Z-INTEGRA5G8 IC: 8855A-INTEGRA5G8 Page 2 of 3 Pic. 3. Label sample of the L (Low) side radio. Pic. 4. Label sample of the H (High) side radio. Rogers Labs, Inc. 4405 West 259th Terrace Louisburg, KS 66053 Phone/Fax: (913) 837-3214 Revision 1 SAF Tehnika AS Model: Integra-5G8 Test: 230709 Test to: 47CFR, Part 15E, §15.407 and Canada RSS-247 Issue 2 File: LabelSmpl_Integra-5G8.pdf Date: July 4, 2023 FCC: W9Z-INTEGRA5G8 IC: 8855A-INTEGRA5G8 Page 3 of 3 Pic. 5. Printed label sample of the L (Low) side radio.

RF Exposure Info

Text truncated - open the document above for the full version.

Contact Information

Applicant

Aivis Danovskis(Product Manager)

[email protected]+37166951256Fax: +37167046809

Test Firm

Rogers Labs, a division of The Compatibility CntrPatrick Powell

[email protected]913-837-3214Fax: 913-837-3214

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.73 GHz - 5.85 GHz	1 W

Confidentiality

Long Term

Grant Notes

Output Power listed is the maximum conducted output power. Professional installation is required. Device is intended for point-to-point applications. The antenna(s) used for this transmitter must be installed and operated so as to provide a separation distance of at least 1024 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Operators must be informed of operating requirements for satisfying RF exposure compliance. This device supports 5, 10, 20, 25 and 30 MHz bandwidth modes.
