Verykool I123M User Guide Document Name I123M User Guide Document No. UM-GW-AL-141(E) Department for Editing Technology Management Department Version V1.0 Prepared By Xi Wang Security Class Confidential Effective Date 2012-08-30 Shenzhen Ginwave Technologies Co., Ltd. 《I123M(TD) User Guide》_V1.0 Proprietary & Confidential -0- Revision History Date Editor Revision Items VersionVerified by Approved by 2012-08-30 Xi Wang Initial version 1.0 《I123M(TD) User Guide》_V1.0 Proprietary & Confidential -I- Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: i123M (FCC ID: WA6I123M) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.735W/kg and when properly worn on the body is 0.695W/kg. This device was tested for typical body-worn operations with the back of the handset kept 1.5cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 1.5cm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 《I123M(TD) User Guide》_V1.0 Proprietary & Confidential -II- Table of Contents 1 SAFETY AND GENERAL INFORMATION ...................................................................................................... 1 1.1 B RIEF INTRODUCTION ................................................................................................................................................... 1 1.2 I MPORTANT SAFETY PRECAUTIONS ................................................................................................................................. 1 1.2.1 General Precautions ....................................................................................................................................... 1 1.2.2 Phone Precautions .......................................................................................................................................... 1 1.2.3 Battery Safety Precautions ............................................................................................................................ 2 1.2.4 Disposing of Used Battery ............................................................................................................................. 2 1.2.5 Charger Precautions ....................................................................................................................................... 3 1.2.6 Clean and Maintenance.................................................................................................................................. 3 1.3 T ERMINOLOGY EXPLANATION .......................................................................................................................................... 3 2 SPECIFICATION ............................................................................................................................................. 4 3 PHONE APPEARANCE AND KEYS ................................................................................................................. 4 3.1 P HYSICAL IMPRESSION .................................................................................................................................................. 4 3.2 K EYS SPECIFICATION ..................................................................................................................................................... 4 3.3 I CONS .......................................................................................................................................................................... 5 4 USER GUIDE ................................................................................................................................................... 6 4.1 INSTALLING THE BATTERY .............................................................................................................................................. 6 4.2 C HARGING THE BATTERY ................................................................................................................................................ 6 4.3 I NSERTING THE SIM CARD ..................................................................................…

Text truncated - open the document above for the full version.

verykool USA INC. FCC Confidentiality Request Number: CF303 Version: V02 Date:17-06-2011 To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name verykool USA INC. Address 4350 Executive Dr. # 100 San Diego, CA 92121 City San Diego Country USA request for this certification filing under: Grantee Code Product Number FCC ID: WA6 I123M to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) Exhibit File Name Description Operational Description Operational description Block Diagrams Block Diagram Schematics Diagrams circuit diagram Bill of Materials BOM Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) 2012-9-3 Sunny Choi San Diego, USA

[company header] FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name verykool USA INC. Address 4350 Executive Dr. # 100 San Diego, CA 92121 City San Diego Country USA declare that the following representative (agent): Name (person) Rex Luo Company name Shenzhen Top-cert Test Service Co., Limited Address Roomu 506, Gushu 2nd Road, Xixiang, Baoan District, City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Mobile Phone Type or Model(s) i123M Tradename or Brand(s) verykool We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) 2012-9-3 Sunny Choi  San Diego, USA verykool USA INC.

Declaration We, verykool USA INC.declare that the phonei123M(FCC ID: WA6I123M)can support of two SIM cards, but the phone can physically only transmit with one base station at the time, and also have one line active at the time. Sunny Choi

FCC ID: WA6I123M Report No.: DPH120829F01 Page 25 of 33 FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE FCC ID: WA6I123M Report No.: DPH120829F01 Page 26 of 33 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FCC ID: WA6I123M Report No.: DPH120829F01 Page 27 of 33 UP VIEW OF SAMPLE DOWN VIEW OF SAMPLE FCC ID: WA6I123M Report No.: DPH120829F01 Page 28 of 33 PHOTO OF CHARGER PHOTO OF HEADPHONE FCC ID: WA6I123M Report No.: DPH120829F01 Page 29 of 33 PHOTO OF BATTERY PHOTO OF USB CABLE

Label Sample

FCC ID: WA6I123M Report No.: DPH120829F01 Page 30 of 33 INTERNAL PHOTO OF SAMPLE - 1 INTERNAL PHOTO OF SAMPLE -2 FCC ID: WA6I123M Report No.: DPH120829F01 Page 31 of 33 INTERNAL PHOTO OF SAMPLE - 3 INTERNAL PHOTO OF SAMPLE - 4 FCC ID: WA6I123M Report No.: DPH120829F01 Page 32 of 33 INTERNAL PHOTO OF SAMPLE - 5 INTERNAL PHOTO OF SAMPLE - 6 FCC ID: WA6I123M Report No.: DPH120829F01 Page 33 of 33 INTERNAL PHOTO OF SAMPLE - 7 ------END OF REPORT------

Compliance Certification Services Inc. Reference No .: KS120829A01-SE Date of Issue: August 30.2012 Report No .: KS120829A01-SE Page 1 of 19 GSM 850-Right Head Cheek Low CH128........................................................................................ 2 GSM 850-Right Head Cheek Middle CH190.................................................................................... 3 GSM 850-Right Head Cheek High CH251........................................................................................ 4 GSM 850-Right Head Tilted High CH251......................................................................................... 5 GSM 850-Left Head Cheek High CH251.......................................................................................... 6 GSM 850-Left Head Tilted High CH251............................................................................................ 7 PCS-1900-Right Head Cheek Low CH512....................................................................................... 8 PCS-1900-Right Head Cheek Middle CH661.................................................................................. 9 PCS-1900-Right Head Cheek High CH810.................................................................................... 10 PCS-1900-Right Head Tilted High CH810......................................................................................11 PCS 1900-Left Head Cheek High CH810....................................................................................... 12 PCS 1900-Left Head Tilted High CH810........................................................................................ 13 GSM 850-Body Up High CH251....................................................................................................... 14 GSM 850-Body Down Low CH128................................................................................................... 15 GSM 850-Body Down Middle CH190.............................................................................................. 16 GSM 850-Body Down High CH251.................................................................................................. 17 PCS1900-Body Up High CH810....................................................................................................... 18 PCS1900-Body Down High CH810................................................................................................. 19 Compliance Certification Services Inc. Reference No .: KS120829A01-SE Date of Issue: August 30.2012 Report No .: KS120829A01-SE Page 2 of 19 Test Laboratory: Compliance Certification Services Inc. May 22, 2012 GSM 850-Right Head Cheek Low CH128 DUT: Mobile Phone; Type: I123M; Serial: 135790246811220 Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 824.2 MHz;Communication System PAR: 9.03 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.88 mho/m; ε r = 41.628; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration: • Probe: EX3DV4 - SN3755; ConvF(8.99, 8.99, 8.99); Calibrated: 1/20/2012 • Sensor-Surface: 2.5mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2012 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.0(692); SEMCAD X 14.6.4(4989) GSM850/Right Head Cheek Low CH128/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.513 mW/g GSM850/Right Head Cheek Low CH128/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.404 V/m; Power Drift = 0.17 dB Peak SAR (extrapolated) = 0.710 W/kg SAR(1 g) = 0.466mW/g; SAR(10 g) = 0.265 mW/g Maximum value of SAR (measured) = 0.480 mW/g Compliance Certification Services Inc. Reference No .: KS120829A01-SE Date of Issue: August 30.2012 Report No .: KS120829A01-SE Page 3 of 19 Test Laboratory: Compliance Certification Services Inc. May 22, 2012 GSM 850-Right Head Cheek Middle CH190 DUT: Mobile Phone; Type: I123M; Serial: 135790246811220 Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 836.6 MHz;Communication System PAR: 9.03 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.89 mho/m; ε r = 41.478; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration: • Probe: EX3DV4 - SN3755; ConvF(8.99, 8.99, 8.99); Calibrated: 1/20/2012 • Sensor-Surface: 2.5mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2012 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.0(692); SEMCAD X 14.6.4(4989) GSM850/Right Head Cheek Middle CH190/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.585 mW/g GSM850/Right Head Cheek Middle CH190/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.332 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 0.837 W/kg SAR(1 g) = 0.533 mW/g; SAR(10 g) = 0.326 mW/g Maximum value of SAR (measured) = 0.561 mW/g Compliance Certification Services Inc. Reference No .: KS120829A01-SE Date of Issue: August 30.2012 Report No .: KS120829A01-SE Page 4 of 19 Test Laboratory: Compliance Certification Services Inc. May 22, 2012 GSM 850-Right Head Cheek High CH251 DUT: Mobile Phone; Type: I123M; Serial: 135790246811220 Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 848.6 MHz;Communication System PAR: 9.03 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 848.6 MHz; σ = 0.899 mho/m; ε r = 41.327; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (I…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: KS120829A01-SF FCCID: WA6I123MDate of Issue :August 30,2012 Page 1 of 99 Rev. 01 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. ANSI/IEEE Std. C95.1-1999 In accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC SAR TEST REPORT For Product Name: Mobile Phone Brand Name: Verykool Model No.:i123M Series Model: Test Report Number: KS120829A01-SF Issued for verykool USA INC. 4350 Executive Dr. 100 San Diego, CA 92121 Issued by Compliance Certification Services Inc. Kun shan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No: KS120829A01-SF FCCID:WA6I123MDate of Issue :August 30,2012 Page 2 of 99 Rev. 01 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) ........................................................... 3 2. EUT DESCRIPTION....................................................................................................................4 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC................................ 5 4. TEST METHODOLOGY.............................................................................................................. 5 5. TEST CONFIGURATION ............................................................................................................ 5 6. DOSIMETRIC ASSESSMENT SETUP........................................................................................ 6 6.1 MEASUREMENT SYSTEM DIAGRAM ...........................................................................................................7 6.2 SYSTEM COMPONENTS...............................................................................................................................8 7. EVALUATION PROCEDURES ................................................................................................. 11 8. MEASUREMENT UNCERTAINTY............................................................................................ 14 9. EXPOSURE LIMIT .................................................................................................................... 15 10. EUT ARRANGEMENT .............................................................................................................. 16 10.1 ANTHROPOMORPHIC HEAD PHANTOM .................................................................................................16 10.2 DEFINITION OF THE “CHEEK/TOUCH” POSITION...................................................................................17 10.3 DEFINITION OF THE “TILTED” POSITION ................................................................................................18 11. MEASUREMENT RESULTS..................................................................................................... 19 11.1 TEST LIQUIDS CONFIRMATION ...............................................................................................................19 11.2 LIQUID MEASUREMENT RESULTS ..........................................................................................................20 11.3 PROBE CALIBRATION PROCEDURE .......................................................................................................21 11.4 SYSTEM PERFORMANCE CHECK...........................................................................................................26 11.5 EUT TUNE-UP PROCEDURES AND TEST MODE....................................................................................29 11.6 SAR HANDSETS MULTI XMITER ASSESSMENT.....................................................................................31 11.7 EUT SETUP PHOTOS ................................................................................................................................32 11.8 SAR MEASUREMENT RESULTS...............................................................................................................33 12. EUT PHOTO ............................................................................................................................. 35 13. EQUIPMENT LIST & CALIBRATION STATUS........................................................................ 39 14. FACILITIES............................................................................................................................... 40 15. REFERENCES.......................................................................................................................... 40 16. ATTACHMENTS ....................................................................................................................... 41 Appendix A: Plots of Performance Check..................................................................................... 42 Appendix B: DASY Calibration Certificate .................................................................................... 49 Appendix C: Plots of SAR Test Result .......................................................................................... 99 Compliance Certification Services Inc. Report No: KS120829A01-SF FCCID:WA6I123MDate of Issue :August 30,2012 Page 3 of 99 Rev. 01 This report shall not be reproduced except in full, without the written approval of Compliance Certification Se…

Text truncated - open the document above for the full version.

FCC 47 CFR PART 22 SUBPART H TEST REPORT For Applicant: verykool USA INC. Address: 4350 Executive Dr. #100,San Diego, CA 92121 Product Name: Mobile Phone Model Name: i123M Brand Name: verykool FCC ID: WA6I123M Report No.: DPH120829F02 Date of Issue: September 03, 2012 Issued by: Super Test Service Technology Co., Ltd. Address: Room 506, Hongyu Commercial Building, Gushu 2nd Road, Baoan District, Shenzhen, China Tel: 0755-61196328 Fax : 0755-61196328 The report consists 39 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by STS. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. FCC ID: WA6I123M Report No.: DPH120829F02 Page 2 of 39 TABLE OF CONTENTS 1 VERIFICATION OF CONFORMITY .......................................................................................................... 4 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 PRODUCT INFORMATION ...................................................................................................................... 5 2.2 OBJECTIVE .............................................................................................................................................. 6 2.3 TEST STANDARDS AND RESULTS ........................................................................................................ 6 2.4 ENVIRONMENTAL CONDITIONS ............................................................................................................ 6 3 TEST FACILITY ....................................................................................................................................... 7 4 TEST EQUIPMENT LIST ......................................................................................................................... 8 5 47 CFR PART 2, PART 22H REQUIREMENTS ....................................................................................... 9 5.1 GENERAL INFORMATION ....................................................................................................................... 9 6 CONDUCTED RF OUTPUT POWER ..................................................................................................... 12 6.1 REQUIREMENT ..................................................................................................................................... 12 6.2 TEST PROCEDURE ............................................................................................................................... 12 6.3 TEST RESULT ........................................................................................................................................ 12 7 OCCUPIED BANDWIDTH ...................................................................................................................... 15 7.1 OCCUPIED BANDWIDTH DEFINITION ................................................................................................. 15 7.2 TEST PROCEDURE ............................................................................................................................... 15 7.3 TEST RESULT ........................................................................................................................................ 15 8 CONDUCTED SPURIOUS EMISSION ................................................................................................... 18 8.1 REQUIREMENT ..................................................................................................................................... 18 8.2 TEST PROCEDURE ............................................................................................................................... 18 8.3 TEST RESULT ........................................................................................................................................ 19 9 TRANSMITTER RADIATED POWER (EIRP/ERP) ................................................................................ 24 9.1 REQUIREMENT ..................................................................................................................................... 24 9.2 TEST PROCEDURE ............................................................................................................................... 24 FCC ID: WA6I123M Report No.: DPH120829F02 Page 3 of 39 9.3 TEST RESULT ........................................................................................................................................ 24 10 RADIATED SPURIOUS EMISSION ....................................................................................................... 25 10.1 REQUIREMENT ..................................................................................................................................... 25 10.2 TEST PROCEDURE ............................................................................................................................... 25 10.3 TEST RESULT ........................................................................................................................................ 25 11 FREQUENCY STABILITY ...................................................................................................................... 26 11.1 FREQUENCY STABILITY REQUIREMENT ........................................................................................... 26 11.2 TEST PROCEDURE ............................................................................................................................... 26 11.3 TEST RESULT ........................................................................................................................................ …

Text truncated - open the document above for the full version.

FCC 47 CFR PART 24 SUBPART E TEST REPORT For Applicant : verykool USA INC. Address : 4350 Executive Dr. #100,San Diego, CA 92121 Product Name : Mobile Phone Model Name : i123M Brand Name : verykool FCC ID : WA6I123M Report No. : DPH120829F03 Date of Issue : September 03, 2012 Issued by :Super Test Service Technology Co., Ltd. Address : Room 506, Hongyu Commercial Building, Gushu 2nd Road, Baoan District, Shenzhen, China Tel : 0755-61196328 Fax : 0755-61196328 The report consists 39 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by STS. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. FCC ID: WA6I123M Report No.: DPH120829F03 Page 2 of 39 TABLE OF CONTENTS 1 VERIFICATION OF CONFORMITY .......................................................................................................... 4 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 PRODUCT INFORMATION ...................................................................................................................... 5 2.2 OBJECTIVE .............................................................................................................................................. 6 2.3 TEST STANDARDS AND RESULTS ........................................................................................................ 6 2.4 ENVIRONMENTAL CONDITIONS ............................................................................................................ 6 3 TEST FACILITY ....................................................................................................................................... 7 4 TEST EQUIPMENT LIST ......................................................................................................................... 8 5 47 CFR Part 2, Part 24E REQUIREMENTS .........…
