WA6M1000m1000

WIRELESS USB MODEM is a kind of online device designed for the user who may use mobile internet to get online, and the user may access to the internet at anywhere and anytime. To Insert (U)SIM Card 1). Unfold the protecting cover of the product; 2). Pull out the (U)SIM card socket; 3). Insert the (U)SIM card into the socket (the golden contact side is downward ) according to the direction indicated in the sketch, and confirm the (U)SIM card is inserted completely. To Insert Micro SD Card 1). Unfold the protecting cover of the product; 2). Insert the Micro SD card into the socket according to the indicated direction and confirm the Micro SD card is inserted completely. Connect the Computer and the WIRELESS USB MODEM 1). Insert MODEM device into the USB socket of the computer; 2). After correctly inserted, the installation procedure will automatically operate; if installation procedure can not pop up automatically, please open My Computer--- MODEM Disk and then double click Modem_installation.exe to start installation. Moreover, in the course of installation, please do not pull out the device; 3). After installation, restart the computer and click desktop Icon to run the procedure, if not, click desktop icon to run the application. 1. About WIRELESS USB MODEM 2. Installation 1 2 3 1 2 4.Indicator light 1). If SMS sending fails, please confirm whether the number of SMS Center is correct or not. 2). If can not receive the SMS, please check whether the storage space of (U)SIM card is full or not. 3). The device will above normal heat phenomena if used under the long-time working environment, weak signal or higher temperature conditions, however, it does not affect the use and life of the device. 4). Please avoid touching with the skin directly for a long time. 5). Please keep the device a minimum physical distance: 20cm For MAC OS or more details of the product, please click <Help>. 3.Connect to the Internet 5. Notes 6. Remark 3.75G USB MODEM HSPA+/HSPA/UMTS/EDGE/GPRS/GSM Status of Indicating Light Colour Flashing Cycle Red Slow Flashing Luminous continuously Green Blue Purple Yellow Description Searching Network Abnormal of (U)SIM card or no network Data transmission HSPA+/HSPA UMTS EDGE GPRS Before installation,please close the antivirus and security software. Connection 1).Select connection profile, click on <Connect> button. 2).If connection success, under the window status bar will turn into . Disconnection Click on <Disconnect> to disconnect the connection. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. The highest SAR value for the device as reported to the FCC when tested for worn on the body, as described in this user guide, is 0.907W/Kg for Body SAR

The external antenna port is used to connect MIMO (Multi Input Multi Output) antenna. MIMO mode only used to improve HSDPA data rate (From 21Mbps to 28Mbps). MIMO antenna is not able to transmit power. It only used received power. MIMO is different from Diversity. The difference is as following: 1. Diversity Mode: Like the Fig 1, Diversity Antenna and Primary Antenna received the independent signal. Because Base Station only has one Antenna for transmitting signal, the independent signal contained the same information. Modem can use any one of these signal waves to demodulate. Fig 1 Diversity Mode 2. MIMO mode: Like the Fig 2, MIMO Antenna and Primary Antenna received the dependent signal. Because Base Station has two independent Antennas for transmitting signal, the signal contained different information. Modem can not use any one of these signal waves to demodulate. Modem must use two signal waves to demodulate. Fig 2 MIMO mode

WA6M1000 External Photo

Made in China 26.6X16.1mm IMEI:01190700665567 Model : m1000 FCC IDWA6M1000 www.verykool.net Made in China IMEI:01190700665567 Model : m1000 FCC ID WA6M1000 www.verykool.net

WA6M1000 Internal Photo

Report No.: RZA1103-0392SAR TESTING No. L2264 OET 65 TEST REPORT Product Name m1000 Model m1000 FCC ID WA6M1000 Client verykool USA Inc TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name m1000 Model m1000 FCC ID WA6M1000 Report No. RZA1103-0392SAR Client verykool USA Inc Manufacturer verykool USA Inc Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radio frequency Emissions. KDB 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: April 18 th , 2011 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Ling Minbao Performed by Liu Jun TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1103-0392SAR Page 3 of 120 TABLE OF CONTENT 1. General Information ........................................................................................................................ 5 1.1. Notes of the Test Report.......................................................................................................... 5 1.2. Testing Laboratory ................................................................................................................... 5 1.3. Applicant Information ............................................................................................................... 6 1.4. Manufacturer Information ......................................................................................................... 6 1.5. Information of EUT................................................................................................................... 7 1.6. The Maximum SAR 1g Values and Conducted Power of Each Tested Mode ............................ 8 1.7. Test Date ................................................................................................................................. 8 2. Operational Conditions during Test ................................................................................................. 9 2.1. General Description of Test Procedures .................................................................................. 9 2.2. GSM Test Configuration ........................................................................................................... 9 2.3. WCDMA Test Configuration ................................................................................................... 10 2.4. HSDPA Test Configuration ..................................................................................................... 10 2.5. HSUPA Test Configuration ..................................................................................................... 12 2.6. Position of Module in Portable Devices.................................................................................. 14 2.7. Picture of Host Product .......................................................................................................... 15 3. SAR Measurements System Configuration ................................................................................... 17 3.1. SAR Measurement Set-up .....................................................................................................17 3.2. DASY5 E-field Probe System ................................................................................................ 18 3.2.1. EX3DV4 Probe Specification .......................................................................................... 18 3.2.2. E-field Probe Calibration ................................................................................................. 19 3.3. Other Test Equipment ............................................................................................................19 3.3.1. Device Holder for Transmitters ....................................................................................... 19 3.3.2. Phantom .........................................................................................................................20 3.4. Scanning Procedure ..............................................................................................................20 3.5. Data Storage and Evaluation ................................................................................................. 22 3.5.1. Data Storage...................................................................................................................22 3.5.2. Data Evaluation by SEMCAD ......................................................................................... 22 3.6. System Check........................................................................................................................ 25 3.7. Equivalent Tissues ................................................................................................................. 26 4. Laboratory Environment................................................................................................................ 26 5. Characteristics of the Test ............................................................................................................. 27 5.1. Applicable Limit Regulations .................................................................................................. 27 5.2. Applicable Measurement Standards...............................…

Text truncated - open the document above for the full version.

Report No.: RZA1103-0392RF01_R1 TESTING No. L2264 Part 22 TEST REPORT Product Name m1000 Model Name m1000 FCC ID WA6M1000 Client verykool USA Inc TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name m1000 Model Name m1000 FCC ID WA6M1000 Report No. RZA1103-0392RF01_R1 Client verykool USA Inc Manufacturer verykool USA Inc Reference Standard(s) FCC CFR47 Part 2 (2010-12) Frequency Allocations And Radio Treaty Matters; General Rules And Regulations FCC CFR 47 Part 22H (2010-12) Public Mobile Services(850MHz) ANSI/TIA-603-C(2004) Land mobile FM or PM Communications Equipment Measurements and Performance Standards. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 2 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: April 23 rd , 2011 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Xu Kai Performed by Kang Lingling TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1103-0392RF01_R1 Page 3of 47 TABLE OF CONTENT 1. General Information ..................................................................................................................... 4 1.1. Notes of the test report.........................................................................................................4 1.2. Testing laboratory .................................................................................................................4 1.3. Applicant Information ............................................................................................................5 1.4. Manufacturer Information ......................................................................................................5 1.5. Information of EUT................................................................................................................6 1.6. Test Date ..............................................................................................................................7 2. Test Information ........................................................................................................................... 8 2.1. Summary of test results ........................................................................................................8 2.2. RF Power Output ..................................................................................................................9 2.3. Effective Radiated Power.................................................................................................... 11 2.4. Occupied Bandwidth...........................................................................................................14 2.5. Band Edge Compliance......................................................................................................22 2.6. Frequency Stability .............................................................................................................28 2.7. Spurious Emissions at Antenna Terminals .........................................................................31 2.8. Radiates Spurious Emission ...............................................................................................38 3. Main Test Instruments .......................................................................................................... ...... 46 ANNEX A: EUT Appearance and Test Setup..................................................................................... 47 A.1 EUT Appearance ................................................................................................................47 A.2 Test Setup ...........................................................................................................................47 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1103-0392RF01_R1 Page 4of 47 1. General Information 1.1. Notes of the test report TA Technology (Shanghai) Co., Ltd. guarantees the reliability of the data presented in this test report, which is the results of measurements and tests performed for the items under test on the date and under the conditions stated in this test report and is based on the knowledge and technical facilities available at TA Technology (Shanghai) Co., Ltd. at the time of execution of the test. TA Technology (Shanghai) Co., Ltd. is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the items under test and the results of the test. This report only refers to the item that has undergone the test. This report standalone dose not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of TA Technology (Shanghai) Co., Ltd. and the Accreditation Bodies, if it applies. If the electrical report is inconsistent with the printed one, it should be subject to the latter. 1.2. Testing laboratory Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong City: Shanghai Post code: 201201 Country: P. R. China Contact: Yang Weizhong Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1103-0392RF01_R1 Page 5of 47 1.3. Applicant Information Company: verykool USA Inc Address: 4350 Executive Dr. #100, San Diego, CA 92121, USA City: San Diego Postal Code: 92121 Country: USA Contact: Sunny Choi / Director of Product Management Telephone: 858-373-1635 Fax: 858-373-1505 1.4. Manufacturer Information Company: verykool USA Inc Address: 4350 Executive Dr. #100, San Diego, CA 92121, USA City: San Diego Postal Code: 92121 Country: USA Telephone: 858-373-1635 Fax: 858-373-1…

Text truncated - open the document above for the full version.

Report No.: RZA1103-0392RF02_R1 TESTING No. L2264 Part 24 TEST REPORT Product Name m1000 Model Name m1000 FCC ID WA6M1000 Client verykool USA Inc TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name m1000 Model Name m1000 FCC ID WA6M1000 Report No. RZA1103-0392RF02_R1 Client verykool USA Inc Manufacturer verykool USA Inc Reference Standard(s) FCC CFR47 Part 2 (2010-12) Frequency Allocations And Radio Treaty Matters; General Rules And Regulations FCC CFR47 Part 24E (2010-12) Personal Communications Services ANSI/TIA-603-C(2004) Land mobile FM or PM Communications Equipment Measurements and Performance Standards. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 2 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: April 23 rd , 2011 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Xu Kai Performed by Kang Lingling TA Technology (Shanghai) Co., Ltd. Test Report Registration Num:428261 Report No.: RZA1103-0392RF02_R1 Page 3of 46 TABLE OF CONTENT 1. General Information ..................................................................................................................... 4 1.1. Notes of the test report.........................................................................................................4 1.2. Testing laboratory .................................................................................................................4 1.3. Applicant Information ............................................................................................................5 1.4. Manufacturer Information ......................................................................................................5 1.5. Information of EUT................................................................................................................6 1.6. Test Date ..............................................................................................................................6 2. Test Information ........................................................................................................................... 7 2.1. Summary of test results ........................................................................................................7 2.2. RF Power Output ..................................................................................................................8 2.3. Effective Isotropic Radiated Power .....................................................................................10 2.4. Occupied Bandwidth...........................................................................................................13 2.5. Band Edge Compliance......................................................................................................21 2.6. Frequency Stability .............................................................................................................27 2.7. Spurious Emissions at Antenna Terminals .........................................................................30 2.1. Radiates Spurious Emission ...............................................................................................37 3. Main Test Instruments .......................................................................................................... ...... 45 ANNEX A: EUT Appearance and Test Setup..................................................................................... 46 A.1 EUT Appearance ................................................................................................................46 A.2 Test Setup ...........................................................................................................................46 TA Technology (Shanghai) Co., Ltd. Test Report Registration Num:428261 Report No.: RZA1103-0392RF02_R1 Page 4of 46 1. General Information 1.1. Notes of the test report TA Technology (Shanghai) Co., Ltd. guarantees the reliability of the data presented in this test report, which is the results of measurements and tests performed for the items under test on the date and under the conditions stated in this test report and is based on the knowledge and technical facilities available at TA Technology (Shanghai) Co., Ltd. at the time of execution of the test. TA Technology (Shanghai) Co., Ltd. is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the items under test and the results of the test. This report only refers to the item that has undergone the test. This report standalone dose not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of TA Technology (Shanghai) Co., Ltd. and the Accreditation Bodies, if it applies. If the electrical report is inconsistent with the printed one, it should be subject to the latter. 1.2. Testing laboratory Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong City: Shanghai Post code: 201201 Country: P. R. China Contact: Yang Weizhong Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] TA Technology (Shanghai) Co., Ltd. Test Report Registration Num:428261 Report No.: RZA1103-0392RF02_R1 Page 5of 46 1.3. Applicant Information Company: verykool USA Inc Address: 4350 Executive Dr. #100, San Diego, CA 92121, USA City: San Diego Postal Code: 92121 Country: USA Contact: Sunny Choi / Director of Product Management Telephone: 858-373-1635 Fax: 858-373-1505 1.4. Manufacturer Information Company: verykool USA Inc Address: 4350 Executive Dr. #100, San Diego, CA 92121, USA City: San Diego Po…

Text truncated - open the document above for the full version.

WA6M1000_FCC Test Setup Photo 1. RSE 2. P15B CE 3.P15B RE Below 1G Above 1G
