WA6S4006Mobile Phone

VeryKool USA Inc

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 29, 2015
Application Purpose: Original Equipment
Date of Application: Jul 29, 2015
Equipment Note: Mobile Phone
Frequency Range: 1712.40000000 - 1752.60000000
Company: VeryKool USA Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

s4006 User Manual 1 Warnings Not following these simple guidelines may be dangerous or illegal. Read the complete user guide for further information. TURN ON SAFELY Do not turn on the phone when wireless phone is prohibited or when it may cause interference or danger. ROAD SAFETY Obey all road safety laws. Always use both of your hands to operate the vehicle while driving. INTERFERENCE All wireless phones may be sensitive to interference, which may affect performance. TURN OFF IN HOSPITALS Follow all restrictions. Turn off the phone near medical equipment. TURN OFF ON AIRCRAFTS Follow all restrictions. Wireless devices can cause interference on aircrafts. 2 TURN OFF WHEN REFUELING Do not use the phone at/near refueling stations. Do not use near fuel or chemicals. USE SENSIBLY Only qualified personnel may install or repair this product. ENHANCEMENTS AND BATTERIES Use only appropriate enhancements and batteries. Do not connect incompatible products. WAT E R-RESISTANCE Your phone is not water-resistant. Keep it dry. BACKUP COPIES Remember to make back-up copies or keep a written record of all important information stored in your phone. CONNECTING TO OTHER DEVICES When connecting to any external device, read its user guide for detailed safety instructions. Do not connect with incompatible products. 3 Your Phone The phone appearance is shown as below. The picture is for reference only; your phone may be different. Please take your actual phone as the standard. Front View 4 Back View 5 Keypad Descriptions Key Description Power Key Long press the key to turn on the phone. In the power on status, press the key to lock keypad and screen; long press the key to show phone options. Menu Key Press the key to enter option menu. Home Key Press the key to return to standby mode. Long press the key to show recent list. Back Key In the menu mode, press the key to go back to upper menu. Volume Keys To adjust incoming call ringtone volume. During a call, playing music, video, or listening to radio, press the keys to adjust volume. Start to Use Install Memory Card and SIM Card When you apply for a network, you will get a plug-in SIM card. SIM (Subscriber Identity Module) card that contains phone number, service projects and can be used to store phone numbers and personal information. 6 Please insert the SIM card according to the mark on the phone. Make sure that the clipped corner of the SIM card and the metallic contacts are facing the correct direction. Slide the SIM card into the slot until it doesn't move up any further. The direction in which the micro SD card has to be inserted into the designated slot is shown by an label on the phone. Tip: For additional media storage insert a micro SD card. 7 Attention: Do not bend or scratch SIM card, do not let it contact with static electricity, dust or water. Keep all SIM cards where children cannot reach or touch. Note: Keep the SIM card chip contacts face downward. Make the SIM card fits card slot. Remove Memory Card and SIM Card Note: If the phone is turned on, long press power key about 3 seconds until it tips phone options and select Power off and then press OK to turn off the phone. Then, remove the battery, SIM card and memory card. Do not plug or remove memory card in boot state, otherwise it will cause damage to the file system. 8 Charge the Battery 1. Before charging, check the battery slot to ensure the battery has been installed correctly. 2. Plug one end of the charger into phone. 3. Connect another end of the charger to the socket. 4. Start charging. It can be charged whether power on or power o f f. ▪ In power on state, when the battery icon on screen start rolling means it is been charged. When the icon is full and stop rolling means charge is completed. ▪ In power off state, the battery icon on screen start rolling means it is been charged. When the icon is full and stop rolling means charge is completed. 5. Unplug the charger from the socket. 6. Disconnect the charger and phone. 9 Turn on/off the Phone Hold down the power button to turn the phone on. Hold down the power button, then touch Power off to turn the phone off Use Touch Screen  Press: Use finger to press the desired option to confirm selection or start an application.  Long press: Long press the screen in current operation interface, icon, or input area; you can open the option menu in current interface.  Slide: Slide the finger on screen horizontally or vertically. For example, slide the screen in standby mode or main menu horizontally to change menu page.  Drag: Use finger to long press desired item, drag it to anywhere on screen. For example, you can drag the icon in main menu to standby screen. 10 Home Screen Status Bar The status bar shows your phone’s status and notifications. (Notifications are described on the next page.) Notification icons Status icons Phone status bar and notifications Slide left or right to see more panels Touch to enter web Touch to enter message Touch to enter main menu Touch to enter people Touch to enter dial pad 11 Status icons The following status icons may appear on your screen: Icon Statement Icon Statement SIM Network signal level Headset is inserted Indicates battery capacity Bluetooth is activated Unread messages Wi-Fi is connected Missed calls Airplane mode is activated Alarm is activated USB is connected Make a Call 1. In standby mode or in main menu, press the dial icon to enter dial panel, press numbers on screen to enter phone number. 2. Press dial icon at bottom and select SIM card to dial the number. You can also press video dial icon to make a video call. 3. Press end icon to cancel the call. 12  You need to unlock the phone if the keypad and screen is locked.  You can make calls through call log, contacts, and messages.  During a call, press Volume Keys to adjust the volume.  Your phone supports intelligent dial. When input numbers, the phone will search the corresponding contact in phonebook or call log. Answer a Call When there…

Text truncated - open the document above for the full version.

Cover Letter(s)

Verykool USA Inc DATE：2015-07-09 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: WA6S4006 Product Name: Mobile Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation Description • BOM • Tune up procedure These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors.

External Photos

ID Label/Location Info

Label location Label location

Internal Photos

Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 66 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 67 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 68 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 69 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 70 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 71 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 72 of 73 Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 73 of 73 ------End of report------

RF Exposure Info

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS15070055201 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Verykool USA Inc Address of Applicant: 3636 Nobel Drive, Suite 325, San Diego, CA92122 USA Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: s4006 FCC ID: WA6S4006 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 13 Jul., 2015 ~ 22 Jul., 2015 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 1.153 Body: 1.334 Hotspot: 1.334 Report No: CCIS15070055201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700552RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 137 2 Version Version No. Date Description 02 24 Jul., 2015 Original Prepared by: Date: 24 Jul., 2015 Report Clerk Reviewed by: Date: 24 Jul., 2015 Project Engineer Report No: CCIS15070055201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700552RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 137 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 6 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 6 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 7 5.4 ENVIRONMENT OF TEST SITE ......................................................................................................................................................... 7 5.5 TEST LOCATION ............................................................................................................................................................................. 7 6 INTRODUCTION ................................................................................................................................................... 8 6.1 INTRODUCTION ............................................................................................................................................................................... 8 6.2 SAR DEFINITION ............................................................................................................................................................................ 8 7 RF EXPOSURE LIMITS ....................................................................................................................................... 9 7.1 UNCONTROLLED ENVIRONMENT ..................................................................................................................................................... 9 7.2 CONTROLLED ENVIRONMENT ......................................................................................................................................................... 9 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................... 9 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 10 8.1 E-FIELD PROBE............................................................................................................................................................................ 11 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 11 8.3 ROBOT ..............................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS15070055101 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT Applicant: Verykool USA Inc Address of Applicant: 3636 Nobel Drive, Suite 325, San Diego, CA92122 USA Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: s4006 FCC ID: WA6S4006 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E FCC CFR Title 47 Part 27 Subpart L Date of sample receipt: 09 Jul., 2015 Date of Test: 09 Jul., to 21 Jul., 2015 Date of report issued: 21 Jul., 2015 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 73 2. Version Version No. Date Description 00 21 Jul., 2015 Original Prepared by: Date: 21 Jul., 2015 Report Clerk Reviewed by: Date: 21 Jul., 2015 Project Engineer Report No: CCIS15070055101 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150700551RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 73 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST MODES .......................................................................................................................................................... 8 5.4 RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................................... 8 5.5 TEST METHODOLOGY ............................................................................................................................................ 8 5.6 LABORATORY FACILITY.......................................................................................................................................... 8 5.7 LABORATORY LOCATION ....................................................................................................................................... 9 5.8 TEST INSTRUMENTS LIST ....................................................................................................................................... 9 6. SYSTEM TEST CONFIGURATION ........................................................................................................................ 10 6.1 EUT CONFIGURATION ......................................................................................................................................... 10 6.2 EUT EXERCISE .................................................................................................................................................... 10 6.3 CONFIGURATION OF TESTED SYSTEM ................................................................................................................ 10 6.4 DESCRIPTION OF TEST MODES ........................................................................................................................... 10 6.5 CONDUCTED OUTPUT POWER ............................................................................................................................ 11 6.6 OCCUPY BANDWIDTH .......................................................................................................................................... 16 6.7 PEAK-TO-AVERAGE RATIO .................................................................................................................................. 28 6.8 MODULATION CHARACTERISTIC ............................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Sunny Choi

[email protected]858-373-1635Fax: 858-373-1505

Test Firm

Shenzhen Zhongjian Nanfang Testing Co.,LtdBruce Zhang

[email protected]86-755-23118282Fax: 86-755-23116366

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
5	27	1.71 GHz - 1.75 GHz	195.00 mW	4M18F9W	0.07 ppm

Confidentiality

Long Term

Grant Notes

Power listed is ERP for Part 22, EIRP for Part 24 and Part 27. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are 1.15 W/kg, 1.33 W/kg, 1.33 W/kg, and 1.40 W/kg, respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
