WA6S50153G Smart Phone

1-Welcome4 1.1.ExcitingFeatures ............................................................................................. 4 1.2.TechnicalSpecification ................................................................................... 5 2-PhoneLayout6 2.1.KeysandParts ................................................................................................. 6 2.2.IconsandIndicators ........................................................................................ 7 3-GettingStarted8 3.1.InsertSIMcard ................................................................................................. 8 3.2.InsertMemorycard ......................................................................................... 9 3.3.UnlockthePhone .......................................................................................... 10 3.4.UsingtheTouchscreen ................................................................................ 11 3.5.UsingthePhone’sButtons..........................................................................12 3.6.ContextMenus...............................................................................................13 3.7.Optionsmenus...............................................................................................13 3.8.MenuIcons.....................................................................................................14 4-PlacingandReceivingCalls15 4.1.MakeaCall.....................................................................................................15 4.2.DisablePhoneCalls(Airplanemode).......................................................15 4.3.DisableSIMcard...........................................................................................16 5-TheHomeScreen17 5.1.OpenandClosetheLauncher...................................................................18 5.2.SwitchtoRecentlyUsedApplication........................................................20 5.3.CustomizeHomeScreen.............................................................................20 6-ConnecttotheInternet22 6.1.ToconfigureyourInternet:...........................................................................22 6.2.AccessInternetviaWi-Fi.............................................................................22 7-ManagingNotifications23 7.1.OpentheNotificationsPanel......................................................................23 s5015UserGuide UserGuide 2 7.2.RespondtoNotifications..............................................................................24 7.3.CloseNotificationsPanel.............................................................................24 8-Messaging25 8.1.Messageenvironment&Settings .............................................................. 25 8.2.UsingtheOnscreenKeyboard ................................................................... 27 8.3.CreateandSendMultimediaMessage....................................................29 8.4.Operationonamessage:............................................................................29 8.5.LockaMessage.............................................................................................30 9-Multimedia31 9.1.Camera............................................................................................................31 9.2.Gallery..............................................................................................................32 9.3.ShareanAlbum.............................................................................................32 9.4.Music32 9.5.FMRadio.........................................................................................................33 9.6.RecordSounds..............................................................................................33 9.7.MakePrintscreens........................................................................................33 10-ConnecttoNetworksandDevices34 10.1.ConnecttoPC..............................................................................................34 10.2.ConnecttoInternet.....................................................................................35 10.3.ConnecttoWi-FiNetworks.......................................................................35 10.4.PairWithBluetoothDevices ..................................................................... 35 11.5.ConnecttoInternetviayourPhone ......................................................... 35 10.6.InstallSecureCertificatefromSDCard ................................................. 36 11-DownloadApplications37 12-PhoneSettings38 13-HealthandSafetyInformation40 UserGuide 3 1- 1- WELCOME WELCOME 1.1.ExcitingFeatures CongratulationsonbecomingaproudowneroftheKitKatAndroidmobilephone.You havenowjoinedthemillionsofsatisfiedcustomersspreadacrosstheGlobe.Your KitKatdeviceoffersyoutheseexcitingfeaturesandmuchmore: Android4.4.2 5inchScreen Cameras(frontandback) 1.3GHzQuadcoreProcessor ExternalMemory(Expandableto32GB) DualSIM Multimediaplayer GPS Gravitysensor Wi-Fi Bluetooth3.0 UserGuide 4 1.2.TechnicalSpecification GENERAL: Android4.4.2 Dimensions:143.5*71.5*8mm/Weight:135g 2100mAhLi-ionbattery SCREEN: 5"HDcapacitivetouchscreen 1280*720pixels,17.1Mofcolors HARDWARE: 1.3GHzProcessor/512MBRAM 8GBROM,1GBRAM ExternalSD-cardslotupto32GB 8MPxBackCameraAuto-Focus+5MPxFrontCamera WhiteLEDflash GravitySensor COMMUNICATION: DUALSIM.2G/3G SupportGPRS,EDGEnetworks.GSM850/900/1800/1900MHzHSDPA WCDMA850/1700/1900 SupportGPSandAGPS(Subjectoftheinstallationoftherelevant software) Bluetooth3.0 Wi-Fi802.11b/g/n 3.5mmJackPlug Micro-USB2.0receiver UserGuide 5 2- 2- PHONE PHONE LAYOUT LAYOUT 2.1.KeysandParts UserGuide 6 UserGuide 7 2.2.IconsandIndicators IconsIndicatorsIconsIndicators SignalstrengthindicatorAlarmhasbeenset NewmissedcallsWi-Fiisactivated USBisconnectedBluetoothison Theheadphoneisbeing used Batterycharging symbol NewmessagefromSIM 1 Airplanemodeis activated UserGuide 8 3- 3- GE…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Verykool USA INC. 2014/12/23 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____Verykool USA INC_____hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Product description : 3G Smart Phone FCC ID : WA6S5015 model name: s5015 We affirm that between SIEMIC, Inc. and ____ Verykool USA INC ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Sunny/Manager Contact information / address : 3636 Nobel Drive, Suite 325, San Diego, CA 92122

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Verykool USA INC. 2014/12/23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: WA6S5015 We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - . Schematics - . Operational Description - . Tune up Procedure - . Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Sunny/Manager Contact information / address: 3636 Nobel Drive, Suite 325, San Diego, CA 92122

Date: 2014-12-23 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: WA6S5015 To Whom It May Concern: This letter is to ascertain that Verykool USA INC . Product 3G Smart Phone has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: Sunny/ Manager Contact information / address: 3636 Nobel Drive, Suite 325, San Diego, CA 92122

Test Report 14070617-FCC-R1 Page 50 of 59 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole Package - Top View Adapter - Front View EUT - Front View EUT - Rear View Test Report 14070617-FCC-R1 Page 51 of 59 EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

Lable location

Test Report 14070617-FCC-R1 Page 52 of 59 Annex B.ii. Photograph: EUT Internal Photo Cover Off - Top View 1 Cover Off - Top View 2 Battery - Top View Battery - Bottom View LCD - Front View LCD - Rear View Test Report 14070617-FCC-R1 Page 53 of 59 Mainborad With Shielding - Front View Mainborad Without Shielding - Front View Mainborad With Shielding - Front View Mainborad Without Shielding - Rear View BT/BLE/WIFI Antenna View GSM/PCS/UMTS-FDD Antenna View

RF EXPOSURE REPORT Report No.: 14070617-FCC-H2 Supersede Report No.: N/A Applicant Verykool USA Inc Product Name Mobile Phone Model No. s5015 Test Standard FCC 2.1093 Test Date December 06, 2014 Issue Date December 15, 2014 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Herith Shi Test Engineer Alex Liu Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 14070617-FCC-H2 Page 2 of 10 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 14070617-FCC-H2 Page 3 of 10 This page has been left blank intentionally. Test Report 14070617-FCC-H2 Page 4 of 10 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. FCC §2.1093 - MAXIMUM PERMISSIBLE EXPOSURE ................................................................................... 8 5.1 RF EXPOSURE .......................................................................................................................................................... 8 5.2 TEST RESULT ........................................................................................................................................................... 9 Test Report 14070617-FCC-H2 Page 5 of 10 1. Report Revision History Report No. Report Version Description Issue Date 14070617-FCC-H2 NONE Original December 15, 2014 2. Customer information Applicant Name Verykool USA Inc Applicant Add 3636 Nobel Drive, Suite 325, San Diego, CA 92122 Manufacturer Sprocomm Technologies CO.,LTD Manufacturer Add 5D-506 F1.6 Block,Tianfa Building,Tianan Chegongmiao Industrial park,Futian Dist,Shenzhen, P.R China 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Labview of SIEMIC version 2.0 Test Report 14070617-FCC-H2 Page 6 of 10 4. Equipment under Test (EUT) Information Description of EUT: Mobile Phone Main Model: s5015 Serial Model: N/A Date EUT received: November 26, 2014 Test Date(s): December 06, 2014 Antenna Gain: UMTS-FDD Band V/GSM850: 0.8 dBi UMTS-FDD Band II: 1.7 dBi UMTS-FDD Band IV: 1.7 dBi PCS1900: 1.2 dBi Bluetooth/BLE: 2.3 dBi WIFI: 2.3 dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK 802.11b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK BLE: GFSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1900 TX: 1850.2 ~ 1909.8 MHz; RX: 1930.2 ~ 1989.8 MHz UMTS-FDD Band V TX: 826.4 ~ 846.6 MHz; RX: 871.4 ~ 891.6 MHz UMTS-FDD Band II TX:1852.4 ~ 1907.6 MHz; RX: 1932.4 ~ 1987.6 MHz UMTS-FDD Band IV TX :1712.4 ~ 1752.6 MHz; RX : 2112.4 ~ 2152.6 MHz WIFI:802.11b/g/n(20M): 2412-2462 MHz WIFI:802.11n(40M): 2422-2452 MHz Bluetooth& BLE: 2402-2480 MHz Test Report 14070617-FCC-H2 Page 7 of 10 Number of Channels: GSM 850: 124CH PCS1900: 299CH UMTS-FDD Band V : 102CH UMTS-FDD Band II : 277CH UMTS-FDD Band IV: 202CH WIFI :802.11b/g/n(20M): 11CH WIFI :802.11n(40M): 7CH Bluetooth: 79CH BLE: 40CH Port: Power Port, USB Port Input Power: Battery: Model: X5021 Spec: 3.8V 2100mAh 7.98Wh Limited charger voltage: 4.35V Adapter: Model: SC050100-US Input: AC 100-240V; 50/60Hz 0.4A Output: DC 5.0V; 1000mA Trade Name : Verykool FCC ID: WA6S5015 Test Report 14070617-FCC-H2 Page 8 of 10 5. FCC §2.1093 - Maximum Permissible exposure 5.1 RF Exposure Standard Requirement: According to §15.247 (i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’ s guidelines. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Test Report 14070617-FCC-H2 Page 9 of 10 5.2 Test Result All The Minimum Test Distance is 5 mm…

Text truncated - open the document above for the full version.

RF TEST REPORT Report No.: 14070617-FCC-R3 Supersede Report No.: N/A Applicant Verykool USA Inc Product Name Mobile Phone Model No. s5015 Test Standard FCC Part 15.247: 2013, ANSI C63.10: 2009 Test Date December 02 to December 17, 2014 Issue Date December 18, 2014 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Herith Shi Test Engineer Alex Liu Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report No. 14070617-FCC-R3 Page 2 of 49 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report No. 14070617-FCC-R3 Page 3 of 49 This page has been left blank intentionally. Test Report No. 14070617-FCC-R3 Page 4 of 49 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. TEST SUMMARY .................................................................................................................................................... 8 6. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................... 9 6.1 ANTENNA REQUIREMENT ..................................................................................................................................... 9 6.2 DTS (6 DB&20 DB) CHANNEL BANDWIDTH ..................................................................................................... 10 6.3 MAXIMUM OUTPUT POWER ............................................................................................................................... 17 6.4 POWER SPECTRAL DENSITY ............................................................................................................................. 21 6.5 BAND-EDGE & UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS .................. 25 6.6 AC POWER LINE CONDUCTED EMISSIONS ................................................................................................... 31 6.7 RADIATED SPURIOUS EMISSIONS ................................................................................................................... 35 ANNEX A. TEST INSTRUMENT ................................................................................................................................. 39 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 40 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 45 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PARTLIST .................................................. 48 ANNEX E. DECLARATION OF SIMILARITY ............................................................................................................ 49 Test Report No. 14070617-FCC-R3 Page 5 of 49 1. Report Revision History Report No. Report Version Description Issue Date 14070617-FCC-R3 NONE Original December 18, 2014 2. Customer information Applicant Name Verykool USA Inc Applicant Add 3636 Nobel Drive, Suite 325, San Diego, CA 92122 Manufacturer Sprocomm Technologies CO.,LTD Manufacturer Add 5D-506 F1.6 Block,Tianfa Building,Tianan Chegongmiao Industrial park,Futian Dist,Shenzhen, P.R China 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Labview of SIEMIC version 2.0 Test Report No. 14070617-FCC-R3 Page 6 of 49 4. Equipment under Test (EUT) Information Description of EUT: Mobile Phone Main Model: s5015 Serial Model: N/A Date EUT received: November 26, 2014 Test Date(s): December 02 to December 17, 2014 Equipment Category： DTS Antenna Gain: UMTS-FDD Band V/GSM850: 0.8 dBi UMTS-FDD Band II: 1.7 dBi UMTS-FDD Band IV: 1.7 dBi PCS1900: 1.2 dBi Bluetooth/BLE: 2.3 dBi WIFI: 2.3 dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK 802.11b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK BLE: GFSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1…

Text truncated - open the document above for the full version.

RF TEST REPORT Report No.: 14070617-FCC-R4 Supersede Report No.: N/A Applicant Verykool USA Inc Product Name Mobile Phone Model No. s5015 Test Standard FCC Part 15.247: 2013, ANSI C63.10: 2009 Test Date December 02 to December 10, 2014 Issue Date December 15, 2014 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Herith Shi Test Engineer Alex Liu Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report No. 14070617-FCC-R4 Page 2 of 38 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report No. 14070617-FCC-R4 Page 3 of 38 This page has been left blank intentionally. Test Report No. 14070617-FCC-R4 Page 4 of 38 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. TEST SUMMARY .................................................................................................................................................... 8 6. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................... 9 6.1 ANTENNA REQUIREMENT ..................................................................................................................................... 9 6.2 DTS (6 DB) CHANNEL BANDWIDTH .................................................................................................................. 10 6.3 MAXIMUM OUTPUT POWER ............................................................................................................................... 12 6.4 POWER SPECTRAL DENSITY ............................................................................................................................. 15 6.5 BAND-EDGE & UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS .................. 17 6.6 AC POWER LINE CONDUCTED EMISSIONS ................................................................................................... 20 6.7 RADIATED SPURIOUS EMISSIONS ................................................................................................................... 24 ANNEX A. TEST INSTRUMENT ................................................................................................................................. 28 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 29 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 34 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PARTLIST .................................................. 37 ANNEX E. DECLARATION OF SIMILARITY ............................................................................................................ 38 Test Report No. 14070617-FCC-R4 Page 5 of 38 1. Report Revision History Report No. Report Version Description Issue Date 14070617-FCC-R4 NONE Original December 15, 2014 2. Customer information Applicant Name Verykool USA Inc Applicant Add 3636 Nobel Drive, Suite 325, San Diego, CA 92122 Manufacturer Sprocomm Technologies CO.,LTD Manufacturer Add 5D-506 F1.6 Block,Tianfa Building,Tianan Chegongmiao Industrial park,Futian Dist,Shenzhen, P.R China 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Labview of SIEMIC version 2.0 Test Report No. 14070617-FCC-R4 Page 6 of 38 4. Equipment under Test (EUT) Information Description of EUT: Mobile Phone Main Model: s5015 Serial Model: N/A Date EUT received: November 26, 2014 Test Date(s): December 02 to December 10, 2014 Equipment Category： DTS Antenna Gain: UMTS-FDD Band V/GSM850: 0.8 dBi UMTS-FDD Band II: 1.7 dBi UMTS-FDD Band IV: 1.7 dBi PCS1900: 1.2 dBi Bluetooth/BLE: 2.3 dBi WIFI: 2.3 dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK 802.11b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK BLE: GFSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 M…

Text truncated - open the document above for the full version.

Test Report No. 14070617-FCC-R3 Page 44 of 49 Annex B.iii. Photograph: Test Setup Photo Conducted Emissions Test Setup Front View Conducted Emissions Test Setup Side View Radiated Spurious Emissions Test Setup Below 1GHz Radiated Spurious Emissions Test Setup Above 1GHz

Test Report No. 14070617-FCC-R4 Page 33 of 38 Annex B.iii. Photograph: Test Setup Photo Conducted Emissions Test Setup Front View Conducted Emissions Test Setup Side View Radiated Spurious Emissions Test Setup Below 1GHz Radiated Spurious Emissions Test Setup Above 1GHz
