LTE Indoor CPE CP860 -NA Quick Start Guide Introduction Panel of Device I/O Panel of Router 1 LED Panel of Router Packing List Make sure you have everything you need to properly configure the device. If you want to remove the SIM card, please lightly press the SIM card, the SIM card will pop out. Make sure the CPE is turned off before you insert or remove your SIM card. Otherwise, the CPE and SIM card may be damaged. IDUEthernet cable 2 How does it Work Configure Hardware Insert SIM Card 3 4 LED Indicators When set up the CP860, you will see the following LED indicators: Power supply Please insert your SIM card (3FF) as following: The figure is just for reference only, please connect according to your requirements. Step 1 Connect the supplied power adapter to the CPE. You can connect your laptop via Wi-Fi. You can connect your telephone via TEL port. Step 2 Connect other devices. POWER SIGNAL IndicatorStatusDescription Steady on Off Off Off Power On No Power Supply INTERNET Steady onInternet Available Internet Unavailable Blinking (500ms interval) WiFi Steady onWiFi Available WiFi unavailable Steady on OffNo Signal Searching network of LTE Blinking one by oneFirmware upgrade VOICE Off Steady onVOICE Available VOICE Unavailable 5 Configure The CPE Login to the Website Use a browser to access the management web page to configure and manage the CPE. The following procedure describes how to use a computer running Windows 7 or above version and Internet Explorer to connect to the CPE webpage. Connect the CPE correctly. Start Internet Explorer, go to http://192.168.1.1 in the address bar, and press Enter. Enter the user name (admin) and password (admin), and click Log In. You can connect to the management web page after the password is verified. Step 1 Step 2 Step 3 When you are using the CPE, you can adjust the position and direction of CPE to get stronger LTE signal, you can judge from the LTE signal LED indicators. You can connect your computer or classic Switch via Ethernet cable to LAN port. Display the current LTE network signal, the stronger signal, the more bars on LTE BTS Wi-Fi 11 a/b/g/n/ac Indoor CPE Power Adapter The CP860 is a premium indoor LTE CPE, designed for 802.11a/b/ g/n/ac dual band Wi-Fi access. The product provides optimized high throughput data and a wide area coverage network for residential, commercial and enterprise users, supporting multiple services. Customers enjoy reliable dual-band Wi-Fi AP functions, broadband access and hot-spot Wi-Fi connections with the CP860-B. 678 Configuration of LTE Step 1 Connect the CPE correctly. Step 2 Enter the management website. Step 3 Choose Settings Network LTE Settings. Step 4 Set the connection mode and scan mode. The default setting is automatically connection and full band scanning,if you want to connect the LTE network according to your needs,you can set the connection mode as manual,and simply scan a specified band. Connect the CPE correctly. Enter the management website. Choose Settings Wi-Fi WLAN Settings. In the General Settings, set Wi-Fi Enable or enable Wi-Fi with the Wi-Fi button. In the Setting, change the SSID, such as "LTE-Router" To ensure data security, it is recommended that you change the Wi-Fi password by default. Click Submit to save the settings. Configuration of Wi-Fi Troubleshooting Make sure that the CPE is started. Verify that the CPE is correctly connected to the computer through Wi-Fi or a network cable. Check that the power adapter is connected properly. Check that the CPE is placed in an open area that is far away from obstructions, such as concrete or wooden walls. Check that the CPE is placed far away from household electrical appliances that generate strong electromagnetic field, such as micro- wave ovens, refrigerators, and satellite dishes. The CPE will be overheated after being used for a long time. There- fore, power off the CPE when you are not using it. Check that the CPE is properly ventilated and shielded from direct sunlight. Fails to login the web management page. Make sure that the power cable is connected properly and the CPE is powered on. Make sure that the power adapter is compatible with the CPE. The POWER indicator does not turn on. The CPE fails to search for the wireless network. The power adapter of the CPE is overheated. If the CPE is powered off unexpectedly while being configured, the parameters may be restored to the default settings. After configuring the parameters, download the configuration file to quickly restore the CPE to the desired settings. The parameters are restored to default values. Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. We reserves the right to change or modify any information or specifica- tions contained in this manual without prior notice or obligation. Notice Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 Step 7 If the problem persists,please contact authorized local service suppliers. This product has reached the standard of shipment inspection. FCC ID: WBKCP860 FCC Regulations: § 15.19 (a)(3) This mobile MIFI complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation § 15.21 Changes or modifications not expressly approved by the party responsi- ble for compliance could void the user ‘s authority to operate the equip- ment. § 15.105 (b) This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a re…
