WBKCP880-ALTE Outdoor CPE

CP880-A LTE CPE User Manual Index 1 Getting Started ............................................................................................................................... 4 1.1 Welcome to the CPE .................................................................................................. 4 1.2 Computer Configuration Requirements .................................................................... 4 1.3 Logging In to the Web Management Page ................................................................ 4 2 Overview ................................................................................................................................... 6 2.1 Viewing Current Connection ..................................................................................... 6 2.2 Viewing LTE Status ..................................................................................................... 6 2.3 Viewing WAN Status .................................................................................................. 6 3 Statistics .................................................................................................................................... 8 3.1 Viewing CPU Usage ................................................................................................... 8 3.2 Viewing Memory Usage ............................................................................................ 8 3.3 Viewing APN List ........................................................................................................ 9 3.4 Viewing Throughput Statistics ................................................................................... 9 3.5 Viewing Device List .................................................................................................... 9 4 Update ..................................................................................................................................... 11 4.1 Version Manager ..................................................................................................... 11 Viewing Version Info ........................................................................................................ 11 Version Upgrade .............................................................................................................. 11 4.2 Auto upgrade ........................................................................................................... 12 5 Settings .................................................................................................................................... 14 5.1 Viewing the Device Information .............................................................................. 14 Viewing the Version Information .................................................................................... 14 Viewing LAN Status ......................................................................................................... 14 5.2 Viewing Network ..................................................................................................... 15 LTE Settings...................................................................................................................... 15 Scan Mode ....................................................................................................................... 18 APN Management ........................................................................................................... 18 PIN Management ............................................................................................................ 19 SIM Lock .................................................................................................................................. 21 LAN Setting ...................................................................................................................... 22 DMZ Settings ................................................................................................................... 23 Static Route ..................................................................................................................... 24 5.3 Firewall .................................................................................................................... 25 Setting Firewall ................................................................................................................ 25 MAC Filtering ................................................................................................................... 26 IP Filtering ....................................................................................................................... 29 URL Filtering .................................................................................................................... 32 Port Forwarding ............................................................................................................... 33 UPnP ................................................................................................................................ 36 DoS .................................................................................................................................. 37 5.6 VPN ............................................................................................................................................ 37 5.7 IPv6 ............................................................................................................................................ 38 Status....................................................................................................................................... 38 IPv6 WAN Settings ................................................................................................................... 39 IPv6 LAN Settings .................................................................................................................... 39 5.8 System .......................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 9 External Photos for SZEM2006004500CR FCC ID: WBKCP880-A SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 9 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 9 Antenna Panel SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 8 of 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 9 of 9

1257019101000071 Product Name: LTE Outdoor CPE FCC ID：WBKCP880-A Grantee Code ：WBK Model Name: CP880-A S/N：1257019101000071 MAC : A893520B1DBA IMEI : 860524031925017 Frequency Band：Band 41 Supply Voltage：24VDC Manufacturer：Bravo Tech Inc

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 7 Internal Photos for SZEM2006004500CR FCC ID: WBKCP880-A SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 7 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 7 Ant 1 Ant 2 Ant 3 Ant 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 7

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450003 Page: 1 of 7 Keny Xu EMC Laboratory Manager 1 Cover RF Exposure Evaluation Report Application No.: SZEM2006004500CR Applicant: BTI Wireless Address of Applicant: 6185 Phyllis Drive #D, Cypress, California 90630, United States Manufacturer: Bravo Tech Inc Address of Manufacturer: 14600 INDUSTRY CIRCLE LA MIRADA, CA 90638 Factory: Bravo Tech Inc Address of Factory: 14600 INDUSTRY CIRCLE LA MIRADA, CA 90638 Product Name: LTE Outdoor CPE Model No.: CP880-A FCC ID: WBKCP880-A Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 Date of Receipt: 2020-06-02 Date of Test: 2020-06-06 to 2020-07-07 Date of Issue: 2020-07-10 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450003 Page: 2 of 7 2 Version Revision Record Version Chapter Date Modifier Remark 01 2020-07-10 Original Authorized for issue by: Jacky Li /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450003 Page: 3 of 7 3 Contents Page 1 COVER .........................................................................................................................................................................1 2 VERSION .....................................................................................................................................................................2 3 CONTENTS .................................................................................................................................................................3 4 GENERAL INFORMATION ......................................................................................................................................4 4.1 GENERAL DESCRIPTION OF EUT ...............................................................................................................................4 4.2 TEST LOCATION .........................................................................................................................................................5 4.3 TEST FACILITY ..........................................................................................................................................................5 4.4 DEVIATION FROM STANDARDS ..................................................................................................................................5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS .......................................................................................................5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER .............................................................................................5 5 RF EXPOSURE EVALUATION ................................................................................................................................6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................6 5.1.1 Limits ..............................................................................................................................................................6 5.1.2 Test Procedure ..............................................................................................................................................6 5.1.3 EUT RF Exposure Evaluation .....................................................................................................................7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450003 Page: 4 of 7 4 General Information 4.1 General Description of EUT Power supply: Adapter Model NO.: ASSA107A-240050 Input: 100-240V~50/60Hz, 0.45A Output: 24.0V, 0.5A POE Model NO.: GRT-HCQ-1000 Test voltage: AC 120V, 60Hz Cable: RJ45 Cable: 100cm DC cable: 148cm unshielded Sample Type: Mobile production LTE Operation Frequency Band: 41 Frequency range: 2496-2690 MHz Modulation Type: UL: QPSK, 16QAM, 64QAM DL: QPSK, 16QAM, 64QAM, 256QAM LTE Release Version: R11 LTE Power Class: Level 3 CA Capability: DL 2CA 4x4 MIMO DL 4CA 2x2 MIMO UL 2CA Support Intra-band contiguous CA and Intra-band non-contiguous CA MIMO: DL 2x2 (4CA 256QAM) DL 4x4 (2CA 64QAM) Antenna Type: Panel Antenna Ant 1: TX & RX(SISO & UL CA) Ant 3: TX & RX(UL CA) Ant 2 & 4: RX Antenna Gain: 10 dBi SIM Card: This device has only one SIM Card sockets. Extreme temp. Tolerance: -30°C to +50°C Extreme vol. Limits: 20.4VDC to 27.6VDC (nominal: 24.0VDC) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450003 Page: 5 of 7 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Desi…

Text truncated - open the document above for the full version.

1. Spurious Emission 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 64QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz 16QAM_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz QPSK_5MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 64QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz 16QAM_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz QPSK_10MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 64QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz 16QAM_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz QPSK_15MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 64QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz 16QAM_20MHz QPSK_20MHz

LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 15-5MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 15-10MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 15-15MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 15-20MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 20-5MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 20-10MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 A Offset 10 dB LVL Att 30 dB ** Ref 25 dBmSWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * RBW 300 kHz * VBW 1 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 20-15MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA QPSK channel-Full RB offset 0 Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA LTE TDD Band 41 Intra-band CA Non-continuous, Nominal Bandwidth: 20-20MHz Q16 channel-Full RB offset 0 Q64 channel-Full RB offset 0 Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 20 of 20 LIMIT CHECK PASS B41 CA Ref 25 dBmAtt 30 dB ** * Offset 10 dB A LVL RBW 1 MHz SWT 500 ms Center 2.593 GHzSpan 300 MHz30 MHz/ * VBW 3 MHz 3DB * AVG SGL *1 RM -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP 2…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450002 Page: 1 of 37 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2006004500CR Applicant: BTI Wireless Address of Applicant: 6185 Phyllis Drive #D, Cypress, California 90630, United States Manufacturer: Bravo Tech Inc Address of Manufacturer: 14600 INDUSTRY CIRCLE LA MIRADA, CA 90638 Factory: Bravo Tech Inc Address of Factory: 14600 INDUSTRY CIRCLE LA MIRADA, CA 90638 Equipment Under Test (EUT): EUT Name: LTE Outdoor CPE Model No.: CP880-A FCC ID: WBKCP880-A Standard(s) : 47 CFR Part 2 47 CFR Part 27 Date of Receipt: 2020-06-02 Date of Test: 2020-06-06 to 2020-07-07 Date of Issue: 2020-07-10 Test Result: Pass * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450002 Page: 2 of 37 Revision Record Version Chapter Date Modifier Remark 01 2020-07-10 Original Authorized for issue by: Jacky Li /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450002 Page: 3 of 37 2 Test Summary Test Item FCC Rule No. Requirements Verdict Effective (Isotropic) Radiated Power Output Data §2.1046, §27.50(h) EIRP≤ 2W (LTE Band 41) PASS Peak-Average Ratio §27.50(h) ≤13dB PASS Modulation Characteristics §2.1047 Digital modulation PASS Bandwidth §2.1049(h) OBW: No limit EBW: No limit PASS Band Edge Compliance §2.1051, §27.53(m) 0-5 MHz: -10 dBm; 5-X MHz: -13 dBm; X- More: -25 dBm PASS Spurious emissions at antenna terminals §2.1051, §27.53(m) ≤ -25dBm (LTE Band 41) PASS Field strength of spurious radiation §2.1051, §27.53(m) ≤ -25dBm (LTE Band 41) PASS Frequency stability §2.1055, §27.54 ≤ ±2.5ppm. PASS SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200600450002 Page: 4 of 37 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 Details of E.U.T. ............................................................................................................................. 6 4.2 Test Frequency .............................................................................................................................. 7 4.3 Test Environment ........................................................................................................................... 7 4.4 Description of Support Units .......................................................................................................... 7 4.5 Measurement Uncertainty .............................................................................................................. 8 4.6 Test Location ................................................................................................................................. 9 4.7 Test Facility .................................................................................................................................... 9 4.8 Deviation from Standards .............................................................................................................. 9 4.9 Abnormalities from Standard Conditions ....................................................................................... 9 5 EQUIPMENT LIST .................................................................................................................................... 10 6 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 12 6.1 Effective (Isotropic) Radiated Power Output Data ....................................................................... 12 6.1.1 E.U.T. Operation .......................................................................................................................... 12 6.1.2 Test Setup Diagram ..................................................................................................................... 12 6.1.3 Measurement Data ...................................................................................................................... 12 6.2 Peak-Average Ratio ..................................................................................................................... 13 6.2.1 E.U.T. Operation .......................................................................................................................... 13 6.2.2 Test Setup Diagram ..................................................................................................................... 13 6.2.3 Measurement Data ...................................................................................................................... 13 6.3 Bandwidth .................................................................................................................................... 14 6.3.1 E.U.T. Operation .......................................................................................................................... 14 6.3.2 Test Setup Diagram ..................................................................................................................... 14 6.3.3 Measurement Data ...................................................................................................................... 14 6.4 Band Edge Compliance ............................................................................................................... 15 6.4…

Text truncated - open the document above for the full version.

1. Effective (Isotropic) Radiated Power Output Data 1.1 Test Result Test Band: 41 _ 5MHz Bandwidth Modulation RB Allocation Conducted Power (dBm) Antenna gain EIRP(dBm) Limit (dBm) Verdict Size Offset LCH MCH HCH (dBd) (dBi) LCH MCH HCH 64QAM 1 0 22.15 22.21 22.48 / 10.00 32.15 32.21 32.48 33.01 PASS 13 22.67 22.61 22.80 / 10.00 32.67 32.61 32.80 33.01 PASS 24 22.37 22.31 22.48 / 10.00 32.37 32.31 32.48 33.01 PASS 12 0 22.56 22.78 22.90 / 10.00 32.56 32.78 32.90 33.01 PASS 6 22.37 22.50 22.72 / 10.00 32.37 32.50 32.72 33.01 PASS 13 22.29 22.42 22.59 / 10.00 32.29 32.42 32.59 33.01 PASS 25 0 22.32 22.31 22.71 / 10.00 32.32 32.31 32.71 33.01 PASS 16QAM 1 0 21.91 22.94 22.24 / 10.00 31.91 32.94 32.24 33.01 PASS 13 22.44 22.17 22.59 / 10.00 32.44 32.17 32.59 33.01 PASS 24 21.95 22.81 22.74 / 10.00 31.95 32.81 32.74 33.01 PASS 12 0 22.33 22.18 22.64 / 10.00 32.33 32.18 32.64 33.01 PASS 6 22.06 22.82 22.43 / 10.00 32.06 32.82 32.43 33.01 PASS 13 22.04 22.87 22.25 / 10.00 32.04 32.87 32.25 33.01 PASS 25 0 21.93 22.81 22.31 / 10.00 31.93 32.81 32.31 33.01 PASS QPSK 1 21.71 22.55 22.09 / 10.00 31.71 32.55 32.09 33.01 PASS 13 22.07 22.84 22.46 / 10.00 32.07 32.84 32.46 33.01 PASS 24 21.58 22.49 22.28 / 10.00 31.58 32.49 32.28 33.01 PASS 12 0 22.21 22.11 22.60 / 10.00 32.21 32.11 32.60 33.01 PASS 6 21.97 22.78 22.33 / 10.00 31.97 32.78 32.33 33.01 PASS 13 21.86 22.83 22.30 / 10.00 31.86 32.83 32.30 33.01 PASS 25 0 21.86 22.81 22.35 / 10.00 31.86 32.81 32.35 33.01 PASS Note: 1) dBd = dBi - 2.15 2) EIRP = Conducted output power + Antenna gain (dBi) Test Band: 41 _ 10MHz Bandwidth Modulation RB Allocation Conducted Power (dBm) Antenna gain EIRP(dBm) Limit (dBm) Verdict Size Offset LCH MCH HCH (dBd) (dBi) LCH MCH HCH 64QAM 1 0 22.26 22.68 22.28 / 10.00 32.26 32.68 32.28 33.01 PASS 25 22.25 22.87 23.00 / 10.00 32.25 32.87 33.00 33.01 PASS 49 22.69 22.57 22.76 / 10.00 32.69 32.57 32.76 33.01 PASS 25 0 22.55 22.77 22.58 / 10.00 32.55 32.77 32.58 33.01 PASS 13 22.48 22.73 22.76 / 10.00 32.48 32.73 32.76 33.01 PASS 25 22.56 22.77 22.86 / 10.00 32.56 32.77 32.86 33.01 PASS 50 0 22.68 22.70 22.71 / 10.00 32.68 32.70 32.71 33.01 PASS 16QAM 1 0 22.08 22.39 22.38 / 10.00 32.08 32.39 32.38 33.01 PASS 25 22.34 22.12 22.56 / 10.00 32.34 32.12 32.56 33.01 PASS 49 22.27 22.17 22.83 / 10.00 32.27 32.17 32.83 33.01 PASS 25 0 22.10 22.99 22.29 / 10.00 32.10 32.99 32.29 33.01 PASS 13 22.04 22.89 22.34 / 10.00 32.04 32.89 32.34 33.01 PASS 25 22.08 22.86 22.38 / 10.00 32.08 32.86 32.38 33.01 PASS 50 0 22.18 22.93 22.32 / 10.00 32.18 32.93 32.32 33.01 PASS QPSK 1 22.07 22.12 22.20 / 10.00 32.07 32.12 32.20 33.01 PASS 25 21.80 22.83 22.23 / 10.00 31.80 32.83 32.23 33.01 PASS 49 22.29 22.10 22.62 / 10.00 32.29 32.10 32.62 33.01 PASS 25 0 22.10 22.04 22.27 / 10.00 32.10 32.04 32.27 33.01 PASS 13 21.97 22.88 22.32 / 10.00 31.97 32.88 32.32 33.01 PASS 25 22.04 22.84 22.44 / 10.00 32.04 32.84 32.44 33.01 PASS 50 0 22.16 22.95 22.31 / 10.00 32.16 32.95 32.31 33.01 PASS Note: 1) dBd = dBi - 2.15 2) EIRP = Conducted output power + Antenna gain (dBi) Test Band: 41 _ 15MHz Bandwidth Modulation RB Allocation Conducted Power (dBm) Antenna gain EIRP(dBm…
