WBKCPX80P5G CPE

CPX80P Quick Start Guide Introduction CPX80P is a highly advanced 5G outdoor multi-service product solution specifically designed to meet integrated data needs for residential, business and enterprise users. The product supports advanced Gigabit networking functionalities. It enables wide service coverage and provides high data throughput and networking features to customers who needs easy broadband access. Panel of device Packing list Make sure you have everything you need to properly configure the device. ODUPoEEthernet cablePower supply Stainless steel clamp Cable glandsSlotted end cap How does it work 1. Connect the Power Adapter to PoE injector. 2. PoE injector provides the power to ODU via LAN cable. 3PC connects LAN Cable to PoE, then PC can surf the Internet when ODU accesses the 5G network. This quick installation guide shows you how to configure your ODU in order to access the Internet. Configure hardware Please make sure that you are familiar with all accident prevention and safety procedures necessary for working at height and with electrici- ty before starting to install the device. DO NOT install the ODU during a lightning storm. Insert a SIM card to the slot Step 1 CAT6 (or above) cable to thread through the cable glands. Step 2 Connect the end of the CAT6 (or above) Ethernet cable to the PoE port of the ODU. Step 3 Wiring the cable glands into ODU and seal tightly. NOTE: Make sure you have inserted the SIM card into the ODU. Mount the ODU See the installation instructions to mount the ODU correctly. Header connection Mounting bracket The ODU can be mounted on an antenna pole or mast or on a wall using the supplied mounting bracket. · Choose a mounting point that is sturdy enough to hold the ODU, even during high winds. · When choosing a location to install the ODU, please note that the ODU’s front panel should point towards your service provider’s nearest base station. You do not need to be able to see the base station from the ODU’s position. However, if you experience difficulties with signal reception, a Line of Sight (LoS) connection may produce better results. · It is suggested that you transport the ODU to its intended installation location in its original protective package. To obtain the best radio signal level and connection quality, the CPE antenna should be aimed towards the best eNB or BS directly.To search for the best eNB direction, the user can rotate the CPE slowly and tilt CPE slightly to find the best signal direction. The CPE radio signal strength level can be observed from the RF LEDs mounted on the lower panel as shown below. Different colored LEDs represent different signal strength. Choose location Connect the PoE Place a CAT6 (or above) Ethernet cable (not included) from the location of your intended Router to the desired PC location. If you intend to use cable clamps or other methods to secure the cable, do not tighten them until you finish installing the Router and ODU. ODU Computer PoEAdapter Hardware connections of Router ODU PWR Steady on Off Off Power on No power supply NET Steady onInternet available Internet unavailable Blinking (500ms interval) Searching network Off SIM Steady onSIM ready No SIM detected Yellow GreenSignal strong Signal good Red Signal weak Off No signal Blinking Green and Red (500ms interval) Firmware upgrade SIG Configure the CPE Login to the website Use a browser to access the management web page to configure and manage the CPE. The following procedure describes how to use a computer running Windows 7 or above version and Internet Explorer to connect to the CPE webpage. Connect to the CPE correctly. Start Internet Explorer, type http://192.168.225.1 in the address bar, and press Enter. Enter the user name and password, and click Log In. You can connect to the management web page after the password is verified. Configuration of 5G Step 1 Connect to the CPE correctly. Step 2 Go to the management website. Step 3 Choose Settings Network Radio Settings. Step 4 Set the connection mode and scan mode. The default setting is automatic connection and full band scanning, if you want to connect to the 5G network according to your needs, you can set the connection mode as manual, and simply scan a specific band. FAQs · Make sure that the CPE is powered on. · Verify that the CPE is correctly connected to the computer through a network cable. If the problem persists, contact authorized local service suppliers. · Check that the power adapter and PoE have connected to the CPE properly. · Check that the CPE is placed in an open area that is far away from obstructions, such as concrete or wooden walls. · Check that the CPE is placed far away from household electrical appliances that generate strong electromagnetic field, such as microwave ovens, refrigerators, and satellite dishes. - If the problem persists, contact your Internet Service Provider. · The CPE is hot after being used for long time. Turn off the CPE when not in use. · Check that the CPE is properly ventilated and protected from direct sunlight. Fails to Log in to the web management page. · Make sure that the power cable is connected to the PoE, and the CPE is connected to the right port of the PoE. · Make sure that the power adapter and PoE are compatible with the CPE. The POWER indicator does not turn on. The CPE fails to search for the 5G network. The CPE power adapter has overheated · If the CPE powers off unexpectedly while being configured, the parameters may be restored to the default settings. · After configuring the parameters, download the configuration file to quickly restore the CPE to the desired settings. The parameters are restored to default values. Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descrip- tions herein may not exactly match the product or its acces…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name BTI Wireless Address 14600 Industry Circle La Mirada, CA 90638 Grantee Code WBK FCC ID WBKCPX80P Authorized Contact Name Richard Xu Contact Email [email protected] Contact Phone +1-214-850-1676 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:2022/11/23 Print Name: Richard Xu Title: Technical Director *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

BTI Wireless Date: 2022-11-23 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: WBKCPX80P To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with BTI Wireless This authorization is valid until further written notice from the applicant. Name (Printed): Richard Xu Title: Technical Director Signature: On behalf of Company: BTI Wireless Telephone: +1-214-850-1676

Corning Restricted BTI Wireless To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: BTI Wireless 14600 Industry Circle La Mirada, CA 90638 Regarding: Confidentiality Request regarding application for FCC ID: WBKCPX80P LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Tune-up BOM The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature/Electronic Signature: Printed Name (on file with the FCC associated with the Grantee Code): Richard Xu Title: Technical Director Company Name: BTI Wireless

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Appendix Photographs of External photo for KSCR2210001943AT Test Model No.: CPX80P Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 Compliance Certification Services (Kunshan) Inc. Page: 6 of 6

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 Appendix Photographs of Internal photo for KSCR2210001943AT Test Model No.: CPX80P Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 1 of 7 Eric Lin EMC Lab Manager 1 Cover Page RF MPE REPORT Application No.: KSCR2210001943AT FCC ID: WBKCPX80P Applicant: BTI Wireless Address of Applicant: 14600 Industry Circle La Mirada, CA 90638 Manufacturer: BTI Wireless Address of Manufacturer: 14600 Industry Circle La Mirada, CA 90638 Factory: Sunwave Communications Co., Ltd. Address of Factory: 581 Huoju Avenue, Binjiang District, Hangzhou, China Equipment Under Test (EUT): EUT Name: 5G CPE Model No.: CPX80P Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2022-10-17 Date of Test: 2022-10-17 to 2022-11-09 Date of Issue: 2022-11-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 2 of 7 Revision Record Version Description Date Remark 00 Original 2022-11-18 / Authorized for issue by: Cloud Peng / Project Engineer Eric Lin / Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 3 of 7 2 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 CONTENTS ................................................................................................................................................ 3 3 GENERAL INFORMATION ........................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ........................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS ................................................................................................................. 4 3.3 TEST LOCATION .................................................................................................................................... 5 3.4 TEST FACILITY ...................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................. 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ........................................................................... 6 5 MEASUREMENT AND CALCULATION .................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................. 7 5.2 MPE CALCULATION .............................................................................................................................. 7 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 4 of 7 3 General Information 3.1 General Description of E.U.T. Power supply: DC 24V/1A,24W by Adapter Adapter Model:ASSA67A-240100 Input:100-240V~50/60Hz,0.8A Output: DC 24V 1A 3.2 Technical Specifications Frequency Band: n48,n78 Antenna Type: Internal Antenna Gain: Antenna 1:14.32dBi (Provided by manufacturer) Antenna 2:14.35dBi (Provided by manufacturer) Modulation Type: CP-OFDM: QPSK, 16QAM, 64QAM, 256QAM Antenna Delivery: 2T2R MIMO Temperature Range: -30°C to 50°C Note: The antenna gain value is provided by the customer. The test lab will not be responsible for wrong test result due to incorrect information about antenna gain values. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 5 of 7 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g., max. internal working frequency, antenna gain, cable loss, etc) is provided by the applicant. (If applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (If applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS Compliance Certification Services (Kunshan) Inc. is accredited by the China National Accreditation Service for Conformity Assessment (CNAS). Registration No. CNAS L4354 • A2LA Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-20134, R-11600, C-11707, T-11499, G-10216 respectively. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR221000194302 Page: 6 of 7 4 Test Standards and Limits 4.1 FCC Radiofrequency radiation exposure limits: According to§1.1310, the limit for general population/uncontrolled exposures Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 …

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 534 Appendix for KSCR2210001943AT-FCC-NR48 1. Duty Cycle 1.1 30k_MIMO_10MHz_NTNV 1.1.1 Test Result 5G NR n48 SCS=30kHz MIMO 10MHz NTNV Modulation Frequency (MHz) RB Allocation T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) CP-OFDM QPSK 3555 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.002 5.000 20.04 6.98 0.00 Outer_Full 1.002 5.000 20.04 6.98 0.00 Inner_Full 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3624.99 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.00 Inner_Full 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3694.98 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.002 5.000 20.04 6.98 0.00 Outer_Full 1.002 5.000 20.04 6.98 0.00 Inner_Full 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 CP-OFDM 16 QAM 3555 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.03 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.03 Outer_Full 1.002 5.000 20.04 6.98 0.00 Inner_Full 1.000 4.998 20.01 6.99 0.02 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3624.99 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.03 Inner_Full 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3694.98 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.002 5.000 20.04 6.98 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.04 Inner_Full 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 CP-OFDM 64 QAM 3555 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.002 5.000 20.04 6.98 0.00 Inner_Full 1.000 4.998 20.01 6.99 0.03 Inner_1RB_Left 1.002 5.000 20.04 6.98 0.00 Compliance Certification Services (Kunshan) Inc. Page: 2 of 534 Inner_1RB_Right 1.002 5.000 20.04 6.98 0.00 3624.99 Edge_1RB_Left 1.002 5.000 20.04 6.98 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.03 Inner_Full 1.000 5.000 20.00 6.99 0.03 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3694.98 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.002 5.000 20.04 6.98 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.03 Inner_Full 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 CP-OFDM 256 QAM 3555 Edge_1RB_Left 1.002 5.000 20.04 6.98 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.002 5.000 20.04 6.98 0.00 Inner_Full 1.002 5.000 20.04 6.98 0.00 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3624.99 Edge_1RB_Left 1.002 5.000 20.04 6.98 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.00 Inner_Full 1.000 5.000 20.00 6.99 0.03 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 3694.98 Edge_1RB_Left 1.000 5.000 20.00 6.99 0.00 Edge_1RB_Right 1.000 5.000 20.00 6.99 0.00 Outer_Full 1.000 5.000 20.00 6.99 0.00 Inner_Full 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Left 1.000 5.000 20.00 6.99 0.00 Inner_1RB_Right 1.000 5.000 20.00 6.99 0.00 Compliance Certification Services (Kunshan) Inc. Page: 3 of 534 1.1.2 Test Graph n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Edge_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Edge_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 4 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Outer_Full n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Inner_Full Compliance Certification Services (Kunshan) Inc. Page: 5 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Inner_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3555MHz_Inner_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 6 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Edge_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Edge_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 7 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Outer_Full n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Inner_Full Compliance Certification Services (Kunshan) Inc. Page: 8 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Inner_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3624.99MHz_Inner_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 9 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Edge_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Edge_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 10 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Outer_Full n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Inner_Full Compliance Certification Services (Kunshan) Inc. Page: 11 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Inner_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM QPSK_3694.98MHz_Inner_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 12 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Edge_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Edge_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 13 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Outer_Full n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Inner_Full Compliance Certification Services (Kunshan) Inc. Page: 14 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Inner_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3555MHz_Inner_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 15 of 534 n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QAM_3624.99MHz_Edge_1RB_Left n48_30kHz_MIMO_NTNV_10MHz_CP-OFDM 16 QA…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 114 of 534 n48_30kHz_MIMO_NTNV_40MHz_CP-OFDM 256 QAM_3679.98MHz_Inner_1RB_Left n48_30kHz_MIMO_NTNV_40MHz_CP-OFDM 256 QAM_3679.98MHz_Inner_1RB_Right Compliance Certification Services (Kunshan) Inc. Page: 115 of 534 2. Effective (Isotropic) Radiated Power Output Data 2.1 30k_MIMO_10MHz_NTNV_EIRP 2.1.1 Test Result 5G NR n48 SCS=30kHz MIMO 10MHz NTNV Modulation Frequency (MHz) RB Allocation Conducted Power(dBm) EIRP(dBm) Verdict Ant1 Ant2 Sum Ant1 Ant2 Sum Limit CP-OFDM QPSK 3555 Edge_1RB_Left 18.58 18.04 21.33 32.90 32.39 35.66 - Pass Edge_1RB_Right 18.53 17.91 21.24 32.85 32.26 35.58 - Pass Outer_Full 18.60 18.58 21.60 32.92 32.93 35.94 - Pass Inner_Full 18.06 18.43 21.26 32.38 32.78 35.59 - Pass Inner_1RB_Left 18.44 18.18 21.32 32.76 32.53 35.66 - Pass Inner_1RB_Right 18.31 18.76 21.55 32.63 33.11 35.89 - Pass 3624.99 Edge_1RB_Left 17.37 18.21 20.82 31.69 32.56 35.16 - Pass Edge_1RB_Right 17.97 17.97 20.98 32.29 32.32 35.32 - Pass Outer_Full 18.24 18.05 21.16 32.56 32.40 35.49 - Pass Inner_Full 18.36 17.89 21.14 32.68 32.24 35.48 - Pass Inner_1RB_Left 17.98 18.00 21.00 32.30 32.35 35.34 - Pass Inner_1RB_Right 17.47 18.04 20.77 31.79 32.39 35.11 - Pass 3694.98 Edge_1RB_Left 17.64 18.28 20.98 31.96 32.63 35.32 - Pass Edge_1RB_Right 18.17 18.07 21.13 32.49 32.42 35.47 - Pass Outer_Full 16.93 17.79 20.39 31.25 32.14 34.73 - Pass Inner_Full 17.73 16.95 20.37 32.05 31.30 34.70 - Pass Inner_1RB_Left 17.93 17.96 20.96 32.25 32.31 35.29 - Pass Inner_1RB_Right 17.90 17.37 20.65 32.22 31.72 34.99 - Pass CP-OFDM 16 QAM 3555 Edge_1RB_Left 17.74 17.49 20.63 32.06 31.84 34.96 - Pass Edge_1RB_Right 18.61 18.84 21.74 32.93 33.19 36.07 - Pass Outer_Full 17.96 18.09 21.04 32.28 32.44 35.37 - Pass Inner_Full 18.94 18.25 21.62 33.26 32.60 35.95 - Pass Inner_1RB_Left 17.68 18.43 21.08 32.00 32.78 35.42 - Pass Inner_1RB_Right 18.37 18.51 21.45 32.69 32.86 35.79 - Pass 3624.99 Edge_1RB_Left 17.46 18.62 21.09 31.78 32.97 35.43 - Pass Edge_1RB_Right 17.55 17.72 20.65 31.87 32.07 34.98 - Pass Outer_Full 17.36 17.02 20.20 31.68 31.37 34.54 - Pass Inner_Full 17.75 17.85 20.81 32.07 32.20 35.15 - Pass Inner_1RB_Left 17.75 18.05 20.91 32.07 32.40 35.25 - Pass Inner_1RB_Right 18.26 16.59 20.52 32.58 30.94 34.85 - Pass 3694.98 Edge_1RB_Left 17.39 18.18 20.81 31.71 32.53 35.15 - Pass Edge_1RB_Right 17.83 17.64 20.75 32.15 31.99 35.08 - Pass Outer_Full 18.29 17.38 20.87 32.61 31.73 35.20 - Pass Inner_Full 17.64 17.72 20.69 31.96 32.07 35.03 - Pass Inner_1RB_Left 18.02 18.76 21.42 32.34 33.11 35.75 - Pass Inner_1RB_Right 16.84 17.06 19.96 31.16 31.41 34.30 - Pass CP-OFDM 64 QAM 3555 Edge_1RB_Left 18.50 17.67 21.12 32.82 32.02 35.45 - Pass Edge_1RB_Right 18.15 18.25 21.21 32.47 32.60 35.55 - Pass Outer_Full 18.14 18.76 21.47 32.46 33.11 35.81 - Pass Inner_Full 18.63 18.19 21.43 32.95 32.54 35.76 - Pass Inner_1RB_Left 18.07 18.18 21.14 32.39 32.53 35.47 - Pass Inner_1RB_Right 18.46 18.39 21.44 32.78 32.74 35.77 - Pass Compliance Certification Services (Kunshan) Inc. Page: 116 of 534 3624.99 Edge_1RB_Left 17.88 17.94 20.92 32.20 32.29 35.26 - Pass Edge_1RB_Right 17.85 16.65 20.30 32.17 31.00 34.63 - Pass Outer_Full 17.60 18.03 20.83 31.92 32.38 35.17 - Pass Inner_Full 17.44 17.25 20.36 31.76 31.60 34.69 - Pass Inner_1RB_Left 17.99 18.13 21.07 32.31 32.48 35.41 - Pass Inner_1RB_Right 18.21 17.72 20.98 32.53 32.07 35.32 - Pass 3694.98 Edge_1RB_Left 17.84 17.86 20.86 32.16 32.21 35.20 - Pass Edge_1RB_Right 17.83 18.55 21.22 32.15 32.90 35.55 - Pass Outer_Full 17.55 17.62 20.60 31.87 31.97 34.93 - Pass Inner_Full 17.30 17.95 20.65 31.62 32.30 34.98 - Pass Inner_1RB_Left 17.49 17.72 20.62 31.81 32.07 34.95 - Pass Inner_1RB_Right 17.55 18.14 20.87 31.87 32.49 35.20 - Pass CP-OFDM 256 QAM 3555 Edge_1RB_Left 16.79 16.64 19.73 31.11 30.99 34.06 - Pass Edge_1RB_Right 16.92 16.70 19.82 31.24 31.05 34.16 - Pass Outer_Full 16.64 16.59 19.63 30.96 30.94 33.96 - Pass Inner_Full 16.76 16.85 19.82 31.08 31.20 34.15 - Pass Inner_1RB_Left 17.17 16.47 19.84 31.49 30.82 34.18 - Pass Inner_1RB_Right 16.51 16.65 19.59 30.83 31.00 33.93 - Pass 3624.99 Edge_1RB_Left 16.64 16.49 19.58 30.96 30.84 33.91 - Pass Edge_1RB_Right 16.09 16.19 19.15 30.41 30.54 33.49 - Pass Outer_Full 16.33 16.31 19.33 30.65 30.66 33.67 - Pass Inner_Full 16.17 16.68 19.44 30.49 31.03 33.78 - Pass Inner_1RB_Left 15.78 16.16 18.98 30.10 30.51 33.32 - Pass Inner_1RB_Right 15.66 16.17 18.93 29.98 30.52 33.27 - Pass 3694.98 Edge_1RB_Left 15.47 15.51 18.50 29.79 29.86 32.84 - Pass Edge_1RB_Right 15.78 16.66 19.25 30.10 31.01 33.59 - Pass Outer_Full 16.41 15.50 18.99 30.73 29.85 33.32 - Pass Inner_Full 16.06 15.97 19.03 30.38 30.32 33.36 - Pass Inner_1RB_Left 15.67 16.35 19.03 29.99 30.70 33.37 - Pass Inner_1RB_Right 16.16 16.51 19.35 30.48 30.86 33.68 - Pass Note1: Antenna Gain: Ant1: 14.32dBi; Ant2: 14.35dBi; Note2: EIRP Ant 1=Conducted Power 1+Ant Gain / EIRP Ant 2=Conducted Power 2+Ant Gain / Sum=EIRP Ant 1+EIRP Ant 2 2.2 30k_MIMO_10MHz_NTNV_EIRP/10MHz 2.2.1 Test Result 5G NR n48 SCS=30kHz MIMO 10MHz NTNV Modulation Frequency (MHz) RB Allocation Conducted Power(dBm/10MHz) EIRP(dBm/10MHz) Verdict Ant1 Ant2 Sum Ant1 Ant2 Sum Limit CP-OFDM QPSK 3555 Edge_1RB_Left 18.58 18.04 21.33 32.90 32.39 35.66 <=47 Pass Edge_1RB_Right 18.53 17.91 21.24 32.85 32.26 35.58 <=47 Pass Outer_Full 18.60 18.58 21.60 32.92 32.93 35.94 <=47 Pass Inner_Full 18.06 18.43 21.26 32.38 32.78 35.59 <=47 Pass Inner_1RB_Left 18.44 18.18 21.32 32.76 32.53 35.66 <=47 Pass Inner_1RB_Right 18.31 18.76 21.55 32.63 33.11 35.89 <=47 Pass 3624.99 Edge_1RB_Left 17.37 18.21 20.82 31.69 32.56 35.16 <=47 Pass Edge_1RB_Right 17.97 17.97 20.98 32.29 32.32 35.32 <=47 Pa…
