WBKDAS2100A80RUM2.1GHz AWS Band 80W Remote Unit on BTI DAS system

BTI Wireless

Click to zoom

Application Details

Equipment Class: B2I - Part 20 Industrial Booster (CMRS)
Date of Grant: Jul 02, 2014
Application Purpose: Original Equipment
Date of Application: Jun 16, 2014
Equipment Note: 2.1GHz AWS Band 80W Remote Unit on BTI DAS system
Frequency Range: 2110.00000000 - 2155.00000000
Company: BTI Wireless
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

mBSC-H DAS System Installation Manual Issue 5 mBSC-H DAS SYSTEM INSTALLATION AND OPERATIONS MANUAL mBSC-H DAS System Installation Manual Issue 7 © 2009-2014, BTI Wireless Page 2 COPYRIGHT This document serves as the System Installation Manual for the BTI mBSC-H Fiber Distributed Antenna System (DAS) system. BTI reserves the right to change the contents without prior notice. No part of this document may be reproduced or utilized. © 2009-2013, BTI, All Rights Reserved REVISION HISTORY ISSUE NO. DESCRIPTION DATE 1 INITIAL DRAFT OCT. 28, 2009 2 UPDATE SPECIFICATIONS JAN. 18, 2010 3 UPDATE SPECIFICATIONS, INSTALLATION, AND ILLUSTRATIONS MAY 31, 2011 4 UPDATE SPECIFICATION, INSTALLATION, MAINTENANCE, AND ILLUSTRATIONS FEB 22, 2012 5 UPDATE SPECIFICATION WITH THE LATEST MECHANICAL DESIGN AUG 31, 2013 6 ADD THE MESSAGE FOR FCC WARING LABEL ON PAGE 6 APR 28, 2014 7 Change the MPE Distance to 6 meters in page 6 JUN 10, 2014 mBSC-H DAS System Installation Manual Issue 7 © 2009-2014, BTI Wireless Page 3 Table of Contents 1 GENERAL INFORMATION ...................................................... 6 1.1 SAFETY PRECAUTIONS ............................................................................... 6 1.2 GLOSSARY AND ACRONYMS ...................................................................... 7 2 INTRODUCTION ...................................................................... 8 3 GENERAL DESCRIPTION ...................................................... 8 3.1 SYSTEM COMPONENTS DESCRIPTION ..................................................... 8 3.1.1 Host Unit ................................................................................................... 9 3.1.2 Network Management System ................................................................ 9 3.1.3 Remote Unit ............................................................................................ 11 3.2 USER INTERFACE ....................................................................................... 14 3.2.1 Host Unit Interface ................................................................................. 14 3.2.2 NMS Interface ......................................................................................... 14 3.2.3 Remote Unit Interface .......................................................................... 16 3.3 SPECIFICATIONS ........................................................................................ 18 3.3.1 Host Unit Specifications ........................................................................ 18 3.3.2 NMS Specifications .............................................................................. 18 3.3.3 Remote Unit Specification ................................................................... 19 4 INSTALLATION ...................................................................... 20 4.1 SYSTEM INSTALLATION OVERVIEW ........................................................ 20 4.2 REMOTE UNIT INSTALLATION ................................................................. 21 4.2.1 Remote Unit Installation Overview ....................................................... 21 4.2.2 Installation Hardware And Tools ........................................................... 21 4.2.3 Unpacking And Inspection .................................................................... 23 4.2.4 Mechanical Installation .......................................................................... 28 4.2.4.1 Mechanical Safety Precautions ....................................................................................... 28 4.2.4.2 Install The Mounting Panel .............................................................................................. 29 4.2.4.3 Install The Remote Unit On The Mounting Panel ............................................................ 30 4.2.4.4 Install The Shroud Cover ................................................................................................. 30 4.2.5 Electrical Installation ............................................................................. 32 4.2.5.1 Electrical Safety Precautions ........................................................................................... 32 4.2.5.2 Grounding ........................................................................................................................ 33 4.2.5.3 Route the Cables ............................................................................................................. 33 4.2.5.4 Fiber Optic Cable Connection ......................................................................................... 33 4.2.5.5 Antenna Cable Connection .............................................................................................. 34 4.2.5.6 AC Power Cable Connection ........................................................................................... 35 4.2.5.7 Slave Cable Connection .................................................................................................. 36 4.2.6 Remote Unit Installation Review ......................................................... 39 mBSC-H DAS System Installation Manual Issue 7 © 2009-2014, BTI Wireless Page 4 4.2.6.1 Mechanical Installation Review ....................................................................................... 39 4.2.6.2 Electrical Installation Review ........................................................................................... 39 4.2.6.3 Field Status Test - Remote Unit LED Status Indicators ................................................... 39 4.2.7 Troubleshooting ..................................................................................... 40 4.3 HOST UNIT INSTALLATION ........................................................................ 41 4.3.1 Host Unit Installation Overview ............................................................ 41 4.3.2 Installation Hardware And Tools ........................................................... 41 4.3.3 Un…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: 5/13/2014 FCC ID: WBKDAS2100A80RUM Non-Conformities FCC ID: WBKDAS2100A80RUM (CKC CS Ref # 95158-06-FCC) Subject: Attestation To whom it may concern: Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device, WBKDAS2100A80RUM. Sincerely, Raymond Shin Senior System Engineer BTI Wireless

Cover Letter(s)

5/19/2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: WBKDAS2100A80RUM 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List / Tune-Up Procedure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Raymond Shin Senior System Engineer BTI Wireless

Cover Letter(s)

WIRELESSTM Monday,June30,2014 ToWhomItMayConcern: IherebyappointRaymondShintosignlettersandapplicationsforanyfilingswithregulatoryagencies onourbehalf,andtoreceiveandexchangedatabetweenourcompany,theagentscompanyandthe agencyinconnectionwithcertificationforanyproductsthatourcompanyownsormanufactures. Sincerely, Coo BTIWireless BaileyZheng 6185PhyllisDr.,UnitD,Cypress,CA90630ITel:+1714-230-8333IFax:+1714-230-8341Iwww.btiwireless.com

External Photos

Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 1 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 2 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 3 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 4 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 5 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 6 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 7 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 8 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 9 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 10 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 11 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 12 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 13 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 14 of 15 Project mBSC2100-080-RUM PCBA Pictures Model Number Revision # Doc. No. Issue Date © 2014 BTI Proprietary and Confidential Page 15 of 15

Internal Photos

RF Exposure Info

Page 1 of 8 Report No: 95158-9 RADIO FREQUENCY EXPOSURE REPORT FOR THE Device: 2100 MHz 80W Remote Transmitting Unit Model: mBSC2100-080-RUMF01 Report No.: 95158-9 Date of issue: May 23, 2014 PREPARED FOR: BTI Wireless 6185 Phyllis Dr. Unit D Cypress, CA 90630 PREPARED BY: Don Nguyen CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 2 of 8 Report No: 95158-9 Purpose: To demonstrate compliance with United States, Canada and/or European Union RF Exposure requirements for Portable equipment (devices used ≤20cm from the body) or Mobile equipment (devices used >20cm from the body) with power output below exemption levels and Mobile equipment, where Maximum Permissible Exposure (MPE) Calculations apply. United States Compliance Requirements (1.1310): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f 2 ) 6 30-300 61.4 0.163 1 6 300-1500 --- --- f/300 6 1500-100,000 --- --- 5.0 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 --- --- f/1500 30 1500-100,000 --- --- 1.0 30 * Plane wave equivalent power density Limit is calculated based on the mid-band frequency used in the operating frequency range. Exemption Level: Power output <60/f GHz (mW) Page 3 of 8 Report No: 95158-9 Canadian Compliance Requirements (RSS-102): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 600 4.9 --- 6 1.0-10 600/f 4.9/f --- 6 10-30 60 4.9/f --- 6 30-300 60 0.163 10 6 300-1500 3.54 f 0.5 0.0094*f 0.5 f/3 6 1500-15,000 137 0.364 50 6 15,000-150,000 137 0.364 50 616000/f 1.2 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 280 2.19 --- 6 1.0-10 280/f 2.19/f --- 6 10-30 28 2.19/f --- 6 30-300 28 0.073 2 6 300-1500 1.585 * f 0.5 0.0042 * f 0.5 f/150 6 1500-15,000 61.4 0.163 10 6 15,000-150,000 61.4 0.163 10 616000/f 1.2 *Power density limit applicable >100MHz Exemption Level: Frequency Range (MHz) Maximum Output Power (Conducted or EIRP) 0.003-1000 ≤ 200 mW 1000-2200 ≤ 100 mW 2200-3000 ≤ 20 mW 3000-6000 ≤ 10 mW Page 4 of 8 Report No: 95158-9 European Union Compliance Requirements (ICNIRP): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.00082-0.065 610 24.4 --- 6 0.065-1.0 610 1.6/f --- 1.0-10 610/f 1.6/f --- 6 10-400 61 0.16 10 6 400-2000 3.0 * f 0.5 0.008 * f 0.5 f/40 6 2000-300,000 137 0.36 50 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-0.150 87 5.0 --- 6 0.150-1.0 87 0.73/f -- 6 1.0-10 87/f 0.5 0.73/f --- 6 10-400 28 0.073 2 6 400-2000 1.375 f 0.5 0.0037*f 0.5 f/200 6 2000-300,000 61 0.16 10 6 *Power density limit applicable >100MHz Exemption Level: Power output < 20mW 1 1 May vary by product type Page 5 of 8 Report No: 95158-9 Device and Antenna Operating Configuration: Device operating at maximum output power with continuous transmission of modulated data. Freq: 2110-2155MHz Signal protocol: UMTS WCDMA_3GPP, LTE-TM1.1 1.4MHz, 5MHz. 20MHz Maximum output power is set at 80W. External antenna gain: 17dbi. Test Procedure: This equipment is evaluated in accordance with the guidelines set forth in OET Guide 65 & ANSI C95.1 for the US and Health Canada Safety Code 6 & RSS 102 for Canada. Other Considerations: None Page 6 of 8 Report No: 95158-9 MPE Calculations Applicability Limit Used X General Population / Uncontrolled Exposure Occupational / Controlled Exposure RF Exposure Exemption No United States No Canada No Europe Equipment Operational Details Config # Operating Frequency (MHz) Measured Output Power (dBm) Antenna Gain (dBi) Antenna Type / Configuration EIRP (dBm) 1 2120.5 49.03 17 External 66.03 Measurements based from EMC Test Report(s): 95158-5 Configuration #1: maximum output power reading 80W, LTE 20MHz, low channel setting. MPE Calculation: 2 4d EIRP DensityPower   Given: EIRP in mW or W and d in cm or m Config Limit US (1.1310) mW/cm 2 Minimum distance to meet the limit cm #1 1 564.800 Page 7 of 8 Report No: 95158-9 Summary Exemptions: In the case the equipment meets compliance requirements by exemption the product is approved for use under mobile or portable conditions without further testing under the condition that any additional collocation or simultaneous transmission requirements (including necessary separation distances) have been met. MPE Calculation Results: In the case the equipment meets compliance by MPE Calculations the product is approved for use under mobile conditions without further testing under the condition that any additional colloc…

Text truncated - open the document above for the full version.

Test Report

This report contains a total of 68 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. BTI Wireless TEST REPORT FOR 2100MHz 80W Transmitting Remote Unit Model: mBSC2100-080-RUMF01 Tested To The Following Standards: FCC Part 27L Report No.: 95158-5 Date of issue: December 23, 2013 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 68 Report No.: 95158-5 TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC 27L .......................................................................................................................................................................... 7 27.50(c)(3) / 2.1046 RF Power Output....................................................................................................................... 7 Occupied Bandwidth................................................................................................................................................ 16 27.53(g) / 2.1051 Conducted Spurious Emissions ................................................................................................... 35 27.53(h) / 2.1053 Antenna Radiated Spurious Emissions ........................................................................................ 38 Bandedge ................................................................................................................................................................. 42 Intermodulation ....................................................................................................................................................... 53 Out of Band Rejection .............................................................................................................................................. 64 Supplemental Information .......................................................................................................................................... 67 Measurement Uncertainty ...................................................................................................................................... 67 Emissions Test Details .............................................................................................................................................. 67 Page 3 of 68 Report No.: 95158-5 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: BTI Wireless 6185 Phyllis Dr. Unit D Cypress CA, 90630 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Raymond Shin Project Number: 95158 Customer Reference Number: 9913651 DATE OF EQUIPMENT RECEIPT: November 25, 2013 DATE(S) OF TESTING: November 25-27, 2013 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 68 Report No.: 95158-5 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Gang Liang(VP of Business Development)

[email protected]250-882-8082Fax: 250-882-8082

Technical Contact

BTI WirelessRaymond Shin

[email protected]714- 230-8333

6185 Phyllis Drive · Cypress, California · United States

Test Firm

CKC Laboratories, Inc.Steve Behm

[email protected]714-993-6112Fax: 866-799-9776

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	27	2.11 GHz - 2.15 GHz	80 W	W7D	Amp

Confidentiality

Long Term

Grant Notes

Booster. Power output listed is the composite for multi-channel operation. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b) (3).
