WNA-HPH9HD SMART TERMINAL STB

User Manual Content General information Main features For your safety Unpacking RCU Front Panel Real Panel Installation System and activation Update Troubleshooting P1 P2 P3 P6 P7 P9 P10 P11 P13 P15 P19 Smart Internet TV is a high-end entertainment equipment of modern family life, which combines high-definition television, network television, local audio and video playback, entertainment, games, news, stock quotes, life service, multi-screen interactive functions into one, its depth customized TV operating system, a delicate UI design, personalized user experience and a wealth of boutique applications to meet your pursuit of high quality of life, and will give you a fashion, technology, convenient new TV experience. General information 1 Main Features General information 2 Vmx player includes 67 Internet channels from multiple countries; Web browser and a multitude of applications; Support 1080p, with HDCP copy protection as well as PAL and NTSC that can switchover automatically; Video decoder supporting DvixH.264MPEG- 1/2/4(ASP)VC-1WMV3XviD Audio decoder supporting MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 7, 8, 9PCM, IMA- ADPCM, MS-ADPCM, U-LawVorbisFlac ALACAPEAAC-LC, AAC-HE(AAC+)AC-3 For Your Safety Do not expose the receiver un-der the sunlight. And keep it away from the heat source. Keep the receiver away from flower vases, tubs, sinks, etc., in order to avoid damaging the equipment. To avoid electric-shock hazards, do not open the cabinet, refer servicing to qualified personnel only. Do not block ventilation holes of the Receiver so that air can circulate freely. General information 3 Do not touch the receiver during thunder, since that might create electric-shock hazards. When the abnormal phenomenon occur, you should cut off the power immediately. General information 4 FCC STATEMENT 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. General information 5 This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. User Manual General information 1. Receiver 1 2. Remote Control1 3. AAA batteries2 4. External power supply1 2 3 4 6. User manul1 7 5. HDMI cable1 7. AV cable1 1 C C 5 Unpacking 6 6 RCU General information The picture is only for reference, please make the object as the standard. Key Function Standby On/Off When watching a channel, mute the sound 0~9 MENU Enter number of the required menu item or select a channel number to watch Press this key one time to run menu onscreen Displays the favorite group list Show information of the current channel FAV INFO When watching a channel, change channels or move to the next higher or lower item in the menu When watching a channel, adjust the volume or move to the left or right item in the menu Call up the EPG (Electronic Program Guide) EPG Switches back to previous channel BACK HOME CH+,CH- VOL+,VOL- Adjust the channel Adjust the volume RADIO Switch to radio mode Confirm OK 7 Enter into launcher screen General information Key Function GAME PROMO LANG SUBTITLE ACCOUNT HELP INTERACTIVE 8 Enter into games Cycle through additional language audio tracks Cycle through subtitle tracks Enter into account settings Enter into some help pages Front Panel General information The picture is only for reference, please make the object as the standard. 9 General information Rear Panel Connect to power supply Power On/Off Connect to AV convertor Connect to TV Set HDMI input Connect to internet Connect to infrared receiver (optional) The picture is only for reference, please make the object as the standard. 10 Connect to digital amplifier Connect to USB device SD Card slot Installation Connecting to TV using AV cable L R IN TV AUDIOVIDEO The picture is only for reference, please make the object as the standard. 11 Connecting to TV using HDMI support Installation IN TV HDMI The picture is only for reference, please make the object as the standard. 12 Menu Operation System activation 1.Language setting Click the language button to choose between Spanish and English. 13 2.Ethernet connection Connect the Ethernet cable to the box. And in this step it will detect the connecting status and inform you. Menu Operation 14 3. Update: Keep your box with the latest version and enjoy the latest features. Turn to the system update item in settings. Here are two ways to update your box: Menu Operation 15 1. Upgrade by USB disk Insert a USB disk with the latest firmware, click your USB disk. Menu Operation Then choose Ok in this pop-up window…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 4.0 Shenzhen Skyworth Digital Technology Co.,LTD 2014-08-07 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen Skyworth Digital Technology Co.,LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product Description: HD SMART TERMINAL STB Model name: A8E, HPH9 FCC ID: WNA-HPH9 Sincerely, Client’s signature ：Wenping Song Client’s name / title：engineer Contact information / address ：86-755-26010039（Unit A14/F.Skyworth Bldg., Gaoxin Ave.1s., Nanshan District, Shenzhen,China）

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Skyworth Digital Technology Co.,LTD 2014-08-07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: WNA-HPH9 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature ：Wenping Song Client’s name / title：engineer Contact information / address ：86-755-26010039（Unit A14/F.Skyworth Bldg., Gaoxin Ave.1s., Nanshan District, Shenzhen,China）

Shenzhen Skyworth Digital Technology Co.,LTD Statement Model number: A8E, HPH9 FCC ID: WNA-HPH9 We hereby state that these models are identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Sincerely, Client’s signature ：Wenping Song Client’s name / title：engineer Contact information / address ：86-755-26010039（Unit A14/F.Skyworth Bldg., Gaoxin Ave.1s., Nanshan District, Shenzhen,China）

Antenna

FCC ID : WNA-HPH9 1. RF EXPOSURE 1.1. The Requirement System operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See Section 15.247(b)(4) and Section 1.1307(b)(1) 1.2. Limit For Maximum Permissible Exposure (MPE) Limits for General Population/ Uncontrolled Exposure F = frequency in MHz, * Plane-wave equivalent power density 1.3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) ( 2 mW/cm) Averaging Time 2 E, 2 H or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the antenna is 3.79 dBi, the RF power density can be obtained. 1.4. TEST RESULTS Maximum measured transmitter power 802.11b Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 16.54 45.08 2.39 1.000 0.021 Pass 2437 20.00 16.20 41.69 2.39 1.000 0.020 Pass 2462 20.00 16.54 45.08 2.39 1.000 0.021 Pass 802.11g Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 15.36 34.36 2.39 1.000 0.016 Pass 2437 20.00 15.21 33.19 2.39 1.000 0.016 Pass 2462 20.00 15.43 34.91 2.39 1.000 0.017 Pass 802.11n(20MHz) Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 14.50 28.18 2.39 1.000 0.013 Pass 2437 20.00 14.80 30.20 2.39 1.000 0.014 Pass 2462 20.00 14.37 27.35 2.39 1.000 0.013 Pass 802.11n (40MHz) Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2422 20.00 13.12 20.51 2.39 1.000 0.010 Pass 2437 20.00 13.15 20.65 2.39 1.000 0.010 Pass 2452 20.00 13.16 20.70 2.39 1.000 0.010 Pass The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure. 1.5. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Proposed RF exposure safety information to include in User’s Manual.

Page 1 of 98 FCC ID: WNA-HPH9 ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20141378 APPLICATION CERTIFICATION FCC Part 15C On Behalf of Shenzhen Skyworth Digital Technology Co.,LTD HD SMART TERMINAL STB Model No.: A8E, HPH9 FCC ID: WNA-HPH9 Prepared for : Shenzhen Skyworth Digital Technology Co.,LTD Address : Unit A14/F.Skyworth Bldg.,Gaoxin Ave.1s., Nanshan District, Shenzhen,China Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20141378 Date of Test : July 18-Aug 04,2014 Date of Report : Aug 04,2014 Page 2 of 98 FCC ID: WNA-HPH9 ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20141378 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Carrier Frequency of Channels .................................................................................................................6 1.3. Special Accessory and Auxiliary Equipment ...........................................................................................6 1.4. Description of Test Facility ......................................................................................................................6 1.5. Measurement Uncertainty.........................................................................................................................7 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 8 3. OPERATION OF EUT DURING TESTING ................................................................................. 9 3.1. Operating Mode ........................................................................................................................................9 3.2. Configuration and peripherals ..................................................................................................................9 4. TEST PROCEDURES AND RESULTS ....................................................................................... 10 5. 6DB BANDWIDTH MEASUREMENT ........................................................................................ 11 5.1. Block Diagram of Test Setup..................................................................................................................11 5.2. The Requirement For Section 15.247(a)(2) ............................................................................................11 5.3. EUT Configuration on Measurement .....................................................................................................11 5.4. Operating Condition of EUT ..................................................................................................................11 5.5. Test Procedure ........................................................................................................................................11 5.6. Test Result ..............................................................................................................................................12 6. MAXIMUM OUTPUT POWER.................................................................................................... 19 6.1. Block Diagram of Test Setup..................................................................................................................19 6.2. The Requirement For Section 15.247(b)(3)............................................................................................19 6.3. EUT Configuration on Measurement .....................................................................................................19 6.4. Operating Condition of EUT ..................................................................................................................19 6.5. Test Procedure ........................................................................................................................................19 6.6. Test Result ..............................................................................................................................................20 7. POWER SPECTRAL DENSITY MEASUREMENT.................................................................. 27 7.1. Block Diagram of Test Setup..................................................................................................................27 7.2. The Requirement For Section 15.247(e).................................................................................................27 7.3. EUT Configuration on Measurement .....................................................................................................27 7.4. Operating Condition of EUT ..................................................................................................................27 7.5. Test Procedure ........................................................................................................................................27 7.6. Test Result ..............................................................................................................................................28 8. BAND EDGE COMPLIANCE TEST ........................................................................................... 35 8.1. Block Diagram of Test Setup..................................................................................................................35 8.2. The Requirement For Section 15.247(d) ................................................................................................35 8.3. EUT Configuration on Measurement .....................................................................................................35 8.4. Opera…
