Intuicom, Inc. 4909 Nautilus Ct. N Ste 111 Boulder, CO 80301 (303) 449‐4330 www.intuicom.com Intuicom® XC400™ Industrial IoT LTE Router Basic User Guide XC400 Basic User Guide INTXC.U.01.1.2.2212 i This manual is for use by purchasers and other authorized users of Intuicom products. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, or for any purpose without the express written permission of Intuicom, Inc. © 2022 Intuicom, Inc. All rights reserved. Intuicom reserves the right to make changes to this manual without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this manual or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this manual a warranty or guarantee. Intuicom ® is a registered trademark of Intuicom, Inc. XC400 TM is a trademark of Intuicom, Inc. Other product names mentioned in this manual may be copyrights, trademarks, or registered trademarks of their respective companies and are hereby acknowledged. XC400 Basic User Guide INTXC.U.01.1.2.2212 ii FCC Notification This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates , uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual , may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Maintain at least 20cm physical separation between human body and any antenna during operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. XC400 Basic User Guide INTXC.U.01.1.2.2212 iii Attention: Incorrect termination of supply wires may cause internal damage and will void warranty. To ensure your XC400 Industrial IoT Router enjoys a long life, double check ALL your connections with the user manual before turning the power on. Note: All equipment must be properly grounded for safe operations. Note: All equipment should be serviced only by a qualified professional. Product disposal: When your product reaches the end of its useful life, it is important to take care in the disposal of the product to minimize the impact on the environment. The product housing is made of aluminum and may be recycled through regular metal reclamation operators in your area. The product circuit board should be disposed according to your country’s regulations for disposing electronics equipment. Safety Information: The products described in this user guide can fail in a variety of modes due to misuse, age, or malfunction and are not designed or intended for use in systems requiring fail‐safe performance, including life safety systems. Systems with the product(s) must be designed to prevent personal injury and property damage during product operation and in the event of product failure. Warning! Verify power is OFF before connecting or disconnecting the interface or RF cables. Important Notice: Intuicom software, firmware, and programs are delivered “as‐is”. The manufacturer does not grant any type of warranty, including guarantees of suitability and applicability to a certain application. Under no circumstances is the manufacturer or developer of any software, firmware or program responsible for any possible damages resulting from use of any software, firmware or program. The names of any software, firmware, or program, as well as any copyrights relating to the software, firmware or programs, are the sole property of Intuicom, Inc. Any transfer or licensing to a third party; leasing, renting, transportation, copying, editing, translating, modifying into another programming language, or reverse engineering for any intent is expressly prohibited without the express written permission of Intuicom, Inc. XC400 Basic User Guide INTXC.U.01.1.2.2212 iv Warranty Information: Intuicom, Inc. warrants the Intuicom® XC400 (Product) that you have purchased against defects in materials and manufacturing for a period of one year from the date of shipment. In the event of a Product failure due to materials or workmanship, Intuicom will, at its discretion, repair or replace the Product. For evaluation of Warranty coverage, return the Product to Intuicom upon receiving a Return Material Authorization (RMA). The replacement product will remain under warranty for 90 days or the remainder of the original product warranty period, whichever is longer. IN NO EVENT WILL INTUICOM, INC., ITS SUPPLIERS, OR ITS LICENSORS BE LIABLE FOR ANY DAMAGES ARISING FROM THE USE OF OR INABILITY TO USE THIS PRODUCT. THIS INCLUDES BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION , INABILITY TO ACCESS OR SEND COMMUNICATION OR DATA, PERSONAL INJURY OR DAMAGE, OR OTHER LOSS WHICH MAY ARISE FROM THE USE OF THIS PRODUCT. THE WARRANTY IS EXCLUSIVE AND ALL OTHER WARRANTIES EXPRESS OR IMPLIED , INCLUDING BUT NOT LIMITED TO ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE ARE EXPRESSLY DISCLAIMED . Intuicom’ s Warranty does not apply in the following circumstances: 1. If Product repair, adjustments, or parts replacements are required due to accident, neglect, or undue physical, electrical, or electromagnetic stress. 2. If Product is used outside of Intuicom sp…

Text truncated - open the document above for the full version.

4909 NAUTILUS COURT N, SUITE 111  BOULDER, CO 80301 T 303.449.4330  F 303.449.4346 www.intuicom.com Differences Declaration December 16, 2022 To whom it may concern: We, Intuicom, Inc., hereby declare: The product models XC400, XC400‐2G, XC400‐2GW are identical in the same PCB layout, interior structure and electrical circuits, the only difference is the model name for commercial purposes. Authorized signature: Peter Miller, Director of Engineering

4909 NAUTILUS COURT N, SUITE 111  BOULDER, CO 80301 T 303.449.4330  F 303.449.4346 www.intuicom.com Letter of Authorization Company: Intuicom, Inc. Address: 4909 Nautilus CT. N. Suite 111, Boulder, CO 80301, USA Product Type: XC400 Model Number(s): XC400, XC400‐2G, XC400‐2GW Product Description: XC400 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above‐named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Name: Peter Miller Title: Director of Engineering Company: Intuicom, Inc. Date: December 16, 2022

4909 NAUTILUS COURT N, SUITE 111  BOULDER, CO 80301 T 303.449.4330  F 303.449.4346 www.intuicom.com December 16, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Request for Confidentiality FCC ID: WOYXC4002GW To Whom It May Concern: Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM Tune‐up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s): External Photos Test Setup Photos Internal Photos User Manual 4909 NAUTILUS COURT N, SUITE 111  BOULDER, CO 80301 T 303.449.4330  F 303.449.4346 www.intuicom.com For 45 days, pursuant to Public Notice DA 04‐1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Peter Miller Director of Engineering, Intuicom, Inc.

Test Model No.: XC400

Label location Label

Test Model No.: XC400

FCC ID: WOYXC4002GW RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: WOYXC4002GW Test Result of RF Exposure Evaluation WIFI 2.4G Channel Max output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 2412MHz SISO(ANT 1) 16.57 45.39 0.0453 1.0 PASS 2412MHz MIMO 16.21 41.78 0.0833 1.0 PASS Antenna gain: ANT 1: 7dBi ANT 2: 7dBi MIMO: 10.01dBi 3G Mode Max output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result WCDMA Band II 23.74 236.59 0.0939 1.0 PASS WCDMA Band IV 24.19 262.42 0.1042 1.0 PASS WCDMA Band V 21.84 152.76 0.0606 0.55 PASS Antenna gain: ANT 1: 3dBi ANT 2: 2dBi FCC ID: WOYXC4002GW 4G Mode Max output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Band 2 24.3 269.15 0.1068 1.0 PASS Band 4 22.92 195.88 0.0778 1.0 PASS Band 5 21.32 135.52 0.0538 0.55 PASS Band 12 19.1 81.28 0.0323 0.47 PASS Band 13 21.95 156.68 0.0622 0.52 PASS Band 14 25.00 316.23 0.1255 0.53 PASS Band 66 25.00 316.23 0.1255 1.0 PASS Band 71 21.06 127.64 0.0507 0.45 PASS Antenna gain: ANT 1: 3dBi ANT 2: 2dBi 802.11 b/g/n could work in Synchronous transmitting mode. The maximum simultaneously power density were as below WCDMA BAND II+2.4G WIFI: 0.18 <1. WCDMA BAND IV +2.4G WIFI: 0.19 <1. WCDMA BAND V +2.4G WIFI: 0.19 <1 LTE BAND 2+2.4G WIFI: 0.19 <1 LTE BAND 4+2.4G WIFI: 0.16<1 LTE BAND 5+2.4G WIFI: 0.18 <1 LTE BAND 12+2.4G WIFI: 0.15 <1 LTE BAND 13+2.4G WIFI: 0.20 <1 LTE BAND 14+2.4G WIFI: 0.32 <1 LTE BAND 66+2.4G WIFI: 0.21 <1 LTE BAND 71+2.4G WIFI: 0.20 <1 Remark: The max power density is less than MPE exempt limit, so it is compliance.

Global United Technology Services Co., Ltd. Report No.: GTS202211000247F02 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 20 TEST REPORT Applicant: Intuicom, Inc. Address of Applicant: 4909 Nautilus CT. N Suite 111, Boulder, Colorado 80301, United States Manufacturer/Factory: Intuicom, Inc. Address of Manufacturer/Factory: 4909 Nautilus CT. N Suite 111, Boulder, Colorado 80301, United States Equipment Under Test (EUT) Product Name: XC400 Model No.: XC400, XC400-2G, XC400-2GW Trade Mark: FCC ID: WOYXC4002GW Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 FCC CFR Title 47 Part 24 FCC CFR Title 47 Part 27 Date of sample receipt: November 23, 2022 Date of Test: November 24, 2022-December 16, 2022 Date of report issued: December 16, 2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202211000247F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 20 2 Version Version No. Date Description 00 December 16, 2022 Original Prepared By: Date: December 16, 2022 Project Engineer Check By: Date: December 16, 2022 Reviewer Report No.: GTS202211000247F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 20 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................... 7 5.3 TEST METHODOLOGY ......................................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 SYSTEM TEST CONFIGURATION ......................................................................................................... 9 7.1 TEST MODE ........................................................................................................................................ 9 7.2 CONFIGURATION OF TESTED SYSTEM .................................................................................................. 9 7.3 ERP/EIRP ....................................................................................................................................... 10 7.4 SPURIOUS RADIATION EMISSIONS ..................................................................................................... 13 8 TEST SETUP PHOTO ............................................................................................................................ 20 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 20 Report No.: GTS202211000247F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 20 4 Test Summary Test Item Section in CFR 47 Result RF Output Power Part 2.1046 Part 22.913 (a) Part 24.232 (c) Part 27.50 Pass* ERP & EIRP Part 2.1046 Part 22.913 (a) Part 24.232 (c) Part 27.50 Pass Peak-to-Average Ratio Part 2.1046 Part 24.232 Part 27.50 Pass* Modulation Characteristics Part 2.1047 N/A 99% Occupied Bandwidth & 26dB Bandwidth Part 2.1049 Part 22.917(b) Part 24.238(b) Part 27.53 Pass* Spurious Emissions at Antenna Terminal Part 2.1051 Part 22.917 Part 24.238 Part 27.53 Pass* Spurious Radiation Emissions Part 2.1053 Part 22.917 Part 24.238 Part 27.53 Pass Out of band emission, Band Edge Part 22.913(a) Part 24.232(b) Part 27.50 Pass* Frequency stability vs. temperature Part 2.1055(a)(1)(b) Part 22.355 Part 24.235 Part 27.54 Pass* Frequency stability vs. voltage Part 2.1055(d)(1)(2) Part 22.355 Part 24.235 Part 27.54 Pass* Remarks: 1. Pa…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTS202211000247F03 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 38 TEST REPORT Applicant: Intuicom, Inc. Address of Applicant: 4909 Nautilus CT. N Suite 111, Boulder, Colorado 80301, United States Manufacturer/Factory: Intuicom, Inc. Address of Manufacturer/Factory: 4909 Nautilus CT. N Suite 111, Boulder, Colorado 80301, United States Equipment Under Test (EUT) Product Name: XC400 Model No.: XC400, XC400-2G, XC400-2GW Trade Mark: FCC ID: WOYXC4002GW Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 FCC CFR Title 47 Part 24 FCC CFR Title 47 Part 27 FCC CFR Title 47 Part 90 Date of sample receipt: November 23, 2022 Date of Test: November 24, 2022-December 16, 2022 Date of report issued: December 16, 2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202211000247F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 38 2 Version Version No. Date Description 00 December 16, 2022 Original Prepared By: Date: December 16, 2022 Project Engineer Check By: Date: December 16, 2022 Reviewer Report No.: GTS202211000247F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 38 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................... 8 5.3 TEST METHODOLOGY ......................................................................................................................... 8 5.4 TEST FACILITY .................................................................................................................................... 8 5.5 TEST LOCATION ................................................................................................................................. 8 6 TEST INSTRUMENTS LIST ..................................................................................................................... 9 7 SYSTEM TEST CONFIGURATION ....................................................................................................... 10 7.1 TEST MODE ...................................................................................................................................... 10 7.2 CONFIGURATION OF TESTED SYSTEM ................................................................................................ 10 7.3 CONDUCTED OUTPUT POWER & E.R.P. & E.I.R.P. ............................................................................ 11 7.4 SPURIOUS RADIATION EMISSIONS ..................................................................................................... 27 8 TEST SETUP PHOTO ............................................................................................................................ 38 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 38 Report No.: GTS202211000247F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 38 4 Test Summary Test Item Section in CFR 47 Result RF Output Power Part 2.1046 Part 22.913 (a) Part 24.232 (c) Part 27.50(h) Part 90.635(b) Pass* ERP & EIRP Part 2.1046 Part 22.913 (a) Part 24.232 (c) Part 27.50(h) Part 90.635(b) Pass Peak-to-Average Ratio Part 22.913 FCC part24.232 FCC Part 27.50 Pass* Modulation Characteristics Part 2.1047 N/A 99% & -26 dB Occupied Bandwidth Part 2.1049 Part 22.917(b) Part 24.238 Part 27.53(h) Part 90.209 Pass* Spurious Emissions at Antenna Terminal Part 2.1051 Part 22.917 Part 24.238 (a) Part 27.53(m) Part 90.691 Pass* Spurious Radiation Emissions Part 2.1053 Part 22.917 Part 24.238 (a) Part 27.53(m) Part 90.691 Pass Out of band emission, Band Edge Part 22.917 Part 24.238 (a) Part 27.53(m) Part 90.691/543 Pass* Frequency stability vs. temperature Part 2.1055(a)(1)(b) Part 90.213 Pass* Frequency stability vs. voltage Part 2.1055(d)(1)(2) Part 90.213 Pass* Remarks: 1. Pass*: This device has installed a certified modular which FCC ID: XMR201909EC25AFX, so these conducted test data directly reference the modular's data.. 2. N/A: Not applicable. Report No.: GTS202211000247F03 Global Uni…

Text truncated - open the document above for the full version.

Test Model No.: XC400 ANT 1: Radiated Emission Conducted Emission ANT 2: Radiated Emission Conducted Emission
