WPV-SEQR10001BASE UNIT

2840 South College Rd. #210 Wilmington NC 28412 www.sequentric.com Tel 704.817.2080 FCC CONFIDENTIALITY LETTER Date June 25, 2010 To: FCC Authorization & Evaluation Division 7435 Oakland Mills Rd Columbia, MD 21045-0429 From: Daniel Flohr., CEO 704-817-2080 [email protected] Applicant: Sequentric Energy Systems, LLC Subject: Request For Non-Disclosure for FCC ID WPV-SEQR10001 To whom it may concern, Request is hereby submitted by Sequentric Energy Systems, LLC to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description Sequentric Energy Systems, LLC has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Daniel Flohr, CEO Sequentric Energy Systems, LLC

Photographs cont... Illustrates Complete Product Photographs cont... Showing Product with Cover Removed 433 MHz Photographs cont... Showing Board out of Enclosure 433 MHz

FCC LABEL FCC LOCATION

Photographs cont... Illustrates Complete Product Photographs cont... Showing Product with Cover Removed 433 MHz Photographs cont... Showing Board out of Enclosure 433 MHz

RF Emissions Test Report To Determine Compliance With: FCC, Part 15.231 Rules and Regulations Model number: SHC-G-MR-433 and SHC-G-433 FCC ID: WPV-SEQR10001 Date: April 26, 2010 Manufacturer: Sequentric Energy Systems, LLC. 2840 South College Rd. Wilmington, NC 28412 EMC Testing Laboratories, Inc. authorizes the above company to reproduce this report provided it is reproduced in its entirety EMC Tests, Inc. (770) 475-8819 Test report no. 10-166A Page 2 of 23 Contents Section General Information -------------------------------------------------------- 1 Test Summary --------------------------------------------------------------- 2 Standard Reference --------------------------------------------------------- 3 Test Method ----------------------------------------------------------------- 4 Output Power --------------------------------------------------------------- 5 Bandwidth ------------------------------------------------------------------- 6 Radiated Emissions Measurements --------------------------------- 7 Conducted Emissions Measurements ------------------------------ 8 Configuration -------------------------------------------------------------- 9 Test Equipment ------------------------------------------------------------ 10 EMC Tests, Inc. (770) 475-8819 Test report no. 10-166A Page 3 of 23 Section 1 GENERAL INFORMATION Manufacturer: Sequentric Energy Systems, LLC. 2840 .South College Rd. Wilmington, NC 28412 Manufacturer representative: Mr. Daniel Flohr Equipment covered by this report: Model nos. SHC-G-MR-433 and SHC-G-433 Options covered by this report: None Transmitting Frequency: 433.92 MHz Test specifications: To determine compliance with: FCC, Part 15.231, Subpart B and C, Rules and Regulations, Class B. Test report number: 10-166A-1 Test commenced: April 12, 2010 Test completed: April 26, 2010 Test engineer: Gene Bailey Test Facility: The test facility used to perform these tests is on file with the FCC under registration number 637500 and located at: EMC Testing Laboratories, Inc. 2100 Brandon Trail Suite 101 Alpharetta, GA 30004 EMC Tests, Inc. (770) 475-8819 Test report no. 10-166A Page 4 of 23 Section 2 PRODUCT DESCRIPTION AND TEST SUMMARY Product description: The product covered by this report is a multi-node system that utilizes the transmission of a control signal in a similar manner as those used with alarm systems, door openers, remote switches, etc. The SQR system is comprised of one master control unit, the Gateway, and a number of slave units. The Gateway includes a microcontroller with an Ethernet interface that communicates using Internet protocol to convey control commands from a utility or other entity’s control server to the control modules installed into the premises to actively manage peak demand power usage or other related services. The Gateway communicates with slave modules using a transceiver The Gateway also acts as a receive-only wireless power meter reading device. The Gateway contains a 433 MHz band receiver that receives the current kilowatt reading from compatible residential and commercial power meters, and communicates this information using the Ethernet interface. The integral L-shaped wire antenna. SHC-G-433 is identical to model no. SHC-G-MR-433 except without populating the integrated 915 meter reading receiver. The test results apply only to the products identified on the test report. Test configuration: The equipment under test (EUT) was set-up and configured as specified by the manufacturer as follows: 1- The product was connected to the following support peripherals: A. A Power supply model no. HHA12-1000. 2- The EUT utilized the following cables and were connected as indicated below: A- An Ethernet cable between the product and laptop. B- Two USB cables C- Power cable EMC Tests, Inc. (770) 475-8819 Test report no. 10-166A Page 5 of 23 Product Description and Test Summary ... Worst case transmit duty Cycle: The duty cycle factor used in the calculation of average radiated limits (15.209 (d)) is described below. Maximum transmit time On equals 10mS over a 125 mS period. The worst case Duty Cycle is calculated as follows: (10/100) 100% = 10% In terms of voltage dB: 20 log (10/100) = -20 dB Modifications: The following modifications were required to comply with the radiated emission limits: 1- None Engineering Statement: All measurement data of this test report was taken in accordance with the FCC, Part 15.231, Class B Rules and Regulations and ANSI C63.4-(09) by EMC Testing Laboratories, Inc. located in Alpharetta, Georgia. Although this data is taken under stringent laboratory conditions and to the best of our knowledge, represents accurate data, it must be recognized that emissions from or immunity to this type equipment may be greatly affected by the final installation of the equipment. Therefore, EMC Testing Laboratories, Inc., while supporting the accuracy of the data in this report, takes no responsibility for use of equipment based on these tests. The manufacturer of this equipment must take full responsibility for any field problems which may arise, and agrees that EMC Testing Laboratories, Inc., in performing its functions in accordance with its objectives and purposes, does not assume or undertake to discharge any responsibility of the manufacturer to any other party or parties. Conclusion: With the above-indicated modifications, the product covered by this report has been tested and found to comply with the above-indicated standards. Tested by: Gene Bailey, RF Engineer Approved by: Glenn Barnes, RF Engineer, EMC Testing Laboratories, Inc. EMC Tests, Inc. (770) 475-8819 Test report no. 10-166A Page 6 of 23 Section 3 STANDARD REFERENCE The following primary standards were used for this test: 1- ANSI C63.4-09: Method of Measurements of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the 9 KHz to 40 GHz. 2- US Code of Federal Regulations (CFR): Title 47, Part 15, Radio Frequency Devices, Subpart B, In…

Text truncated - open the document above for the full version.

PHOTOGRAPHS Photographs cont... Radiated Emissions Measurements Product Photographs cont... Radiated Emissions Measurements Product Photographs cont... Conducted Emissions Measurements Product
