WUQ-NTG5STAR1Car radio with Bluetooth handsfree

NTG5*1 US BLUETOOTH USER MANUAL CONTENTSGENERAL INSTRUCTIONS .................................2 TECHNICAL INFORMATION ..............................3 APPLICATION GROUP OVERVIEW ...................4 SEARCHING FOR MOBILE TELEPHONES .........5 AUTHORIZING A MOBILE TELEPHONE ..........6 EXTERNAL AUTHORIZATION ...........................7 DE-AUTHORIZE A MOBILE TELEPHONE ........8 ACTIVATE\DEACTIVATE BLUETOOTH ...............9 APPENDIX - REGULATORY INFORMATION ...10 Draft Version 1 GENERAL INSTRUCTIONS Warning! The NTG5*1 can distract your attention from the tra ffic conditions. You could cause an accident and place y ourself and others in danger.- Always devote your complete attention to the traff ic situation.- Only operate the NTG5*1 when traffic and driving conditions are appropriate.- Only change discs while the vehicle is stationary.- Set the volume to a level that allows you to hear important sounds outside the vehicle e.g. horns, sirens and a larms. Warning! The NTG5*1 is a Class 1 laser product. There is a r isk of damage to the eyes from invisiblelaser radiation if the housing is opened or if it i s faulty or damaged.- Do not open the housing.- Do not remove any covers.- Do not carry out any repairs to the device. If nec essary, the device must be repaired by a suitably qualified rep airer. Protective circuits The NTG5*1 includes protective circuits that preven t damage to the device as far as possible:- If the supply voltage is too low or too high, or i f the NTG5*1 becomes too hot, the NTG5*1 will switch off automatically.- In case of a failure of the disconnect device, rep lace the fuse in the back of the equipment for another fuse of the same value, 15A.Never open the NTG5*1 yourself in the event of a fa ult! Take the faulty appliance to be repaired by a compe tent specialist repairer. We recommend that you use a service center for this work as this will ensure that trained workshop staff and the necessary parts and tools will be available. Draft Version 2 TECHNICAL INFORMATIONThe products, NTG5*1 US, brand Panasonic are manufa ctured by Panasonic Automotive Systems Europe GmbH. The products are an integrated car entertainment sy stems with a separate external display (display is no part of th e Panasonic product). It supports several sources dependent on HU version like. CD, MP3, USB (external connection box), SD, BT Handsfree, BT -Audio, Navigation, AM/FM radio, DAB, HD-radio. Power supply voltage: DC +12 [V]Temperature range: -20 to +70 [degree C]RF technical specification – Bluetooth 2.1 +EDR: Frequency Range: 2400 – 2483.5 MHz Maximum RF Output Power (W): 2.5 mWModulations: FHSS: GFSK, pi/4 DQPSK, 8DPSK Draft Version 3 INTRODUCTION TO OPERATIONOperate your mobile telephone conveniently via the Telephone function of the MMI system. Telephone functions can be accessed via the Applica tion group “Tel” and Audio streaming functions via “Media”. Application GroupsApplication line to select Application group via CCEApplication GroupsSelect Application group via hardkey Draft Version 4 BT AUDIO BT TELEPHONE SEARCHING FOR MOBILE TELEPHONESThe NTG5*1 will search for devices that support the Bluetooth handsfree profile (HFP) and the audio streaming profile (A2DP\AVRCP).Activating Bluetooth on your mobile telephone.If necessary, make the mobile telephone visibleto other devices.The NTG5*1 will display a maximum of 15 devices found in the device list. Draft Version 5 BT AUDIO BT TELEPHONE AUTHORIZING A MOBILE TELEPHONEEach mobile telephone must be authorized thefirst time it is connected with the NTG5*1.Up to 15 mobile telephones can be authorizedfor use with the NTG5*1. Once authorized, a mobile telephone can be connected to the NTG5*1 in order to make use of the telephone functions that it provides.Select the desired mobile phone from the found device list.If your mobile telephone supports secure simple pairing, a 6-digit PIN will be shown on your mobile telephone and on the MMI display simultaneously.Confirm this PIN on your mobile telephone and in the MMI.Otherwise if your mobile telephone supports onlyPIN entry, a own personal 1 to 16 digit PIN needs tobe entered on your mobile telephone and on theMMI display. Draft Version 6 BT AUDIO BT TELEPHONE EXTERNAL AUTHORIZATIONIf the NTG5*1 cannot find your mobile telephone, or the authorization process repeatedly fails when initiated by the NTG5*1, then the authorization can be initiated from the mobile telephone.Press the option “Search via telephone”.The NTG5*1 is now visible to external devices.Use the mobile telephone to search for devices that support Bluetooth (refer to the instruction manual for the mobile telephone).Send a connection request from the mobile telephone (refer to the instruction manual for the mobile telephone).If your mobile telephone supports secure simple pairing, a 6-digit PIN will be shown on your mobile telephone and on the MMI display simultaneously.Confirm this PIN on your mobile telephone and in the MMI.Otherwise if your mobile telephone supports onlyPIN entry, a own personal 1 to 16 digit PIN needs tobe entered on your mobile telephone and on theMMI display. Draft Version 7 BT AUDIO BT TELEPHONE DE-AUTHORIZE A MOBILE TELEPHONESelect the options of the device from the list and press button “De-Authorize”. Draft Version 8 ACTIVATE\DEACTIVATE BLUETOOTHThe Bluetooth functionality can be activated anddeactivated via System-Settings. Draft Version 9 10 APPENDIX - REGULATORY INFORMATIONUSA / Canada MarketModification statementPanasonic Automotive Systems Europe GmbH has not approved a ny changes or modifications to this device by the user. Any changes or modifications could void the user's authorit y to operate the equipment. Panasonic Automotive Systems Europe GmbH n'approuve aucun e modification apportée à l'appareil par l'utilisateur, quelle qu'en soit la nature. Tout changement ou modificatio n peuvent annuler le droit d'utilisation de l'appareil par l'utilisateur.Interference statementThis device complies wit…

Text truncated - open the document above for the full version.

BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Date: Dec. 13, 2013 Ref: Confidentiality request for FCC ID: WUQ-NTG5STAR1 FCC ID: Title/model: WUQ-NTG5STAR1 Radio car with Bluetooth handsfree / NTG5*1 US To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Panasonic Automotive Systems Europe GmbH hereby request permanent confidentiality to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: - Schematics - Operational description - Block diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to Panasonic Automotive Systems Europe GmbH and provide unjustified benefits to our competitors. Panasonic Automotive Systems Europe GmbH understand that pursuant to §0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, By: Mr. Hassan Haidar __p.a.________________________ Title: Development Manager (Signature) Company: Panasonic Automotive Systems Europe GmbH, Robert-Bosch-Str. 27-29, 63225 Langen, GERMANY Telephone / Fax: +49 (6103) 3759478 / +49 (6103) 3759343 e-mail: [email protected]

BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Date: Dec. 13, 2013 REF: Short-term confidentiality request for FCC ID: WUQ-NTG5STAR1 FCC ID: Title/model: WUQ-NTG5STAR1 Radio car with Bluetooth handsfree / NTG5*1 US To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Panasonic Automotive Systems Europe GmbH hereby request short-term confidentiality to avoid premature release of sensitive information prior to marketing or release of the product to the public. For the product stated above, we request that the following information be temporarily withheld from public disclose for an initial period of 180 days: - External photographs - Internal photographs - Test setup photographs - User’s guide It is understood that no extensions of the short-term confidentiality may be requested. Sincerely, By: Mr. Hassan Haidar __p.a.________________________ Title: Development Manager (Signature) Company: Panasonic Automotive Systems Europe GmbH, Robert-Bosch-Str. 27-29, 63225 Langen, GERMANY Telephone / Fax: +49 (6103) 3759478 / +49 (6103) 3759343 e-mail: [email protected]

BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Date: Dec. 19, 2013 RF exposure analysis for the equipment NTG5*1 US (FCC ID: WUQ-NTG5STAR1, IC: 216R-NTG5STAR1) The output power of the device is extremely low (1.44 mW conducted, 2.50 mW eirp) and far below the FCC 60/f(GHz) mW (60/2.45 GHz = 24.48 mW) threshold and 20 mW threshold stated in IC RSS-102 Issue 4 Clause 2.5.1. For that reason the equipment is categorically excluded from routine environmental evaluation for RF exposure and it is deemed to comply with FCC and IC limits for exposure to electromagnetic fields. Sincerely, By: Mr. Hassan Haidar __p.a.________________________ Title: Development Manager (Signature) Company: Panasonic Automotive Systems Europe GmbH, Robert-Bosch-Str. 27-29, 63225 Langen, GERMANY Telephone / Fax: +49 (6103) 3759478 / +49 (6103) 3759343 e-mail: [email protected]

Report Nº(NIE): 38386RRF.002 Page 1 of 7 2013-07-09 APPENDIX B: Photographs Report Nº(NIE): 38386RRF.002 Page 2 of 7 2013-07-09 EQUIPMENT FOR RADIATED MEASUREMENTS Report Nº(NIE): 38386RRF.002 Page 3 of 7 2013-07-09 EQUIPMENT FOR CONDUCTED MEASUREMENTS Report Nº(NIE): 38386RRF.002 Page 4 of 7 2013-07-09 GENERAL SET-UP FOR RADIATED MEASUREMENTS Report Nº(NIE): 38386RRF.002 Page 5 of 7 2013-07-09 TEST SET-UP FOR RADIATED MEASUREMENTS BELOW 1 GHz Report Nº(NIE): 38386RRF.002 Page 6 of 7 2013-07-09 TEST SET-UP FOR RADIATED MEASUREMENTES ABOVE 1GHz Report Nº(NIE): 38386RRF.002 Page 7 of 7 2013-07-09 TEST SET-UP FOR CONDUCTED MEASUREMENTES
