WZI-UHR-230LBooster

FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 1/1 ATTACHMENT E. - USER MANUAL -

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 U UFINE Technologies Co., Ltd. February 3, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We,UFINE Technologies Co.,Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Booster, UHR-230L We affirm that between SIEMIC and UFINE Technologies Co.,Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, John Ryu/ Assistant Manager UFINE Technologies Co.,Ltd. 46, Geumgok-dong, Bundang-gu, Seong Nam-si, Gyeonggi-do, 463-804 KOREA

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 UFINE Technologies Co.,Ltd. February 3, 2010 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID WZI-UHR-230L We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Schematics 3 Operational Description 4 Part List, Tune up Procedure CONFIDENTIAL 5 TTuneTune up Tune-UP Procedure 6 External Photos 7 Internal Photos 8 Test-Setup Photos SHORT-TERM CONFIDENTIAL 9 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, John Ryu/ Assistant Manager UFINE Technologies Co.,Ltd. 46, Geumgok-dong, Bundang-gu, Seong Nam-si, Gyeonggi-do, 463-804 KOREA

FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 1/7 ATTACHMENT B. -EXTERNAL PHOTOS - FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 2/7 (Front) FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 3/7 (Back) FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 4/7 (Left) FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 5/7 (Right) FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 6/7 (Lower Side) FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 7/7 (Upper Side)

FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 1/3 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS - FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 2/3 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL Model No : UHR-230L FCC ID : WZI-UHR-230L EUT Type : UFINE Technologies Co.,Ltd. Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. UFINE Technologies Co.,Ltd. 46, Geumgok-dong, Bundang-gu, Seong Nam-si, Gyeonggi-do, MADE IN KOREA FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 3/3 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL LABEL

FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 1/4 ATTACHMENT F. - INTERNAL PHOTOS - FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 2/4 FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 3/4 FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 4/4

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 10. RF EXPOSURE STATEMENT 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 2-1. GSM Uplink Max Peak output Power at antenna input terminal 14.980 dBm Max Peak output Power at antenna input terminal 31.477 mW Prediction distance 20.000 cm Prediction frequency 824.200 MHz Antenna Gain(typical) 5.000 dBi Antenna Gain(numeric) 3.162 - Power density at prediction frequency( S) 0.020 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.549 mW/cm 2 3. RESULTS The power density level at 20 cm is 0.020 (GSM), which is below the uncontrolled exposure limit for GSM band. Warning: In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, it must also have a minimum distance of 20 cm from the body during normal operation.

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L CONTENTS 1. CLIENT INFORMATION............................................................................................................................................ 4 2. TEST SPECIFICATIONS........................................................................................................................................... 5 3. STANDARDS ENVIRONMENTAL TEST CONDITIONS...................................................................................... 5 4. TEST EQUIPMENT..................................................................................................................................................... 6 5. RF OUTPUT POWER................................................................................................................................................. 7 6. OCCUPIED BANDWIDTH....................................................................................................................................... 10 7. SPURIOUS AND HARMONIC EMISSION AT ANTENNA TERMINAL........................................................... 18 8. RADIATED SPURIOUS EMISSIONS.................................................................................................................... 31 9. FREQUENCY STABILITY OVER TEMPERATURE AND VOLTAGE VARIATIONS...................................... 34 10. RF EXPOSURE STATEMENT.............................................................................................................................. 36 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 1. CLIENT INFORMATION The EUT has been tested by request of Company UFINE Technologies Co., Ltd. Contact Point 46, Geumgok-dong, Bundang-gu, Seong Nam-si, Gyeonggi-do, 463-804, Korea „ EUT Type: Booster „ MODEL : UHR-230L „ Frequency Ranges: 824 – 849 MHz (GSM) „ RF Output Power: 15 dBm(GSM) „ FCC Rules Part(s): Title 47 of CFR, Part 22 „ Emission Designators: G7W (GSM/EDGE) „ Modulation : GMSK (GSM), 8PSK (EDGE) „ Place of Tests: HCT Co., Ltd. FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 2. TEST SPECIFICATIONS 2.1 Standards The following tests were conducted on a sample of the equipment for the purpose of demonstrating compliance With Part 22 Subpart H., Part 27 Subpart C Description Reference (FCC) Results RF Power Output §2.1046 §22.913 Compliant Modulation Characteristics §2.1047 N/A Occupied Bandwidth §2.1049 Compliant Spurious Emissions at Antenna Terminals §2.1051 §22.917 Compliant Frequency Stability §2.1055 §22.355 Compliant 3. STANDARDS ENVIRONMENTAL TEST CONDITIONS Temperature : + 15 °C to + 35 °C Relative humidity: 30 % to 60 % Air pressure 860 mbar to 1060 mbar FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 4. TEST EQUIPMENT Manufacturer Model / Equipment Cal Interval Calibration Due Serial No. Agilent E4438C /Signal Generator Annual 12/15/2010 MY42082646 Agilent E4416A /Power Meter Annual 01/21/2010 GB41291412 WEINSCHEL 67-30-33/ATTENUATOR Annual 02/03/2010 BR0530 Schwarzbeck VULB 9168/ TRILOG Antenna Annual 01/06/2011 9168-200 HD MA240/ Antenna Position Tower N/A N/A 556 EMCO 1050/ Turn Table N/A N/A 114 HD GmbH HD 100/ Controller N/A N/A 13 HD GmbH KMS 560/ SlideBar N/A N/A 12 MITEQ AMF-60-0010 1800-35-20P Annual 04/25/2010 1200937 Schwarzbeck BBHA 9120D/ Horn Antenna Annual 03/26/2010 147 Agilent N9020A/ Signal Analyzer Annual 02/19/2010 US46220219 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L 5. RF OUTPUT POWER 5.1 Test Procedure Test Requirements: § 2.1046 Measurements required: RF power output: § 2.1046 (a) For transmitters other than single sideband, independent sideband and controlled carrier radiotelephone, power output shall be measured at the RF output terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on the circuit elements specified in § 2.1033(c)(8).The electrical characteristics of the radio frequency load attached to the output terminals when this test is made shall be stated. § 2.1046 (b) For single sideband, independent sideband, and single channel, controlled carrier radiotelephone transmitters, the procedure specified in paragraph (a) of this section shall be employed and, in addition, the transmitter shall be modulated during the test as specified and as applicable in § 2.1046 (b) (1-5). In all tests, the input level of the modulating signal shall be such as to develop rated peak envelope power or carrier power, as appropriate, for the transmitter. § 2.1046 (c) For measurements conducted pursuant to paragraphs (a) and (b) of this section, all calculations and methods used by the applicant for determining carrier power or peak envelope power, as appropriate, on the basis of measured power in the radio frequency load attached to the transmitter output terminals shall be shown. Under the test conditions specified, no components of the emission spectrum shall exceed the limits specified in the applicable rule parts as necessary for meeting occupied bandwidth or emission limitations. § 22.913 Effective radiated power limits. The effective radiated power (ERP) of transmitters in the Cellular Radiotelephone Service must not exceed the limits in this section. (a) Maximum ERP. In general, the effective radiated power (ERP) of base transmitters and cellular repeaters must not exceed 500 Watts. FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR06 Date of Issue: January 20, 2010 EUT Type: Booster FCC ID: WZI-UHR-230L Test Procedures: As required by 47 CFR 2.1046, RF powe…

Text truncated - open the document above for the full version.

FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 1/2 ATTACHMENT D. - SETUP PHOTO - FCC ID : WZI-UHR-230L HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR06 2/2 ( Open Site Test Setup)
